Philips DVP5500S User manual

02(A)_8239 300 34351
DVD VIDEOPLAYER DVP5500S
DVP5505S
Usermanual
Thank you for choosing Philips.
Need help fast?
ReadyourUser’sManualfirstforquicktipsthatmakeusing
yourPhilipsproductmoreenjoyable.
Ifyouhavereadyourinstructionsandstillneedassistance,
youmayaccessouronlinehelpatwww.philips.com/support
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM1

02(A)_8239 300 34351
Important notes for users in the
U.K.
Mains plug
This apparatus is fitted with an approved 13
Amp plug. To change a fuse in this type of plug
proceed as follows:
1Remove fuse cover and fuse.
2Fix new fuse which should be a BS1362 5 Amp,
A.S.T.A.or BSI approved type.
3Refit the fuse cover.
If the fitted plug is not suitable for your jack
outlets,it should be cut off and an appropriate
plug fitted in its place.
If the mains plug contains a fuse, this should
have a value of 5Amp.If a plug without a fuse
is used,the fuse at the distribution board
should not be greater than 5 Amp.
Note: The severed plug must be disposed to
avoid a possible shock hazard should it be
inserted into a 13 Amp jack elsewhere.
How to connect a plug
The wires in the mains lead are coloured with
the following code:blue = neutral (N),
brown = live (L).
¶As these colours may not correspond with the
colour markings identifying the terminals in
your plug,proceed as follows:
– Connect the blue wire to the terminal
marked N or coloured black.
– Connect the brown wire to the terminal
marked L or coloured red.
– Do not connect either wire to the earth
terminal in the plug, marked E (or e) or
coloured green (or green and yellow).
Before replacing the plug cover,make certain
that the cord grip is clamped over the sheath
of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may
require consent.See Copyright Act 1956 and
The Performer’s Protection Acts 1958 to 1972.
CAUTION
Use of controls or adjustments or
performance of procedures other
than herein may result in hazardous
radiation exposure or other unsafe
operation.
VAROITUS
Muiden kuin tässä esitettyjen
toimintojen säädön tai asetusten
muutto saattaa altistaa vaaralliselle
säteilylle tai muille vaarallisille
toiminnoille.
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM2

02(A)_8239 300 34351
DK
Advarsel: Usynlig laserstråling ved
åbning når sikkerhedsafbrydere er ude
af funktion. Undgå utsættelse for
stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen
fra nettet. Den indbyggede netdel er
derfor tilsluttet til lysnettet så længe
netstikket sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på
annat sätt än i denna bruksanvisning
specificerats, kan användaren utsättas
för osynlig laserstrålning, som
överskrider gränsen för laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är
därför ansluten till elnätet så länge
stickproppen sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen muulla
kuin tässä käyttöohjeessa mainitulla
tavalla saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei
saa olla alttiina tippu-ja roiskevedelle.
Huom.Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu
verkko-osa on kytkettynä
sähköverkkoon aina silloin, kun pistoke
on pistorasiassa.
‘CONSUMERS SHOULD NOTETHAT NOT
ALL HIGH DEFINITIONTELEVISION SETS
ARE FULLY COMPATIBLEWITHTHIS
PRODUCTAND MAY CAUSEARTIFACTS
TO BE DISPLAYED INTHE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN
PICTURE PROBLEMS,IT IS RECOMMENDED
THATTHE USER SWITCHTHE
CONNECTIONTOTHE‘STANDARD
DEFINITION’ OUTPUT. IFTHEREARE
QUESTIONS REGARDING OURTV SET
COMPATIBILITYWITHTHIS MODEL 525p
AND 625p DVD PLAYER,PLEASE CONTACT
OUR CUSTOMER SERVICE CENTER.’
The apparatus shall not be exposed to dripping
or splashing and no objects filled with liquids,
such as vases,shall be placed on apparatus.
Due to the inconsistency of disc formats
provided by various disc manufacturers,your
DVD system may require a playability
enhancement or upgrade. As DVD technology
advances, these enhancements will become
common and will be easy to complete.
Go to www.philips.com/support for
software upgrade.
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM3

02(A)_8239 300 34351
General Information
CAUTION
(WARNING LOCATION:ONTHE
BACKPLATE OFTHE SET)
NEVER MAKE OR CHANGE
CONNECTIONSWITHTHE
POWER SWITCHED ON.
This DVD player is in conformity
with the EMC directive and low-
voltage directive.
Manufactured under license from Dolby
Laboratories.“Dolby”,“Pro Logic”and the
double-D symbol are trademarks of Dolby
Laboratories.
Laser safety
This unit employs a laser.Due to possible
eye injury,only a qualified service person
should remove the cover or attempt to
service this device.
NOTE:
PICTURES SHOWN MAYBE
DIFFERENT BETWEEN
COUNTRIES.
LASER
Type Semiconductor laser
GaAlAs
Wave length 650 nm (DVD)
780 nm (VCD/CD)
Output Power 7 mW (DVD)
10 mW (VCD/CD)
Beam divergence 60 degree
For Customer Use:
Read carefully the information located at
the rear of your DVDVIDEO player and
enter below the Serial No.Retain this
information for future reference.
Model No.DVP 5500S / DVP 5505S
Serial No. _______________
Environmental Information
All unnecessary packaging has been
omitted.The packaging has been made
easy to separate into two materials:
cardboard (box,buffer) and polyethylene
(bags,protective foam sheet).
Your DVD player consists of materials
which can be recycled and reused if
disassembled by a specialised company.
Please observe the local regulations
regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Important Note:
Due to the numerous versions of new
CD-Audio copy protection or
enhanced CD-Audio protection
recently available on certain discs,
Philips is unable to guarantee that
this DVD Player is fully compatible
with such new discs. Should you have
difficulty playing any such CD-Audio
discs, kindly refer them to your CD-
Audio disc retailer.
DivX, DivX Certified, and
associated logos are
trademarks of
DivXNetworks, Inc and
are used under license.
“DTS”,and“DTS Digital Surround” are
registered trademarks of DigitalTheater
Systems,Inc.
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM4

02(A)_8239 300 34351
English
Français
Deutsch
Español
5
Italiano
Swedish
Dansk
Index
CAUTION
VISIBLEAND INVISIBLE LASER
RADIATIONWHEN OPEN.
AVOID EXPOSURETO BEAM.
ADVARSEL
SYNLIG OG USYNLIG
LASERSTRÅLINGVED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÅLING
VARNING
SYNLIG OCH OSYNLIG
LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD BETRAKTA EJ STRÅLEN
VARO!
AVATTAESSA OLETALTTIINA
NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE
LASER SÄTEILYLLE.ÄLÄ KATSO
SÄTEESEEN
VORSICHT
GEFAHRVON SICHTBARER UND
UNSICHTBARER LASERSTRAHLUNG
BEI GEÖFFNETEM GEHÄUSE.
ATTENTION
RAYONNEMENT LASERVISIBLE ET
INVISIBLE EN CAS D’OUVERTURE
EXPOSITION DANGEREUSEAU
FAISCEAU
English --------------------------------------- 6
Français------------------------------------ 42
Deutsch------------------------------------ 78
Español -----------------------------------114
Italiano------------------------------------150
Swedish -----------------------------------186
Dansk--------------------------------------222
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM5

02(A)_8239 300 34351
English
6
Introduction
Supplied accessories ....................................... 8
Care and safety information..........................8
Connections
ConnectingTV............................................ 9-10
Using SCART jack........................................... 9
Using CompositeVideo jacks (CVBS)........ 9
Using ComponentVideo jacks (Pr PbY) . 10
Using an accessory RF modulator ............10
Connecting the power cord........................11
Optional: Connecting to a Multi-channel
Receiver ...........................................................11
Receiver has a Dolby Digital or DTS
decoder........................................................... 11
Optional :Connecting to anAudio System .
...........................................................................12
Stereo system has Dolby Pro Logic or Right
/ LeftAudio In jack ....................................... 12
Optional:Connecting DigitalAV Receiver ...
...........................................................................12
Receiver has a PCM,Dolby Digital,or
MPEG2 decoder............................................ 12
Functional Overview
Front and Rear Panels ..................................13
Remote Control ............................................14
Getting Started
Step 1:Inserting batteries into the
Remote Control ............................................15
Using the Remote Control to operate the
Player ...............................................................15
Step 2:Setting up theTV........................15-17
Setting up Progressive Scan feature (for
Progressive ScanTV only)........................... 16
To deactivate Progressive manually .......... 17
Selecting the colour system that
corresponds to yourTV.............................. 17
Step 3:Setting language preference ...........18
Setting the OSD Language.......................... 18
Setting theAudio,Subtitle and Disc menu
language .......................................................... 18
Disc Operations
Playable Discs .................................................19
Region Codes .................................................19
Playing discs.....................................................19
Basic playback controls.................................20
Selecting various repeat/shuffle functions 20
Repeat play mode .........................................20
Repeating a section within a chapter/track .
......................................................................... 20
Operations for video playback ...................21
Using the Disc Menu.................................... 21
Zooming in..................................................... 21
Resuming playback from the last stopped
point ................................................................ 21
Slow motion................................................... 21
Using the OSD menu .................................. 21
Special DVD features....................................22
Playing aTitle ................................................. 22
CameraAngle ................................................ 22
Changing theAudio Language.................... 22
Subtitles ..........................................................22
SpecialVCD & SVCD Features.............22-23
Playback Control (PBC) .............................. 22
Preview .................................................... 22-23
Playing SuperAudio CD (SACD) ...............23
Playing DivX disc ...........................................23
Playing MP3/WMA/MPEG-4/JPEG/Kodak
Picture CD ......................................................24
General Operation.......................................24
Selecting a folder and track/file .................24
Special picture disc features ........................25
Preview Function .......................................... 25
Zoom picture ................................................ 25
Playback with multi-angles .......................... 25
Scan Effect ......................................................25
Playing MP3/WMA music and JPEG picture
simultaneously ...............................................25
Contents
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM6

02(A)_8239 300 34351
English
7
DVD Menu Options
General Setup menu ...............................26-27
Locking/Unlocking the disc for viewing... 26
Dimming system’s display screen .............. 26
Programming disc tracks.......................26-27
OSD Language............................................... 27
Screen Saver - turning on/off .....................27
Sleep ................................................................ 27
DivXVOD registration code ..................... 27
Audio Setup Menu...................................28-29
Analogue output ........................................... 28
DigitalAudio Setup....................................... 28
Sound Mode................................................... 29
Speaker setup ................................................ 29
CD Upsampling ............................................. 29
Night Mode - turning on/off....................... 29
Video Setup Menu ...................................30-32
TVType ........................................................... 30
Setting theTV Display .................................30
Progressive - turning on/off........................ 31
Picture Setting ........................................ 31-32
Switching theYUV/RGB .............................. 32
Preference Page........................................33-35
Audio,Subtitle, Disc Menu.......................... 33
Restricting playback by Parental Control.....
.................................................................. 33-34
PBC .................................................................. 34
MP3/JPEG Menu - turning on/off............... 34
Changing the Password ...............................35
Setting the DivX Subtitle font ................... 35
Restoring to original settings..................... 35
Sound andVolume Controls
Setting the speakers’ channels....................36
Selecting surround sound ............................37
Selecting digital sound effects .....................37
Volume control ..............................................37
Troubleshooting ......................... 38–39
Specifications ......................................40
Glossary......................................................................41
Contents
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM7

02(A)_8239 300 34351
English
8
Supplied accessories
Remote Control
and
twoAA batteries
Introduction
Care and safety information
●Power consumption
– When the system is switched to
Standby mode,it is still consuming power.
To disconnect the system from the power
supply completely,remove theAC power
plug from the wall jack.
●Avoid high temperatures,moisture,
water and dust
– Do not expose the player,batteries or
discs to humidity,rain,sand or excessive
heat (caused by heating equipment or
direct sunlight.)
●Avoid condensation problem
– The lens may cloud over when the
player is suddenly moved from cold to
warm surroundings,making it impossible
to play a disc.Leave the player in the
warm environment until the moisture
evaporates.
PREVIEW
PREVIEW
MUTE
MUTE
SOUND
SOUND
SURROUND
SURROUND
SLEEP
SLEEP
DIM
DIM
●Do not block the vents
– Do not operate the DVD Player in an
enclosed cabinet, allow about 10 cm (4
inch) of free space all around the player
for adequate ventilation.
10 cm
(4 inches)
10 cm
(4 inches) 10 cm
(4 inches)
PHILIPS
●Care of the cabinet
– Use a soft cloth slightly moistened with
a mild detergent solution. Do not use a
solution containing alcohol, spirits,
ammonia or abrasives.
●Finding a suitable location
– Place the player on a flat,hard,and
stable surface.
●Disc handling
– To clean a CD,wipe it in a
straight line from the center
towards the edge using a soft,
lint-free cloth. A cleaning
agent may damage the disc!
– Write only on the printed
side of a CDR(W) and only with a soft felt-
tipped pen.
– Handle the disc by its edge,do not
touch the surface.
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM8

02(A)_8239 300 34351
English
9
Connections
ConnectingTV
AUDIO
IN
S-VIDEO
IN
VIDEOIN
TVIN
AUDIO
IN
S-VIDEO
IN
VIDEO IN
TV IN
1
IMPORTANT!
– You only need to make one video
connection from the following
options, depending on the
capabilities of yourTV system.
– Connect the DVD system directly
to theTV.
– A SCART connection will let you
use features bothAudio andVideo
on the DVD Player.
Using SCART jack
●Use the SCART cable (black) to connect
the DVD Player’s SCART jack (TV OUT)
to the corresponding Scart input jacks on
theTV (cable not supplied).
Helpful Hint:
– Ensure that the “TV” indication on
SCART cable is connected to the TV
set and “DVD” indication on SCART
cable is connected to the DVD Player.
AUDIO
IN
S-VIDEO
IN
VIDEOIN
TVIN
AUDIO
IN
S-VIDEO
IN
VIDEO IN
TV IN
2
1
Using CompositeVideo jacks
(CVBS)
1Use the composite video cable (yellow) to
connect the DVD Player’s CVBS (VIDEO)
jack to the video input jack (or labeled as
A/V In,Video In,Composite or Baseband)
on theTV (cable not supplied).
2To hear the sound of this DVD Player
through yourTV,use the audio cables
(white/red) to connectAUDIO OUT
[FRONT (L/R)] jacks of the DVD Player
to the correspondingAUDIO IN jacks on
theTV (cable not supplied).
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM9

02(A)_8239 300 34351
English
10
Connections
AUDIO
IN
V (Pr/Cr)
U (Pb/Cb)
Y
S-VIDEO
IN
VIDEO IN
COMPONENT
VIDEO IN
AUDIO
IN
V(Pr/Cr)
U(Pb/Cb)
Y
S-VIDEO
IN
VIDEOIN
COMPONENT
VIDEOIN
2
1
IMPORTANT!
– The progressive scan video
quality is only possible when usingY
Pb Pr and a progressive scanTV is
required.
Using ComponentVideo jacks
(Y Pb Pr)
1Use the component video cables (red/
blue/green) to connect the DVD system’s
Y Pb Pr jacks to the corresponding
Component video input jacks (or labeled
asY Pb Pr) on theTV (cable not supplied).
2To hear the sound of this DVD Player
through yourTV,use the audio cables
(white/red) to connectAUDIO OUT
[FRONT (L/R)] jacks of the DVD Player
to the correspondingAUDIO IN jacks on
theTV (cable not supplied).
3Proceed to page 16 for detailed
Progressive Scan set up.
IMPORTANT!
– If yourTV only has a single
Antenna In jack (or labeled as 75
ohm or RF In,) you will need an RF
modulator in order to view the DVD
playback on theTV. See your
electronics retailer or contact
Philips for details on RF modulator
availability and operations.
Using an accessory RF modulator
1Use the composite video cable (yellow) to
connect the DVD Player’sVIDEO OUT
jack to the video input jack on the RF
modulator.
2Use the RF coaxial cable (not supplied) to
connect the RF modulator to yourTV’s
RF jack.
AUDIO IN
R L
VIDEO
IN
TO TVINT IN
CH3 CH4
2
1
RF coaxial cable toTV
Back of RF Modulator
(example only)
Antenna or
CableTV signal
01-41 DVP5505S_EU_02A 20/01/2005, 5:14 PM10

02(A)_8239 300 34351
English
11
Connections
~AC MAINS
AUDIO
OUT V(Pr/Cr)
U(Pb/Cb)
Y
S-VIDEO
IN
VIDEOIN
COMPONENT
VIDEOIN
After everything is connected
properly,plug in theAC power cord
to the power outlet.
Never make or change any connections
with the power switched on.
When no disc is loaded,press
STANDBY ON on the DVD Player
front panel,
“NO DISC” may appear on the
display panel.
Connecting the power cord
NO DISC
Optional: Connecting to a Multi-
channel Receiver
MULTICHANNEL AUDIO IN
SUBW.
AV Receiver
REARFRONT
CENTERREARFRONT
LL
RR
Receiver has a Dolby Digital or DTS
decoder
1Select one of the video connections
(CVBSVIDEO IN,S-VIDEO IN,SCART or
COMPONENTVIDEO IN) depending on
the options available on yourTV.
2Connect theAudio Out Left and Right
jack for Front and Rear speakers to the
corresponding input sockets on your
Receiver (cable not supplied).
3Connect theAudio Out for Center
speaker and Subwoofer to the
corresponding inputs on your Receiver
(cable not supplied).
4Set the DVD Player’sAnalog Output to
‘Multichannel’ to enable playback of DVDs
recorded in Multi-channel. (see page 28
“Analogue output”).
Helpful Hint:
– If the subwoofer is equipped with its own
amplifier,the Subwoofer connection should
be connected directly to the subwoofer.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM11

02(A)_8239 300 34351
English
12
Connections
Stereo system has Dolby Pro Logic
or Right / LeftAudio In jack
1Select one of the video connections
(CVBSVIDEO IN,SCART or
COMPONENTVIDEO IN) depending on
the options available on yourTV.
2Use the audio cables (white/red) to
connectAUDIO OUT [FRONT (L/R)]
jacks of the DVD Player to the
correspondingAUDIO IN jacks on the
stereo system (cable not supplied).
AUDIO
IN
STEREO
DIGITAL
Optional: Connecting to an
Audio System Optional:Connecting DigitalAV
Receiver
Receiver has a PCM,Dolby Digital,
or MPEG2 decoder
1Select one of the video connections
(CVBSVIDEO IN,SCART or
COMPONENTVIDEO IN) depending on
the options available on yourTV.
2Connect the COAXIAL jack of the DVD
Player to the corresponding DigitalAudio
In jack on your Receiver (cable not
supplied).
3Set the DVD Player’s Digital Output to
PCM-ONLY orALL depending on the
capabilities of your Receiver (see page 28
“Digital Output”).
Helpful Hint:
– If the audio format of the Digital Output
does not match the capabilities of your
receiver,the receiver will produce a strong,
distorted sound or no sound at all.
AUDIO
IN
DIGITAL
AV Receiver
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM12

02(A)_8239 300 34351
English
13
Functional Overview
Front and Rear Panels
TV OUT
– Connect to Scart input of aTV
Multichannel Audio Out
– Center speaker,subwoofer,front
and rear speakers multichannel
connection
COAXIAL (Digital audio out)
– Connect to coaxialAUDIO input of a
digital audio equipment
Mains (AC Power Cord)
– Connect to a standardAC outlet
VIDEO OUT (CVBS)
– Connect to CVBSVideo input of aTV
YPbPr (ComponentVideo Out)
– Connect toYPbPr input of aTV
T NEXT
–To search or select next chapter or track
PREV S
–To search or select previous chapter or
track
9 STOP
–To stop playback
2; PLAY
–To start or interrupt playback
IR Sensor
– Point the remote control towards this
sensor
STANDBY-ON B
– To switch the DVD Player to Standby
mode or ON
Disc tray
OPEN/CLOSE /
– Open/Close the disc tray
Display
– Shows the current status of the DVD
Player
Caution:Do not touch the inner pins of the jacks on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM13

02(A)_8239 300 34351
English
14
Functional Overview
Remote Control
PREVIEW
PREVIEW
MUTE
MUTE
SOUND
SOUND
SURROUND
SURROUND
SLEEP
SLEEP
DIM
DIM
RETURN/TITLE
–To go back to previous menu/ show
title menu
DISC MENU
– Enters or exits the disc contents
menu
– Switches on or off the playback
control mode (forVCD version
2.0 only)
1 2 3 4
– Selects an item in the menu/
fast forward/backward,slow forward/
backward
OK
–Acknowledge menu selection
S
–To search or select previous
chapter or track
STOP ( 9)
–To stop playback
PLAY ( B)
–To start playback
PAUSE ( ;)
–To pause playback temporarily /
frame-by-frame playback
REPEAT
– Selects various repeat modes
REPEAT (A-B)
– Repeats playback a specific section
on a disc
PREVIEW
–To preview the content of a track
or whole disc
MUTE
– Disables or enables sound output
POWER B
– To switch the DVD player to
standby mode or ON
0-9 numerical key pad
– Selects numbered items in a
menu
DISPLAY
– Displays information onTV
screen during playback
SYSTEM MENU
– Access or exit DVD Player’s
system menu
T
– To search or select next chapter
or track
SUBTITLE
– To access subtitle language
system menu
ANGLE
– Selects a DVD camera angle
ZOOM
– Enlarge a picture on theTV
screen
AUDIO
– To access audio language system
menu
DIM
– Selects different levels of
brightness for display panel
SLEEP
– Sets the sleep timer function.
SOUND
– Selects a sound effect.
SURROUND
– Selects multichannel surround or
stereo mode.
Helpful Hint:
Press “STOP” for about 2 seconds to
OPEN or CLOSE disc tray.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM14

02(A)_8239 300 34351
English
15
PREVIEWPREVIEW MUTEMUTE
SOUND SURROUNDSLEEPDIM
Getting Started
Step 1: Inserting batteries into
the Remote Control
1
3
2
1Open the battery compartment.
2Insert two batteries type R06 orAA,
following the indications (+-) inside
the compartment.
3Close the cover.
Using the Remote Control to
operate the Player
1Aim the Remote Control
directly at the remote
sensor (IR) on the front
panel.
2Do not put any objects
between the Remote
Control and the DVD
Player while operating
the DVD Player.
CAUTION!
–Remove batteries if they are
exhausted or if the Remote Control
is not being used for a long time.
–Do not use old and new or
different types of batteries in
combination.
–Batteries contain chemical
substances,so they should be
disposed properly.
Step 2: Setting up theTV
IMPORTANT!
Make sure you have completed all
the necessary connections.(See
pages 9-10“ConnectingTV”).
1Turn on theTV and set to the correct
video-in channel. You should see the
Philips DVD background screen on the
TV.
2Usually these channels are between the
lowest and highest channels and may be
called FRONT,A/V IN,orVIDEO.See your
TV manual for more details.
➜Or,you may go to channel 1 on your
TV,then press the Channel down button
repeatedly until you see theVideo In
channel.
➜Or,theTV Remote Control may have a
button or switch that chooses different
video modes.
➜Or,set theTV to channel 3 or 4 if you
are using an RF modulator.
3If you are using external equipment,(eg.
audio system or receiver),turn it on and
select the appropriate input source for
the DVD Player output.Refer to the
equipment owner’s manual for detail.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM15

02(A)_8239 300 34351
English
16
Setting up Progressive Scan feature
(for Progressive ScanTV only)
The progressive scan display twice the
number of frames per seconds than
interlaced scanning (ordinary normalTV
system).With nearly double the number
of lines,progressive scan offers higher
picture resolution and quality.
IMPORTANT!
Before enabling the progressive scan
feature,you must ensure:
1)YourTV can accept progressive signals,
a progressive scanTV is required.
2)You have connected the DVD player to
yourTV usingY Pb Pr (see page 10.)
1Turn on yourTV.
2Turn off yourTV progressive scan mode
or turn on interlaced mode (refer to your
TV user manual.)
3Press POWER on the remote control to
turn on the DVD player.
4Select the correctVideo Input channel.
(See page 15).
➜The DVD background screen appears
on theTV.
5Press SYSTEM MENU.
6Press 2repeatedly to select {VIDEO
SETUP PAGE}.
Set P-SCAN On/Off
- - Video Setup Page - -
TV Type
TV Display
Progressive On
Picture Setting Off
Component
7Select {PROGRESSIVE} to {ON},then OK
to confirm.
➜The instruction menu appears on the
TV.
1 ENSURE YOUR TV HAS PROGRESSIVE SCAN.
2 CONNECT WITH YPBPR (GBR VIDEO CABLE.
3 IF THERE IS A DISTORTED PICTURE, WAIT
Cancel
OK
ACTIVATING PROGRESSIVE:
15 SECONDS FOR AUTO RECOVERY.
8Press 1to highlight
OK
in the menu
and press OK to confirm.
There will be a distorted picture on
yourTV at this state until you turn
on the progressive scan mode on
yourTV.
9Turn on yourTV progressive scan mode
(refer to yourTV user manual.)
➜The below menu appears on theTV.
CONFIRM AGAIN TO USE PROGRESSIVE
SCAN. IF THE PICTURE IS GOOD,
PRESS OK BUTTON ON REMOTE
Cancel
OK
0Press 1to highlight
OK
in the menu
and press OK to confirm.
➜The set up is complete now and you
can start enjoy the high quality picture.
Getting Started
TIPS: To return to the previous menu,press 1.
To remove the menu,press SYSTEM MENU.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM16

02(A)_8239 300 34351
English
17
Selecting the colour system that
corresponds to yourTV
This DVD Player is compatible with both
NTSC and PAL.In order for a DVD disc
to play on this Player,the colour system of
the Disc,theTV and the DVD Player
should match.
NTSC TV
- - Video Setup Page - -
TV Type PAL
TV Display Multi
Progressive NTSC
Picture Setting
Component
1Press SYSTEM MENU.
2Press 2repeatedly to select {VIDEO
SETUP PAGE}.
3Press 34to highlight {TVTYPE},then
press 2.
Getting Started
4Press 34to highlight one of the options
below:
PAL – Select this if the connectedTV is
PAL system.It will change the video signal
of a NTSC disc and output in PAL format.
NTSC – Select this if the connectedTV
is NTSC system. It will change the video
signal of a PAL disc (VCD only) and
output in NTSC format.
Multi – Select this if the connectedTV is
compatible with both NTSC and PAL
(multi-system). The output format will be
in accordance with the video signal of the
disc.
5Select an item and press OK.
Helpful Hints:
– Before changing the currentTV
Standard setting, ensure that your TV
supports the ‘selected TV Type’ system.
– If there is no proper picture on
your TV, wait for 15 seconds for auto
recovery.
CHANGING PAL TO NTSC:
1. ENSURE THAT YOUR TV SUPPORTS
NTSC STANDARD.
2. IF THERE IS A DISTORTED PICTURE
DISPLAYED ON THE TV, WAIT 15
SECONDS FOR AUTO RECOVER.
CANCELOK
CONFIRM AGAIN TO USE NEW TV
TYPE SETTING.
CANCELOK
TIPS: To return to the previous menu,press 1.
To remove the menu,press SYSTEM MENU.
To deactivate Progressive manually
●When the distorted picture still
appears on theTV, it may be due to
the connectedTV does not accept
progressive signals,and progressive is set
by mistake. You must reset the unit to
interlace format.
1Turn off yourTV progressive scan mode
or turn on to interlaced mode (refer to
yourTV user manual.)
2Press OPEN/CLOSE on the DVD player
to open the disc tray.
3Press numeric keypad‘1’on the
remote control for few seconds.
➜The DVD blue background screen
will appear on theTV.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM17

02(A)_8239 300 34351
English
18
Step 3: Setting language
preference
You can select your preferred language
settings.This DVD Player will
automatically switch to the language for
you whenever you load a disc.
Setting the OSD Language
The On-screen language for the system
menu will remain as you set it,regardless
of various disc languages.
Set OSD Language English(UK
- - General Setup Page - -
Disc Lock
Display Dim
Program
OSD Language ENGLISH(UK
Screen Saver FRANÇAIS
Sleep DEUTSCH
DIVX(R Vod Code NEDERLANDS
1Press SYSTEM MENU.
2Press 2to select {GENERAL SETUP
PAGE}.
3Press 34to highlight {OSD
LANGUAGE},then press 2.
4Press 34 to select a language and press
OK.
Getting Started
Setting theAudio,Subtitle and Disc
menu language
You can choose your own preferred
language or soundtrack from audio,
subtitles and disc menu languages.If the
language selected is not available on the
disc,the disc’s default language will be
used instead.
Set Preference To English
Audio English
Subtitle French
Disc Menu Spanish
Parental Chinese
PBC Japanese
Mp3 / Jpeg Nav Korean
Password Setup Russian
- - Preference Page - -
1Press STOP twice then,press SYSTEM
MENU.
2Press 2repeatedly to select
{PREFERENCE PAGE}.
3Press 34 to highlight one of the options
below at a time,then press 2.
– ‘Audio’ (disc’s soundtrack)
– ‘Subtitle’ (disc’s subtitles)
– ‘Disc Menu’ (disc’s menu)
4Press 34 to select a language and press
OK.
If the language you want is not in the
list,then select {OTHERS},
then use the numeric keypad (0-9) on
the remote to enter the 4-digit language
code‘XXXX’ (see page 258“Language
Code”) and press OK.
5Repeat steps 3~4for other language
settings.
TIPS: To return to the previous menu,press 1.
To remove the menu,press SYSTEM MENU.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM18

02(A)_8239 300 34351
English
19
Disc Operations
IMPORTANT!
–If the inhibit icon (ø) appears on
theTV screen when a button is
pressed,it means the function is not
available on the current disc or at
the current time.
–Depending on the DVD orVIDEO
CD, some operations may be
different or restricted.
–Do not push on the disc tray or
put any objects other than disc on
the disc tray. Doing so may cause
the disc player malfunction.
Playable Discs
Your DVD Player will play:
– DigitalVideo Discs (DVDs)
– Video CDs (VCDs)
– SuperVideo CDs (SVCDs)
– SuperAudio CDs (SACDs)
– DigitalVideo Discs +
Recordable[Rewritable] (DVD+R[W])
– Compact Discs (CDs)
– MP3/WMA discs,picture (Kodak,JPEG)
files on CD-R(W).
– JPEG/ISO 9660 format
– Maximum 30 characters display.
– Supported sampling frequencies :
32 kHz, 44.1 kHz, 48 kHz (MPEG-1)
16 kHz, 22.05 kHz, 24 kHz (MPEG-2)
– Supported Bit-rates :32~256 kbps
(MPEG-1), 8~160 kbps (MPEG-2)
variable bitrates
– MPEG-4 disc on CD-R(W):
– Simple profile
– Advanced simple profile (640-480)
– DivX disc on CD-R[W]/DVD+R[W]:
– DivX 3.11, 4.x and 5.x
– Q-pel accurate motion compensation
– Global Motion Compensation (GMC) playback
SUPER VIDEO
Region Codes
DVD discs must be labeled forALL
regions or Region 2 in order to
play on this Player.You cannot play
Discs that are labeled for other
regions.
Helpful Hints:
– It may not be possible to play CD-R/RW
or DVD-R/RW in all cases due to the type of
disc or condition of the recording.
– If you are having trouble playing a
certain disc,remove the disc and try a
different one. Improper formatted disc will
not play on this DVD Player.
TIPS: The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
Playing discs
1Connect the power cords of the DVD
Player andTV (and any optional stereo or
AV receiver) to a power outlet.
2Turn on theTV power and set to the
correctVideo In channel. (See page 15
“Setting up theTV”).
3Press STANDBY-ON on the DVD Player
front panel.
➜You should see the Philips DVD
background screen on theTV.
4Press OPEN/CLOSE 0button to open
the disc tray and load in a disc,then press
the same button again to close the disc
tray.
➜Make sure the label side is facing up.
For double-sided discs,load the side you
want to play facing up.
5Playback will start automatically.If not
press PLAY B.
➜If a disc menu appears on theTV,see
page 21“Using the Disc Menu”.
➜If the disc is locked by parental control,
you must enter your six-digit password.
(See page 35).
ALL
2
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM19

02(A)_8239 300 34351
English
20
Disc Operations
Basic playback controls
Unless otherwise stated, all operations
described are based on Remote Control
use.
Pausing playback
1During playback,press PAUSEÅ.
➜Playback will pause and sound will be
muted.
2To resume normal playback,press
PLAY B.
Selecting track/chapter
●Press S/ Tor use the numeric
keypad (0-9) to key in a track/chapter
number.
➜If repeat mode is active,pressing S/
Twill replay the same track/chapter.
Searching backward/forward
●Press and hold 1/ 2,then press PLAY
Bto resume normal playback.
➜While searching,pressing 1/ 2
repeatedly again will decrease/increase
the search speed.
Stopping playback
●Press Ç.
TIPS: The operating features described here might not be possible for certain discs. Always refer
to the instructions supplied with the discs.
Selecting various repeat/shuffle
functions
Repeat play mode
●While playing a disc,press REPEAT
continuously to choose a‘Play Mode’.
CHAPTER (DVD)
– to repeat playback of the current
chapter.
TRACK/TITLE (CD/SVCD/VCD/DVD)
– to repeat playback of the current
track (CD/SVCD/VCD)/title (DVD).
ALL
– to repeat playback of all the disc and
all the programmed tracks.
Helpful Hint:
– ForVCD,repeat playback is not possible
if the PBC mode is switched on.
Repeating a section within a
chapter/track
1While playing a disc,press REPEATA-B
at your chosen starting point.
2Press REPEATA-B again at your chosen
end point.
➜The sectionA and B can be set only
within the same chapter/track.
➜The section will now repeat
continuously.
3To exit the sequence,press REPEAT
A-B.
01-41 DVP5505S_EU_02A 20/01/2005, 5:15 PM20
