Comica CVM-VS07C User manual

CVM-VS07C
Mini Flexible Plug-in Cardioid Microphone
(Universal for Camera, Phone, GoPro)
User Manual

Foreword
Thanks for purchasing COMICA CVM-VS07C
Notice
For the smartphone with Android system, the Mic works well in Audio Mode, it may not be
compatible with most of the smartphones in Default Video Mode (Then we suggest you to
try the 3rd party's video APP, such as TikTok, FiLMiC Pro, ect.);
For the smartphone with iOS system(iPhone), the Mic works well either in Audio or Video
mode;
Do not use this equipment near heat source or interference source, such as radiator,
oven, refrigerator or air conditioner;
Please use the windscreen while the sound distance is too closed or in outdoor to avoid
sound broken or wind noise;
Do not use the equipment in rain or in a damp environment to avoid short-circuit danger.
1

Main Features
Packing List
. Intelligent TRS and TRRS Sensing
. 90 Degree Adjustable Recording Direction Construction
. Metal Housing for Excellent Shielding
. Built-in Shock Mount and Gold Plated Capsule
. Universal for Camera, Phone, GoPro
Microphone Windscreen User Manual Warranty Card
CVM-VS07C
MiniFlexible Plug-in Cardioid Microphone
(Universalfor Camera, Phone, GoPro)
User Manual
2

Components and Instruction
Capsule
Rotary Axis
3.5mm TRRS Plug
①
③
②
①②③
3

Installation and Usage
Windscreen Installation
First Step: Put on the Windscreen Second Step: Normal use
4

Work with GoPro
First Step:
Insert microphone into 3.5mm socket
Second Step:
Adjust to right direction
Third Step:
Normal use
5

Work with Camera
First Step:
Insert microphone into 3.5mm socket
Second Step:
Adjust to right direction
Third Step:
Normal use
6

Work with Phone
First Step:
Insert microphone into 3.5mm socket
Second Step:
Adjust to right direction
Third Step:
Normal use
7

Specifications
1.Frequency Response 2.Polar Pattern
8

3.Technology Parameters
Polar Pattern
Frequency Response
Sensitivity
S/N
Equivalent Noise
Maximum SPL
Dynamic Range
Output Port
Maximum Rotation Angle
Dimension
Net Weight
Working Temperature
Storage Temperature
Cardioid Pattern
60Hz ~ 20kHz
-36dB±2dB
70dB
24dBA
110dB
86dB
3.5mm TRRS
90°
Φ15mm x L61mm
16.5g
0℃~ 50℃
-20℃~ 60℃
9

CVM-VS07C
多功能迷你直插式心型指向麦克风
（通用于相机、手机、GoPro）
使用说明书

前 言
感谢您购买COMICA/科唛CVM-VS07C
注意事项
配合Android（安卓）系统的手机使用时,录音模式下均可正常工作,视频模式下部分手机会出现不
兼容情况（此时建议使用第三方视频软件如抖音、快手等）；
配合iOS系统手机使用时,在所有录音模式、视频模式以及第三方视频软件下均可正常使用；
请勿将本设备放置在热源或干扰源附近使用,如散热器、烤箱、冰箱和空调旁边；
如拾音距离较近或于户外使用时,请套上麦克风防风棉,防止声音爆裂或降低风噪；
不要在雨中或潮湿的环境中使用该设备,否则会有短路的危险。
1

产品主要功能
包装清单
. 智能识别TRS和TRRS
. 90度可调录音角度
. 全金属制造，优异屏蔽性能
. 内置减震结构、镀金膜咪头
. 通用于相机、手机、GoPro
麦克风主体 防风棉 说明书 保修卡
CVM-VS07C
MiniFlexible Plug-in Cardioid Microphone
(Universalfor Camera, Phone, GoPro)
User Manual
2

部件介绍及说明
拾音头
旋转轴
3.5mm TRRS插头
①②③
3
①
③
②

安装与使用方法
防风棉安装方式
第一步：
插入防风棉
第二步：
正常使用
4

搭配GoPro安装方式
第一步：
插入3.5mm插口
第二步：
调整到合适的方向
第三步：
正常使用
5

搭配相机安装方式
第一步：
插入3.5mm插口
第二步：
调整到合适的方向
第三步：
正常使用
6
