Philips DVP3990 User manual

gInstruction…………………………………………………...................2-1
g
g
gRevision List………………………………………..….....…................5-1
This simple Service Manual is for " Exchange" Scenario
TABLE OF CONTENTS
Page
Version 1.0
Service Manual
PHILIPS
GB
©
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
CLASS 1
LASER PRODUCT
Service
DVD Player
Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
Software Upgrade .............................................................................3-1
Accessory list...............................................................................................4-1
Published by LLL - 1224BU AVM Printed in The Netherlands Subject to modification
3141 785 38220
DVP3990
DVP3990/05/12/58/51

How to remove the CD manually from the tray
I. Power off the DVD player.
II. Please gently push the guider and wait until the tray comes out (Figure1).
2-1
Figure 1
1. Please do as below instruction in case the tray can not be open:

Software upgrade
Preparation to upgrade software
1) Start the CD Burning software and create a new CD
project (Data Disc) with the following setting: B. Read out the software versions to confirm upgrading
Label: DVP3XXX (No need the label name)
File Name: DVPXXXX_XX.BIN 1) Power on the set and press <Setup> button on the
Power on the set and open the tray, then press <option> remote control.
to check the File Name. 2) Press <Next><Next><Prev><Prev> button.
The software version and other information are display
Note: It is required capital letter for the File System on the TV screen as follows:
name. Version XX.XX.XX.XX (Main version)
2) Burn the data onto a blank CDR SUB-VER XX.XX.XX.XX (software version of
application software)
A. Procedure for software upgrade: 8032 XX.XX.XX.XX
1) Power on the set and insert the prepared Upgrade Servo XX.XX.XX.XX (software version of servo)
CDR. RIS XX.XX.XX.XX
2) The set will starts reading disc & response with the DSP XX.XX.XX.XX
following display TV screen: Region Code X
Upgrade File DETECTED
Upgrade?
Press Play TO START.
3) Press <OK> button to confirm, then screen will display :
Files coping… Caution: The set must not be power off during
UPGRADING… upgrading, Otherwise the Main board will be
4) The upgraded tray will automatically open when files damaged entirely.
coping complete, then take out the disc.
5) About 1 minute later, the trace will automatically close
when upgrading complete.
3-1

Item No. 12NC No. Description
Accessories Spare Parts List
4-1
RC 996510040711 Remote control for DVP3990/05/12/58/51

5-1
Revision List
Version 1.0

γ
Initial Release for DVP3990/05/12/58/51
