Philips CED229X/78 User manual

Register your product and get support at
www.philips.com/welcome
EN User manual

3
6 System settings 19
Adjust general settings 19
Select DVD video settings 19
Select language settings 20
Adjust radio settings 20
7 Other settings 21
Select equalizer settings 21
Control zone settings 21
Other sound settings 22
Select Video Output format 22
Turn on or off the screen backlight 22
Reset 23
Replace fuse 23
8 Product information 24
General 24
Disc player 24
Tuner 24
LCD 24
Compatible USB devices 24
Supported formats 24
Unsupported formats 25
9 Troubleshooting 26
Contents
1 Important 4
Notice 4
2 Your car audio system 6
Introduction 6
What’s in the box 6
Install the car audio 6
Connect 7
Connect parking brake cable and
reverse driving cable to a rear view
backup camera 7
Mount into dashboard 8
Install remote control battery 9
3 Get started 10
Turn on and turn off 10
Adjust volume 10
Mute 10
4 Play 11
Load and eject discs 11
Insert and remove USB device 12
Insert and remove SD/MMC card 12
Skip/search 12
Intro play 13
Repeat play 13
Random play 14
Select Language 14
Dynamic Bass Boost 14
MAX sound 15
Zoom 15
5 Radio 16
Select tuner sensitivity 16
Manual tune to a radio station 16
Auto tune to a radio station 17
Store stations manually 17
Store stations automatically 17
Select the preset station 17
Select stereo or mono broadcasting 18
English
EN

4
Notice
The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.
“DivX, DivX” Certified, and associated logos
are trademarks of DivX, Inc. and are used
under license.
Offical DivX® Certified product. Plays all
versions of DivX® video (including DivX® 6)
with standard playback of DivX® media files.
Manufactured under license from Dolby
Laboratories.
“Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
Other trademarks and trade names are those
of their respective owners.
This apparatus includes this label:
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
1 Important
Read and understand all instructions•
before you use the apparatus. If damage
is caused by failure to follow instructions,
the warranty does not apply.
Use of controls or adjustments or•
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
This unit is designed for negative ground•
(earth) 12 V DC operation only.
To reduce the risk of traffic accident, do•
no watch video during driving.
To ensure safe driving, adjust the volume•
to a safe and comfortable level.
Improper fuses can cause damage or•
fire. When you need to change the fuse,
consult a professional.
Use only the supplied mounting hardware•
for a safe and secure installation.
To avoid short circuit, do not expose the•
apparatus, remote control or remote
control batteries to rain or water.
Never insert objects into the ventilation•
slots or other openings on the apparatus.
Never place any objects other than discs•
into the disc tray/slot.
Visible and invisible laser radiation when•
open. Avoid exposure to beam.
Risk of damage to the screen! Never•
touch, push, rub or strike the screen with
any object.
Never use solvents such as benzene,•
thinner, cleaners available commercially,
or anti-static sprays intended for discs.
Clean the apparatus with soft, damp•
cloth. Never use substances such as
alcohol, chemicals or household cleaners
on the apparatus.
EN

5
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
2010 © Koninklijke Philips Electronics N.V. All
rights reserved.
Specifications are subject to change without
notice. Trademarks are the property of
Koninklijke Philips Electronics N.V. or their
respective owners. Philips reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
English
EN

6
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of your apparatus.The
model number and serial number are on the
bottom of your apparatus.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Install the car audio
These instructions are for a typical installation.
However, if your car has different requirements,
make the corresponding adjustment. If you have
any questions regarding installation kits, consult
your Philips car audio dealer.
Caution
This unit is designed for negative ground•
(earth) 12 V DC operation only.
Always install this unit in the car dashboard.•
Other locations can be dangerous as the rear
of the unit heats up during use.
To avoid short-circuit: before you connect,•
ensure that the ignition is off.
Ensure that you connect the yellow and red•
power supply leads after all other leads are
connected.
Ensure that all loose leads are insulated with•
electrical tape.
Ensure that the leads do not get caught under•
screws orin parts that will move (e.g. seat rail).
Ensure that all ground (earth) leads are run to•
a common ground (earth) point.
Use only the supplied mounting hardware for a•
safe and secure installation.
Improper fuses can cause damage or fire.•
When you need to change the fuse, consult a
professional.
Note on the power supply lead (yellow)
When you connect other devices to this•
apparatus, ensure that the rating of the
car circuit is higher than the total fuse
value of all the connected devices.
Notes on speaker connection
Never connect speaker wires to the•
metal body or chassis of the car.
Never connect speaker wires with stripes•
to one another.
2 Your car audio
system
Congratulations on your purchase, and
welcome to Philips!
To fully benefit from the support that Philips
offers, register your product at www.Philips.
com/welcome.
Read this user manual carefully before you
install and use the unit. Save it for future
reference.
Introduction
With the in-car audio system, you can enjoy
your drive while you listen to:
FM or AM (MW) radio•
Audio from a USB drive, a SD/SDHC•
card, external devices.
Music CDs•
DVD and VCD video•
What’s in the box
Caution
Use the controls only as stated in this user•
manual.
Registeryourproductandgetsupportat
www.philips.com/welcome
EN Usermanual
CED229
EN

7
aIllumination switch
bTo the +12V car battery which is
energized at all time
cMotor/electric antenna relay control
lead/ Amplifier relay control lead
dGround
eIgnition Key +12V DC when ON/
ACC
fAntenna
gAux-In
hParking Switch Cable
iReverse Driving Cable
jVideo-In
kCamera-In
lVideo-Out 1 and 2
mRear line-Out
nFront line-Out
Connect parking brake cable and
reverse driving cable to a rear view
backup camera
Note
Check your local driving regulations on•
whether it is legally required to install the
rear view backup camera. These connections
require a professional mechanic to install.
This car audio video system allows you to
connect to the rear view backup camera. You
can view the things that happens behind your
car in the display, especially you are driving a
big vehicle. This helps protecting your bumper
and anything it might contact.
Connect
Caution
Make sure that all bare wires are insulated with•
electrical tape.
Note
As different cars have different requirements,•
you might need to connect CED229 differently
from the user manual’s instructions. In that
case, consult a professional mechanic to
connect.
OR
1
2
3
4
5
++
++
--
--
12
11
10
67
8
9
mn
FR
FLRL
RR
1
2
3
4
5
English
EN

8
c
d
e
f
gReconnect the negative terminal of the
car battery.
Mount into dashboard
Note
For proper operation of the DVD player, the•
chassis must be mounted within 20 degree
horizontal. Ensure that the unit is mounted
within this limitation.
Caution
Keep the connection of the car battery if there•
is an on-board drive or navigation computer.
Otherwise, the computer may lost its memory.
To avoid short circuit, ensure the bare wires•
do not touch each other and disconnect the
negative terminal of the car battery.
a
b
183mm
53.5mm
EN

9
CR2025
CR2025
3V
CR2025
3V
Install remote control battery
Caution
Risk of explosion! Keep batteries away from•
heat, sunshine or fire. Never discard batteries
in fire.
Risk of decreased battery life! Never mix•
different brands or types of batteries.
Risk of product damage! When the remote•
control is not used for long periods, remove
the batteries.
Perchlorate Material - special handling may•
apply. See www.dtsc.ca.gov/hazardouswaste/
percholorate.
For first time use
To replace the remote control battery
2
1
English
EN

10
Mute
3 Get started
Turn on and turn off
Turn On
Turn Off
Press and hold the same power button for 3
seconds.
Adjust volume
EN

11
3To remove the disc, press the button.
When the disc is ejected, the»
unit switches to TUNER mode
automatically.
4Close the front panel.
After a few seconds, the screen»
illuminates.
For video discs, press• or to select
an item, then press to start playing.
For discs that contain MP3s, WMAs, or•
JPEGs, press or to select a folder,
track or picture. Press to start playing.
Tip
If the disc is blocked in the disc compartment,•
press and hold the button until the disc
comes out.
4 Play
Make sure that the disc or device contains
playable music or video.
Note
For CDs recorded in multiple sessions, only•
the first session is played.
Does not support MP3 Pro audio format.•
It may not support and display special•
characters track name (ID3) or album name
properly.
It cannot play some WMA is protected by•
Digital Rights Management (DRM).
The system does not display or play the folders•
or files that exceed the supporting limit.
Warning
To reduce the risk of traffic accident, do not•
watch video during driving.
Load and eject discs
1Press to open the front panel.
2Insert the disc into the disc slot with label
side facing up.
Play resumes from the point where it»
was last stopped.
English
EN

12
The unit starts playing from the SD/»
SDHC card automatically.
3To remove the SD or SDHC card, press
to turn off the unit.
4Press the card until you hear a click
sound.
The card is now disengaged.»
Skip/search
During video and audio disc play
To skip to a specified chapter or track,•
press the numeric buttons.
To skip to the previous or next chapter•
or track, press or .
Insert and remove USB
device
1Slide down the USB socket cover.
2Insert the USB device into the USB
socket.
The unit starts playing from the USB»
device automatically.
3To remove the USB device, press to
turn off the unit.
4Remove the USB device.
Insert and remove SD/MMC
card
1Press to open the front panel.
2Insert SD or SDHC card into the card
slot.
EN

13
Repeat play
There are 3 standard modes of repeat play for
video, audio, and MP3/WMA.
Press the button repeated to select.
• [REP ONE]: play the current chapter or
track repeatedly.
• [REP DIR]: play the current folder
repeatedly.
• [REP ALL]: play all chapters in the title or
all tracks repeatedly.
• [REP CANCEL]: cancel repeat play.
To search backward or forward quickly,•
press or for 3 seconds.
Press• to resume normal play.
During MP3/WMA play
To select a track, press• or to
select a folder. Press or to skip to
previous or next track.
To skip to a specified chapter or track,•
press the numeric buttons.
Intro play
This feature plays the first 10 seconds of each
audio track.
Press the button to select [INTRO
ON] or [INTRO OFF].
English
EN

14
You can select the audio language if the video
discs contain two or more audio channels.
During play, press on the remote control
repeatedly until the language is selected.
Dynamic Bass Boost
1Press / on the car audio
system for 3 seconds or press on
the remote control.
»[DBB ON]:The Dynamic Bass Boost
(DBB) function is on.
»[DBB OFF]:The DBB function is off.
2Press again to change the DBB
setting.
Random play
There are 3 standard modes of random play for
audio and MP3/WMA.
Press the button repeatedly to select.
• [SHUFFLE ALL]: start random play for all
tracks.
• [SHUFFLE DIR]: start random play in
current folder.
• [SHUFFLE OFF]: cancel random play.
Select Language
Subtitle
You can select the subtitle language if the DVD
or DivX discs contain two or more subtitle
languages.
During play, press on the remote
control repeatedly until the language is selected.
Audio
EN

15
MAX sound
1Press / to produce
an instant boost in bass and maximize
volume.
2Press / again to turn off.
Zoom
To zoom in and out of video images and
pictures:
1Press on the remote control
repeatedly.
»[ZOOM] is displayed.
2Press the navigation buttons to pan
across the display.
English
EN

16
Manual tune to a radio station
1Press .
2Press the navigation buttons to select
[RADIO], then press .
3Press and hold or to select band.
»[FM] or [AM] is display.
4Press or to tune to a radio station
manually.
5 Radio
Select tuner sensitivity
Before you start to search for radio station, you
can select tuner sensitivity.
1Press .
The main menu is displayed.»
2Press the navigation buttons to select
[RADIO], then press .
3Press to select [LOC/DX], then press
.
• [LOC]: only broadcast local stations
with strong signals.
• [DX]: broadcast any stations with
strong and weak signals.
4Press or buttons to select [LOC]
or[DX] , then press to confirm.
EN

17
Select the preset station
1Press and hold or to select band.
»[FM] or [AM] is display.
2Press the numeric button (1 to 6) to
select the preset station.
You may also press• or to select
the preset station.
Auto tune to a radio station
In [RADIO] mode, press and hold or
for 3 seconds.
Store stations manually
You can store up to 6 stations in each band.
1Tune to the station which you want to
store.
2Press and hold the numeric buttons (1 to
6) for 3 seconds.
Store stations automatically
You can store up to 6 stations in each band.
1Press .
The six strongest stations of the»
selected band are saved in preset
channels 1-6 automatically.
English
EN

18
Select stereo or mono
broadcasting
1Press .
The main menu is displayed.»
2Press the navigation buttons to select
[RADIO], then press .
3Press to select [STEREO/MONO],
then press .
4Press or buttons to select
[STEREO], [MIX MONO], [MONO L],
or [MONO R], then press to confirm.
EN

19
3Press or buttons to select the
general setting .
4Press , and then or to select the
sub-menus.
Select DVD video settings
You can adjust the settings for the video output
and the screen display.
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
The general settings menu is displayed»
6 System settings
Within system settings, there are:
General settings,•
DVD settings,•
Language settings, and•
Radio settings.•
Adjust general settings
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
The settings menu is displayed»
English
EN

20
Adjust radio settings
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
The settings menu is displayed»
3Press or buttons to select the radio
setting .
4Press , and then or button to
select [LOC/DX] or [STEREO/MONO].
3Press or buttons to select the DVD
setting .
4Press , and then or button to
select the sub-menus.
Select language settings
1Press .
2Press the navigation buttons to select
[SETTINGS], the press to confirm.
The settings menu is displayed»
3Press or buttons to select the
language setting .
4Press , and then or button to
adjust.
EN

21
2Press or to select one of the
preset equalizer settings.
3You can also select [USER], and then
press to confirm.
4Then, press or to select of [BASS]
and [TREBLE].
5Press or to adjust the values.
6Press to exit.
Control zone settings
1Press .
The current zone setting is displayed.»
2Press or to select one of the
preset zone settings:
• [ALL] - all speakers are in same
volume level.
• [LEFT] - front left speaker is louder
than the rest of the speakers.
• [RIGHT] - front right speaker is
louder than the rest of the speakers.
7 Other settings
Select equalizer settings
You can select preset equalizer settings, and
they are:
• [USER]
• [TECHNO]
• [ROCK]
• [CLASSIC]
• [JAZZ]
• [OPTIMAL]
• [FLAT]
• [POP]
Note
Only when you select• [USER], then you
can adjust the sound value of [BASS] and
[TREBLE] .
1Press .
The current equalizer setting is»
displayed.
English
EN
