Philips HQ8865/19 User manual

ENGLISH 4
BAHASA MELAYU 16
BAHASA INDONESIA 29
TI”NG VI◊T 42
 54
64
76
87
HQ8865

Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the powerplug supplied.
◗The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
◗The powerplug contains a transformer. Do
not cut off the powerplug to replace it with
another plug, as this will cause a hazardous
situation.
◗Do not use a damaged powerplug.
◗If the powerplug is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
C◗Make sure the powerplug does not get wet.
◗Charge, store and use the appliance at a
temperature between 5cC and 35cC.
◗Always unplug the shaver before cleaning it
under the tap.
◗Do not recharge the shaver in a closed pouch.
C◗The appliance complies with the
internationally approved IEC safety regulations
and can be safely cleaned under the tap.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Charging
Make sure the appliance is switched off before
you start charging it.
ENGLISH4

When you charge the shaver for the first time or
after a long period of disuse, let it charge
continuously for 4 hours. Charging normally takes
approx. 1 hour.
You can also shave without charging by
connecting the shaver to the mains.
Do not leave the appliance connected to the
mains for more than 24 hours.
Charge indications
Charging
C◗As soon as you start charging the empty
shaver, the 20% charge indication starts
burning green.When there is sufficient power
for one shave, the 20% indication starts
blinking green.As charging continues, more
and more green charge percentage indications
go on to indicate to what level the batteries
have been charged.
Batteries fully charged
C◗When the batteries have been fully charged,
all green charge percentage indication are on.
ENGLISH 5

Remaining battery capacity
C◗As the energy level of the batteries decreases,
the number of green charge percentage
indications that are burning decreases too.
Batteries running low
C◗When the batteries are running low, the 20%
charge indication turns red.When you switch
the shaver off, the 20% charge indication
blinks red for 4 seconds.
Charging the appliance
Charge the appliance when the 20% charge
indication blinks red.
Do not recharge the shaver in a closed pouch.
C1Put the appliance plug in the shaver.
2Put the powerplug in the wall socket.
3Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver when the batteries have been
fully charged.
ENGLISH6

Cordless shaving time
A fully charged shaver has a cordless shaving time
of up to 45 minutes.
Using the appliance
Personal Comfort Control
C◗The Personal Comfort Control system allows
you to adapt the shaver to your skin type.
- You can set the shaver to 'Normal' for a fast
and comfortable close shave.
- You can set the shaver to 'Sensitive' for a
comfortable close shave with optimal skin
comfort.
C◗The …position is the neutral position.
C◗The 'S' position is best suited for sensitive
skin.
C◗The 'N' position is best suited for normal
skin.
ENGLISH 7
S
N

Shaving
1Switch the shaver on by pressing the on/off
button once.
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philishave system.
3Switch the shaver off by pressing the on/off
button once.
C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
The easiest and most hygienic way to clean the
appliance is to rinse the shaving unit and the hair
ENGLISH8

chamber with hot water every time you have
used the shaver.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
C◗For extra thorough cleaning, the Philishave
Action Clean (shaving head cleaner, type
HQ100) is available.Ask your Philishave dealer
for information.
The Philishave Action Clean may not be available
in all countries. Contact the Customer Care
Centre in your country about the availability of
this accessory.
You can also clean the shaver in the following
way:
Every day: shaving unit and hair chamber
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button (1) and open the
shaving unit (2).
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
for some time.
4Rinse the outside of the appliance.
ENGLISH 9

5Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.
C6Open the shaving unit again and leave it
open to let the appliance dry completely.
You can also clean the hair chamber without
water by using the brush supplied.
Every six months: shaving heads
C1Open the shaving unit, turn the wheel
anticlockwise (1) and remove the retaining
frame (2).
2Clean the cutters and guards with the
brush supplied.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
3Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit, press the wheel (1) and turn it
clockwise (2).
4Close the shaving unit.
ENGLISH10
1
2

Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Storage
C◗Put the protection cap on the shaver to
prevent damage.
◗The appliance can be stored in the pouch
supplied.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with
HQ8 Philishave Sensotec shaving heads only.
ENGLISH 11

1Switch the shaver off, remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button (1) and open the
shaving unit (2).
C3Turn the wheel anticlockwise (1) and
remove the retaining frame (2).
C4Remove the shaving heads and place new
ones in the shaving unit in such a way that
the parts with the small holes point
towards the centre of the shaving unit.
Make sure that the projections of the shaving
heads fit exactly into the recesses.
C5Put the retaining frame back into the
shaving unit, press the wheel (1) and turn it
clockwise (2).
6Close the shaving unit.
Accessories
The following accessories are available:
- HQ8000 powerplug.
- HQ8 Philishave Sensotec shaving heads.
- HQ100 Philishave Action Clean (shaving head
cleaner).
ENGLISH12
1
2
2
1

- HQ101 Philishave Action Clean refill (shaving
head cleaning liquid).
- HQ110 Philishave shaving head cleaner (shaving
head cleaning spray).
Environment
The built-in rechargeable batteries contain
substances that may pollute the environment.
Disposal of the batteries
Remove the batteries when you discard the
appliance. Do not throw the batteries away with
the normal household waste, but hand them in at
an official collection point.You can also take the
appliance to a Philips service centre, which will
remove the batteries for you and will dispose of
them in an environmentally safe way.
Only remove the batteries if they are completely
empty.
1Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver.
C2Let the shaver run until it stops, undo the
screws and open the shaver.
3Remove the batteries.
Do not connect the shaver to the mains again
after the batteries have been removed.
ENGLISH 13

Guarantee & service
If you need information or if you have a
problem, please visit the Philips Web site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been rinsed long enough or
the water used was not hot enough.
◗Clean the shaver thoroughly before you
continue shaving. See chapter 'Cleaning and
maintenance'.
BCause 2: long hairs are obstructing the shaving
heads.
◗Clean the cutters and guards with the brush
supplied. See chapter 'Cleaning and
maintenance', section 'Every six months:
shaving heads'.
BCause 3: the shaving heads are damaged or worn.
ENGLISH14

◗Replace the shaving heads. See chapter
'Replacement'.
2The shaver does not work when the on/off
button is pressed
BCause 1: the batteries are empty.
◗Recharge the batteries. See chapter 'Charging'.
BCause 2: the shaver is not connected to the mains.
◗Put the powerplug in the wall socket.
3The shaving unit has come off the shaver.
BCause: the shaving unit has not been placed
correctly.
◗If the shaving unit becomes detached from the
shaver, check whether the hinge spring is still
properly attached, i.e. has not come loose and
does not show any cracks or damage. If the
hinge spring is still properly attached, the
shaving unit can be easily put back on the
shaver again. However, if the hinge spring has
come loose, is cracked or damaged, please
contact your Philips dealer or the nearest
Philips service centre to avoid damage to your
shaver.
ENGLISH 15

Penting
Baca arahan penggunaan ini dengan teliti sebelum
menggunakan peralatan dan simpan untuk rujukan
di masa depan.
◗Hanya gunakan plag kuasa yang dibekalkan.
◗Plag kuasa mengubah 100-240 volt kepada
voltan rendah dan selamat tidak melebihi 24
volt.
◗Plag kuasa mengandungi sebuah transformer.
Jangan potong plag kuasa untuk
menggantikannya dengan plag yang lain kerana
ini akan menimbulkan situasi berbahaya.
◗Jangan gunakan plag kuasa yang rosak.
◗Jika plag kuasa rosak, gantikan dengan
pengganti jenis tulen untuk mengelakkan
daripada kemudaratan.
C◗Pastikan plag kuasa tidak kena basah.
◗Cas, simpan dan gunakan peralatan pada suhu
di antara 5cC dan 35cC.
◗Sentiasa cabut plag daripada pencukur
sebelum membersihkannya di bawah pili air.
◗Jangan mengecas semula pencukur di dalam
pau tertutup.
C◗Peralatan ini mematuhi peraturan keselamatan
antarabangsa IEC yang diluluskan dan selamat
dibersihkan dengan air paip.
Berhati-hati dengan air panas. Sentiasa periksa
agar air tidak begitu panas, untuk mengelakkan
tangan anda daripada kelecuran.
BAHASA MELAYU16

Mengecas
Pastikan peralatan dimatikan sebelum dicas.
Apabila anda mengecas pencukur bagi kali
pertama setelah lama tidak digunakan, biarkannya
dicas berterusan selama 4 jam. Mengecas biasanya
mengambil lebih kurang 1 jam.
Anda juga dapat bercukur tanpa mengecas,
dengan menyambung pencukur kepada punca
kuasa utama.
Jangan biarkan peralatan dipasang pada punca
kuasa utama lebih daripada 24 jam.
Arahan cas
Mengecas
C◗Sebaik saja anda mula mengecas pencukur
yang kehabisan tenaga, lampu hijau penunjuk
cas 20% akan menyala.Apabila tenaga bagi satu
pencukur telah mencukupi, lampu hijau
penunjuk 20% akan berkerlip. Selagi
pengecasan diteruskan, penunjuk peratusan
cas akan meningkat untuk menandakan tahap
bateri yang telah dicas.
BAHASA MELAYU 17

Bateri dicas penuh
C◗Apabila bateri telah dicas sepenuhnya, semua
lampu hijau penunjuk bilangan peratusan cas
akan menyala.
Baki kapasiti bateri
C◗Apabila tahap tenaga bateri berkurangan,
penunjuk bilangan peratusan cas yang menyala
hijau juga berkurangan.
Bateri lemah
C◗Apabila bateri semakin lemah, lampu merah
penunjuk bilangan peratusan akan menyala.
Apabila anda mematikan pencukur, lampu
merah penunjuk peratusan 20% akan berkerlip
selama 4 saat.
Mengecas peralatan
Cas peralatan apabila lampu merah penunjuk chas
20% berkerlip.
Jangan cas semula pencukur di dalam pau
tertutup.
C1Pasangkan plag peralatan pada alat
pencukur.
2Pasangkan plag kuasa ke soket dinding.
BAHASA MELAYU18

3Cabutkan plag kuasa dari soket dinding dan
tarik keluar plag peralatan dari pencukur
apabila bateri sudah tercas dengan
sepenuhnya.
Masa pencukuran tanpa kord
Pencukur yang dicas penuh mempunyai masa
pencukuran tanpa kord sehingga kira-kira 45
minit.
Pencukuran
Kawalan Keselesaan Peribadi
C◗Sistem Kawalan Keselesaan Peribadi
menyesuaikan pencukur dengan jenis kulit
anda.
- Anda boleh tetapkan pencukur kepada
'Normal' untuk cukuran yang cepat dan selesa.
- Anda boleh tetapkan pencukur kepada
'Sensitive' untuk cukuran selesa dengan
keselesaan kulit yang optimum.
C◗Kedudukan …ialah kedudukan neutral.
C◗Kedudukan 'S' adalah sesuai sekali untuk kulit
sensitif.
BAHASA MELAYU 19
S

C◗Kedudukan 'N' adalah sesuai sekali untuk kulit
biasa.
Pencukuran
1Hidupkan alat pencukur dengan menekan
butang hidup/mati sekali.
C2Gerakkan kepala pencukur denagn gerakan
lurus dan membulat di atas permukaan
kulit dengan pantas.
Mencukur pada muka yang kering memberikan
hasil cukuran yang terbaik.
Kulit anda mungkin memerlukan 2 atau 3 minggu
untuk membiasakan diri dengan sistem Philishave.
3Matikan pencukur dengan menekan butang
hidup/mati sekali.
C4Pasang semula penutup pelindung pada
pencukur selepas setiap penggunaan untuk
mengelakkan kerosakan.
Perapian
Untuk jambang dan kumis kemas.
C1Buka perapi dengan menekan selak ke atas.
Perapi dapat dihidupkan semasa motor berjalan.
BAHASA MELAYU20
N

Pembersihan dan penyenggaraan
Membersih alat pencukur dengan kerapkali
menjamin prestasi pencukuran terbaik.
Cara yang senang dan bersih untuk mencuci
peralatan adalah membilas unit mencukur dan
ruangan menyimpan rambut dengan air panas
setiap kali setelah anda menggunakan alat
pencukur tersebut.
Berhati-hati dengan air panas. Sentiasa periksa
agar air tidak begitu panas, untuk mengelakkan
tangan anda daripada kelecuran.
C◗Untuk pembersihan tambahan yang
menyeluruh, Philishave Action Clean
(pembersih kepala pencukur, jenis HQ100)
boleh didapati. Bertanya kepada penjual
Philishave anda untuk dapatkan maklumat.
Philishave Action Clean mungkin tidak terdapat di
semua negeri. Hubungi Pusat Khidmat Pelanggan
di negeri anda untuk mengetahui sama aksesori ini
boleh didapati.
Anda juga dapat membersihkan pencukur dengan
cara yang berikut:
Setiap hari: unit pencukur dan ruang rambut
1Matikan alat pencukur, tanggalkan plag
kuasa dari soket dinding dan cabut plag
peralatan dari pencukur.
BAHASA MELAYU 21

C2Tekan punat pelepas (1) dan buka unit
pencukur (2).
C3Bersihkan unit pencukur dan ruang rambut
dengan membilasnya di bawah paip air
panas untuk beberapa waktu
4Bilaskan bahagian luar peralatan.
5Tutup unit pencukur dan renjiskan air
berlebihan.
Jangan keringkan unit pencukur dengan tuala atau
tisu, kerana ini akan merosakkan kepala alat
pencukur.
C6Buka unit pencukur sekali lagi dan biarkan
ia terbuka supaya peralatan kering
sepenuhnya.
Anda juga boleh membersihkan ruang rambut
tanpa air dengan menggunakan berus yang
dibekalkan.
Setiap enam bulan: kepala pencukur
C1Buka unit pencukur, putar roda lawan arah
jam (1) dan tanggalkan rangka penahan (2).
2Buka unit pencukur, pusingkan roda ke
arah lawan jam (1) dan tanggalkan rangka
penahan (2).
BAHASA MELAYU22
1
2
