Philco PC700SNL User manual

1
INSTALLATION
Positioning
660mm
top of cooking
surface
Fixing dimensions
WARNING!
these instructions may result in electrical hazards.
700/900/1200
500
52
550
316
286
Min 724/Max 1032

2
●Mark the location for flue cover wall mounting brackets, rangehood
mounting points and anti-tilt fixing points above the rangehood
using the base as the reference point (Fig. 1).
Drilling holes
Fig.1
●Attach the upper hood mounting screws in the locations shown
in Fig.2. Use the ST3.9 x 32 screws and expansion plugs if
attaching to masonry.
Attach chimney brackets and hood mounting screws

3
●Remove the aluminium filters from the rangehood body and hang
it on the ST3.9 x 32mm screws then secure at the anti-tilt locations
as indicated in Fig. 3.
Attached hood on wall
2mm
Fig.2
Fig.3
Screws
ST3.9 x 32mm

4
●Connect Ø120mm ducting adapter to the blower outlet and use
ST3.9 x 13mm screws to fix it to the range hood (Fig. 4).
Connect ducting adapter
Fig.4
●If need exhaust air to the outside.
Connect Ø125 mm flexible duct to the
adapter and fix it (Fig. 5).
Fixing flexible duct
Fig.5
Screws ST3.9 x 13mm
Ø120mm
Ducting adapter

5
Attach the chimney
●Fix the chimney to the top bracket
using the ST3.9 x 13mm screws. Connect top of
the ducting tube to vent kit as per
manufacturers instructions (Fig. 7).
Connect ducting adapter
Fig.6
Fig.7
●Install back the aluminium filters to
rangehood, and for Stainless Steel
appliance, remove the protection
film from rangehood and chimney.

6
700/900/1200
500
52
550
316
286
724 1032

7
僅600/700
僅900
僅1200
最小660
裝上煙囪ST3.9 x 32毫米螺絲安裝在圖2的所示位置。如安裝至磚
石上，請使用Ø6 x 30毫米膨脹膠塞。

8
ST3.9 x 32毫米

9
將Ø120毫米排氣管接合器連接在排風口上，並用ST3.9 x 13毫米
螺絲固定在抽油煙機上(圖4)。
Ø125毫米的
伸縮排氣管連接在接合器上，並用螺
絲固定位置。

10
安裝煙囪
連接煙囪
圖6
圖
將金屬隔油網裝回抽油煙機上，並
將其保護膜取下。
將煙囪固定在頂部支架上，用ST3.9 x 13
毫米螺絲安裝及固定。將排氣管的頂
部連接到支架上(圖7)。
