Philips RQ1087/21 User manual

3
H
I
J
K
L
MN
B
A
E
CD
F
G
R
Q
P
O
5

4
1 2 3 4
67 8 9
10 11 12 13
14 15 16 17
18 19 20 21

RQ1095, RQ1087, RQ1085, RQ1077, RQ1075
ENGLISH 6
 22
 40
 56
 71
 87
 103
 121
 137
 152
 168
 185
 203
 219
 234
 250

Introduction
Thank you for buying this Philips shaver. Please read this user manual, as it
contains information about the wonderful features of this shaver as well
as some tips to make shaving easier and more enjoyable.
Important
Read this user manual carefully before you use the shaver, the Jet Clean
System and the Power Pod. Save the user manual for future reference.
Danger
Make sure the adapter does not get wet (Fig. 1).
Warning
Be careful with hot water. Always check if the water is not too hot, to
prevent your hands from getting burnt.
The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
These appliances are not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliances by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliances.
Caution
Do not use the shaver, the Jet Clean System, the Power Pod or the
adapter if it is damaged.
Charge and store the shaver at a temperature between 5°C and
35°C.
Always put the protection cap on the shaver to protect the shaving
heads when you are travelling.
Never use scouring pads, abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the appliance.
Only use the adapter supplied.
If the adapter is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
-
-
-
-
-
-
-
-
-
-
-
ENGLISH6

Only use the Jet Clean System with the original HQ200 cleaning uid.
Never immerse the Jet Clean System in water nor rinse it under the
tap. (Fig. 2)
Use and store the Jet Clean System at a temperature between 5°C
and 35°C.
Always place the Jet Clean System on a stable, level and horizontal
surface to prevent leakage.
Empty the cleaning chamber and clean it thoroughly by rinsing it with
hot tap water every 15 days.
Always place the Jet Clean System on a uid-resistant surface.
The Jet Clean System thoroughly cleans but does not disinfect your
shaver, therefore do not share the shaver with others.
The cleaning chamber of the Jet Clean System is not dishwasher-
proof.
When the Jet Clean System is ready for use, do not move it to
prevent leakage of cleaning uid.
Never immerse the Power Pod in water, nor rinse it under the
tap (Fig. 3).
Compliance with standards
The shaver complies with the internationally approved IEC safety
regulations and can be safely cleaned under the tap (Fig. 4).
These Philips appliances comply with all standards regarding
electromagnetic elds (EMF). If handled properly and according to the
instructions in this user manual, the appliances are safe to use based
on scientic evidence available today.
General
The adapter transforms 100-240 volts to a safe low voltage of less
than 24 volts.
Noiselevel: Lc= 64 dB(A)
Overview (Fig. 5)
AProtection cap
BShaving unit
CTrimmer
DTrimmer on/off slide
-
-
-
-
-
-
-
-
-
-
-
-
-
-
ENGLISH 7

EShaver (RQ1090/RQ1062/RQ1060/RQ1052/RQ1050)
FShaver on/off button
GDisplay
HShaver holder
IJet Clean System (RQ1005/RQ1000)
JJet Clean System on/off button
KCleaning symbol
LDrying symbol
M’Cleaning chamber empty’ symbol
NCleaning chamber
OPower Pod
PCleaning brush
QAdapter
RSmall plug

Before you use the shaver for the rst time, remove the protective foil
from the display.
The ve shaver types (RQ1090, RQ1062, RQ1060, RQ1052 and
RQ1050) have different displays, which are shown in the gures below.
RQ1090 (Fig. 6)
RQ1062/RQ1060 (Fig. 7)
RQ1052/RQ1050 (Fig. 8)
Charging
Charging takes approx. 1 hour.
When you place the shaver in the Jet Clean System or in the Power
Pod, the display automatically switches off after approx. 5 hours.
RQ1090
When the shaver is charging, the minutes indication and the plug
symbol ash (Fig. 9).
The shaving minutes increase until the shaver is fully charged.
RQ1062/RQ1060
When the shaver is charging, the plug symbol ashes. (Fig. 10)
-
-
-
-
-
-
-
-
ENGLISH8

First the arrowheads of the bottom charge level ash, then the
arrowheads of the second level ash, and so on until the shaver is
fully charged.
RQ1052/RQ1050
When the shaver is charging, the battery symbol ashes
blue. (Fig. 11)

RQ1090
When the battery is fully charged, the minutes indication is visible on
the display and the plug symbol disappears from the display. (Fig. 12)
RQ1062/RQ1060
When the battery is fully charged, all arrowheads and all charge level
lights light up blue continuously and the plug symbol disappears from
the display (Fig. 13).
When you remove the shaver from the Jet Clean System or the
Power Pod, the arrowheads of the top charge level light up blue to
indicate that the battery is full (Fig. 14).
RQ1052/RQ1050
When the battery is fully charged, the battery symbol lights up blue c
ontinuously. (Fig. 15)

RQ1090
When the battery is almost empty (when there are only 5 or fewer
shaving minutes left), the minutes indication and the plug symbol start
to ash (Fig. 9).
When you switch off the shaver, the shaving minutes and the plug
symbol continue to ash for a few more seconds. You hear a beep
when there are no minutes left.
RQ1062/RQ1060
When the battery is almost empty (when there are only 5 or fewer
shaving minutes left), the battery symbol ashes red and the
arrowheads of the bottom charge level ash blue. (Fig. 16)
-
-
-
-
-
-
-
-
-
ENGLISH 9

When you switch off the shaver, the battery symbol and the
arrowheads of the bottom charge level continue to ash for a few
seconds.
RQ1052/RQ1050
When the battery is almost empty (when there are only 5 or fewer
shaving minutes left), the battery symbol lights up red. (Fig. 11)
When you switch off the shaver, the battery symbol starts to ash for
a few seconds.

RQ1090
The remaining battery capacity is indicated by the number of shaving
minutes shown on the display. (Fig. 12)
RQ1062/RQ1060
The remaining battery capacity is indicated by the ashing
arrowheads of a particular charge level (Fig. 14)
Clean shaver
For optimal shaving performance, we advise you to clean the shaver after
every use.
The tap symbol ashes to remind you to clean the shaver (Fig. 17).
Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look
different but show the same indication.
Replace shaving unit
For maximum shaving performance, we advise you to replace the shaving
unit every two years.
To remind you to replace the shaving unit, the shaving unit symbol
ashes (all types) and you hear a beep when you switch off the
shaver (RQ1090 only).This happens at the end of 7 successive shaves
to remind you to replace the shaving unit. (Fig. 18)
Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look
different but show the same indication.
-
-
-
-
-
-
-
ENGLISH10


You can lock the shaver when you are going to travel. The travel lock
prevents the shaver from being switched on by accident.

1 Press the on/off button for 3 seconds to enter the travel lock
mode (Fig. 19).
The lock symbol appears on the display (all types) and you hear a
beep (RQ1090 only) to indicate that the travel lock has been
activated.
Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look
different but show the same indication.

1 Press the on/off button for 3 seconds.
The motor starts running to indicate that the travel lock has been
deactivated.
The shaver is now ready for use again.
Note:When you place the shaver in the plugged-in Power Pod or Jet Clean
System, the travel lock is automatically deactivated.

If the shaving heads are blocked, the shaving unit symbol and the tap
symbol with exclamation mark ash. In this case, the motor cannot
run because the shaving heads are soiled or damaged. (Fig. 20)
Note:The displays of types RQ1062, RQ1060, RQ1052 and RQ1050 look
different but show the same indication.
When this happens, you have to clean the shaving unit or replace it.
The shaving unit symbol and the tap symbol with exclamation mark
continue to ash until you unblock the shaving heads.
Charging
Charging takes approx. 1 hour.
,
,
-
-
-
ENGLISH 11

A fully charged shaver has a shaving time of up to 65 minutes, which is
enough for approx. 21 shaves.
The actual shaving time is calculated by the shaver. If you have a heavy
beard, the shaving time may be less than 65 minutes.The shaving time
may also vary over time, depending on your shaving behaviour and beard
type.

After the shaver has charged for 5 minutes, it contains enough energy for
one shave.
Charging in the Power Pod
1 Put the small plug in the Power Pod (Fig. 21).
2 Put the adapter in the wall socket.
3 Pull at the top of the lid (1) and remove it (2) (Fig. 22).
4 First insert the top of the shaver into the Power Pod (1) and then
press the bottom part into the Power Pod (2) (Fig. 23).
Note:The shaver cannot be placed in the Power Pod when the protection cap
is on the shaving unit.
The display shows that the shaver is charging (see chapter ‘The
display’).

1 Put the small plug in the Jet Clean System.
2 Put the adapter in the wall socket.
3 Place the shaver upside down in the holder with the display
pointing towards the front of the Jet Clean System (Fig. 24).
Note: RQ1090,RQ1062,RQ1060 only: when you turn the shaver upside
down, the indications on the display are also turned upside down so you can
still see the remaining battery capacity.
4 Press the shaver tightly into the holder to lock it into place (Fig. 25).
,
ENGLISH12

Note:The shaver cannot be placed in the Jet Clean System when the
protection cap is on the shaving unit.
The display shows that the shaver is charging (see chapter ‘The
display’).

Shaving
1 Press the on/off button once to switch on the shaver.
The display lights up for a few seconds.
2 Move the shaving heads over your skin. Make both straight and
circular movements (Fig. 26).
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get accustomed to the Philips
shaving system.
3 Press the on/off button once to switch off the shaver.
The display lights up for a few seconds and then shows the
remaining battery capacity (RQ1090/RQ1062/RQ1060 only).

You can use the trimmer to groom your sideburns and moustache.
1 Pull the shaving unit off the shaver (Fig. 27).
2 Press the on/off button once to switch on the shaver.
The display lights up for a few seconds.
3 Press the trimmer slide forwards to slide out the trimmer (Fig. 28).
4 You can now start trimming.
5 Press the trimmer slide backwards to retract the trimmer.
6 Press the on/off button once to switch off the shaver.
The display lights up for a few seconds and then shows the
remaining battery capacity (RQ1090/RQ1062/RQ1060 only).
,
,
-
-
,
,
,
ENGLISH 13

7 Insert the lug of the shaving unit into the slot in the top of the
shaver (1).Then press the shaving unit downwards (2) to attach
it to the shaver (‘click’) (Fig. 29).
Cleaning and maintenance
Never use scouring pads, abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the appliance.
The best and most hygienic way to clean the shaver is in the Jet Clean
System. You can also rinse the shaver under the tap or clean it with
the brush supplied.
Be careful with hot water. Always check if the water is not too hot, to
prevent your hands from getting burnt.
Clean the shaver after every shave for optimal shaving performance.
You can clean the outside of the shaver with a damp cloth.
Regular cleaning guarantees better shaving performance.

The Jet Clean System has three cleaning programs: the eco program, the
normal program and the intensive program.The shaver automatically
chooses the appropriate cleaning program.

Fill the cleaning chamber before rst use.
1 Put the small plug in the Jet Clean System.
2 Put the adapter in the wall socket.
The holder automatically moves to the highest position.
3 Simultaneously press the release buttons on both sides of the
cleaning chamber (1).Then lift the Jet Clean System off the cleaning
chamber (2). (Fig. 30)
The cleaning chamber remains behind.
4 Unscrewthecapfromthebottlewithcleaninguidandremove
the airtight seal.
-
-
-
-
-
,
,
ENGLISH14

5 FillthecleaningchamberwithHQ200cleaninguiduptotheMAX
indication (Fig. 31).
6 Place the Jet Clean System back onto the cleaning
chamber (Fig. 32).
Make sure the release buttons click back into place.

1 Place the shaver in the holder.
The display shows that the shaver is charging (see chapter ‘The
display’) (Fig. 33).
2 Press the on/off button on the Jet Clean System to start the
cleaning program. (Fig. 34)
The shaver display stops showing the charging indication.
Thecleaninglightstartstoashandtheshaverisautomatically
loweredintothecleaninguid(Fig.35).
Thecleaninglightashesthroughoutthecleaningprogram,which
takes 4 to 6 minutes, depending on the cleaning program.
Duringtherstphaseofthecleaningprogram,theshaver
automatically switches on and off several times and moves up and
down.
During the second phase of the cleaning program, the shaver is
placedinthedryingposition,indicatedbyaashingdryingsymbol.
This phase takes approx. 2 hours.The shaver stays in this position
until the end of the program. (Fig. 36)
Afterthecleaningprogram,thechargingindicationappearsonthe
shaver display (see chapter ‘The display’).
Note: If you press the on/off button of the Jet Clean System during the
cleaning program, the program aborts and resets. In this case, the cleaning or
drying light stops ashing and the holder returns to its starting position.
Note: If you remove the adapter from the wall socket during the cleaning
program, the program aborts.The holder remains in its current position.When
you put the adapter back into the wall socket, the holder moves to the
highest position.
,
,
,
,
,
,
,
ENGLISH 15

When the uid level drops below the minimum level, the cleaning
light and the ‘cleaning chamber empty’ symbol start to ash and the
holder returns to its starting position (Fig. 37).
If you use the washing machine to clean your shaver every day, you
need to rell the cleaning chamber approx. every 15 days.

1 Simultaneously press the release buttons on both sides of the Jet
Clean System (1).Then lift the Jet Clean System off the cleaning
chamber (2). (Fig. 30)
The cleaning chamber remains behind.
2 Pouranyremainingcleaninguidoutofthecleaning
chamber. (Fig. 38)
You can simply pour the cleaning uid down the sink.
3 Rinse the cleaning chamber under the tap (Fig. 39).
The cleaning chamber is not dishwasher-proof.
4 FillthecleaningchamberwithHQ200cleaninguiduptotheMAX
indication (Fig. 31).
5 Place the Jet Clean System back onto the cleaning
chamber. (Fig. 32)
Make sure the release buttons click back into place.
You can clean the Jet Clean System with a moist cloth.
Clean the cleaning chamber every 15 days.
Cleaning the shaving unit under the tap
1 Switch off the shaver.
2 Pull open the three shaving heads one by one (Fig. 40).
3 Rinse all three shaving heads and all three hair chambers under a
hot tap for 30 seconds. (Fig. 41)
Becarefulwithhotwater.Alwayscheckifthewaterisnottoohot,to
prevent your hands from getting burnt.
-
-
,
-
-
ENGLISH16

4 Carefully shake off excess water and leave the shaving heads open
to let the shaving unit dry completely.
Never dry the shaving unit with a towel or tissue, as this may damage
the shaving heads.
Cleaning the shaving unit with the brush supplied
1 Switch off the shaver.
2 Pull open the three shaving heads one by one (Fig. 40).
3 Clean the shaving heads and the hair chambers with the brush
supplied (Fig. 42).
4 Close the shaving heads.
Cleaning the trimmer with the brush supplied
Clean the trimmer every time you have used it.
1 Switch off the shaver.
2 Press the trimmer slide forwards to slide out the trimmer (Fig. 28).
3 Clean the trimmer with the short-bristled side of the brush
supplied. Brush up and down along the trimmer teeth. (Fig. 43)
4 Switch the shaver on and off and repeat step 3.
5 Press the trimmer slide backwards to retract the trimmer.
Tip: For optimal trimmer performance, lubricate the trimmer teeth with a
drop of sewing machine oil every six months.
Storage
There are two ways to store the shaver or to take it with you when you
travel:
put the shaver in the Power Pod or in the Jet Clean system. Make
sure the protection cap is not on the shaving unit.
slide the protection cap onto the shaving unit to prevent damage to
the shaving heads (Fig. 44).
-
-
ENGLISH 17

Replacement
Replace the shaving unit when the shaving unit symbol appears on the
display. Replace a damaged shaving unit right away.
For maximum shaving performance, we advise you to replace the shaving
unit every two years.
Only replace the shaving unit with an original RQ10 Philips
arcitec Shaving Unit.
1 Pull the old shaving unit off the shaver (Fig. 27).
2 Insert the lug of the new shaving unit into the slot in the top of the
shaver (1).Then press the shaving unit downwards (2) to attach it
to the shaver (‘click’) (Fig. 29).
Ordering parts
The following parts are available:
HQ8500 adapter
RQ10 Philips arcitec Shaving Unit
HQ110 Philips Shaving Head Cleaning Spray
HQ200 Philips Cleaning Fluid
Environment
Do not throw away the appliances with the normal household waste
at the end of their life, but hand them in at an ofcial collection point
for recycling. By doing this, you help to preserve the
environment (Fig. 45).
The built-in rechargeable shaver battery contains substances that may
pollute the environment. Always remove the battery before you
discard or hand in the shaver at an ofcial collection point. Dispose of
the battery at an ofcial collection point for batteries. If you have
trouble removing the battery, you can also take the appliance to a
Philips service centre.The staff of this centre will remove the battery
for you and will dispose of it in an environmentally safe way.

Only remove the battery when you discard the shaver. Make sure the
battery is completely empty when you remove it.
-
-
-
-
-
-
ENGLISH18

1 Remove the shaver from the Power Pod or the Jet Clean System.
2 Let the shaver run until it stops.
3 Pull the shaving unit off the shaver.
4 Undo the 2 screws on the back of the shaver. (Fig. 46)
5 Insert a screwdriver between the front and back panel to open
the shaver. (Fig. 47)
6 Remove the side panels (Fig. 48).
7 Unscrew the 3 screws on the inside of the shaver and remove the
back cover (Fig. 49).
8 Pull the wires out of the motor unit and remove the
battery (Fig. 50).
Be careful, the battery strips are sharp.
Do not put the shaver back into the plugged-in Power Pod or Jet Clean
System after you have removed the battery.
Guarantee & service
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the
worldwide guarantee leaet). If there is no Consumer Care Centre in
your country, go to your local Philips dealer.
Guarantee restrictions
The shaving heads (cutters and guards) are not covered by the terms of
the international guarantee because they are subject to wear.

1 Why doesn’t the shaver shave as well as it used to?
The Jet Clean System may not have cleaned the shaver properly,
because the cleaning uid in the cleaning chamber is soiled or the
-
ENGLISH 19

cleaning uid level is too low. Clean the shaver thoroughly before you
continue shaving. If necessary, clean and rell the cleaning chamber
(see chapter ‘Cleaning and maintenance’).
The shaving heads may be damaged or worn. Replace the shaving
unit (see chapter ‘Replacement’).
2 Why doesn’t the shaver work when I press the on/off button?
The battery may be empty. Recharge the battery (see chapter
‘Charging’).
The travel lock may be activated. Press the on/off button for 3
seconds to deactivate the travel lock.
The shaving unit is soiled or damaged to such an extent that the
motor cannot run. In this case, the shaving unit symbol, the tap
symbol and the exclamation mark ash. When this happens, you have
to clean the shaving unit or replace it.
The temperature of the shaver may be too high. In this case, the
shaver does not work and the exclamation mark on the display
ashes. As soon as the temperature of the shaver has dropped
sufciently, you can switch on the shaver again.
3 Why isn’t the shaver entirely clean after I cleaned it in the Jet Clean
System?
The cleaning uid in the cleaning chamber may be soiled. Empty and
rinse the cleaning chamber.
The cleaning uid level may be too low. If the uid volume in the
cleaning chamber drops below the minimum level during the cleaning
program, the program aborts.The cleaning light and the
‘cleaning chamber empty’ symbol ash at intervals and the holder
returns to its starting position. Rell the cleaning chamber with
cleaning uid up to the MAX indication (see chapter ‘Cleaning and
maintenance’).
You may have used another cleaning uid than the original Philips
cleaning uid. Only use HQ200 cleaning uid.
4 Why doesn’t the Jet Clean System work when I press the on/off
button?
-
-
-
-
-
-
-
-
ENGLISH20

The Jet Clean System may not be connected to the mains. Put the
small plug into the Jet Clean System and put the adapter in the wall
socket.
There may not be an electrical connection between the Jet Clean
System and the shaver. Press the shaver tightly into the holder to lock
it into place.
5 Why does the operating time of the Jet Clean System vary?
The Jet Clean System has three cleaning programs: the eco program,
the normal program and the intensive program. Each of these
programs has a different operating time.The shaver automatically
chooses the appropriate cleaning program.
6 Why is the shaver not fully charged after I charged it in the Power
Pod/Jet Clean System?
You may not have placed the shaver in the Power Pod/Jet Clean
System properly. Make sure you press the shaver until it locks into
place.
-
-
-
-
ENGLISH 21

22

Благодарим ви, че купихте тази самобръсначка Philips. Прочетете
внимателно това ръководство за експлоатация, тъй като то съдържа
информация за прекрасните функции на тази самобръсначка, а също
и някои съвети, които ще направят бръсненето ви по-бързо и по-
приятно.

Преди да използвате самобръсначката, системата Jet Clean и
зарядната поставка, прочетете внимателно това ръководство за
експлоатация. Запазете го за справка в бъдеще.

Внимавайте щепселът да не се мокри (фиг. 1).

Внимавайте с горещата вода. Винаги проверявайте дали водата
не е прекалено гореща, за да предпазите ръцете си от изгаряне.
В адаптера има трансформатор. Не отрязвайте адаптера, за да го
замените с друг щепсел, тъй като това носи опасност.
Тези уреди не са предназначени за ползване от хора
(включително деца) с намалени физически възприятия или
умствени недъзи или без опит и познания, ако са оставени без
наблюдение и не са инструктирани от страна на отговарящо за
тяхната безопасност лице относно начина на използване на
уредите.
Наглеждайте децата, за да не си играят с уредите.

Не използвайте самобръсначката, системата Jet Clean, зарядната
поставка или адаптера, ако са повредени.
Зареждайте и съхранявайте самобръсначката при температури
от 5°C до 35°C.
За да предпазите бръснещите глави при пътуване, винаги
поставяйте предпазната капачка на самобръсначката.
-
-
-
-
-
-
-
-

