Philips HP6479 User manual

Satin ICE
HP6479, HP6475, HP6473

2

3

4

ENGLISH 6
FRANÇAIS 18
 30
39
50
60
82
v<ñUã 93
HP6479, HP675, HP673

Introduction
◗With your new Satin ICE you can remove unwanted hairs quickly,
easily and effectively.The combination of the proven epilating disc
system with the newly developed contour-following skin cooler
constitutes a revolution in epilation.Thanks to the natural
numbing effect of ice on the skin, the new Satin ICE makes
epilation more comfortable and less painful than ever.The result
is a silky-smooth skin and a hair growth reduction of up to 50%,
assuming you use the appliance regularly (every 4 weeks).
◗The Satin ICE is particularly suitable for the legs.Type HP6479
also comes with a skin cooler that has been specially developed
for epilating sensitive areas (underarms, bikini line).These areas
are particularly sensitive to pain, which this special skin cooler
helps to diminish.
◗The rapidly rotating epilating discs catch even the shortest hairs
(up to half a millimetre!) and pull them out by the roots.As a
result, your skin stays smooth for up to four weeks and regrowth
is soft and downy.
General description
AProtective sleeve for skin cooler
BLeg skin cooler with pivoting cooling head
CSkin cooler for underarms and bikini line (HP6479 only)
DFreezer cassette
EEpilating head
FProtective cap of exfoliating head
GExfoliating head
HProtective cap of shaving head (HP6479 and HP6475 only)
IShaving head (HP6479 and HP6475 only)
JAppliance
KAdapter
LCleaning brush
ENGLISH6

Important
Read these instructions for use carefully before using the appliance and
save them for future reference.
◗Check if the voltage indicated on the adapter corresponds to the
local mains voltage before you connect the appliance.
◗Only use the appliance in combination with the adapter supplied.
◗Do not use the appliance if the adapter or the appliance itself is
damaged.
◗If the adapter is damaged, always have it replaced by one of the
original type in order to avoid a hazard.
◗The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this will cause a hazardous
situation.
◗Keep the appliance and the adapter dry.
◗Keep the appliance out of the reach of children.
◗Do not expose the appliance to temperatures lower than 5cC or
higher than 35cC.
◗To prevent damage and injuries, keep the running appliance away
from your hair, eyebrows, eyelashes, clothes, threads, cords,
brushes etc.
◗Do not use the appliance on irritated skin or skin with varicose
veins, rashes, spots, moles (with hairs) or wounds without
consulting your doctor first. People with a reduced immune
response, e.g. during pregnancy, or people suffering from diabetes
mellitus, Raynaud's disease or immunodeficiency should contact
their doctor first.
Preparing for use
Freezing the skin cooler
1Remove the protective sleeve from the skin cooler (fig. 1).
2Put the skin cooler WITHOUT the protective sleeve in the
freezer cassette and put it in the freezer or freezing
compartment (***) at least 6 hours before you start epilating
(fig. 2).
ENGLISH 7

Make sure the outside of the skin cooler is completely dry before you
freeze it.
◗Tip:You can store the skin cooler in the freezer permanently.
Using the appliance
General information about epilation
◗Epilation is easier just after taking a bath or shower. Make sure
your skin is completely dry when you start epilating.
◗When you use the appliance for the first time, we advise you to try
it out on an area with only light hair growth to get accustomed to
the epilation process.After epilation you can apply a mild cream
or body milk to soothe your skin and reduce skin irritation.
◗Before epilating longer hairs on sensitive skin areas, shorten them
with a trimmer or a pair of scissors.
◗We advise you to epilate before going to bed at night, as this will
allow any skin irritation that may develop to diminish overnight.
◗Your skin may become a little red and irritated the first few times
you use the epilator.This phenomenon is absolutely normal and
will quickly disappear.As you use the appliance more often, your
skin will get used to epilation, skin irritation will decrease and
regrowth will become thinner and softer. If the irritation has not
disappeared within three days, we advise you to consult a doctor.
◗Epilation can lead to ingrown hairs or minor skin injuries, which
may cause inflammations due to penetration of bacteria into the
skin. It is therefore important to clean the epilating head very
carefully after each use.
Epilating the legs
Make sure your skin is clean, entirely dry and free from grease. Do not
use any cream before you start epilating.
1Slide the protective sleeve onto the skin cooler (fig. 3).
The protective sleeve prevents an unpleasant sensation of coldness in
your hand while using the appliance.
ENGLISH8

Occasionally the pivoting head may freeze onto the skin cooler and
doesn't move when you take the skin cooler from the freezer.The
pivoting head will start pivoting again after you have passed it over your
leg a few times.
2Snap the appliance onto the skin cooler (fig. 4).
3Insert the appliance plug into the inlet socket and put the adapter
in the wall socket.
4Switch the appliance on by selecting the desired speed (fig. 5).
Select speed I for areas with little hair growth and for areas where
bones are located directly beneath the skin, such as knees and ankles.
Select speed II for larger areas with stronger hair growth.
5Stretch your skin with your free hand to make the hairs stand
upright.
6Place the appliance perpendicularly onto the skin and move it
against the direction of hair growth (fig. 6).
Make sure both the epilating discs and the skin cooler are in proper
contact with the skin.
Do not press the appliance onto the skin.
Epilating underarms and bikini line (HP6479 only)
The special skin cooler for the underarms and bikini line reduces the
number of active epilating discs. Combined with the large cooling
surface, this skin cooler makes epilating sensitive areas less painful.You
will get the best results when the hairs are not too long (max. 1 cm).
1Slide the protective sleeve onto the skin cooler (fig. 7).
2Snap the appliance onto the skin cooler (fig. 8).
3Switch the appliance on by selecting the desired speed (fig. 9).
We advise you to use speed II.
4To epilate the underarm area, place one arm behind your head to
stretch the skin and place the appliance perpendicularly onto the
skin with the hand of the other arm (fig. 10).
ENGLISH 9

5To epilate the bikini line, stretch the skin with your free hand and
place the appliance perpendicularly onto your skin, without
exerting any pressure (fig. 11).
6Move the appliance slowly across the skin against the direction of
hair growth.
Shaving (HP6479 and HP6475 only)
You can use the shaving head to shave delicate body parts, such as your
underarms and bikini line.With the shaving head you will obtain a
smooth result in a comfortable and gentle way.
1Make sure the appliance is switched off.
2Remove the skin cooler.
3Remove the epilating head (fig. 12).
Grab the epilating head by the ribbed sections and move it in the
direction of the arrow indicated on the epilating head.
4Place the shaving head on the appliance and move it against the
direction of the arrow indicated on the shaving head until it snaps
home (fig. 13).
The shaving head can only be fitted onto the appliance in one way.
5Switch the appliance on by selecting the desired speed.
We advise you to use speed I.
6Place the shaving head onto your skin and move the appliance
slowly and smoothly against the direction of hair growth, while
pressing it lightly.
Exfoliating
Using the exfoliating head regularly improves the appearance of the
skin and reduces the risk of ingrown hairs. Do not use the exfoliating
head immediately before or within two days after epilation.
Only use the exfoliating head on your legs, not on your underarms or
bikini line.
ENGLISH10

1Make sure the appliance is switched off.
2Remove the skin cooler.
3Remove the epilating head (fig. 12).
Grab the epilating head by the ribbed sections and move it in the
direction of the arrow indicated on the epilating head.
4Place the exfoliating head on the appliance and move it against
the direction of the arrow indicated on the exfoliating head until
it snaps home (fig. 14).
The exfoliating head can only be fitted onto the appliance in one way.
5Switch the appliance on.
Use speed I or II, depending on the required exfoliating intensity.We
recommend exfoliating each leg for 1-3 minutes.
- Use the exfoliating head once or twice a week to improve the
appearance of your skin.
- Don't use any cream, foam, gel or lotion just before or during
exfoliation.
- Don't use the exfoliating head immediately before or within two
days after epilation.
- For hygienic reasons, the exfoliating head should only be used by
one person.
- We advise you to exfoliate before going to bed at night, as this will
allow any skin irritation that may develop to diminish overnight.
- Apply a mild cream or body milk after exfoliating.
Cleaning and maintenance
Never rinse the adapter plug or the appliance itself with water.
Do not use any corrosive detergents, scouring pads or cloths, petrol,
acetone etc. to clean the appliance.
1Make sure the appliance is switched off and unplugged.
2Remove the skin cooler from the appliance and slide the
protective sleeve off the skin cooler.
ENGLISH 11

3Clean the skin cooler, the appliance and the protective sleeve
with a moist cloth.
4Clean the pivoting cooling head of the leg skin cooler with a
brush or moist cloth after each use (fig. 15).
Make sure the outside of the skin cooler is completely dry before
freezing it again.
5Remove the epilating head (fig. 12).
Grab the epilating head by the ribbed sections and move it in the
direction of the arrow indicated on the epilating head.
6Clean all accessible parts and the epilating discs with the brush
(fig. 16).
Never try to detach the epilating discs from the appliance.
7Place the epilating head on the appliance and move it against the
direction of the arrow indicated on the epilating head until it
snaps home (fig. 17).
The epilating head can only be fitted onto the appliance in one way.
Cleaning the shaving head (HP6479 and HP6475 only)
1Make sure the appliance is switched off and unplugged.
2Remove the shaving foil.
3Clean the hair chamber and the cutter block with the brush
(fig. 18).
Do not exert pressure on the shaving foil to avoid damaging it.
◗Rub a drop of sewing machine oil onto the trimmers and shaving
foil of the shaving head twice a year.
Cleaning the exfoliating head
1Switch the appliance off.
2Remove the exfoliating head by moving it in the direction of the
arrow indicated on the exfoliating head.
ENGLISH12

3Clean the exfoliating head with the brush regularly (fig. 19).
You can clean the exfoliating head more thoroughly by rinsing it under
the tap.
Never rinse the adapter or the epilator itself with water.
Storage
1Put the protective caps back onto the shaving head and
exfoliating head after use.
2Store the appliance and the accessories in the pouch.
3Put the skin cooler in the freezer cassette.
Replacement
BHP6479 and HP6475 only
◗When you use the shaving head several times a week, replace the
shaving foil (type HP6116) and the cutter block (type HP2911)
after one or two years of use or if these parts are damaged.
Guarantee & service
If you need information or if you have a problem, please visit the Philips
website at www.philips.com or contact the Philips Customer Care
Centre in your country (you will find its phone number in the
worldwide guarantee leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and Personal Care BV.
ENGLISH 13

14
Solution
Move the appliance against the
direction of hair growth.
Make sure you place the
appliance perpendicularly onto
the skin.
Make sure both the epilating
head and the skin cooler are
in proper contact with your
skin during epilation.
Make sure your skin is entirely
dry and free from grease. Do
not put any cream, milk or
other skincare product on
your skin before you start
epilating.
Only use the leg skin cooler to
epilate your legs.
Make sure the socket you use
is live. If you are using a socket
in a bathroom cabinet, you
may need to switch on the
light to activate the socket.
Make sure that the appliance
is plugged in and switched on.
Cause
The epilator is being
moved in the wrong
direction.
The epilating head is
placed on the skin at
the wrong angle.
The epilating head
does not touch the
skin.
The skin was
moistened with water
or a cream or other
skincare product was
applied prior to
epilation.
The underarm skin
cooler is on the
appliance while you
are epilating your legs.
The socket to which
the appliance is
connected is not live.
The appliance is not
switched on.
Problem
Reduced epilating
performance.
The appliance does
not work.
Troubleshooting
ENGLISH

15
Solution
Place the epilating head on the
appliance and move it against
the direction of the arrow
indicated on the epilating head
until it snaps home.
Some skin irritation may occur
the first few times you use the
appliance.This is absolutely
normal and should quickly
disappear. For tips to reduce
skin irritation, see the first
section of chapter 'Using the
appliance'. Also make sure you
keep the epilating head clean.
Make sure you store the skin
cooler in the freezer or
freezing compartment (***)
for at least 6 hours before you
use it.
Make sure you store the skin
cooler in the freezer or
freezing compartment (***)
for at least 6 hours. Do not
store the skin cooler in the
refrigerator.
Make sure the skin cooler is
always in proper contact with
your skin during epilation.
Pass the skin cooler over your
leg a few times to make it
start pivoting again. Always
make sure the outside of the
skin cooler is completely dry
before you freeze it.
Cause
The epilating head has
not been attached
correctly.
You used the epilator
for the first time or
after a long period of
disuse.
The skin cooler was
not cooled long
enough.
The skin cooler was
not cooled in the
freezer or freezing
compartment.
The skin cooler does
not touch the skin.
The pivoting cooling
head is frozen.
Problem
Skin irritation occurs.
The skin cooler is not
cool enough.
The pivoting cooling
head of the leg skin
cooler doesn't move.
ENGLISH

16
Solution
Remove the protective sleeve
before putting the skin cooler
in the freezer cassette.
Move the epilating head
against the direction of the
arrow to attach it and move it
in the direction of the arrow
to remove it.
Move the shaving head against
the direction of the arrow to
attach it and move it in the
direction of the arrow to
remove it.
Switch the appliance off,
unplug it and remove the
shaving foil.Then clean the hair
chamber and the cutter block
with the cleaning brush
supplied. Remove any hairs
that may have got stuck under
the trimmer.
Replace the shaving foil if it is
damaged or worn.
Move the peeling head against
the direction of the arrow to
attach it and move it in the
direction of the arrow to
remove it.
Do not use the exfoliating
head within two days after
epilation.
Cause
The protective sleeve
is still around the skin
cooler.
You are not moving
the epilating head in
the right direction.
You are not moving
the shaving head in
the right direction.
The shaving head is
dirty.
The shaving foil is
damaged or worn.
You are not moving
the peeling head in
the right direction.
You used the
exfoliating head
shortly after epilation.
Problem
The freezer cassette
cannot be closed
when the skin cooler
is in it.
The epilating head
cannot be attached or
removed.
The shaving head
(HP6479 and HP6475
only) cannot be
attached or removed.
Reduced shaving
performance (HP6479
and HP6475 only).
Stronger skin irritation
than usual after
shaving (HP6479 and
HP6475 only).
The peeling head
cannot be attached or
removed.
Skin irritation occurs
after exfoliation.
ENGLISH

17
Solution
QFor hygienic reasons, the
exfoliating head should only
be used by one person.
We recommend exfoliating
each leg no longer than 1-3
minutes.
Remove the exfoliating head
from the appliance and clean
it under a running tap with the
cleaning brush supplied.
Do not apply any cream, foam,
gel or lotion to the skin just
before or during exfoliation.
Cause
The exfoliating head is
used by different
persons.
You have exceeded
the recommended
exfoliating time.
The exfoliating head is
dirty.
Remove the
exfoliating head from
the appliance and
clean it under a
running tap with the
cleaning brush
supplied.A cream or
other skincare product
was applied before or
during exfoliation.
Problem
Reduced exfoliating
performance.
ENGLISH

Introduction
◗Avec votre nouvel épilateur Satin ICE vous pouvez enlever les
poils rapidement et efficacement. La combinaison d'un système
d'épilation à disques déjà éprouvé avec le nouvel applicateur de
froid qui suit les contours amène une évolution notable dans la
technique d'épilation. Grâce à l'effet naturel anesthésiant de la
glace sur la peau, le nouvel épilateur Satin ICE rend l'épilation plus
confortable et moins douloureuse comme jamais elle ne l'a été.
Le résultat sera une peau plus douce et sans poils et la repousse
sera diminuée de 50% si vous vous épilez régulièrement toutes
les quatre semaines.
◗Votre épilateur Satin ICE est particulièrement adapté à l'épilation
de vos jambes. Le modèle HP6479 est doté d'un applicateur de
froid spécialement conçu pour l'épilation des zones sensibles
(aisselles et maillot). Cet applicateur de froid spécial réduit la
sensation de douleur ressentie lors de l'épilation des zones
sensibles.
◗Les disques rotatifs attrapent même les poils les plus courts
(jusqu'à un demi millimètre!) et les retirent à partir de la racine.
Ainsi votre peau reste lisse jusqu'à quatre semaines et le poil de
repousse est doux et fin.
Description générale
AManchon pour applicateur de froid
BApplicateur de froid pour jambes avec tête pivotante
CApplicateur de froid pour aisselles et maillot (HP6479 uniquement)
DCassette freezer
ETête d'épilation
FCapot de protection pour la tête d'exfoliation
GTête d'exfoliation
HCapot de protection pour la tête de rasage (HP6479 et HP6475
uniquement)
ITête de rasage (HP6479 et HP6475 uniquement)
JAppareil
KAdaptateur
LBrosse de nettoyage
FRANÇAIS18

19
Important
Lisez les instructions du mode d'emploi avant d'utiliser l'appareil et
conservez-les pour un usage ultérieur.
◗Avant de brancher l'appareil, vérifiez que la tension indiquée sur
l'adaptateur correspond à la tension de votre secteur.
◗Utilisez l'appareil uniquement avec l'adaptateur fourni.
◗N'utilisez pas l'appareil lorsque l'adaptateur ou l'épilateur est
endommagé.
◗Si l'adaptateur est endommagé, pour plus de sécurité et pour
éviter tout accident, il ne doit être remplacé que par un
adaptateur d'origine.
◗L'adaptateur a un transformateur. N'essayez pas de remplacer
l'adaptateur secteur par un autre pour éviter tout accident.
◗Assurez-vous que l'appareil et son adaptateur ne sont pas en
contact avec de l'eau.
◗Tenez l'appareil hors de portée des enfants.
◗N'exposez pas l'appareil à une température inférieure à 5 cC ou
supérieure à 35 cC.
◗Pour prévenir des dommages ou des blessures, utilisez l'appareil à
distance respectable des cheveux, cils, sourcils, vêtements, fils,
cordons, brosses etc.
◗N'utilisez pas l'appareil sur une peau irritée ou avec des varices,
rougeurs, tâches de vin (avec pilosités) ou blessures sans consulter
votre médecin au préalable. Les mêmes recommandations
s'appliquent aux personnes ayant des protections immunitaires
réduites, par exemple les femmes enceintes, les diabétiques, les
hémophiles ou les déficients immunitaires.
Préparation à l'emploi
Congeler l'applicateur de froid
1Retirez le manchon de l'applicateur de froid (fig. 1).
2Mettez l'applicateur de froid SANS le manchon dans la cassette
freezer et puis mettez-la dans le congélateur ou dans le freezer
(***) 6 heures au moins avant de s'épiler (fig. 2).
FRANÇAIS

20
Assurez-vous que l'applicateur de froid est parfaitement sec avant de le
congeler.
◗Suggestion:Vous pouvez conserver l'applicateur de froid dans le
freezer du réfrigérateur en permanence.
Mode d'emploi
Epilation en général
◗Les poils sont plus faciles à épiler après un bain ou une douche.
Mais votre peau doit être complètement sèche durant l'épilation.
◗Quand vous utilisez l'appareil pour la première fois, nous vous
conseillons de commencer par un endroit avec peu de croissance
de poils de manière à vous habituer à l'épilation.Après utilisation,
vous pouvez appliquer une crème hydratante ou un lait corporel
qui aidera à calmer la peau et à réduire l'irritation.
◗Lorsque les poils dans les zones sensibles sont longs, coupez-les
avec une tondeuse ou des ciseaux avant de vous épiler.
◗Il est conseillé de s'épiler le soir, afin de laisser les irritations
disparaître pendant la nuit.
◗Pendant les premières utilisations l'épilateur peut provoquer un
rougissement ou une irritation de la peau. Il s'agit d'une réaction
normale qui disparaîtra rapidement. La gêne ressentie au début
diminuera graduellement à chaque utilisation car la repousse a
tendance à être plus douce au toucher. Cependant, si l'irritation
persiste plus de trois jours, consultez votre médecin.
◗Les poils incarnés ou les blessures superficielles peuvent
provoquer des inflammations à cause de la pénétration des
bactéries au-dessous de la peau. Il est donc très important de
nettoyer la tête d'épilation après chaque utilisation.
Epilation des jambes
Assurez-vous que votre peau est propre, sans graisse ni crèmes.
N'appliquez aucune crème avant l'épilation.
1Glissez le manchon sur l'applicateur de froid (fig. 3).
Le manchon masque la sensation désagréable de froideur pendant
FRANÇAIS
