Philips HD7826/18 User manual

HD7826

1

HD7826
ENGLISH 6
DEUTSCH 33
FRANÇAIS (BELGIQUE) 62
NEDERLANDS 91

6
Table of contents
Introduction 6
Green coffee machine 7
SENSEO®coffee system 8
A clean machine with the new flushing and
descaling procedures 9
General description 9
Important 10
Compliance with standards 12
First use 12
Unpacking 12
Flushing the machine to fill the boiler 12
Brewing SENSEO®coffee 14
Tips for the best SENSEO®quality 14
Filling the water reservoir 15
Switching on the machine 15
Placing a pod holder 16
Placing one or two pods 16
Interrupting the brewing process 19
Switching off 19
Cleaning the machine 19
Cleaning the coffee machine 19
Flushing the coffee machine 21
Descaling (new procedure) 22
Descaling procedure 23
Frost-free storage 26
Replacement 26
Environment 26
Guarantee and service 26
Troubleshooting 27
Introduction
Congratulations on your purchase and welcome to
Philips!To fully benefit from the support that Philips
offers, register your product at
www.philips.com/welcome.
ENGLISH

Green coffee machine
Enjoy your favourite coffee in an eco-friendly way
with the uniquely designed SENSEO®Viva Café Eco.
Because half of its plastics are recycled and it saves
energy with its 5-minute auto shut-off function, this
is the most sustainable SENSEO®coffee machine
yet. Now you can enjoy the coffee you love, from
a stylish machine, while helping to protect the
environment.
Philips uses the latest technologies to create
products that are good for the environment,
in terms of material usage as well as energy
consumption.The Philips SENSEO®Viva Café Eco
coffee machine is made of 50% recycled plastics.
Recycled plastics are environment friendly because
they are derived from other products that are no
longer used.This production method results in
considerably less waste than the traditional method
of creating new parts.
At the end of the machine’s life, up to 90% of its
materials can be recycled thanks to its design and
the materials that were used to produce it.
This is a green product according to Philips’ own
requirements. Philips has committed itself to
continuously improving its performance in the green
focus areas: energy efficiency, packaging, hazardous
substances, weight, recycling, disposal and lifetime
reliability. For more information on this and other
environmental efforts by Philips, please visit
www.asimpleswitch.com
Because of the recycled materials used, there may
be some slight blemishes in the colour of the plastics.
Philips tries to ensure that these blemishes are not in
view on the nished product.
ENGLISH 7

SENSEO®coffee system
Make your coffee moments truly special with
SENSEO®.This unique system combines the
easy-to-use Philips SENSEO®coffee machine with
the specially developed Douwe Egberts SENSEO®
coffee pods, giving you a full, smooth coffee with a
delicious foam layer.
The Douwe Egberts coffee in convenient SENSEO®
coffee pods and Philips’ unique new SENSEO®
brewing system are perfectly matched to ensure that
the best taste and aroma are extracted from the
coffee.
To ensure a smooth and full coffee taste, you should
keep the following things in mind:
Fresh water
Use fresh water every day. If you have not used the
coffee machine for one day, you have to flush it with
fresh water before you use it again (see section
‘Flushing’ in chapter ‘Cleaning’).
Fresh coffee pods
Use the SENSEO®coffee pods that have been
specially developed by Douwe Egberts for your
SENSEO®coffee machine for a full, round taste.
The Douwe Egberts SENSEO®coffee pods stay
fresh longer if you store them in an airtight storage
container.
Discover all SENSEO®coffee blends that are
available at www.senseo.com.
A clean machine with the new flushing and
descaling procedures
Note: Philips has improved the ushing and descaling
procedures. See chapters ‘Cleaning’ and ‘Descaling’ for
the new procedures.
ENGLISH8

Clean and descale your Philips SENSEO®coffee
machine regularly.
- Remove used coffee pods after brewing. If a used
pod has been left in the coffee machine and you
have not used the machine for some time, flush
the machine before you use it again (see section
‘Flushing’ in chapter ‘Cleaning’).
- If you have not used the coffee machine for one
day, you have to flush the machine with fresh
water before you use the machine again (see
section ‘Flushing’ in chapter ‘Cleaning’).
- Descale the SENSEO®coffee machine as
described in chapter ‘Descaling’ when the
CALC light goes on (after you have brewed
approx. 400 cups of SENSEO®coffee).You can
also descale the SENSEO®coffee machine more
often (every 3 months) in the same way. Descaling
takes 20 to 30 minutes. Do not interrupt the
descaling process.
General description (Fig. 1)
A Water reservoir
B Water reservoir cover
C Sealing ring
D Water distribution disc
E CALC light
F 1-cup button q
G On/off button with light ring
H 2-cup button qq
I Drip tray
J Cup tray
K Coffee spout
L Cover of coffee spout
M Coffee collector
N 2-cup pod holder qq
O 1-cup pod holder q
ENGLISH 9

Important
Read this user manual carefully before you use the
machine and save it for future reference.
Danger
- Never immerse the machine in water or any
other liquid.
Warning
- Check if the voltage indicated on the bottom
of the machine corresponds to the local mains
voltage before you connect the machine.
- This machine is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
machine by a person responsible for their safety.
- Children should be supervised to ensure that they
do not play with the machine.
- Do not use the machine if the plug, the mains
cord or the machine itself is damaged.
- If the mains cord is damaged, you must have it
replaced by Philips, a service centre authorised by
Philips or similarly qualified persons in order to
avoid a hazard.
Caution
- Always return the machine to a service centre
authorised by Philips for examination or repair.
Do not attempt to repair the machine yourself,
otherwise your guarantee becomes invalid.
- Never put normal ground coffee or use torn
pods in the SENSEO®machine, as this causes it to
become blocked.
- Do not use the machine in combination with a
transformer, as this could cause hazardous situations.
ENGLISH10

- Always put the machine on a flat and stable surface.
- Never let the machine operate unattended.
- Do not use the machine at altitudes higher than
2200 metres above sea level.
- The machine does not work at temperatures
below 10°C.
- Flush the coffee machine with fresh water before
you use it for the first time (see chapter ‘Before
first use’).This causes the boiler to fill with water,
which is essential for the machine to work
properly.
- Do not use the SENSEO®machine in
combination with water softeners based on
sodium exchange.
- Philips strongly advises you to descale this
SENSEO®machine every 3 months. If the
machine is not descaled in time and according to
the procedure described in chapter ‘Descaling’,
this may lead to technical failures.
- Never interrupt the descaling process.
- Never use a descaling agent based on mineral
acids such as sulphuric acid, hydrochloric acid,
sulphamic acid and acetic acid (e.g. vinegar).These
descaling agents may damage your SENSEO®
coffee machine.
- After unpacking the machine, never put your
SENSEO®machine on its side.Always keep it in
upright position, also during transport.
- This machine is intended for normal household
use only. It is not intended for use in environments
such as staff kitchens of shops, offices, farms or
other work environments. Nor is it intended
to be used by clients in hotels, motels, bed and
breakfasts and other residential environments.
ENGLISH 11

Compliance with standards
This machine complies with all standards regarding
electromagnetic fields (EMF). If handled properly and
according to the instructions in this user manual, the
machine is safe to use based on scientific evidence
available today.
The energy consumption of this machine in off
mode is less than 1 watt.This means that this
machine complies with European Directive 2005/32/
EC, which sets the ecological design requirements
for energy-using products.
First use
Unpacking
1 Remove the machine from the box.
Note: Make sure you store the 2-cup pod holder in a
safe place. It is an essential part of the machine.
Flushing the machine to fill the boiler
YOU CANNOT BREW COFFEE IFYOU
HAVE NOT FLUSHED THE SENSEO®COFFEE
MACHINE FIRST!
The flushing cycle causes the boiler to be filled with
water. After this, the coffee machine is ready for use.
Flush the machine in the following way:
1 Remove the water reservoir.
ENGLISH12

2 Fill the water reservoir with water up to the
MAX indication.
3 Put the water reservoir back.
4 Place a bowl with a capacity of at least 1.5
litres on the cup tray.
5 Make sure a pod holder, without pod or pods,
is in place.
6 Put the plug in an earthed wall socket.
7 Press the on/off button 3.
The light ring around the on/off button lights up to
indicate that you have to flush the machine.
ENGLISH 13

8 To start flushing, press the 1-cup button qand
the 2-cup button qq briefly at the same time.
Never interrupt the flushing cycle halfway. If you
do, the boiler does not fill itself properly.
,The light ring around the on/off button starts
flashing to indicate that the flushing cycle has
started.The flushing cycle takes approx. 1.5 to
2.5 minutes.
,During the flushing cycle, the boiler fills itself
with water from the water reservoir and cold
water comes out of the coffee spout. During the
flushing cycle, the machine produces more noise
than during a regular brewing cycle.
,When all the water in the water reservoir has
been used up, the flushing cycle is finished and
the machine switches off.
Now your Philips SENSEO®coffee machine
is ready for use.
Note: If the machine does not work, repeat steps 1-8.
Do not interrupt the ushing cycle.
Brewing SENSEO®coffee
Tips for the best SENSEO®quality
- Use fresh water every time.
- Use the SENSEO®coffee pods that have been
specially developed by Douwe Egberts for your
SENSEO®coffee machine for a full, round taste.
The Douwe Egberts SENSEO®coffee pods
stay fresh longer if you store them in an airtight
storage container.
- To make sure that the coffee always tastes
optimally, rinse the pod holders, the coffee
collector and the coffee spout regularly.
ENGLISH14

- The SENSEO®coffee tastes best if you stir it
before you drink it.
- If you have not used the coffee machine for
some time, flush the machine before you use it
again (see section ‘Flushing the coffee machine’ in
chapter ‘Cleaning the machine’) with fresh water
before you use it again.
- If you intend to make another cup of SENSEO®
coffee later, just leave the coffee machine switched
on.The machine automatically switches off after
5 minutes.
Filling the water reservoir
1 Fill the water reservoir with cold water up to
the MAX indication and put it back onto the
machine.
Never pour milk, coffee, hot water or carbonated
water into the water reservoir.
The MIN indication on the water reservoir
indicated the minimum amount of water required
for brewing coffee.Always fill the water reservoir
beyond the MIN level.
Switching on the machine
1 Put the plug in an earthed wall socket.
2 Press the on/off button 3.
,The light ring flashes slowly while the water
heats up. Heating up takes approx. 75 seconds.
,The coffee machine is ready for use when
the light ring lights up continuously.
Note: If the light ring ashes rapidly, the water reservoir
does not contain enough water for brewing one cup
of coffee.
ENGLISH 15

Placing a pod holder
1 Release the lid by moving the lever upwards.
,The lid opens automatically.
2 Place the appropriate pod holder in the
machine.
Note: Make sure the pod holder is clean and the
sieve in the centre is not clogged, e.g. with loose coffee
grounds.
- If you want to make one cup of SENSEO®coffee,
use 1 coffee pod in combination with the 1-cup
pod holder qand the 1- cup button q.
- If you want to make two cups of SENSEO ®
coffee, use 2 coffee pods in combination with
the deeper 2-cup pod holder qq and the 2-cup
button qq.
Placing one or two pods
1 Place the SENSEO®coffee pod(s) properly in
the centre of the pod holder, with the convex
side pointing downwards.
Note: Use SENSEO®coffee pods from Douwe Egberts
specially designed for your SENSEO®coffee machine
for a full and round taste.
ENGLISH16

Note: Make sure the coffee in the pod(s) is evenly
distributed and press the pod(s) lightly into the
pod holder.
Note: Never put normal ground coffee or use torn
pods in the SENSEO®machine, as this causes it to
become blocked.
- Place 1 SENSEO®coffee pod in the 1-cup pod
holder q.
- Place 2 SENSEO®coffee pods in the 2-cup pod
holder qq.
2 Close the lid and lock the lever.
It is not possible to brew coffee when the lid is not
properly closed and the lid lever is not locked. In
this case, the light ring around the on/off button
flashes intermittently
3 Place one cup or two cups under the
spout openings.You can adjust the height
of the coffee spout by sliding it upwards or
downwards.
The cups you use should have a capacity of at least
150 ml. Do not use cups that are too large, as
they cause the coffee to get cold more quickly.
ENGLISH 17

4 Press the button indicating the number of cups
of SENSEO®coffee you want to brew.
- Press the 1-cup button qfor one cup.
- Press the 2-cup button qq for two cups.
The SENSEO®coffee machine starts
brewing.
- The machine automatically supplies the optimal
amount of water.
- You can interrupt the brewing process at any time
by pressing the on/off button 3. If you switch
the machine back on after having interrupted the
brewing process, the machine does not complete
the interrupted brewing cycle.
Do not remove the water reservoir during a
brewing cycle, as this causes the machine to
draw in air.When this happens, the next cup is
only partly filled.
Note: If no coffee comes out of the machine, you have
not ushed the machine before rst use. As a result,
the boiler is not lled. Flush the machine as described
in chapter ‘Before rst use’ before you start brewing
coffee. If only a small amount of coffee comes out of
the machine, ush the machine as described in section
‘Flushing’ in chapter ‘Cleaning’ before you brew another
cup of coffee.
5 Remove the coffee pod(s) after use by lifting
the pod holder out of the machine and
emptying it.
Be careful when you do this, for there may still be
some water/coffee on the coffee pod(s).
ENGLISH18

Interrupting the brewing process
1 Press the on/off button 3to interrupt the
brewing process.
Note: If you switch the machine back on after you have
interrupted the brewing process, the machine does not
complete the interrupted brewing cycle.
Switching off
1 After use, press the on/off button 3to switch
off the machine.
Note: If you do not use the machine, it switches off
automatically after 5 minutes, for energy saving.
Cleaning the machine
Never immerse the SENSEO®coffee machine in
water.
Cleaning the coffee machine
1 Always unplug the machine before you clean it.
2 Clean the outside of the machine with a moist
cloth.
3 Remove the coffee collector.
4 Take the coffee spout out of the machine by
sliding it upwards.
Note:You can only remove the coffee spout after you
have removed the coffee collector.
ENGLISH 19

5 Disassemble the coffee spout if you want to
clean it more thoroughly.
6 Clean the coffee spout, the coffee collector
and the drip tray in hot water, if necessary with
some washing-up liquid, or in the dishwasher.
7 Hold the cup tray in your hand while you
clean it with hot water. If necessary, use some
washing-up liquid.
The cup tray can also be cleaned in the dishwasher.
To clean the cup tray, always remove it from the
machine, as it might prove sharp when handled
incorrectly.Always handle it carefully.
8 Clean the pod holders in hot water, if
necessary with some washing-up liquid, or in
the dishwasher.
Check if the sieve in the centre of the pod holder is
clogged. If this is the case, unclog the sieve by rinsing
the pod holder under a running tap. If necessary, use
a washing-up brush to clean the sieve.
9 Clean the water reservoir in hot water, if
necessary with some washing-up liquid, or in
the dishwasher.
Note: If you use a washing-up brush, be careful not to
damage the valve in the bottom of the water reservoir.
Remove the water reservoir cover for easier cleaning.
ENGLISH20
