Philips DC220/12 User manual

Register your product and get support at DC220
EN User manual

EN
1 Important
Safety
Important Safety Instructions
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
gDo not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
hDo not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
iProtect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
j Only use attachments/accessories specied by the
manufacturer.
kUse only with the cart, stand, tripod, bracket, or table
specied by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.

lUnplug this apparatus during lightning storms or when unused
for long periods of time.
m Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
nBattery usage CAUTION – To prevent battery leakage which
may result in bodily injury, property damage, or damage to
the unit:
Install all batteries correctly, + and - as marked on the unit.•
Do not mix batteries (old and new or carbon and alkaline,•
etc.).
Remove batteries when the unit is not used for a long time.•
The batteries shall not be exposed to excessive heat such as•
sunshine,reorthelike.
oApparatus shall not be exposed to dripping or splashing.
pDo not place any sources of danger on the apparatus (e.g.
liquid lled objects, lighted candles).
qThis product may contain lead and mercury. Disposal of
these materials may be regulated due to environmental
considerations. For disposal or recycling information, please
contact your local authorities or the Electronic Industries
Alliance: www.eiae.org.

rWhere the MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable.
Warning
Never remove the casing of this apparatus.•
Never lubricate any part of this apparatus.•
Never place this apparatus on other electrical equipment.•
Keepthisapparatusawayfromdirectsunlight,nakedamesorheat.•
Ensure that you always have easy access to the power cord, plug or•
adaptor to disconnect the apparatus from the power.
Notice
Anychangesormodicationsmadetothisdevicethatarenot
expressly approved by Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.
This product complies with the radio interference requirements of
the European Community.
Recycling
Your product is designed and manufactured with high quality
materials and components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a
product, it means the product is covered by the European Directive
2002/96/EC:

Never dispose of your product with other household waste. Please
inform yourself about the local rules on the separate collection of
electrical and electronic products. The correct disposal of your old
product helps prevent potentially negative consequences on the
environment and human health.
Your product contains batteries covered by the European Directive
2006/66/EC, which cannot be disposed of with normal household
waste.
Please inform yourself about the local rules on separate collection of
batteries. The correct disposal of batteries helps prevent potentially
negative consequences on the environment and human health.
Norge
Typeskiltnnespåapparatensunderside.
Observer: Nettbryteren er sekundert innkoplet. Den innebygde
netdelenerderforikkefrakopletnettetsålengeapparateter
tilsluttet nettkontakten.
Foråreduserefarenforbrannellerelektriskstøt,skalapparatetikke
utsettes for regn eller fuktighet.
Environmental information
All unnecessary packaging has been omitted. We have tried to make
the packaging easy to separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags, protective foam
sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local

regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Note
The type plate is located on the bottom of the apparatus.•
2 Your Clock Radio for iPhone/
iPod
Congratulations on your purchase, and welcome to Philips!To fully
benetfromthesupportthatPhilipsoffers,registeryourproductat
www.philips.com/welcome.
Introduction
With this unit, you can enjoy audio from the iPod, iPhone, other audio
devices, or the radio.
The radio, iPod, or iPhone can be set as the alarm timer.You can set two
alarm timers to go off at different time.
What’s in the box
Check and identify the contents of your package:
Main unit•
1 x AC power adaptor•
1 x MP3 LINK cable•
User manual•
Quick start guide•

Overview of the main unit
Top View
aPOWER
Turn on the unit or switch to standby mode.•
Deactivate the sleep timer.•
Stop alarm.•
b DATE • AUTO TUNE/TIME SET
Set the date and clock.•
Search and program radio stations automatically.•
cAL 1/AL 2
Set the alarm timer.•
Turn off the alarm tone.•
View alarm settings.•
REPEAT ALARM
BRIGHTNESS CONTROL
E
MULOV
TUNING
TUNING
SOURCESLEEPAL2
AL1
BBD
DOCK for
a b c d e
l jk i gh f

d/
Skiptotheprevious/nextaudiole.•
Searchwithinanaudiole.•
Select a preset radio station.•
Adjust time.•
eTUNING +/-
Tune to a radio station.•
Adjust time.•
fVOL +/-
Adjust volume.•
g
Start or pause iPod/iPhone play.•
hREPEAT ALARM/BRIGHTNESS CONTROL
Repeat the alarm.•
Adjust the display brightness.•
iiPod/iPhone dock
Load an iPod/iPhone.•
jDBB
Turn on or off dynamic bass enhancement.•
kSLEEP
Set the sleep timer.•
lSOURCE
Select a source: iPod/iPhone, FM tuner or AUX.•

Back View
mBackup battery compartment
Insert 2 pieces of AAA/R03/UM4, 1.5V batteries.•
nFM AERIAL
Improve FM reception.•
oMP3-LINK
Jack for an external audio device.•
pDC IN
Power supply socket.•
3 Get started
Caution
Use of controls or adjustments or performance of procedures other•
than herein may result in hazardous radiation exposure or other
unsafe operation.
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number
of this apparatus.The model number and serial number are on the
bottom of the apparatus.Write the numbers here:
Model No. __________________________
OPEN
MP3 LINK FM AERIAL
9V DC IN
n
o
m
p

Serial No. ___________________________
Connect power
Caution
Risk of product damage! Ensure that the power voltage corresponds•
to the voltage printed on the back or underside of the apparatus.
Risk of electric shock! When you unplug the AC adaptor, always pull
•
the plug from the socket. Never pull the cord.
Before connecting the AC adaptor, ensure you have completed all
•
other connections.
1Connect one end of the AC adaptor to the DC IN socket on
the main unit.
2Connect the other end of the AC adaptor to the wall outlet.
Note
The voltage and power rating information is located on the bottom•
of the unit.

Set time and date
1Dock the iPod / iPhone on the unit.
2Open the iPod / iPhone.
Time and date information on the iPod / iPhone transfers to»
the unit automatically.
To set time and date manually:
1In standby mode, press and hold DATE • AUTO TUNE/TIME
SET for 2 seconds.
[24 HR] begins to blink.»
2PressTUNING +/- or / to select 12/24 hour format.
3Press DATE • AUTO TUNE/TIME SETtoconrm.
The hour digits begin to blink.»
4Press TUNING +/- or / to set the hour.
5Press DATE • AUTO TUNE/TIME SETtoconrm.
The minute digits begin to blink.»
6Repeat steps 4-5 to set the minute, year, month, and day.
Turn on
1Press POWER.
The unit switches to the last selected source.»
Switch to standby
1Press POWER again to switch the unit to standby mode.
The time and date (if set) appear on the display panel.»

4 Play
Play from iPod/iPhone
You can enjoy audio from iPod/iPhone through this unit.
Compatible iPod/iPhone
Apple iPod and iPhone models with a 30-pin dock connector:
iPod classic, iPod touch, iPod nano, iPod 5th generation (video),•
iPod with color display, iPod mini.
iPhone, iPhone 3G, iPhone 3GS.•
Listen to the iPod/iPhone
1Place the iPod/iPhone into the dock.
2Press SOURCE repeatedly to select iPod/iPhone source.
The connected iPod/iPhone plays automatically.»
To pause/resume play, press• .
To skip to a track, press• / .
To search during play, press and hold• / , then release
to resume normal play.
Charge the iPod/iPhone
When the unit is connected to power, the docked iPod/iPhone
begins to charge.
Tip
For certain iPod models, it may take up to a minute before the•
charging indication appears.

Play from an external device
You can also listen to an external audio device through this unit.
1Press SOURCE repeatedly to select AUX source.
2Connect the supplied MP3 link cable to:
the• MP3 LINK jack (3.5mm) on the back of the unit.
the headphone jack on an external device.•
3Start to play the device (see the device user manual).
5 Listen to radio
Note
Only FM radio reception is available on this unit.•
Tune to a radio station
Tip
Position the antenna as far as possible from TV, VCR or other•
radiation source.
Note
For optimal reception, fully extend and adjust the position of the•
antenna.
1Press SOURCE to select FM.

2Press and hold TUNING +/- for more than 2 seconds.
[SRCH] (search) displays.»
The radio tunes to a station with strong reception»
automatically.
3Repeat step 2 to tune to more stations.
To tune to a weak station, press• TUNING +/- repeatedly
untilyoundoptimalreception.
Program radio stations automatically
You can program a maximum of 20 preset radio stations.
1In the tuner mode, press and hold DATE • AUTO TUNE/TIME
SET for more than 2 seconds to activate automatic program
mode.
[AUTO] (auto) displays.»
All available stations are programmed in the order of»
waveband reception strength.
Therstprogrammedradiostationisbroadcastautomatically.»
Program radio stations manually
You can program a maximum of 20 preset radio stations.
1Tune to a radio station.
2Press DATE • AUTO TUNE/TIME SET to activate the program
mode.
PR01 begins to blink.»
3Press DATE • AUTO TUNE/TIME SETtoconrm.
4Repeat the above steps to program other stations.

Tip
To overwrite a programmed station, store another station in its•
place.
Select a preset radio station
1Press / to select a preset program number.
6 Other features
Set the alarm timer
You can set two alarms which go off at different time.
1Ensure that you have set the clock correctly.
2Press and hold AL 1 or AL 2 for 2 seconds.
[AL 1] or [AL 2] begin to blink.»
3Press SOURCE repeatedly to select an alarm sound source:
iPod/iPhone, iPod/iPhone playlist, FM tuner, or buzzer.
4Press AL 1 or AL 2.
Hour digits begin to blink.»
5Press TUNING +/- or / repeatedly to set the hour.
6Press AL 1 or AL 2toconrm.
Minute digits begin to blink.»
7Repeat steps 5-6 to set the minute.
8Repeat steps 5-6 to select whether to ring alarm the whole
week, on weekdays, or at weekend.
9Repeat steps 5-6 to set the alarm volume.

Tip
Ifyouwanttowakeuptospecicmusictrack(s)oniPhone/iPod,•
after set iPhone/iPod playlist as the wake up source on the unit, you
need to create a playlist called ‘PHILIPS’ via iTunes and copy the
track(s) to this new ‘PHILIPS’ playlist.
If no playlist is created or there is no song in the playlist, the unit will
•
play the music track according to the last music playback preference
on iPhone/iPod.
Activate and deactivate the alarm timer
1Press AL 1 or AL 2 repeatedly to activate or deactivate the timer.
If the timer is activated, [»AL 1] or [ AL2] is displayed.
If the timer is deactivated,»before [AL1] or [AL2] disappears.
Gentle wake
Gentle wake function peacefully wakes you with gently ascending
alarm volume.
If selected the alarm source iPhone/iPod, iPhone/iPod playlist or•
FM, alarm volume will gentle increase.
If selected the alarm source Buzzer, the alarm will increases•
beep tone frequency within seconds.
Repeat alarm
1When the alarm rings, press BRIGHTNESS/REP ALM.
The alarm repeats ringing minutes later.»

Tip
You can press•/ to adjust the interval to repeat alarm.
Stop alarm ring
1When the alarm rings, press the corresponding AL 1 or AL 2.
The alarm stops but the alarm settings remain.»
View the alarm settings
1Press AL 1 or AL 2.
Backup Battery Mode
Under normal use, the unit should be powered through the AC adapter.
If the AC adapter is disconnected, the unit will automatically switch to
Backup Battery mode.
Under Backup Battery mode:
The unit displays the same as under the Standby mode, with•
backlight off.
Only the functions below are available:•
Clock•
Alarm•
Note
Alarm source is defaulted to ‘Buzzer’ under Backup Battery mode.•
When AC Power is plugged back, the unit will exit Backup Battery
mode and go to Standby mode.

Note
Under Backup Battery mode, the unit can work over 3 months.•
When the battery power is low, the display panel will indicate “bAtt Lo”•
until the batteries are empty and the unit will switch off automatically.
In this case, please replace the batteries in the backup battery
compartment with 2 pieces of new 1.5V, AAA/R03/UM4 batteries.
Install backup batteries
Caution
Riskofexplosion!Keepbatteriesawayfromheat,sunshineorre.•
Neverdiscardbatteriesinre.
Risk of product damage! When the apparatus is not used for long
•
periods, remove the battery.
1Open the battery compartment on the back of the unit.
2Insert 2 x 1.5V R03/UM-4/AAA batteries with correct polarity.
3Close the battery compartment.
Note
Batteries contain chemical substances, so they should be disposed•
of properly.

Set the sleep timer
This unit can switch to standby automatically after a set period of time.
Note
Make sure the time and date is set before setting the sleep timer.•
1Press SLEEP repeatedly to select a set period of time (in minutes).
The sleep timer is activated»
The display shows»
The volume starts to decrease gradually from the last 5»
minutes of sleep timer
The unit switches to standby when reaches the set time.»
To deactivate sleep timer
1Press SLEEP repeatedly until [OFF] displays.
»disappears on the display.
Adjust display brightness
1Press BRIGHTNESS/REP ALM repeatedly to select different
levels of display brightness.
7 Adjust sound
Adjust volume level
1During play, press VOL +/- to increase/decrease the volume level.

Enhance bass
1During play, press DBB to turn on or off dynamic bass
enhancement.
If DBB is activated, [DBB 1] is displayed.»
If DBB is de-activated, [DBB 0] is displayed.»
8 Product information
Note
Product information is subject to change without prior notice.•
Specications
Amplier
Rated Output Power 2 x 2.5 W RMS
Frequency Response 125 Hz - 16 kHz, ±3 dB
Signal to Noise Ratio >55 dB
MP3 link 500 mV RMS 10 kohm
