ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ6605
03/04
PRODUCT INFORMATION
Shaving system
- 3-dimentional contour following system
- Lift & Cut system
- Individually floating heads
- Three Super Reflex Action shavingheads HQ55
- Silent power
- Hair collecting chamber
Power system
- Rechargeable
- 16 hour charge time
- Up to 30 minutes cordless shaving time
- World-wide automatic voltage selection
Features
- Travel pouch
- Pop-up trimmer
Luxe
*
Safety information
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Voltage : 100-240 V AC 50-60 Hz
- Power consumption : Motor depending
- Motor Voltage : 1,2 V
- Power system : Rechargeable
- Shaving heads : HQ55 - 4222 036 08370
- Charging indication : 1 led
- SAP coding : HQ6605
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- Remove shaving unit, to prevent damages during repairs.
- Remove the screws A1 (2x).
- Remove cover. (See Fig. 1)
- To remove the trimmer, first
disassemble the trimmer slide
by pushing down the locking
pegs (2 x “X” in exploded view)
and move the slide slightly
outwards.
- Make room between trimmer
and cover with a small screw-
driver (“Y” in exploded view).
- Remove screws B1 (2 x).
- The PC-board with motor and
hairchamber can now be removed from the housing.
- Detach the motor clamping springs (item 17) on the
bearing block with a small screwdriver
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- Pouch - 4222 036 05740
Fig. 1

HQ6605
EXPLODED VIEW & PARTS LIST
A1
Ni-Cd
B1
14
19
20
21
18
22
6
5
4
3
2
1
7
8
12
16
17
15
10
9
11
13
X
Y
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
4222 036 05430
4222 036 09010
4222 036 08370
4222 036 05460
4222 036 08380
4822 466 10937
4222 036 08390
4222 036 08490
4222 036 08500
4222 036 05650
4822 479 30183
4222 036 08510
4222 036 05550
protecting cap
bracket
HQ55 shaving head
holder assy
hair chamber complete
dust seal
on/off knob
panel EUR
housing
on/off slide assy
cleaning brush
printed circuit board
inlet
Pos Service code Description
14
15
16
17
18
19
20
21
22
4822 138 10633
4822 522 33605
4822 361 10959
4822 492 71735
4222 036 08420
4822 466 12153
4222 036 05670
4222 036 08520
4822 321 10095
4822 321 10096
4222 036 02480
4822 502 30526
4222 036 05740
AA NiCd cell
pinion
motor assy
motor spring
trimmer assy
foam
connecting strip
cover
flex assy EUR
flex assy GBR
flex assy KOR
screw (torx-slot)
pouch EUR
