Phantos P24HEX User manual

V1.0
20150826
Panel Wash HEX
Model Number: P24HEX
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to
change without notice. Whilst every care is taken in the preparation of this manual we reserve the right to change
specifications in the course of product improvement. The publishers cannot be held responsible for the accuracy of the
information herein, or any consequence arising from them.
1/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
1. INTRODUCTION
Thank you for purchasing Panel Wash HEX. Please read this user manual
carefully and thoroughly before operation. Please keep this user guide for
future reference. This device has left our premises in absolutely perfect
condition. In order to maintain this condition and to ensure a safe operation,
it is absolutely necessary for the user to follow the safety instructions and
warning notes written in this manual. The manufacturer/distributors/dealers
will not accept liability for any resulting damages caused by the
non-observance of this manual or any unauthorized modification to the
device.
1.1 What is Included
a) 1X Panel Wash HEX with barn door
b) 1X user manual
Carefully unpack the carton, check the contents to ensure that all parts are
present and in good condition. Contact your supplier if any part is missing or
damaged.
1.3 Safety Instructions
▪ Avoid brute force when installing or operating the fixture.
▪ This device is for professional use only. It is not for household use.
▪ When choosing the installation spot, please make sure that the fixture is not
exposed to extreme heat or dust.
▪ Avoid using the unit in locations subject to possible impacts.
▪This unit is intended for indoor use only, use of this product outdoors voids
all warranties.
WARNING!!! To reduce risk of fire, electric shock, or
injury, follow these important safety instructions

2/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
▪ Always turn off, unplug power and allow fixture to cool before servicing.
▪ Ensure that fixture is properly grounded. Do not attempt to remove or
break off the ground prong from the electrical cord. This prong is used to
reduce the risk of electrical shock and fire in case of an internal short.
▪ Always make sure that you are connecting to the proper voltage and that
the line voltage you are connecting to is not higher than that stated on decal
or rear panel of the fixture.
▪ To prevent risk of fire or shock, do not expose fixture to rain or moisture.
▪ Make sure power cord is never crimped or damaged. Do not attempt to
operate this unit if the power cord has been frayed or broken.
▪ Do not remove the cover under any conditions, unless consent given by
distributor. There are no user serviceable parts inside.
▪ Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 15cm between this device and a wall.
▪DO NOT connect this product to a dimmer or rheostat.
▪ONLY connect this product to a grounded and protected circuit.
▪ONLY use the hanging/mounting bracket to carry this product.
▪USE a safety cable when mounting this product overhead.
▪DO NOT look at the light source when the product is on.
3/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
2. SET UP
2.1 Mounting
With adjustable mounting double brackets, this unit may be wall mounted, free
standing, or clamp mounted.
IMPORTANT!!! Safety cables must always be used. The safety cable must
be capable of holding 10 times the weight of the fixture.
2.2 Fixture Linking
To run your light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures in master/slave operating mode,
you need DMX cables to link the units from DMX IN to DMX OUT.
Only use standard 110-120 Ohm shielded cable. These are 2 core-screened
cables, with each core having at least a 0.5mm diameter. Do not use the
ground lug on the XLR connector. Do not connect the cable’s shield
conductor to the ground lug or allow the shield conductor to come in contact
with the XLR’s outer casing. Grounding the shield could cause a short circuit
and erratic behavior.

4/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
2.2.1 Line Termination
In DMX Mode, at the last fixture in the chain, the DMX output has to be
connected with a DMX terminator. This prevents electrical noise from
disturbing and corrupting the DMX control signals. The DMX terminator is
simply an XLR connector with a 120 (ohm) resistor connected across pins 2
and 3, which is then plugged into the output socket on the last projector in
the chain. The connections are illustrated below.
2.3 AC Power
This product has an auto-ranging power supply that can work with an input
voltage range of 100~240 VAC, 50/60 Hz.
Warning!!! All fixtures must be connected to circuits with a
suitable Earth Ground.
5/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
3 OPERATION INSTRUCTIONS
3.1 Menu Map
Display Function
A001-A512 DMX mode, 6CH
d001-d512 DMX mode, 10CH
CC00-CC99 Color macro 1
CP00-CP99 Color macro 2
dE00-dE99 Color macro 3
SS01-SS99 Macro Speed
bEbE Master mode
F --on-- Display on (--oFF, Display off)
R000-R255 Red Dimmer
G000-G255 Green Dimmer
B000-B255 Blue Dimmer
O000-O255 White Dimmer
Y000-Y255 Amber Dimmer
P000-P255 UV Dimmer
3.2 Auto Mode
In this mode, you can set the unit to run in static colors, strobe, or do color
changing without a DMX controller.
1. Press MENU button until display reads: “ CCxx ”, “CPxx” or “dExx”.
2. Press ENTER button and use UP/DOWN button to select number from 00-99
to adjust running speed from slow to fast.
3.3 DMX Mode
In DMX mode, you can control the fixture with a DMX controller.
1. Press MENU button until display reads: “ dxxx ” for DMX mode.
2. Then press ENTER button and use Up/Down button to set DMX address for the
fixture.

6/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
DMX Protocol:
6CH 10CH DMX Function
Ch1 0-255 Master dimmer
Ch1 Ch2 0-255 Red dimmer
Ch2 Ch3 0-255 Green dimmer
Ch3 Ch4 0-255 Blue dimmer
Ch4 Ch5 0-255 White dimmer
Ch5 CH6 0-255 Amber dimmer
Ch6 CH7 0-255 UV dimmer
Ch8 0-255 Master strobe
Ch9
0-49 No function
50-99 Macro 1
100-149 Macro 2
150-199 Macro 3
200-255 Sound activated
Ch10 0-255 Macro speed
3.4 Master/Slave Mode
In this mode, multiple units can be linked together as one system and run in sync.
Maximum 31pcs can be linked in a daisy chain as Master/Slave system.
1. Use DMX cable to link your lights together via DMX OUT to DMX IN connector.
2. One of the fixtures is set as Master (refer to 3.1 Menu Map on how to set a
fixture as Master) and this unit can then be set to work under any of the Auto,
Macro, Static Color, or Sound mode specified in 3.1 Menu Map. Others are to be
set as Slave mode (refer to 3.1 Menu Map on how to set a fixture to Slave mode,
if not mentioned then set to DMX address d001).
3. All slave units will follow master unit.
7/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
4.SERVICING
4.1 Fuse Replacement
1. Disconnect this product from power.
2. Using a flat-head screwdriver, unscrew the fuse holder cap from the housing.
3. Remove blown fuse and replace with a good fuse of the same type and rating.
4. Screw the fuse holder cap back in place and reconnect power
4.2 Cleaning
Due to fog residue, smoke, and dust cleaning the internal and external optical
lenses must be carried out periodically to optimize light output.
1. Use normal glass cleaner and a soft cloth to wipe down the outside casing.
2. Clean the external optics with glass cleaner and a soft cloth.
3. Always be sure to dry all parts completely before plugging the unit back in.
Cleaning frequency depends on the environment in which the fixture operates
(i.e. smoke, fog residue, dust, dew).
4.3 Trouble Shooting
1. Unit does not respond to DMX:
Check that the DMX cables are connected properly and are wired correctly (pin 3
is “hot”; on some other DMX devices pin 2 may be ‘hot’). It does matter which
way the inputs and outputs are connected.
Disconnect from mains before servicing.

8/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
5.TECHNICAL SPECIFICATIONS
WEIGHT&DIMENSIONS
Length 36cm including yoke
Depth 24cm including yoke
Height 15cm
Weight 5.3kg
POWER
AC Power AC110-240V 50/60Hz
Power Consumption 295W MAX.
Fuse
LIGHT SOURCE 24X12W RGBWAUV LEDs
Beam Angle 38 degree
PHOTOMETRICS DATA
N INTRODUCTIO
9/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
6 WARRANTY
Phantos Lighting hereby warrants, to the original purchaser, distributed products
to be free of manufacturing defects in material and workmanship for a prescribed
period from the date of purchase. This warranty shall be valid only if the product
is purchased in Australia through distributor/dealers. It is the owner’s
responsibility to establish the date and place of purchase by acceptable evidence,
at the time service is sought.
For warranty service you must obtain a Return Authorization number (RA#) via
email before sending back the product. Send the product only to Phantos
Lighting. All shipping charges must be pre-paid. If the requested repairs or
service (including parts replacement) are within the terms of this warranty,
Phantos Lighting will pay return shipping charges only to a designated point
within Australia. No accessories should be shipped with the product. If any
accessories are shipped with the product, Phantos Lighting shall have no liability
whatsoever for loss of or damage to any such accessories, nor for the safe return
thereof.
This warranty is void if:
the serial number (if applied) has been altered or removed;
the product is modified in any manner which Phantos Lighting concludes,
after inspection, affects the reliability of the product;
the product has been repaired or serviced by anyone other than Phantos
Lighting unless prior written authorization was issued to purchaser by
Phantos Lighting;
the product is damaged because not properly maintained as set forth in
the instruction manual.
This is not a service contract, and this warranty does not include maintenance,
cleaning or periodic check-up. During the period specified above, Phantos
Lighting will replace defective parts at its expense with new or refurbished parts,
and will absorb all expenses for warranty service and repair labor by reason of
defects in material or workmanship. The sole responsibility of Phantos Lighting

10/11 ©PHANTOS® Distributed in Australia by PHANTOS www.phantos.com.au
under this warranty shall be limited to the repair of the product, or replacement
thereof, including parts, at the sole discretion of Phantos Lighting.
Phantos Lighting reserves the right to make changes in design and/or
improvements upon its products without any obligation to include these changes
in any products theretofore manufactured. No warranty, whether expressed or
implied, is given or made with respect to any accessory supplied with products
described above. Except to the extent prohibited by applicable law, all implied
warranties made by Phantos Lighting in connection with this product, including
warranties of merchantability or fitness, are limited in duration to the warranty
period set forth above. And no warranties, whether expressed or implied,
including warranties of merchantability or fitness, shall apply to this product after
said period has expired. The consumer’s sole remedy shall be such repair or
replacement as is expressly provided above; and under no circumstances shall
Phantos Lighting be liable for any loss or damage, direct or consequential, arising
out of the use of, or inability to use, this product.
©Phantos Lighting
45/7-9 Percy St, Auburn, NSW 2144, Australia
02 8034 8680
www.phantos.com.au
[email protected]
Stay Connected:
facebook.com/phantoslighting
twitter.com/phantoslighting
