Phenyx PTM-11 User manual
PHENYX PRO
Phenyx Pro Wireless In-Ear Monitor System
PTM-11 PTM-22
Thank you for purchasing the PHENYX PRO PTM-11/PTM-22 UHF
Wireless In-Ear Monitor System.Please read this manual carefully
to ensure proper use and operation, and keep it for future reference.
- 1 x Wireless Base Unit Transmitter
- 1 x UHF Bodypack Receiver
- 1 x In-ear earbud
- 1 x Power Adapter
- 1 x Antenna
- 2 x AA Battery
- 1 x Antenna Kit
- 1 x Carry Case
- 1 x User Manual
PTM-11:
1 x Wireless Base Unit Transmitter
2 x UHF Bodypack Receiver
2 x In-ear earbud
1 x Power Adapter
2 x Antenna
4 x AA Battery
1 x Antenna Kit
1 x User Manual
PTM-22:
4
Box Contents
System Overview
The Phenyx Pro PTM-11 is a great solution for making sure you can hear your
monitor mix on stage, no matther where you stand or how loud the rest of your
band and the environment are. There are many plus sides using the PTM-11 in
-ear monitor system: wireless design for less clutter on stage, up to 164ft
operation for more freedom to move around, and specially engineered circutry
for reliable sound performance. There are 50 selectable frequencies available
for the PTM-11, up to 20 systems can be used at the same time. There are two
channels (2x50 frequencies) for the PTM-22 for two members in the band using
it at the same time.
Volume Control
1
IR Window
Aim the IR window of the bodypack receiver to the IR window of the transmitter to pair up
2
Sync Button
3
LCD Display
4
Group Button
Press Group Button to change group number
5
13-15V DC Input
Connect AC/DC adapter to transmitter
1
Left/Right Outputs
Output audio to amplifier/speaker, can also work as input
2
Left/Right Inputs
Two inputs for audio mix
3
PAD Switch
Adjust output gain. To cut gain, set to (-12dB). The default setting of 0dB will have no
effect on gain
4
Antenna Jack
5
Channel Button
Press Channel Button to change channel number
6
Power Switch
7
TRANSMITTER FOR PTM-11
Back Panel
1 2 3 4 5
1 2 3 4 5 6 7
Front Panel
6
Power Switch
1CH1 Volume Control
2
CH1 LCD Display
5
CH2 Sync Button
8CH2 LCD Display
9
CH1 Sync Button
6
CH1 Group Button
Press Group Button to change group number for CH1
3
12-18V DC Input
Connect AC/DC adapter to transmitter
1
CH2 Left/Right Outputs
Output CH2 audio to amplifier/speaker, can also work as input
2
CH2 Left/Right Inputs
Two inputs for CH2 audio mix
3
CH1 Left/Right Outputs
Output CH1 audio to amplifier/speaker, can also work as input
6
PAD Switch
Adjust output gain. To cut gain, set to (-12dB). The default setting of 0dB will have no effect on gain
4
CH1 Channel Button
Press Channel Button to change channel number for CH1
4
IR Window
Aim the IR window of the bodypack receiver to the IR window of the transmitter to pair up
7
CH2 Group Button
Press Group Button to change group number for CH2
10
CH2 Channel Button
Press Channel Button to change channel number for CH2
11
CH2 Volume Control
12
TRANSMITTER FOR PTM-22
Back Panel
CH2 Antenna Jack
5
Left/Right Inputs
Two inputs for CH1 audio mix
7PAD Switch
8CH1 Antenna Jack
9
1 2 3 4 5 6 7 8 9
12 3 4 5 6 7 8 9 10 11 12
Front Panel
7
Bodypack
Good Quality Earphone
RECEIVER
IR Window
Aim the IR window of the bodypack receiver to the IR window of the transmitter to pair up
1
LCD Display
2Battery Compartment
3
Phone Jack
5Volume Control/Power Switch
6
Antenna
4
1
4
26
3
5
8
A - Remove packing material
B - Set up the PTM-11/PTM-22 receiver
1.Open the battery cover of the bodypack receiver and place two 1.5V AA batteries into the
batter housing with the batteries polarity orientation as indicated
2.Plug the supplied earphones into the earphone output jack on the bodypack receiver
3.Turn the volume control knob toward right to turn on the bodypack receiver
C - Set up the PTM-11/PTM-22 transmitter
1.Place the transmitter at least 3.5ft (1m) away from the ground and all walls. Also, keep the
transmitter as far away as possible from any electromagnetic noise sources
2.Mount the antenna onto the antenna jack
3.Plug the AC/DC adapter to the transmitter’s DC input, and then plug the AC input of the
adapter to a 110V - 220V outlet
4.Turn on the transmitter
D - Set up the PTM-11/PTM-22 in ear monitor system
1.Press Group and Channel button to select desired frequency
2.Press Sync button to initiate the synchronization. Align the IR window on the bodypack
to the IR window on the base unit. The frequency will synchronize within seconds
3.Enjoy reliable wireless sound monitoring performance
NOTE: There are left/right audio inputs for the PTM-11 and PTM-22 system to mix
different audio sources, but there is no stereo function for this IEM system.
Operation
9
Specifications
System
Transmitter
Bodypack Receiver
Frequency Range and Transmitter Output Level
Frequency Range: 902 - 928MHz
Transmitter Output Level: 10dBm
Operating Range Under Typical Conditions
50m/164ft
Note: Actual range depnds on RF signal absortuon,reflection, and interference
Audio Frequency Response (+/- 3dB)
50Hz - 16KHz
Harmonic Distortion (+/- 30KHz deviation)
<1%
Dynamic Range
> 90dB
Operating Temperature Range
- 10°— + 50°
Max Audio Input Level
+6dBV
Audio Output Level
80mW
Sensitivity
-90dBm for 30dB SINAD, typical
Power Requirements
2 AA alkaline or recharging batteries
Battery Life
>6 hours
Gain Adjustment Range
40dB
Input Impedance
6.8KΩ
Power Requirements
12 - 18V DC, 350mA, supplied by external power supply
Our Warranty to you:
Phenyx Technology (“Phenyx”) warrants Phenyx products against evident de-fects
in material and workmanship for a period of one year from the date of original
purchase for use. This warranty is valid exclusively in the US and applies only to the
original owner. If you discover a defect covered by this warranty, Phenyx will repair
or replace the product at our sole discretion using new or refurbished components.
Performance of repairs or replacements under this Warranty is sub-ject to registration
of your product at www.phenyxusa.com/registerproduct.
Product failures not covered by this warranty:
This warranty covers defects in manufacturing that arise from the correct use of
the device. It is limited to defects in materials or workmanship and does not cover
electrical or mechanical damage resulting from abuse, misuse, unauthorized
modification, lack of reasonable care, extreme heat, cold, damage due to natural
forces, or corrosive environments. This warranty does not cover the normal wear
and tear on covers, housing, connectors, and accessories.
Limits of liability:
If your Phenyx product fails or does not perform as warranted, your sole recourse
shall be to replace or repair it as described above. Phenyx will not be liable to you
or anyone else for any damages that result from the failure of this product. These
damages include, but are not limited to, the following: lost profi ts, lost savings,
lost data, damage to other equipment, and incidental or consequential damages
arising from the use of or inability to use this product. IN NO EVENT PHENYX
SHALL BE LIABLE FOR MORE THAN THE AMOUNT OF YOUR PURCHASE
PRICE, NOT TO EXCEED THE CURRENT LIST PRICE OF THE PRODUCT.
How to obtain service under this warranty:
If you are receiving a system that is defective or you have any questions regarding
any questions or concerns and a Phenyx Pro representative will contact you to
provide assistance. You can also reach out to us through Facebook page:
www.facebook.com/phenyxusa/ or our official website: www.phenyxpro.com
10
Designed in US Made in China
www.phenyxpro.com
