Philips Satinelle Ice Premium HP6501 User manual

Satinelle Ice Premium
HP6502, HP6501

2

3
11

4

HP6502,HP6501
ENGLISH 6
 17
 30
 42
 54
 65
 77
 91

6
Introduction
With your new Satinelle ICE PREMIUM you can remove unwanted hairs
quickly, easily and effectively.The combination of the ceramic epilating
system with the contour-following skin cooler and the new
sonic massaging system constitutes a revolution in epilation.Thanks to the
natural numbing effect of ice and massaging, the new Satinelle ICE
PREMIUM makes epilation more comfortable and less painful than ever.
The result is a silky-smooth skin and a hair growth reduction of up to
50%, assuming you use the appliance regularly (every 4 weeks).
The rapidly rotating epilating discs catch even the shortest hairs (down to
0.5 millimetre!) and pull them out by the roots. As a result, your skin stays
smooth for up to four weeks and regrowth is soft and downy.
General description (Fig. 1)
ASensitive area cap
BMassaging element
CEpilating head
DRelease button
EAppliance
FOn/off slide
GProtective cap of shaving head (HP6502 only)
HShaving head (HP6502 only)
ILeg skin cooler with pivoting cooling head
JInsulating sleeve for skin cooler
KAdapter
LExfoliating body puff
MCleaning brush
Important
Read this user manual carefully before you use the appliance and save it
for future reference.
Check if the voltage indicated on the adapter corresponds to the
local mains voltage before you connect the appliance.
Only use the appliance in combination with the adapter supplied.
,
,
ENGLISH

Do not use the appliance if the adapter or the appliance itself is
damaged.
If the adapter is damaged, always have it replaced with one of the
original type in order to avoid a hazard.
The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
Keep the appliance and the adapter dry.
Keep the appliance out of the reach of children.
Do not expose the appliance to temperatures lower than 5°C or
higher than 35°C.
To prevent damage and injuries, keep the running appliance away
from your scalp hair, eyebrows, eyelashes, clothes, threads, cords,
brushes etc.
Do not use the epilating head on irritated skin or skin with
varicose veins, rashes, spots, moles (with hairs) or wounds without
consulting your doctor rst. People with a reduced immune
response or people who suffer from diabetes mellitus, Raynaud’s
disease or immunodeciency should contact their doctor rst.
Always check the shaving head before you use the appliance. Do
not use the shaving head if the foil or the trimmers are damaged, as
this may cause injury.
Noise level: Lc = 75.8dB [A]

This Philips appliance complies with all standards regarding
electromagnetic elds (EMF). If handled properly and according to
the instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.
Preparing for use
Freezing the skin cooler
1 Put the skin cooler WITHOUT the insulating sleeve in the freezer
or freezing compartment (***) at least 4 hours before you start to
epilate. When the uid has turned completely blue, the skin cooler
is ready for use.
,
,
,
,
,
,
,
,
,
,
ENGLISH 7

Make sure the outside of the skin cooler is completely dry before you
freeze it.
Tip:You can store the skin cooler in the freezer permanently.

General information about epilation
Epilation is easier just after a bath or shower. Make sure your skin
is completely dry when you start to epilate.
When you use the appliance for the rst time, we advise you to try
it out on an area with only light hair growth.This helps you get
accustomed to the epilation process.
For optimal epilating results, the hairs should not be longer than 10
millimetres (Fig. 2)
To epilate longer hairs: (Fig. 2)
shorten the hairs to a maximum length of 10mm with a trimmer. In
this case, you can start to epilate right away.
shave the hairs completely. In this case you can start to epilate after a
few days (the hairs must be at least 0.5mm long).
Your skin may become a little red and irritated the rst few times
you use the epilator.This phenomenon is absolutely normal
and quickly disappears.As you use the appliance more often, your
skin gets used to epilation, skin irritation decreases and
regrowth becomes thinner and softer. If the irritation has not
disappeared within three days, we advise you to consult a doctor.
We advise you to epilate before you go to bed at night, as
this allows any skin irritation that may develop to diminish
overnight.
Epilating with the skin cooler
Make sure your skin is clean, entirely dry and free from grease. Do not
use any cream before you start to epilate.
1 Slide the insulating sleeve onto the skin cooler. (Fig. 3)
,
,
,
,
-
-
,
,
ENGLISH8

The insulating sleeve prevents an unpleasant sensation of coldness in your
hand while you use the appliance. It also keeps the skin cooler cold as
long as possible.
Sometimes the pivoting cooling head freezes onto the skin cooler and
does not move when you take the skin cooler from the freezer.The
pivoting cooling head starts to pivot again after you have passed it over
your leg a few times.
2 Snap the appliance onto the skin cooler (Fig. 4).
3 Insert the appliance plug into the bottom of the appliance and put
the adapter in the wall socket.
4 Select the desired speed to switch on the appliance (Fig. 5).
Select speed I for areas with little hair growth and for areas where bones
are located directly beneath the skin, such as knees and ankles.
Select speed II for larger areas with stronger hair growth.
5 Stretch your skin with your free hand to make the hairs stand
upright.
6 Place the appliance perpendicularly onto the skin with the epilating
head pointing forward. Move the appliance against the direction of
hair growth at a moderate speed. (Fig. 6)
Make sure both the epilating discs and the skin cooler are in proper
contact with the skin.
Press the appliance lightly onto the skin.
If you are not completely satised with the epilation result, try
moving the epilator more slowly over your skin.
7 Use the tab on the bottom end of the appliance to remove the
appliance from the skin cooler (Fig. 7).
Epilating without skin cooler
If you do not want to use the skin cooler, for instance because you
have grown accustomed to the sensation of epilation, you can also
use the appliance without the skin cooler.
Make sure that you place the epilator perpendicularly onto your
skin and that you move it against the direction of hair growth.
,
,
,
ENGLISH 9

Epilating the underarms and bikini line
Your epilator comes with a sensitive area cap that reduces the number of
active epilating discs.This makes the appliance ideal for epilating the more
delicate areas of the body, such as the underarms and bikini line.
Note:You get the best results when the hairs are not too long (max.1cm).
1 Put the sensitive area cap on the epilating head (Fig. 8).
The sensitive area cap can only be tted onto the appliance in one way.
2 Switch on the appliance by selecting the desired speed. (Fig. 5)
We advise you to use speed II.
3 Stretch the skin with your free hand.
4 Place the appliance perpendicularly onto your skin, with the on/off
slide pointing in the direction in which you are going to move the
appliance (Fig. 6).
5 Move the appliance slowly over the skin, against the direction of
the hair growth (Fig. 6).
Epilate your bikini line as shown in the gure (Fig. 9).
Epilate your underarms as shown in the gure (Fig. 10).
For a cool sensation, you can dab the area you have just epilated with
a cloth soaked in cold water.
6 Remove the sensitive area cap from the epilator after use (Fig. 11).

Use the exfoliating body puff in the shower.
Regular massages with the puff may help to prevent ingrown hairs. Do
not use the puff immediately before or after epilation.

You can use the shaving head to shave sensitive body parts, such as your
underarms and bikini line.With the shaving head, you obtain a smooth
result in a comfortable and gentle way.
1 Make sure the appliance is switched off.
-
-
-
ENGLISH10

2 Remove the skin cooler (Fig. 7).
3 Remove epilating head (Fig. 12).
Press the release button (1) and move the epilating head in the direction
of the arrow (2).
4 Place the shaving head on the appliance and press it onto the
appliance until it snaps home (‘click’) (Fig. 13).
5 Switch on the appliance by selecting speed II.
6 Place the shaving head onto your skin and move the appliance
slowly and smoothly against the direction of hair growth. Press the
appliance lightly (Fig. 14).
Cleaning and maintenance
Never rinse the adapter or the appliance itself with water.
Do not use any corrosive detergents, scouring pads or cloths, petrol,
acetone etc. to clean the appliance.
1 Make sure the appliance is switched off and unplugged.
2 Remove the skin cooler from the appliance and slide the insulating
sleeve off the skin cooler.
3 Clean the pivoting cooling head of the leg skin cooler with the
brush supplied or with a moist cloth after each use.
Make sure the outside of the skin cooler is completely dry before
you freeze it again.
Cleaning the epilating head
Clean the epilating head after every use.
1 Make sure the appliance is switched off and unplugged.
2 Remove the epilating head (Fig. 12).
Press the release button (1) and move the epilating head in the direction
of the arrow (2).
3 Remove the massaging element (Fig. 15).
ENGLISH 11

4 Clean all accessible parts, including the bottom of the epilating head
and the epilating discs, with the brush (Fig. 16).
5 You can also rinse the epilating head (not the appliance!) under the
tap to clean it more thoroughly (Fig. 17).
Never try to detach the epilating discs from the epilating head.
6 Reattach the massaging element to the epilating head.Then place
the epilating head on the appliance and press it until it snaps home
(‘click’) (Fig. 18).
The epilating head only ts onto the appliance in one way.

Clean the shaving head after every use.
1 Make sure the appliance is switched off and unplugged.
2 Remove the shaving head.
3 Pull the cutter unit out of the shaving head. (Fig. 19)
4 Brush the hairs off the cutter unit and the shaving head. Make sure
that you also brush away any hairs that have collected under the
trimmers (Fig. 20).
5 You can also rinse the cutter unit and the rest of the shaving head
(not the appliance!) under the tap (Fig. 21).
6 Put the cutter unit back into the shaving head and snap the shaving
head back onto the appliance (‘click’) (Fig. 22).
Do not exert pressure on the shaving foil to avoid damage.
7 Rub a drop of sewing machine oil onto the trimmers and shaving
foil of the shaving unit twice a year.
Storage
1 Put the protective cap on the shaving head (‘click’). (Fig. 23)
2 Store the appliance and the accessories in the pouch.
ENGLISH12


If you use the shaving head several times a week, replace the shaving foil
and the cutter unit (type HP6193) after one or two years of use or if it is
damaged.
Environment
Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the
environment (Fig. 24).
Guarantee & service
If you need information or if you have a problem, please visit the Philips
website at www.philips.com or contact the Philips Customer Care
Centre in your country (you nd its phone number in the worldwide
guarantee leaet). If there is no Customer Care Centre in your country,
go to your local Philips dealer or contact the Service Department of
Philips Domestic Appliances and Personal Care BV.

Problem Possible cause Solution
Reduced
epilating
performance.
You moved the
epilator in the
wrong direction.
Move the appliance against the
direction of hair growth.
You placed the
epilating
head on the
skin at the
wrong angle.
Make sure you place the appliance
perpendicularly onto the skin.
-
ENGLISH 13

Problem Possible cause Solution
The epilating
head did not
touch the skin.
Make sure both the epilating head
and the skin cooler are in proper
contact with your skin during
epilation.
You moistened
your skin with
water or a
cream or other
skincare
product prior to
epilation.
Make sure your skin is entirely dry
and free from grease. Do not put
any cream, body milk or other
skincare product on your skin
before you start to epilate.
The sensitive
area cap was on
the appliance
when you
epilated your
legs.
Only use the sensitive area cap to
epilate your underarms and bikini
line.
The appliance
has been
moved over the
skin too fast.
Move the appliance over the skin
at a moderate speed.
The appliance
does not work.
The socket to
which the
appliance is
connected is
not live.
Make sure the socket you use is
live. If you use a socket in a
bathroom cabinet, you may need
to switch on the light to activate
the socket.
The appliance is
not switched
on.
Switch on the appliance.
ENGLISH14

Problem Possible cause Solution
You did not
attach the
epilating
head correctly.
Place the epilating head on the
appliance and press it onto the
appliance until it snaps home
(‘click’).
Skin irritation
occurs.
You used the
epilator for the
rst time or
after a long
period of disuse.
Some skin irritation may occur the
rst few times you use the
appliance.This is absolutely normal
and usually disappears quickly. For
tips to reduce skin irritation, see
the rst section of chapter ‘Using
the appliance’. Also make sure you
keep the epilating head clean.
You have
applied too
much pressure
to the appliance
Do not use any pressure when
moving the appliance over skin
The skin cooler
is not cold
enough.
You did not
freeze the skin
cooler long
enough.
Put the skin cooler without the
insulating sleeve in the freezer or
freezing compartment (***) for at
least 4 hours.When the colour of
the uid has changed from white
to completely blue, the skin cooler
is ready for use.
You did not put
the skin
cooler in the
freezer or
freezing
compartment.
Put the skin cooler without the
insulating sleeve in the freezer or
freezing compartment (***) for at
least 4 hours. Do not store the
skin cooler in the refrigerator.
The skin cooler
did not touch
the skin.
Make sure the skin cooler is
always in proper contact with your
skin during epilation.
ENGLISH 15

Problem Possible cause Solution
The pivoting
cooling head of
the leg skin
cooler does
not move.
The pivoting
cooling head is
frozen.
Pass the skin cooler over your leg
a few times to make it pivot again.
Always make sure the outside of
the skin cooler is completely dry
before you freeze it.
It is not
possible to
remove the
epilating head.
You did not
move the
epilating head in
the right
direction.
Press the release button and move
the epilating head in the direction
of the arrow to remove it. (Fig. 12)
It is not
possible to
remove the
shaving head
(HP6502 only).
You did move
the shaving
head in the right
direction.
Press the release button and move
the shaving head in the direction
of the arrow to remove it. (Fig. 12)
Reduced
shaving
performance
(HP6502 only).
The shaving
head is dirty.
Switch off the appliance, unplug it
and remove the shaving head.
Then clean the cutter unit and the
shaving head with the cleaning
brush supplied. Remove any hairs
that are stuck under the trimmers.
The cutter unit
is damaged or
worn.
Replace the cutter unit.
Stronger skin
irritation than
usual after
shaving
(HP6502 only).
The cutter unit
is damaged or
worn.
Replace the cutter unit.
ENGLISH16

17

С новия Satinelle ICE PREMIUM можете да отстранявате нежеланите
косми бързо, лесно и ефикасно. Съчетанието от керамична
епилираща система със следващия контура охладител за кожа и
новата ултразвукова масажираща система представлява революция в
епилацията. Благодарение на естествения замразяващ ефект на леда
и на масажирането, новият Satinelle ICE PREMIUM прави епилацията
по-удобна и по-малко болезнена от когато и да било. Резултатът е
копринено гладка кожа и намаляване на растежа на космите до 50%,
ако използвате уреда редовно (на всеки 4 седмици).
Бързо въртящите се епилиращи дискове улавят дори и най-късите
косъмчета (до половин милиметър!) и ги изтръгват от корен. В
резултат на това кожата ви остава гладка до четири седмици, а
наново поникналите косми са меки и мъхообразни.

A Капаче за чувствителни зони
B Масажиращ елемент
C Епилираща глава
D Бутон за освобождаване
E Уред
F Плъзгач включване/изключване
G Предпазно капаче на бръснещата глава (само за HP6502)
H Бръснеща глава (само за HP6502)
I Охлаждаща приставка за кожата на краката с подвижна
охлаждаща глава
J Изолиращ капак за охлаждащата приставка.
K Адаптер
L Ексфолиращо пухче за тяло
M Четка за почистване

Преди да използвате уреда, прочетете внимателно това
ръководство за експлоатация и го запазете за справка в бъдеще.


Преди да свържете уреда, проверете дали напрежението,
посочено върху адаптера, отговаря на това на местната
електрическа мрежа.
Използвайте уреда само в съчетание с приложения към него
адаптер.
Не използвайте уреда, ако са повредени адаптерът или самият
уред.
С оглед на предотвратяване на злополука, винаги заменяйте
повредения адаптер само с оригинален такъв.
В адаптера има трансформатор. Не отрязвайте адаптера, за да
го замените с друг щепсел, тъй като това носи опасност.
Пазете уреда и адаптера от влага.
Дръжте уреда извън обсега на деца.
Не излагайте уреда на температури, по-ниски от 5°C или по-
високи от 35°C.
За да избегнете повреди и наранявания, дръжте работещия
уред далече от косата си, веждите, миглите, от дрехи, влакна,
конци, четки и др.
Не използвайте епилиращата глава върху възпалена кожа или
кожа с разширени вени, обриви, петна, бенки (с косми) или
рани без предварителна консултация с лекар. Лица с отслабен
имунитет или страдащи от захарен диабет, хемофилия или
имунна недостатъчност също трябва предварително да се
консултират с лекар.
Преди употреба на уреда винаги проверявайте бръснещата
глава. Не използвайте бръснещата глава, ако пластината или
бръснещите елементи са повредени, тъй като това може да
доведе до нараняване.
Ниво на шума: Lc = 75,8 dB [A]

Този уред Philips е в съответствие с всички стандарти по отношение
на електромагнитните излъчвания (EMF). Ако се употребява
правилно и съобразно напътствията в Ръководството, уредът е
безопасен за използване според наличните досега научни факти.
,
,
,
,
,
,
,
,
,
,
,
,
18



1 Поставете охладителя за кожа БЕЗ изолиращия капак във
фризера или отделението за замразяване (***) поне за 4 часа,
преди да започнете епилацията. Когато течността стане
напълно синя, охладителят за кожа е готов за използване.
Преди да го замразите, проверете дали външната страна на
охладителя за кожа е съвсем суха.
Съвет: Можете да държите охлаждащата приставка постоянно във
фризера.


Епилацията се прави по-лесно непосредствено след като сте
взели вана или душ. Кожата ви трябва да е напълно суха, преди
да започнете епилацията.
Когато използвате уреда за пръв път, съветваме ви да опитате
върху област със слабо окосмяване. Това ще ви помогне да
свикнете с процеса на епилация.
С оглед на най-добър резултат при епилация космите не трябва
да са по-дълги от 10 милиметра (фиг. 2)
За епилиране на по-дълги косми: (фиг. 2)
скъсете космите с машинка за подстригване до максимална
дължина от 10 мм. В такъв случай ще можете да започнете
епилацията веднага.
обръснете космите докрай. В този случай ще можете да
започнете епилацията след няколко дни (космите трябва да са с
дължина не по-малко от 0,5 мм).
При първите няколко използвания на епилатора кожата ви
може малко да се зачерви и възпали. Това явление е абсолютно
нормално и бързо ще изчезне. Като използвате уреда по-често,
кожата ви ще свикне с епилацията, възпалението ще намалее, а
наново поникналите косми ще станат по-тънки и по-меки. Ако
,
,
,
,
-
-
,
 19

възпалението не изчезне до три дни, съветваме ви да се
консултирате с лекар.
Съветваме ви да правите епилацията вечер преди лягане, тъй
като това ще позволи евентуалното възпаление на кожата да
намалее до другия ден.

Кожата ви трябва да е чиста, съвсем суха и неомазнена. Не
използвайте никакъв крем, преди да започнете епилацията.
1 Затворете с приплъзване изолиращия капак на охладителя за
кожа. (фиг. 3)
Изолиращият капак предотвратява неприятното усещане на студ в
ръката ви, когато използвате уреда. Същевременно това запазва
охлаждащата приставка за кожа студена колкото е възможно по-
дълго време.
Понякога подвижната охлаждаща глава може да замръзне върху
охладителя за кожа и да не се движи, когато извадите охладителя от
фризера. Подвижната глава ще започне отново да се върти, след
като я прекарате няколко пъти по крака.
2 Поставете с щракване уреда върху охладителя за кожа (фиг. 4).
3 Поставете щекера в гнездото отдолу на уреда и включете
адаптера в мрежов контакт.
4 Включете уреда, като изберете желаната скорост (фиг. 5).
Изберете скорост І за области със слабо окосмяване и области, в
които костите са непосредствено под кожата, например колена и
глезени.
Изберете скорост ІІ за по-големи области с повече окосмяване.
5 Опънете кожата с една ръка, за да се изправят космите.
6 Поставете уреда перпендикулярно върху кожата, като
епилиращата глава сочи напред. Движете го срещу посоката на
растежа на космите при умерена скорост. (фиг. 6)
Погрижете се както епилиращите дискове, така и охладителят за
кожа да са в добър контакт с кожата.
,
20
