Philips DVD-Video/SACD Changer DVD920
DVD SA SA920
Progressive Scan SACD
PICTURE QUALITY
• 27 Mhz/10bit video processing
• High Quality Progressive Scan with DCDi
• Parallel Component, S-Video & Composite Video outputs
SOUND QUALITY
• Built-in DSD, Dolby Digital and DTS decoders
•CD upsampling to 176.4Khz/24bit
•SACD advanced bass management for optimized bass response
•3D sound: surround sound for stereo systems
•Optical and coaxial digital audio output
(Dolby Digital, DTS, MPEG2 and PCM)
GREAT CONVENIENCE
•Plays DVD-Video, SACD, CD, CD-R/RW, MP3-CD,VCD and S-VCD
•SACD/CD text
•5 disc DVD/CD Changer
•Play exchange/Smart Play
•Bit Rate Indicator
•5 disc resume/120 disc lock enhanced parental control
AUDIO
upsampling
108 MHz
8 x
oversampling
Video Processing

Playback system
• SACD multi-channel
• SACD Stereo
• DVD-Video
• Video CD (VCD)
• S-Video CD (SVCD)
• MP3-CD
• CD (CD-R and CD-RW)1
• DVD+RW
Optical read-out system
• Laser type Semiconductor AlGaAs
• Numerical Aperture 0.60 (DVD)
0.45 (VCD/SVCD/CD)
• Wavelength 650 nm (DVD)
780 nm (VCD/SVCD/CD)
DVD disc format
• Medium Optical disc
• Diameter 12 cm (8 cm)
• Playing time One layer 2.15 h2
(12cm) Dual layer 4 h2
Two side, single layer 4.30 h2
Two side, dual layer 8 h2
TV standard PAL NTSC
50 Hz 60Hz
• Number of lines 625 525
• Playback Multi-standard (PAL/NTSC)
Audio format
• Digital DSD Uncompressed
digital
MPEG/ Dolby Compressed digital,
Digital/DTS/PCM 16, 20, 24 bits
fs, 44.1, 48, 96 kHz
MP3 (ISO 9660) 96,112, 128, 256kbps
and variable bit rate
fs 32,44.1, 48kHz
• Full decoding of Dolby Digital and DTS
multi-channel sound
• Analog Sound Stereo
• Dolby surround compatible downmix from
Dolby Digital multi-channel sound
• 3D Sound for virtual 5.1 channel sound on
2 speakers
Video format
• Digital compression MPEG 2 for DVD, SVCD
MPEG 1 for VCD
DVD 50Hz 60Hz
Horiz. resolution 720 pixels 720 pixels
Vertical resolution 576 lines 480 lines
VCD 50Hz 60Hz
Horiz. resolution 352 pixels 352 pixels
Vertical resolution 288 lines 240 lines
DVD-Video player/SACD Changer
UPC Not yet available
Package contents
• DVD-video player
• Remote control with batteries
• User manual
• Video cable/Audio cable
General functionality
• Stop/ play/ pause
• Fast forward/ backward
• Step forward/ backward
• Slow motion
• Title/ chapter/ track select
• Skip next/ skip previous
• Repeat (Chapter/ title/ all) or (Track/ all)
• A-B repeat, Shuffle & Scan
• Zoom (x1.33, x2, x4) with picture enhancement
• 3D sound
• 5.1 Channels user defined speaker settings
• Virtual Jog Shuttle
• Enhanced smart picture with Monitor type selector
• SACD/CD Text
• Resume (5 disc) after stop / standby3
• Parental Control and Disc lock (120 disc)
• NTSC/PAL conversion
• Smart power off for better energy saving
• SACD bass management
• Audio Upsampling
• Progressive Scan with DCDi
• 5-disc changer
DVD functionality
• Multi-angle selection
• Audio selection (1 out of max. 8 languages)
• Subtitles selection (1 out of max. 32 languages)
• Aspect ratio conversion (16:9,4:3 letterbox,
4:3 Pan Scan)
• Disc Menu support (title menu and root menu)
Video CD, SVCD functionality
• Playback control forVCD 2.0 discs and SVCD
• Audio Selection (1 out of max. 4 languages)
for SVCD
MP3 functionality
• Time display (Track)
• Album and track selection
• Repeat (disc/album/ track)
• Nested directory levels supported to 8 levels
• Max. albums possible is 32
• Max. number of tracks is 999
1 Applicable for finalized multi-session discs also.
2 Typical playing time for movie with 2 spoken
languages and 3 subtitle languages.
3 Applicable only for DVD,VCD, SVCD discs
SACD audio performance
D/A converter DSD
SACD: fs 2.8224Mhz DC - 100kHz
Max. output 2V rms
voltage (OdB)
Channel unbalance <0.5 dB
Cut-off frequency 40kHz
• Signal-Noise (1kHz) 105 dB
• Dynamic Range (1kHz) 105 dB
• Crosstalk (1kHz) 105 dB
• Total harmonic distortion (1kHz) 97 dB
Audio performance (Without upsampling)
• D/A converter 24 bits
DVD Fs 96 kHz 4 Hz- 44 kHz
Fs 48 kHz 4 Hz- 22 kHz
CD/Video CD Fs 44.1 kHz 4 Hz- 20 kHz
S-Video CD Fs 48 kHz 4 Hz- 22 kHz
Fs 44.1 kHz 4 Hz- 20 kHz
• Signal-Noise (1kHz) 100 dB
• Dynamic Range (1kHz) 95 dB
• Crosstalk (1kHz) 105 dB
• Total harmonic distortion (1kHz) 97 dB
Video performance
• YUV output Y: 1 Vpp into 75 ohm
CrCb: 0.7Vpp into 75 ohm
• S-Video Output Y: 1 Vpp into 75 ohm
C: 0.3 Vpp into 75 ohm
• Video output 1 Vpp into 75 ohm
• Black Level Shift On/off
• Video Shift Left/right
Connections
• Y,Cb,Cr output (480i/p) Cinch 3x (green, blue,red)
• S-Video output Mini DIN, 4 pins
• Video Output Cinch (yellow) 2x
• Audio L+R output Cinch (white/red)
• Digital Output 1 coaxial, 1 optical
IEC958 for CDDA / LPCM
IEC1937 for MPEG1/2,
Dolby Digital, DTS
6 Channel analog output
• Audio Front L/R Cinch (white/red)
• Audio Surround L/R Cinch (white/red)
• Audio Centre Cinch (blue)
• Audio Subwoofer Cinch (black)
Power supply
• Power inlet 110V, 60 Hz
• Power usage Approx. 20 watt
• Power usage standby Less than 4 watt
Product
• Dimension 17 x 4.5 x 16.3 inches
(w x h x d)
• Weight Approx. 9.25 lbs
Carton
• Dimension 20.6 x 6.2 x 17.4 inches
(w x h x d)
• Weight Approx. 11.2 lbs
Technical specifications DVD 920SA
DVD920
DVD SA SA920
Printed in USA © 2002 Philips Consumer Electronics A Division of
Philips Electronics North America Corp. http://www.philips.com
Specifications subject to change without notice.The products and services
described here will not necessarily become available in the market.
This document contains preliminary information. All rights reserved.
DVD920SA-USA
Dolby and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.DTS is a registered trademark of DigitalTheater Systems, Inc.
