Philips HQ9160/27 User manual

ENGLISH 4
POLSKI 19
РУССКИЙ 33
УКРАЇНСЬКА 49
EESTI 64
LATVISKI 78
LIETUVIŠKAI 93
107
ROMÂNĂ 122
ČESKY 136
MAGYAR 150
SLOVENSKY 165
HRVATSKI 179
SLOVENŠČINA 193
БЪЛГАРСКИ 208
SRPSKI 224
HQ9160
4222 002 48152 08-11-2006 14:32 Pagina 3

Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the powerplug supplied.
◗The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
◗The powerplug contains a transformer. Do
not cut off the powerplug to replace it with
another plug, as this will cause a hazardous
situation.
◗Do not use a damaged powerplug.
◗If the powerplug is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
◗Make sure the powerplug does not get wet.
◗Charge and store the appliance at a
temperature between 5cC and 35cC.
C◗Never immerse the charging stand in water
nor rinse it under the tap.
◗Do not recharge the shaver in a closed pouch.
◗Always unplug the shaver before cleaning it
under the tap.
C◗The appliance complies with the
internationally approved IEC safety regulations
and can be safely cleaned under the tap.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
◗Noise level: Lc = 64 dB [A]
ENGLISH4
4222 002 48152 08-11-2006 14:32 Pagina 4

Charging
Make sure the appliance is switched off before
you start charging it.
Charging normally takes approx. 1 hour.
You can also shave without charging by
connecting the shaver to the mains.
Charge indications
Charging
C◗When you start charging the empty shaver,
the bottom light burns red.When the battery
contains enough power for one shave, all
lights start blinking green sequentially.
Battery fully charged
C◗When the battery has been fully charged, all
green light are on.
A few hours after charging, all lights go out.
Remaining battery capacity
C◗The amount of power left in the battery is
indicated by the number of lights that are on.
ENGLISH 5
4222 002 48152 08-11-2006 14:32 Pagina 5

The remaining battery capacity is shown when
you unplug the shaver or when you switch it on
or off:
- When all lights burn green, the battery is 100%
charged.
- When the bottom light burns green, 20% of the
battery capacity is left.
Battery running low
C◗When the battery is running low, the bottom
light starts burning red.
When you switch the shaver off, this light blinks a
few times.
Cordless shaving time
A fully charged shaver has a cordless shaving time
of up to 80 minutes.
Charging the appliance
C1Put the appliance plug in the shaver.
2Put the powerplug in the wall socket.
3Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver when the battery has been fully
charged.
ENGLISH6
4222 002 48152 08-11-2006 14:32 Pagina 6

Charging stand
You can also charge the appliance by placing it in
the charging stand, if provided.
Never immerse the charging stand in water nor
rinse it under the tap.
C◗Place the shaver properly in the plugged-in
charging stand.
The bottom light starts burning red.
C◗Lift the shaver from the stand without tilting
it.
Removing and inserting the clock
C1Turn the clock anticlockwise (1) ('click')
and pull it out (2).
C2Insert the clock (1) and turn it clockwise
(2) ('click').
ENGLISH 7
4222 002 48152 08-11-2006 14:32 Pagina 7

Setting the time
C◗Set the time by pressing the small button at
the back of the clock.
The time can only be set forward.
Replacing the battery
C1Remove the cap.Then remove the battery
by means of a miniature screwdriver.
C2Insert a new battery and put the cap back
into place.
Using the appliance
Personal Comfort Control
C◗The Personal Comfort Control system allows
you to adapt the shaver to your skin type.
- You can set the shaver to 'Normal' for a fast
and comfortable close shave.
- You can set the shaver to 'Sensitive' for a
comfortable close shave with optimal skin
comfort.
ENGLISH8
4222 002 48152 08-11-2006 14:32 Pagina 8

C◗The 'S' position is best suited for sensitive
skin.
C◗The 'N' position is best suited for normal
skin.
◗The in-between positions are suitable for skin
types between normal and sensitive.
Shaving
1Switch the shaver on by pressing the on/off
button once.
When you switch the shaver on or off, all lights
and symbols go on and then the remaining
battery capacity is shown for a few seconds.
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
- Shaving on a dry face gives the best results.
- Your skin may need 2 or 3 weeks to get
accustomed to the Philips system.
3Switch the shaver off by pressing the on/off
button once.
C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
ENGLISH 9
4222 002 48152 08-11-2006 14:32 Pagina 9

Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
C2Close the trimmer with your index finger.
Cleaning and maintenance
C◗The tap symbol starts blinking after every
shave to remind you that the shaver needs to
be cleaned (except when the bottom light
burns red).
Regular cleaning guarantees better shaving
performance.
◗If provided, use the washing machine to clean
the shaver. See the seperate instruction
booklet.
The normal way to clean the appliance is to rinse
the shaving unit and the hair chamber with hot
water every time you have used the shaver.
ENGLISH10
4222 002 48152 08-11-2006 14:32 Pagina 10

Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Every day: shaving unit and hair chamber
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
for some time.
Make sure the inside of the shaving unit and the
hair chamber have been cleaned properly.
C4Rinse the outside of the appliance.
5Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.
C6Open the shaving unit again and leave it
open to let the appliance dry completely.
You can also clean the hair chamber without
water by using the brush supplied.
ENGLISH 11
4222 002 48152 08-11-2006 14:32 Pagina 11

Every six months: shaving heads
C1Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
2Clean the cutters and guards with the
brush supplied.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
3Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn it clockwise.
4Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
ENGLISH12
4222 002 48152 08-11-2006 14:32 Pagina 12

C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Charging stand
You can clean the charging stand with a moist
cloth.
Storage
C◗Put the protection cap on the shaver to
prevent damage.
C◗Store the appliance in the luxury pouch or
place the appliance in the stand to dry.
Replacement
C◗Replace the shaving heads as soon as the
shaving unit symbol starts blinking.
Replace damaged or worn shaving heads with
HQ9 Philips shaving heads only.
ENGLISH 13
4222 002 48152 08-11-2006 14:32 Pagina 13

1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button to open the
shaving unit.
C3Turn the lock anticlockwise (1) and
remove the retaining frame (2).
C4Remove the shaving heads and place new
ones in the shaving unit.
Make sure that the projections of the shaving
heads fit exactly into the recesses.
C5Put the retaining frame back into the
shaving unit (1) and turn the lock
clockwise (2).
6Close the shaving unit.
◗The shaving unit symbol will go out if you
keep the on/off button pressed for 6 seconds.
ENGLISH14
4222 002 48152 08-11-2006 14:32 Pagina 14

Accessories
The following accessories are available:
- HQ8500/HQ8000 powerplug.
- HQ9 Philips shaving heads.
- HQ110 Philips shaving head cleaner
(shaving head cleaning spray).
- HQ8010 car cord.
Environment
C◗Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this you will help to
preserve the environment.
◗Charging stand
Do not throw the battery away with the normal
household waste, but hand it in at an official
collection point.
◗Shaver
The built-in rechargeable battery contains
substances that may pollute the environment.
Disposal of the shaver battery
Remove the battery when you discard the
appliance. Do not throw the battery away with
the normal household waste, but hand it in at an
official collection point.You can also take the
appliance to a Philips service centre, which will
remove the battery for you and will dispose of it
in an environmentally safe way.
ENGLISH 15
4222 002 48152 08-11-2006 14:32 Pagina 15

Only remove the battery if it is completely empty.
1Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver.
C2Let the shaver run until it stops, undo the
screws and open the shaver.
3Remove the battery.
Do not connect the shaver to the mains again
after the battery has been removed.
Guarantee & service
If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in
your country (you will find its phone number in
the worldwide guarantee leaflet). If there is no
Customer Care Centre in your country, turn to
your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been rinsed long enough or
the water used was not hot enough.
ENGLISH16
4222 002 48152 08-11-2006 14:32 Pagina 16

◗Clean the shaver thoroughly before you
continue shaving. See chapter 'Cleaning and
maintenance'.
BCause 2: long hairs are obstructing the shaving
heads.
◗Clean the cutters and guards with the brush
supplied. See chapter 'Cleaning and
maintenance', section 'Every six months:
shaving heads'.
BCause 3: the shaving heads are damaged or worn.
◗Replace the shaving heads. See chapter
'Replacement'.
2The shaver does not work when the on/off
button is pressed.
BCause 1: the battery is empty.
◗Recharge the battery. See chapter 'Charging'.
BCause 2: the appliance is not connected to the
mains.
◗Put the powerplug in the wall socket.
C3The shaving unit has come off the shaver.
ENGLISH 17
4222 002 48152 08-11-2006 14:32 Pagina 17

BCause: the shaving unit has not been placed
correctly.
◗If the shaving unit becomes detached from the
shaver, you can easily reattach it ('click').
ENGLISH18
4222 002 48152 08-11-2006 14:32 Pagina 18

Ważne
Przed pierwszym użyciem urządzenia zapoznaj się
dokładnie z instrukcją jego obsługi i zachowaj ją na
przyszłość, do ewentualnej konsultacji.
◗W celu naładowania akumulatorów używaj
wyłącznie załączonej do urządzenia ładowarki.
◗Zasilacz przekształca napięcie 100-240V na
bezpieczne niskie napięcie niższe niż 24V.
◗Wtyczka zasilacza zawiera transformator.
Odcięcie wtyczki celem wymiany jej na nową
może spowodować niebezpieczeństwo.
◗Nie używaj uszkodzonego zasilacza.
◗Jeśli uszkodzona jest wtyczka przewodu
zasilającego, wówczas, aby uniknąć
niebezpieczeństwa należy zawsze zastąpić ją
wtyczką oryginalną
◗Sprawdź, czy zasilacz jest zupełnie suchy.
◗Ładuj i przechowuj urządzenie w
temperaturze pomiędzy 5ca 35cC.
C◗Nigdy nie zanurzaj podstawki ładującej w
wodzie ani nie spłukuj jej pod kranem.
◗Nie ładuj golarki w zamkniętej saszetce.
◗Zanim zaczniesz czyścić golarkę pod kranem,
zawsze wyjmij wtyczkę z gniazdka sieciowego.
C◗Niniejsze urządzenie spełnia międzynarodowe,
zatwierdzone normy bezpieczeństwa IEC i
można je myć pod kranem.
Postępuj ostrożnie z gorącą wodą. Zawsze
sprawdzaj, czy jej temperatura jest odpowiednia
dla kontaktu z rękami.
◗Poziom hałasu: Lc = 64 dB [A]
POLSKI 19
4222 002 48152 08-11-2006 14:32 Pagina 19

Ładowanie
Przed rozpoczęciem ładowania należy sprawdzić,
czy urządzenie jest wyłączone.
Normalne ładowanie trwa ok. 1 godziny.
Możesz także używać golarki bez ładowania,
podłączając ją bezpośrednio do sieci.
Wskaźniki ładowania
Ładowanie
C◗W momencie rozpoczęcia ładowania golarki
zaświeci się w kolorze czerwonym lampka
umieszczona w jej dolnej części. Gdy
akumulator dysponuje pojemnością
wystarczającą tylko na jedno golenie, zaczynają
kolejno migotać wszystkie lampki.
Ładowanie
C◗Po pełnym naładowaniu akumulatora świecą
się wszystkie zielone lampki.
Kilka godzin po ładowaniu golarki wszystkie
lampki zgasną.
POLSKI20
4222 002 48152 08-11-2006 14:32 Pagina 20

Pozostała pojemność akumulatora
C◗Liczba świecących się lampek wskazuje na
ilość zmagazynowanej w akumulatorze energii.
Pozostała pojemność akumulatora wyświetlana
jest po wyjęciu z gniazdka wtyczki lub po
wyłączeniu golarki.
- Gdy wszystkie lampki świecą się w kolorze
zielonym, akumulator jest naładowany w 100%.
- Gdy dolna lampka świeci się w kolorze
zielonym, oznacza to, że pozostało 20%
pojemności akumulatora.
Akumulatory wyczerpują się
C◗Gdy akumulator jest już niemal całkowicie
rozładowany, dolna lampka zaczyna świecić się
w kolorze czerwonym.
Po wyłączeniu golarki lampka ta kilkakrotnie
migocze.
Czas bezprzewodowej pracy
W pełni naładowana golarka może pracować
bezprzewodowo nie dłużej niż 80 minut.
Ładowanie urządzenia
C1Włóż małą wtyczkę przewodu zasilającego
do golarki.
2Podłącz ładowarkę do sieci.
POLSKI 21
4222 002 48152 08-11-2006 14:32 Pagina 21

3Gdy akumulator jest całkowicie
naładowany wyjmij wtyczkę z gniazdka
sieciowego i odłącz urządzenie.
Podstawka ładująca
Urządzenie można naładować również,
umieszczając je w podstawce ładującej, jeśli jest
ona dołączona do kompletu.
Nigdy nie zanurzaj podstawki ładującej w wodzie
ani nie spłukuj jej pod kranem.
C◗Umieść prawidłowo golarkę w podłączonej do
sieci elektrycznej podstawce ładującej.
Dolna lampka zaczyna świecić się w kolorze
czerwonym.
C◗Wyjmij golarkę z podstawki ładującej, nie
przechylając jej.
Wyjmowanie i zakładanie zegara.
C1Obróć zegarem w kierunku przeciwnym
do ruchu wskazówek zegara (1)
("kliknięcie") i wyjmij go (2).
C2Wsuń zegar (1) i obróć nim zgodnie z
ruchem wskazówek zegara (2)
("kliknięcie").
POLSKI22
4222 002 48152 08-11-2006 14:32 Pagina 22
