Philco PX 4011 X User manual

SIDEBYSIDE REFRIGERATOR
NOFROST
USER’SMANUAL
PX 4011 X

Dear customer,
Thank you for buying aPHILCO brand product. So that your appliance serves you well, please read
all the instructions in this user'smanual.

EN - 1
05/2015Copyright © 2015, Fast ČR, a. s.
CONTENTS
PART 1: SAFETY INFORMATION..................................................................................................................... 2
PART 2: OVERVIEW.......................................................................................................................................... 8
PART 3: INSTALLATION.................................................................................................................................... 9
PART 4: DAILY USE AND TROUBLESHOOTING ........................................................................................... 13
PART 5: INFORMATION SHEET ...................................................................................................................... 21

EN - 2
05/2015Copyright © 2015, Fast ČR, a. s.
PART 1: SAFETY INFORMATION
In theinterest of your safety andto ensure thecorrect use, before installingand rst usingthe appliance,read
this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents,
it is important to ensure that all people using the appliance are thoroughly familiar with its operation and
safety features. Save these instructions and make sure that they remain with the appliance if it is moved or
sold, so that everyone using it through its life will be properly informed on appliance use and safety.
For the safety of life and property keep the precautions of these user’sinstructions as the manufacturer
is not responsible for damages caused by omission.
CHILDREN AND VULNERABLE PEOPLE SAFETY
• This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given super vision or
instruction concerning use of the appliance in asafe way
and understand the hazards involved.
• Children should be supervised to ensure that they do
not play with the appliance.
• Cleaning and user maintenance shall not be made by
children unless they are aged from 8years and above
and supervised.
• Keep all packaging well away from children. There is risk
of suocation.
• If you are discarding the appliance pull the plug out of the
socket, cut the connection cable (as close to the appliance
asyoucan)andremovethedoortopreventplayingchildren
to suer electric shock or to close themselves into it.
• If this appliance featuring magnetic door seals is to
replace an older appliance having aspring lock (latch) on

EN - 3
05/2015Copyright © 2015, Fast ČR, a. s.
the door or lid, be sure to make that spring lack unusable
before you discard the old appliance. This will prevent it
from becoming adeath trap for achild.
GENERAL SAFETY
WARNING! Keep ventilation openings, in the appliance
enclosureorinthebuilt-instructure,clearofobstruction.
WARNING! Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING! Do not damage the refrigerant circuit.
WARNING! Do not use other electrical appliances
(such as ice cream makers) inside of refrigerating
appliances, unless they are approved for this purpose
by the manufacture.
WARNING! Do not touch the light bulb if it has been
on for along period of time because it could be very
hot.1)
• Do not store explosive substances such as aerosol cans
with aammable propellant in this appliance.
• The refrigerant isobutane (R600a) is contained within
the refrigerant circuit of the appliance, anatural gas with
a high level of environmental compatibility, which is
nevertheless ammable.
1) If there is alight in the compartment.

EN - 4
05/2015Copyright © 2015, Fast ČR, a. s.
• During transportation and installation of the
appliance, be certain that none of the components of
the refrigerant circuit become damaged.
- avoid open ames and sources of ignition
- thoroughly ventilate the room in which the appliance
is situated
• It is dangerous to alter the specications or modify this
product in any way. Any damage to the cord may cause
ashort circuit, re and/or electric shock.
• This appliance is intended to be used in household and
similar applications such as
- sta kitchen areas in shops, oces and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
Any electrical components (plug, power cord,
compressor and etc.) must be replaced by acertied
service agent or qualied service personnel.
The LED light supplied with this appliance is a“special
uselampbulb”usableonlywiththeappliancesupplied.
This“special use of LED light”is not usable for domestic
lighting.1)
• Power cord must not be lengthened.
1) If there is alight in the compartment.

EN - 5
05/2015Copyright © 2015, Fast ČR, a. s.
• Make sure that the power plug is not squashed or
damaged by the back of the appliance. Asquashed or
damaged power plug may overheat and cause are.
• Make sure that you can come to the mains plug of the
appliance.
• Do not pull the mains cable.
• If the power plug socket is loose, do not insert the
power plug. There is arisk of electric shock or re.
• You must not operate the appliance without the lamp.
• This appliance is heavy. Care should be taken when
moving it.
• Do not remove nor touch items from the freezer
compartment if you hands are damp/wet, as this could
cause skin abrasions or frost/freezer burns.
• Avoid prolonged exposure of the appliance to direct
sunlight.
DAILY USE
• Do not put hot on the plastic parts in the appliance.
• Do not place food products directly against the rear wall.
• Frozen food must not be re-frozen once it has been thawed out.2)
• Store pre-packed frozen food in accordance with the frozen food manufacture,sinstructions.2)
• Appliance’s manufactures storage recommendations should be strictly adhered to. Refer to relevant
instructions.
• Do not place carbonated of zzy drinks in the freezer compartment as it creates pressure on the container,
which may cause it to explode, resulting in damage to the appliance.2)
• Ice lollies can cause frost burns if consumed straight from the appliance.2)
CARE AND CLEANING
• Before maintenance, switch o the appliance and disconnect the mains plug from the mains socket.
• Do not clean the appliance with metal objects.
• Do not use sharp objects to remove frost from the appliance. Use aplastic scraper.2)
• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean the drain. If the drain
is blocked, water will collect in te bottom of the appliance.3)
2) If there is afreezer compartment.
3) If there is afresh-food storage compartment.

EN - 6
05/2015Copyright © 2015, Fast ČR, a. s.
INSTALLATION
IMPORTANT:
For electrical connection carefully follow the instruc-
tions given in specic paragraphs.
• Unpack the appliance and check if there are damages on
it. Do not connect the appliance if it is damaged. Report
possible damages immediately to the place you bought
it. In that case retain packing.
• It is advisable to wait at least four hours before connecting
theappliancetoallowtheoiltoowbackinthecompressor.
• Adequate air circulation should be around the appliance,
lacking this leads to overheating. To achieve sucient
ventilationfollowthe instructions relevanttoinstallation.
• Wherever possible the spacers of the product should be
against awall to avoid touching or catching warm parts
(compressor, condenser) to prevent possible burn.
• The appliance must not be located close to radiators or
cookers.
• Make sure that the mains plug is accessible after the
installation of the appliance.
SERVICE
• Any electrical work required to do the servicing of the
appliance should be carried out by aqualied electrician
or competent person.
• This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.

EN - 7
05/2015Copyright © 2015, Fast ČR, a. s.
ENERGY SAVING
• Don’t put hot food in the appliance;
• Don’t pack food close together as this prevents air
circulating;
• Make sure food don’t touch the back of the compartment(s);
• If electricity goes o, don’t open the door(s);
• Don’t open the door(s) frequently;
• Don’t keep the door(s) open for too long time;
• Don’tsetthethermostatonexceedingcoldtemperatures;
• Some accessaries,such asdrawers,can be removedtoget
larger storage volume and lower energy consumption.

EN - 8
05/2015Copyright © 2015, Fast ČR, a. s.
PART 2: OVERVIEW
Refrigerator Shelves
Crisper Cover
Chiller Zone
Sliding Tray
Freezer Drawer
Leveling Feet
LED Light
Door Balcony
Crisper Zone
NOTE:
Above picture is for reference only. Real appliance probably is dierent.

EN - 9
05/2015Copyright © 2015, Fast ČR, a. s.
PART 3: INSTALLATION
Space Requirement
• Select alocation without direct exposure to sunlight;
• Select alocation with enough space for the refrigerator doors to open easily;
• Select alocation with level (or nearly level) ooring;
• Allow sucient space to install the refrigerator on aat surface;
• Allow clearance to the right, left, back and top when installing. This will help reduce power consumption
and keep your energy bills lower.
At least
50 mm
At least
50 mm
130°
1030 mm
1380 mm
Levelling and anchor the refrigerator
• Leveling and anchor the refrigerator by adjust the feet.
• Clockwise rotate feet to heighten them by hand.
• Anticioclockwise rotate feet to lower them by hand.
Doors

EN - 10
05/2015Copyright © 2015, Fast ČR, a. s.
Level doors
After transportation or door balconies are loaded by food or beverage, upper two doors may not be aligned.
There are 3C type washers which are used to adjust doors. Please follow below process to level doors.
1. Before check alignment of doors, please make sure appliance stand levelly .
2. If top of upper two doors looks not in aline, please slightly lift lower door and insert apieces of C type
washer by aclip between bottom of door and middle hinge.
WARNING! Please be careful to avoid ngers are
clipped by door. Please use tool.
WARNING! Please keep C type washers far away
children to avoid them are swallowed by children.
They are small parts.

EN - 11
05/2015Copyright © 2015, Fast ČR, a. s.
Rubber blocks
There is one rubber block on each door. They function as spring to relieve impact when door closes.
Please not pull the rubber blocks. If they absent from the doors, please take one from accessary bag and insert
it to the hole of door.
WARNING! Please keep rubber blocks far away
children to avoid them are swallowed by children.
They are small parts.

EN - 12
05/2015Copyright © 2015, Fast ČR, a. s.
Positioning
Install this appliance at alocation where the ambient temperature corresponds to the climate class indicated
on the rating plate of the appliance:
Climatic class Ambient temperature °C
SN +10 °C to +32 °C
N +16 °C to +32 °C
ST +16 °C to +38 °C
T +16 °C to +43 °C
Location
The appliance should be installed well away from sources of heat such as radiators, boilers, direct sunlight
etc. Ensure that air can circulate freely around the back of the cabinet. To ensure best performance, if the
appliance is positioned below an overhanging wall unit, the minimum distance between the top of the cabinet
and the wall unit must be at least 100 mm. Ideally, however, the appliance should not be positioned below
overhanging wall units. Accurate leveling is ensured by one or more adjustable feet at the base of the cabinet.
WARNING! It must be possible to disconnect the
appliance from the mains power supply; the plug must
therefore be easily accessible after installation.
Electrical connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond to your
domestic power supply. The appliance must be earthed. The power supply cable plug is provided with acontact
for this purpose. If the domestic power supply socket is not earthed, connect the appliance to aseparate earth
in compliance with current regulations, consulting aqualied electrician.
The manufacturer declines all responsibility if the above safety precautions are not observed.
This appliance complies with the E.E.C. Directives.

EN - 13
05/2015Copyright © 2015, Fast ČR, a. s.
PART 4: DAILY USE
Using the Control Panel
NO FROST
FRIDGE
FREEZER
MODE
LOCK 3’S
1
2
3
4
5
6
A
B
C
1.1KEY OPERATION
A. Temperature Control of Fridge Compartment
B. Temperature Control of Freezer Compartment
C. Mode/ Locking / Unlocking
1.2LED DISPLAY
1. Temperature of Fridge Comparment
2. Temperature of Freezer Comparment
3. ECO Mode
4. Holiday Mode
5. Super Mode
6. Locking / Unlocking
2.0OPERATING CONDITION
a. The control panel is 100% lit up for 3seconds, which operates exactly as per the setting (mode and
temperature) before the powero. The system will be automatically locked 25 seconds after the last key
operation. After locking, the light of the panel would be out 30 seconds after the last key operation.
b. Both preset temperatures of fridge compartemnt and freezer compartment would be shown on the
display.
2.1DISPLAY
2.1.1 The panel will be lit up for 2minutes once the door of fridge compartment or freezer compartment is
opened. (one door signal is sensed at atime)
2.1.2 The panel will be lit up by any key operation whereas the light would be out 2minutes after the last
operation.

EN - 14
05/2015Copyright © 2015, Fast ČR, a. s.
2.1.3 Display during normal operation
Temperature Display of the Fridge Compartment: Indicating the temperature of the current setting.
Temperature Display of the Freezer Compartment: Indicating the temperature of the current setting.
3.0ILLUSTION OF THE KEY
3.1 Temperature Control of the Fridge Compartment
a. Temperature Control of the Fridge Compartment:
This key is workable both in User Dened Mode as well as Super Mode. After entering the temperature
control of the fridge compartment, this key ashes. By touching the key consecutively, the temperature
would change in acircle of“2°C, 3°C, 4°C, 5°C, 6°C, 7°C, 8°C, OFF”, after which 5-second ashing means
the selection of temperature is settled.
b. Shuto of the Fridge Compartment:
Press the key of“Temperature Control of Fridge Compartment”, choose “OFF”, a5-second ashing
means the selection of temperature is made, namely the fridge compartment would stop refrigeration.
3.2 Temperature Control of the Freezer Compartment
Temperature Control of the Freezer Compartment: This key is workable both in User Dened Mode as well as
Holiday Mode. After entering the temperature control of the freezer compartment, the key ashes. By touching
the key consecutively, the temperature would change in acircle from -1°C to -22°C, after which a5-second
ashing means the selection of temperature is settled.
3.3 Mode/ Locking / Unlocking
a. By touching this key consecutively, the operation mode of the refrigerator will change in acircle of
“ECO Mode-Holiday Mode-Super Mode-User Dened Mode. A5-second ashing means the selection of
temperature is settled.
b. Long Press to Enter / Exit Locking Mode
· Unlocking: Press for 3seconds in the mode of locking, all the keys would be unlocked after the abeep.
· Locking: Press for 3seconds in the mode of unlocking, all the keys would be locked after the abeep.
3.4 Press Button
Short beep after per press button
All buttons will only valid under unlock mode.
3.5 Lock Function
N operation in 25 sec will lock the display automatically.

EN - 15
05/2015Copyright © 2015, Fast ČR, a. s.
4.0ECO mode
Press mode to choose ECO mode, ECO icon keeps bright after 5sec ashing. 5° in fridge compartment and
-18° in freezer compartment under eco mode,“Freezer”&“Fridge“ button in vain while eco icon will ash three
times in alarm.
Exit eco mode
Press mode again to exit eco mode after 5sec, entering the selected mode.
4.1Holiday Mode
Press mode to choose Holiday Mode, the icon keeps bright after 5sec ashing, entering holiday mode.
Temperature x 17°in fridge compartment, “fridge”button in vain, while holiday icon will ash three times in
alarm.
Exit holiday mode: choose mode, exit holiday mode after 5sec, entering the selected mode.
4.2Super Freezing mode
Choose mode, icon keeps bright after 5sec ashing, entering freezing mode.
Freezing mode:
Temperature nonadjustable in freezing compartment,“freezer” button in vain, while freezing icon will ash
three times in alarm.
Exit freezing mode: meeting below conditions.
- manually exit freezing mode
- freezing period more than 50 hours
Mode remains the same before entering super freezing mode.

EN - 16
05/2015Copyright © 2015, Fast ČR, a. s.
First use
Cleaning the interior
Before using the appliance for the rst time, wash the interior and all internal accessories with lukewarm water
and some neutral soap so as to remove the typical smell of abrand new product, then dry thoroughly.
IMPORTANT:
Do not use detergents or abrasive powders, as these will damage the nish.
Daily use
Freezing fresh food
• The freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen food for
along time.
• Place the fresh food to be frozen in the bottom compartment.
• The maximum amount of food that can be frozen in 24 hours is specied on the rating plate.
• The freezing process lasts 24 hours: during this period do not add other food to be frozen.
Storing frozen food
When rst starting-up or after aperiod out of use. Before putting the product in the compartment let the
appliance run at least 2hours on the higher settings.
IMPORTANT:
In the event of accidental defrosting, for example the power has been o for longer than the
value shown in the technical characteristics chart under “rising time”, the defrosted food must be
consumed quickly or cooked immediately and then re-frozen (after cooked).
Thawing
Deep-frozen or frozen food, prior to be used, can be thawed in the freezer compartment or at room temperature,
depending on the time available for this operation. Small pieces may even be cooked still frozen, directly from
the freezer. In this case, cooking will take longer.
Defrost Description (No Frost)
It is atotal no frost refrigerator-freezer which will be defrosted automatically.
Helpful hints and tips
Hints for freezing
To help you make the most of the freezing process, here are some important hints:
• the maximum quantity of food which can be frozen in 24 hrs. is shown on the rating plate;
• the freezing process takes 24 hours. No further food to be frozen should be added during this period;
• only freeze top quality, fresh and thoroughly cleaned, foodstus;
• prepare food in small portions to enable it to be rapidly and completely frozen and to make it possible
subsequently to thaw only the quantity required;
• wrap up the food in aluminium foil or polythene and make sure that the packages are airtight;
• do not allow fresh, unfrozen food to touch food which is already frozen, thus avoiding arise in temperature
of the latter;
• lean foods store better and longer than fatty ones; salt reduces the storage life of food;
• water ices, if consumed immediately after removal from the freezer compartment, can possibly cause the
skin to be freeze burnt;
• it is advisable to show the freezing in date on each individual pack to enable you removal from the freezer
compartment, can possibly cause the skin to be freeze burnt;
• it is advisable to show the freezing in date on each individual pack to enable you to keep tab of the storage time.

EN - 17
05/2015Copyright © 2015, Fast ČR, a. s.
Hints for storage of frozen food
To obtain the best performance from this appliance, you should: make sure that the commercially frozen
foodstus were adequately stored by the retailer; be sure that frozen foodstus are transferred from the food
store to the freezer in the shortest possible time; not open the door frequently or leave it open longer than
absolutely necessary. Once defrosted, food deteriorates rapidly and cannot be refrozen. Do not exceed the
storage period indicated by the food manufacture.
Hints for fresh food refrigeration
To obtain the best performance:
• Do not store warm food or evaporating liquids in the refrigerator
• Do cover or wrap the food, particularly if it has astrong avour
Hints for refrigeration
Useful hints:
• Make (all types): wrap in polythene bags and place on the glass shelves above the vegetable drawer.
• For safety, store in this way only one or two days at the most.
• Cooked foods, cold dishes, etc...: these should be covered and may be placed on any shelf.
• Fruit and vegetables: these should be thoroughly cleaned and placed in the special drawer(s) provided.
• Butter and cheese: these should be placed in special airtight containers or wrapped in aluminum foil or
• polythene bags to exclude as much air as possible.
• Milk bottle: these should have acap and should be stored in the balconies on the door.
• Bananas, potatoes, onions and garlic, if not packed, must not be kept in the fridge.
Fresh Zone Temperature Control
• Temperature of the fresh can be adjusted according to the type of storage food.
• Push the knob upward from the bottom, temperature in the fresh zone will be gradually decreased.
• When the knob is placed at the “CRISPER” position, the fresh zone can be functioned as acrisper zone and
maintain the appropriate temperature and humidity for fruits and vegetable.
• When the knob is placed at the“CHILLER”position, it is suitable for short-term storage of sh or other fresh
food. The food will keep fresh but not frozen which makes it the best choice for storing fresh food.
• Tips: When you choose “CHILLER” function, it is recommended to set the refrigerator temperature below
4°C. and preserved lead-time no more than 3days , in order to keep the best freshness.
CHILLER & CRISPER
TEMPERATURE
CONTROL
CHILLER
CRISPER

EN - 18
05/2015Copyright © 2015, Fast ČR, a. s.
Using the freezer section as arefrigerator
• Make (all types): wrap in polythene bags and place on the glass shelves above the vegetable drawer.
• For safety, store in this way only one or two days at the most.
HIGHLOW
HUMIDITY CONTROL
Cleaning
For hygienic reasons the appliance interior, including interior accessories, should be cleaned regularly.
CAUTION! The appliance may not be connected to
the mains during cleaning. Danger of electrical shock!
Before cleaning switch the appliance o and remove
the plug from the mains, or switch o or turn out the
circuit breaker or fuse. Never clean the appliance with
asteam cleaner. Moisture could accumulate in electrical
components, danger of electrical shock! Hot vapors can
lead to the damage of plastic parts. The appliance must
be dry before it is placed back into service.
IMPORTANT:
Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice form orange peel,
butyric acid, cleanser that contain acetic acid.
• Do not allow such substances to come into contact the appliance parts.
• Do not use any abrasive cleaners
• Remove the food from the freezer. Store them in acool place, well covered.
• Switch the appliance o and remove the plug from the mains, or switch o or turn out the circuit breaker
of fuse.
• Clean the appliance and the interior accessories with acloth and lukewarm water. After cleaning wipe with
fresh water and rub dry.
• After everything is dry place appliance back into service.
