Phenix Technologies KVM50A User manual

AC/ DC KILOVOLTMETER
MODEL NO. KVM50A
SERIAL NUMBER
Phenix Technologies, Inc.
75 Speicher Drive
Accident, Maryland 21520
Copyright © Phenix Technologies, Inc.
DMC
2/2020
Rev New

TABLE OF CONTENTS
Description Section Number
DANGER / GENERAL SAFETY PRECAUTIONS 1
TECHNICAL SPECIFICATIONS 2
UNCRATING/MECHANICAL SET-UP 3
ELECTRICAL SET-UP / OPERATIONAL NOTES 4
OPERATING INSTRUCTIONS 5
CALIBRATION 6
MECHANICAL MAINTENANCE 7
STORAGE OF EQUIPMENT 8
TROUBLESHOOTING 9
PARTS LISTS 10
RECOMMENDED SPARE PARTS 11
PARTS ORDERING INFORMATION 12
RETURNED MATERIAL 13
CIRCUIT DIAGRAM SYMBOLS 14
ELECTRICAL SCHEMATICS 15
CUSTOMER COMMENTS / SUGGESTIONS 16

1-1
DANGER / WARNINGS
Complete Grounding of this unit is necessary for
the safe operation of this equipment. Disconnect
inputs before ungrounding this equipment

1-2
GENERAL SAFETY PRECAUTIONS
HIGH VOLTAGE
This equipment is capable of providing POTENTIALLY LETHAL VOLTAGES!
Improper operation or test practices may result in injury or death to the
operator or surrounding personnel.
The operation of High Voltage test equipment should only be performed by
personnel familiar with HIGH VOLTAGE testing and safety procedures. The
operator of this equipment must be aware of all hazards associated with High
Voltage testing. The operator is responsible for himself and others in close
proximity of the testing area.
Some General Safety Practices for working with High Voltage Test Equipment
have been listed below for your reference.
•Become familiar with your instrument before performing an actual test
•Know your work area, check that all circuits are de-energized and locked
out.
•Never work alone; always work with another qualified worker.
•Mark off entire work area with barriers and warning tape.
•Make all personnel aware of your testing activities.
•Be aware of dangerous conditions that may arise from energizing a test
specimen.
•Never modify test equipment, modifications to equipment could introduce
an unknown hazard or hinder a designed-in safety feature.
•DO NOT operate damaged equipment. Remove power, and do not use
the equipment until safe operation can be verified by service-trained
personnel.
Phenix Technologies, Inc. assumes no liability for unsafe or improper use of test
equipment.



2-1
SECTION 2: TECHNICAL SPECIFICATIONS
AC/DC KILOVOLTMETERKVM50E
KVM50 DIVIDER
HIGH VOLTAGE AC INPUT:
50kVAC maximum
HIGH VOLTAGE DC INPUT:
50kVDC maximum
HIGH VOLTAGE PK INPUT:
74kV PEAK (AC)
DIVIDER RESISTANCE:
300M 
DIVIDER CAPACITANCE:
≤15 pF
DIVIDER RATIO:
10,000:1
INSTRUMENTATION:
AC / BATTERY POWERED
POWER ADAPTOR:
INPUT: 85-264 Volts AC, 0.6 AMPS, 47-63 HZ
OUTPUT: +15 VDC, 1.66 AMP
INPUT JACK:
+15 VDC, 1 AMP
BATTERY PACK:
9.6 Volt Ni-MH 3800 mA hr
VOLTAGE MEASUREMENT:
Voltage is measured by means of Peak Responding, RMS or AVG
Circuitry. 4 ½ Digit LCD display.
RANGES:
Low Range –20kV AC & DC
High Range –50kV AC & DC
ACCURACY: 1% of Reading from 10% -100% of Range
FUNCTION SELECTIONS:
1. Peak / 2 (Peak responding calibrated to RMS Value)
2. Peak (Peak responding calibrated to Peak Value)
3. RMS (True RMS)
4. AVG (True Average Value, not RMS equivalent)
5. Peak DC (Peak responding including ripple peak
6. Ripple Voltage (RMS value of a DC Ripple voltage)
7. DC RIPPLE (Peak to peak AC ripple on DC voltage / 2)
FREQUENCY RESPONSE:
(SINUSOIDAL WAVEFORM)
AC and Ripple voltage measurement functions in the range of 20-
1000Hz.
SETTLING TIME:
AC Peak, AC Peak / 2,
DC Peak, DC Ripple
AC AVG, AC RMS, DC AVG
--Up to 30 seconds
--Up to 5 seconds
ENVIRONMENTAL
CONDITIONS:
10-40°C, Indoor/Outdoor in fair weather
Humidity <95%, non-condensing
Altitude <3000 ft (1000 meters)

2-2
DIMENSIONS:
30 ½” H X 9 ½” W X 91/2” D
775mm H X 241 mm W X 241 mm D
WEIGHT:
30.5 LBS. 13.8 kg
* WEIGHT INCLUDES ALL CABLES

3-1
SECTION 3: UNCRATING/MECHANICAL SET-UP
Exercise care in removing shipping materials so as not to damage the unit.
Perform a visual inspection to determine if the unit was damaged in shipment. If there are any
signs of physical damage such as dents, scratches, or oil leaks, contact the Service Department
at Phenix Technologies before proceeding.
Read and understand all setup and operating instructions before use of the unit. Failure
to do so may cause damage to the unit and possibly void the warranty.

4-1
SECTION 4: ELECTRICAL SET-UP / OPERATIONAL NOTES
•Place the test set in the desired location. Divider base must be at ground level. High voltage
should enter divider from above at an angle of no greater than forty-five degrees from
vertical for highest accuracy readings.
•Connect a ground of sufficient size from the source ground to the grounding post located at
the base of the divider. (A 10’ lead is supplied with the unit.)
CAUTION: The ground post on the divider base must be connected to the ground or
damage to the unit may result.
•Connect the supplied coaxial cable between the low voltage arm located at the base of the
divider and the metering module. (A 25’ lead is supplied with the unit.)
NOTE: The coaxial lead is part of the calibration. Significantly changing the length of the meter
lead will affect the AC calibration.
CAUTION: The meter module has to be grounded for safe and proper operation.
•Connect the ground post on the metering module to an appropriate ground (A 10’ lead is
supplied with the unit).
CAUTION: A ground should always be connected to the ground post on the metering
module.
•Connect the source voltage to be measured to the top of the divider by an appropriate and
safe method.
NOTE: Unit is designed to measure voltage in reference to ground. Source voltage
and divider ground post must be ground referenced for unit to operate
properly.
WARNING!
THIS UNIT SHOULD ONLY BE OPERATED BY PERSONS KNOWLEDGEABLE OF HIGH
VOLTAGE TESTING AND SAFETY PROCEDURES. IMPROPER OPERATION MAY
RESULT IN INJURY OR DEATH.
ENSURE THAT UNIT TO BE TESTED IS DE-ENERGIZED AND DISCHARGED! ENSURE
THAT WORKING ENVIRONMENT IS SAFE AND FREE OF HAZARDS.

4-2
ELECTRICAL SET-UP / OPERATIONAL NOTES
1. CONTROL POWER SWITCH: Button will turn on or turn off control power of KVM.
2. BATTERY STATUS: Press button to indicate charge level of battery.
3. INPUT / CHARGING LAMP: Illuminates when external input / charging power is present.
4. INPUT JACK: External input / charging jack provides for battery charging or AC operation with
included power adapter.
5. GROUND STUD: Ground stud for connected metering module to ground.
6. BNC INPUT CONNECTOR: BNC input connector connects the metering module to divider.
7. METER: 4 1/2 digit meter displays measured value of input voltage.
8. MEASUREMENT RANGE SELECTOR: Pressing range button will changes between the low
and high range of the meter.
9. MEASURING FUNCTION SELECTOR: Pressing function up/function down will allow for
selecting measurement function.

5-1
SECTION 5: OPERATING INSTRUCTIONS
1. DIVIDER WITH METER MODULE OPERATION:
•Make sure connections have been made as described in “Set-Up” section.
•Press and hold power button to turn metering module on.
•Select the desired range for voltmeter based on the expected input signal level.
•Select desired mode for voltmeter with function buttons.
NOTE: If the Ripple voltage measurement mode is to be selected, the Range selector must be set
for the required input voltage level. If ripple voltage is to be read on input voltage over
20kV, the range selector has to be on high range, regardless of the expected ripple voltage
level. To avoid damage to the unit, ascertain that the unit will not over-range on the AVG
or the DC modes before attempting to read the ripple voltages. DO NOT attempt to read
ripple voltage on a range lower than required to measure the full input voltage.
•Activate high voltage source.
•Measure voltage as required.
•De-activate high voltage source and assure, as appropriate, high voltage source is de-energized
and discharged.
•Press and hold power button to turn metering module off.
•After ensuring high voltage source and divider are de-energized and discharged, all leads and
connections may be disconnected and unit.
•Do not subject unit to Flashovers. Damage may occur. If meter becomes disabled from Flashover
or Transient condition, refer to Troubleshooting section.
WARNING
THIS UNIT SHOULD ONLY BE OPERATED BY PERSONS KNOWLEDGEABLE OF HIGH
VOLTAGE TESTING AND SAFETY PROCEDURES. IMPROPER OPERATION MAY RESULT IN
INJURY OR DEATH.

5-2
OPERATING INSTRUCTIONS
2. STAND ALONE DIVIDER OPERATION:
•Make sure connections have been made as described in “Set-Up” section, except that the meter
module will not be used or connected.
•Connect a Voltmeter to the BNC output on the base of the divider with the 25’ coaxial cable.
NOTE: The divider has a 10,000 to 1 ratio. At 50kV input, the output voltage will be 5V. The meter
impedance needs to be 10MDC, and 1 M, ≤ 200pF AC for the highest possible accuracy. Readings
will correspond to the type of meter used. AVG will show AVG, RMS will show RMS etc. Use DC range
for DC signals (10 meg input meter).
•Select desired mode for voltmeter.
•Activate high voltage source.
•Measure voltage as required.
•De-activate high voltage source and ensure, as appropriate, that high voltage source is de-
energized and discharged.
•After ensuring that high voltage source and unit are de-energized and discharged, all leads and
connections may be disconnected and unit packaged for transport or storage.
3. STAND ALONE METER MODULE OPERATION:
It is not recommended to operate the meter head without the divider. The meter head is not a stand alone
voltmeter.

6-1
SECTION 6: CALIBRATION
It is recommended that calibration be performed on a yearly basis.
CAUTION: CALIBRATION SHOULD ONLY BE DONE BY PERSONS FAMILIAR WITH HIGH
VOLTAGE TESTING AND SAFETY PROCEDURES!
CALIBRATION PROCEDURES
Due to the complexity and the standards required to calibrate this instrument, Phenix Technologies does
not recommend customer calibration. For further information please contact our Service Department.

7-1
SECTION 7: MECHANICAL MAINTENANCE
SURFACE
All surfaces will provide adequate protection against the elements in normal use. It is recommended that
the finish be wiped down with nothing stronger than ordinary household cleaner for longer life and for
proper electrical operation of the unit. Also inspect all fabrication joints for oil leakage. If a leak is found,
consult the Service Department at Phenix Technologies.

8-1
SECTION 8: STORAGE OF EQUIPMENT
If the equipment will be stored for a prolonged period, the following precautions are recommended.
•The equipment should be covered and kept in a warm, dry environment (95% maximum humidity, 5
to 50 degrees C).
•Prior to placing the equipment back into operation, all aspects of the maintenance schedule should
be strictly adhered to.

9-1
SECTION 9: TROUBLESHOOTING
METERING MODULE
•Unit will not turn on: Battery may be discharged. Recharge battery
•Unit blanked out during testing because of transient discharge occurrence and won’t come
back on by cycling the power switch: Carefully remove front panel, and unplug the battery pack
for approximately 30 seconds, then retry power switch.

10-1
SECTION 10: KVM50EA PARTS LIST
QTY.
ITEM
PART #
DESCRIPTION
METERING MODULE
1
BATTERY
-
BATTERY PACK
1
BNC
1153068
31-010 BNC PNL MT ISOL
1
CABLE
30080007
10FT 10 GA GND CABLE
1
CASE-GND
1351103
BINDING POST (GREEN) 459-104
1
DC JK
-
DC POWER JACK- 2.1MM
1
M1
4-1/2 DIGIT LCD PANEL
1
METER PLUG
1152210
1-640440-0,CON 10CKT.1
1
NE1
1609990
NE-2B NEON
1
PCB 1372P1
-
BATTERY POWER MANAGER
1
PCB 1405P0
-
KVM INTERFACE BRD
1
PCB 1417P1
-
METERING BRD
1
PWR ADAPT
-
15VDC SW. POWER SUPPLY 2.1MM
1
PWR CABLE
1077167
INPUT POWER CABLE
DIVIDER BASE
1
BNC
1153068
31-010 BNC PNL MT ISOL
2
SPACER
1350101
SPCR #6 X 1/4 ALUM 1/4 RND
1
BINDING POST
1351103
BINDING POST (GREEN) 459-104
1
NE2
1609990
NE-2B NEON
3
HIGH ARM
1748315
15W,100MEG,1% MG815 {SGT154}
1
BRACKET
40400058
LOW ARM BRKT, DVD SERIES
1
CABLE
30050003
RG-58 CBL, 25FT, BNC-BNC
1
CABLE
30080007
GND CABLE, 10FT, GRN/YEL STRIPE 10 GA, BLK
1
LOW ARM
7060193746
KVM50E PCB

11-1
SECTION 11: RECOMMENDED SPARE PARTS
Phenix Technologies recommends that the customer purchase and stock the following parts for normal
maintenance of the unit. The recommended quantity should be sufficient to support the unit during
normal operation.
If the unit will be operated at an isolated site for an extended period or will be subjected to unusual
stresses, a larger quantity of parts should be stocked as spares. In such a case, contact your Phenix
Technologies’ sales representative for a recommendation.
Current prices may be obtained by contacting the Service Department at Phenix Technologies.
Part Number
Description
Quantity
30050003
25’ COAXIAL CABLE
1
30080007
10’ GND CABLE
1
1077167
MODULAR POWER CORD
1

12-1
SECTION 12: PARTS ORDERING INFORMATION
Replacement parts are available from Phenix Technologies, Inc.
Changes to Phenix Technologies' products are sometimes made to accommodate improved components
as they become available, and to give you the benefit of the latest technical improvements developed in
our Engineering Department. It is, therefore, important when ordering parts to include the serial number
of the unit as well as the part number of the replacement part.
When your purchase order is received at our office, a representative of Phenix Technologies will contact
you to confirm the current price of the part being ordered. If a part you order has been replaced with a
new or improved part, an Applications Engineer will contact you concerning any change in part number.
Send orders for replacement parts to:
Service Department
Phenix Technologies, Inc.
75 Speicher Drive
Accident, Maryland 21520
PH: 1 [phone]
Fax: [phone]
E-mail: [e-mail]

13-1
SECTION 13: RETURNED MATERIAL
If for any reason it should become necessary to return this equipment to the factory, the Service
Department of Phenix Technologies, Inc. must be given the following information:
Name Plate Information
Model Number
Serial Number
Reason for Return
Cause of Defect
If Phenix Technologies, Inc. deems return of the part appropriate; it will then issue an "Authorization for
Return."
If return is not deemed advisable, other inspection arrangements will be made.
NOTE: Material received at this plant without the proper authorization shall be held as "Customer's
Property" with no service until such time as the proper steps have been taken.
Your cooperation is requested in order to ensure prompt service.

14-1
SECTION 14: CIRCUIT DIAGRAM SYMBOLS
Dispositif De Sur
Interrupteur Normalement
Interrupteur Normalement
Maintenu Ouvert
Interrupteur Normalement
Maintenu Ferme
Ouvert Momentanement
Ferme Momentanement
Interrupteur Normalement
DESCRIPTION
Condensateur
Unite d'amplificateur
Relais, Contacteur
Transformateur
Condensateur electrol
Transformateur de
Resistance Variable
Prise de Courant
Contact Normalement
Contact Normalement
Changement
Insrument Analogue
Diode Zener
Cable blinde
T Transformer
Device
Current Overload
Momentary Switch
Normally Open
Momentary Switch
Normally Closed
Normally Closed
Maintained Switch
Maintained Switch
Normally Closed
Normally Open
Normally Open
Thyristor
Zener
Diode
Analog Meter
Shielded Wire
Transistor
Changeover Contact
Relay Contact
Relay Contact
Connector
Terminal Block
DP
SW
SW
SW
SW
SCR
Z
D
TR
M
K
K
K
TB
X
Intensite
Diode
Transisteur
Thyristor
Borne
Ouvert
Ferme
Contact de
SYMBOLE ZU SCHEMA
SYMBOLES POUR SCHEMA DE CIRCUIT
CIRCUIT DIAGRAM SYMBOLS
Variable Resisitor
Resistor
Lamp, Indicator
Neon
Movistor
Motor
Inductor
Relay, Contactor
Circuit Breaker
Current Transfomer
Fuse
Electrolytic Capacitor
Bushing
Capacitor
Surge Arrestor
Amplifier
BSHG
LP
R
R
NE
MOV
MOT
CB
K
L
CT
F
C
SYMBOL
ARSR
C
REF
A
Tranversee
Parafoudre
Moteur
Parafoudre
Lampe
Resistance
Courant
Fusible
Interupteur
Self
DESCRIPTION
Parafoudre
Transformer
Oeffnungskontakt
Abgeschirmetes Kabel
UeberstromschutzEinheit
Schrittschalter
Druckschalter
(Schliesser)
Schrittshalter
(Oeffner)
(Schliesser)
(Oeffner)
Druckschalter
Analog Meter
Transistor
Thyristor
Diode
Zener
Losbare Klemme
Steckverbindung
Schlierskontakt
Umschaltkontakt
BEMENKUNG
Ueberspannungsableiter
Ueberspannungsableiter
Eleckrolytik kondensator
Stromtransformer
Durchfuehoung
Widerstand
Movistor
Meldeleuchte
Widerstand
Motor
Sicherung
Drossel, Spule
Relais, Schutz
Unterbrecher
Kondensator
Verstarker
