Phcbi MCO-80IC Series User manual

MCO-80ICSeries
Please read the operating instructions carefully before using this product, and keep the operating
instructions for future use.
See page 42 for model number.

Operating Instructions
CO2Incubator

1
CONTENTS
INTRODUCTION ................................................................................................. 2
PRECAUTIONS FOR SAFE OPERATION.......................................................... 3
LABELS ON UNI.................................................................................................. 6
ENVIRONMENTAL CONDITIONS ...................................................................... 7
INCUBATOR COMPONENTS............................................................................. 8
Control panel and keypad .............................................................................. 10
Remote alarm terminal................................................................................... 12
INSTALLATION SITE ........................................................................................ 13
INSTALLATION ................................................................................................. 14
Connection of CO2gas cylinder ..................................................................... 15
CAUTIONS FOR USING EQUIPMENT IN CHAMBER..................................... 16
PREVENT CONTAMINATION........................................................................... 17
CAUTIONS FOR CULTURE.............................................................................. 18
START-UP OF UNIT.......................................................................................... 19
SETTING OF CHAMBER TEMPERATURE AND CO2DENSITY..................... 20
KEY LOCK FUNCTION ..................................................................................... 23
ALARMS & SAFETY FUNCTIONS.................................................................... 24
SETTING OF ALARM RESUME TIME.............................................................. 26
Operation after power failure.......................................................................... 26
ROUTINE MAINTENANCE................................................................................ 27
Sterilizing of chamber and attachments......................................................... 27
Filling water reservoir ..................................................................................... 29
CALIBRATION
Temperature calibration ................................................................................. 30
CO
2calibration ............................................................................................... 31
TROUBLESHOOTING....................................................................................... 32
DISPOSAL OF UNIT.......................................................................................... 34
AUTOMATIC CO2CYLINDER CHANGEOVER ................................................ 39
AUTO WATER SUPPLY SYSTEM.................................................................... 40
SPECIFICATIONS............................................................................................. 41
PERFORMANCE ............................................................................................... 42
SAFETY CHECK SHEET .................................................................................. 43

2
INTRODUCTION
■Read this operating instruction carefully before using the Product and follow the instructions for safety
operation.
■Our company disavows any responsibility for safety if the Product is used for other than the intended
use or used with any procedures other than those given in this operating instruction.
■Keep this operating instruction in a suitable place so that it can be referred to as necessary.
■The contents of this operating instruction are subject to change without notice for improvement of
performance or functions.
■Contact our sales representative or agent if any page of the operating instruction is lost or the page
order is incorrect.
■Contact our sales representative or agent if any point in this operating instruction is unclear or if there
are any inaccuracies.
■No part of this operating instruction may be reproduced in any form without the expressed written
permission of our company.
CAUTION
Our company guarantees the product under certain warranty conditions. Our company in no
way shall be responsible for any loss of content or damage of content.

3
PRECAUTIONS FOR SAFE OPERATION
It is imperative that the user complies with this operating instruction
as it contains important safety advice.
Items and procedures are described so that you can use this unit correctly and safely.
If the precautions advised are followed, this will prevent possible injury to the user and
any other person.
Precautions are illustrated in the following way:
WARNING
Failure to observe WARNING signs could result in a hazard to personnel
possibly resulting in serious injury or death.
CAUTION
Failure to observe CAUTION signs could result in injury to personnel and
damage to the unit and associated property.
Symbol shows;
this symbol means caution.
this symbol means an action is prohibited.
this symbol means an instruction must be followed.
Be sure to keep this operating instruction in a place accessible to users of this unit.
< Label on the unit >
This mark is labeled on the cover in which the electrical components of high voltage
are enclosed to prevent the electric shock.
The cover should be removed by a qualified engineer or a service personnel only.
WARNING
As with any equipment that uses CO2gas, there is a likelihood of oxygen depletion in the vicinity
of the equipment. It is important that you assess the work site to ensure there is suitable and
sufficient ventilation. If restricted ventilation is suspected, then other methods of ensuring a
safe environment must be considered. These may include atmosphere monitoring and
warning devices.

4
PRECAUTIONS FOR SAFE OPERATION
Do not use the unit outdoors. Current leakage or electric shock may result if the unit is exposed to
rain water.
Only qualified engineers or service personnel should install the unit. The installation by
unqualified personnel may cause electric shock or fire.
Install the unit on a sturdy floor and take an adequate precaution to prevent the unit from
turning over. If the floor is not strong enough or the installation site is not adequate, this may result
in injury from the unit falling or tipping over.
Never install the unit in a humid place or a place where it is likely to be splashed by water.
Deterioration of the insulation may result which could cause current leakage or electric shock.
Never install the unit in a flammable or volatile location. This may cause explosion or fire.
Never install the unit where acid or corrosive gases are present as current leakage or electric
shock may result due to corrosion.
Always ground (earth) the unit to prevent electric shock. If the power supply outlet is not
grounded, it will be necessary to install a ground by qualified engineers.
Never ground the unit through a gas pipe, water main, telephone line or lightning rod. Such
grounding may cause electric shock in the case of an incomplete circuit.
Connect the unit to a power source as indicated on the rating label attached to the unit. Use
of any other voltage or frequency other than that on the rating label may cause fire or electric shock.
Never store volatile or flammable substances in this unit if the container cannot be sealed. These
may cause explosion or fire.
Do not insert metal objects such as a pin or a wire into any vent, gap or any outlet on the unit.
This may cause electric shock or injury by accidental contact with moving parts.
Use this unit in safe area when treating the poison, harmful or radiate articles. Improper use
may cause bad effect on your health or environment.
Turn off the power switch (if provided) and disconnect the power supply to the unit prior to any
repair or maintenance of the unit in order to prevent electric shock or injury.
Do not touch any electrical parts (such as power supply plug) or operate switches with a wet
hand. This may cause electric shock.
WARNING

5
Ensure you do not inhale or consume medication or aerosols from around the unit at the time of
maintenance. These may be harmful to your health.
Never splash water directly onto the unit as this may cause electric shock or short circuit.
Never put containers with liquid on the unit as this may cause electric shock or short circuit when
the liquid is spilled.
Never bind, process, or step on the power supply cord, or never damage or break the power
supply plug. A broken supply cord or plug may cause fire or electric shock.
Do not use the supply cord if its plug is loose. Such supply cord may cause fire or electric shock.
Never disassemble, repair, or modify the unit yourself. Any such work carried out by an
unauthorized person may result in fire, or electric shock or injury due to a malfunction.
Disconnect the power supply plug if there is something wrong with the unit. Continued
abnormal operation may cause electric shock or fire.
When removing the plug from the power supply outlet, grip the power supply plug, not the cord.
Pulling the cord may result in electric shock or fire by short circuit.
Disconnect the power supply plug before moving the unit. Take care not to damage the power
cord. A damaged cord may cause electric shock or fire.
Disconnect the power supply plug when the unit is not used for long periods. Keeping the
connection may cause electric shock, current leakage, or fire due to the deterioration of insulation.
If the unit is to be stored unused in an unsupervised area for an extended period, ensure that
children do not have access and that doors cannot be closed completely.
The disposal of the unit should be accomplished by appropriate personnel. Remove doors to
prevent accidents such as suffocation.
Do not put the packing plastic bag within reach of children as suffocation may result.
WARNING

6
PRECAUTIONS FOR SAFE OPERATION
This unit must be plugged into a dedicated circuit protected by branch circuit breaker.
Use a dedicated power source as indicated on the rating label attached to the unit. A multiple-tap
may cause fire resulting from abnormal heating.
Never store corrosive substances such as acid or alkali in this unit if the container cannot be
sealed. These may cause corrosion of inner components or electric parts.
Check the setting when starting up of operation after power failure or turning off of power
switch. The stored items may be damaged due to the change of setting.
Be careful not to tip over the unit during movement to prevent damage or injury.
Prepare a safety check sheet (copy the last page) when you request any repair or maintenance for
the safety of service personnel.
LABELS ON UNIT
Some warning and/or caution labels are attached on the unit. Following shows the description of such
labels.
This label is on the cover in which the electrical components of high voltage are
enclosed to prevent the electric shock. The cover should be removed by a
qualified engineer or a service personnel only.
This symbol means UV caution.
This symbol means attention or refer to document.
This symbol means hot surface.
This symbol means earth.
This symbol means power switch “ON”.
This symbol means power switch “OFF”.
CAUTION

7
ENVIRONMENTAL CONDITIONS
This equipment is designed to be safe at least under the following conditions (based on the IEC 61010-1):
■Indoor use;
■Altitude up to 1000 m;
■Ambient temperature 5 oC to 40 oC
■Maximum relative humidity 80 % for temperature up to 31 oC decreasing linearly to 50 % relative
humidity at 40 oC;
■Mains supply voltage fluctuations not to exceed ±10 % of the nominal voltage;
■Other supply voltage fluctuations as stated by the manufacturer;
■Transient overvoltages according to Installation Categories (Overvoltage Categories) II; For mains
supply the minimum and normal category is II;
■Pollution degree 2 in accordance with IEC 60664.

8
INCUBATOR COMPONENTS
Rear upper side
Upper left side
Bottom of chamber When the bottom cover is removed
1
2
3
4
5
6
(
inner face of ceilin
g)
7,8
9
11
10
12
,
1
3
14
15
1
6
,
17
1819 20 22 2321 25 24
