Philips HC9550 User manual
HC9450
1
8
7
9
10
11
12
13
65
2
4
3
14
1
4
Introduction
Congratulations on your purchase and welcome to Philips!
www.philips.com/welcome.
General description (Fig. 1)
1 Cutting unit
2 Memory button
3 Touch area
4 On/off button
5 Length setting lock
6 Charging light
7 Memory settings
8 Display
9 Trimming comb 1-7mm
10 Trimming comb 7-24mm
11 Trimming comb 24-42mm
12 Adapter
13 Small plug
14 Cleaning brush
Important
Read this user manual carefully before you use the appliance and save it for
future reference.
Danger
- Keep the appliance and the adapter dry.
Warning
- The adapter contains a transformer. Do not cut off the adapter to
- This appliance can be used by children aged from 8 years and above
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and if
the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
Caution
-
nor rinse it under the tap.
- Always check the appliance before you use it.
-
as this may cause injury.
- Always replace a damaged adapter or part with one of the original
type.
- Only use this appliance for its intended purpose as shown in the user
manual.
-
aggressive liquids such as petrol or acetone to clean the appliance.
ENGLISH
This Philips appliance complies with all applicable standards and regulations
General
- The appliance is equipped with an automatic voltage selector and is
suitable for mains voltages ranging from 100 to 240 volts.
- The adapter transforms 100-240 volts to a safe low voltage of less than
24 volts.
Charging
period of disuse.
of up to 120 minutes.
Charging indications
Battery low indication
-
Charging
-
Battery fully charged
-
continuously.
Charging the appliance
1 Make sure the appliance is switched off.
2 Insert the small plug into the appliance.
3 Put the adapter in the wall socket.
4 After charging, remove the adapter from the wall socket and pull the
small plug out of the appliance.
ENGLISH 5
Optimising the lifetime of the rechargeable battery
use it until the battery is completely empty. Continue to use the appliance
until the motor almost stops operating during a session.Then recharge the
battery. Follow this procedure at least twice a year.
Using the appliance
The hair length settings are indicated in millimeters.The settings
correspond to the remaining hair length after trimming.
too fast. Make smooth and gentle movements.
Using the display
This appliance has a swipe and tap display that you can use in three
different ways:
through the length settings quickly.
through the length settings slowly.
3 Tap on the bottom or top part of the touch area to go through
the length settings one by one.To scroll through the length settings
of the touch area.
ENGLISH6
Trimming with comb
There are 3 different combs:
- 1-7mm
- 7-24mm
- 24-42mm
1 Attach one of the combs to the appliance.
2 Swipe upwards or downwards to select the desired length setting.
3 Switch on the appliance.
4 To trim most effectively, move the trimmer against the hair growth
direction. Make sure that the surface of the comb always stays in
contact with the skin.
ENGLISH 7
Trimming without comb
Use the trimmer without the trimming comb to trim hair close to the skin
(0.5mm) or to contour the neckline and sideburns.
Be careful when you trim without comb because the cutting
element removes every hair it touches.
1 Push the comb off the appliance.
2 Switch on the appliance.
3 Touch the hair lightly with the trimmer. Make well-controlled
movements.
Features
Memory
The appliance has a memory which allows you to save three frequently
used length settings for each comb. Each comb has different length ranges.
Saving a setting
1 Swipe upwards or downwards to select the desired length setting.
2 To enter the memory, press the ‘M’ button for 2 seconds.
,
2 sec.
ENGLISH8
3 To save a length setting as number 1, 2 or 3 of the memory, press the
‘M’ button for 2 seconds.
,The display shows the word ‘SEt’ when the length setting is correctly
saved. Memory setting number 1,2 or 3 lights up continuously.
Selecting a memory setting
1 To enter the memory, press the ‘M’ button once.
,
Length setting lock
This feature prevents accidental changing of the length setting during
is activated.You can only change the length setting if you switch off the
appliance.
1 Swipe upwards or downwards to select the desired length setting.
2 Switch on the appliance.
,
anymore.
2 sec.
ENGLISH 9
Cleaning
Never use scouring pads, abrasive cleaning agents or aggressive liquids
such as alcohol, petrol or acetone to clean the appliance.
Never immerse the appliance in water or rinse it under the tap.
1 Make sure the appliance is switched off and disconnected from the
mains.
2 Wipe the housing of the appliance with a dry cloth.
3 Remove the comb and clean it with the brush.
4 Press the release button (1).The cutting unit comes off the appliance
(2).
5 Clean the cutting unit with the brush.
6 Clean the inside of the appliance with the cleaning brush.
Never immerse the appliance in water or rinse it under the tap.
1
2
ENGLISH10
7 Insert the lug of the cutting unit into the guiding slot (1) and push
the cutting unit back onto the appliance (2).
Replacement
Only replace a worn or damaged cutting unit with an original Philips cutting
1 Press the release button (1).The cutting unit comes off the appliance
(2).
2 Insert the lug of the new cutting unit into the guiding slot (1) and
push the cutting unit onto the appliance (2).
Ordering accessories
www.shop.philips.com/service
or go to your Philips dealer.You can also contact the Philips Consumer
contact details).
1
2
1
2
1
2
ENGLISH 11
Recycling
- This symbol on a product means that the product is covered by
European Directive 2012/19/EU.
- This symbol means that the product contains a built-in rechargeable
battery covered by European Directive 2006/66/EC which cannot be
disposed of with normal household waste.We strongly advise you to
centre to have a professional remove the rechargeable battery.
- Inform yourself about the local separate collection system for electrical
and electronic products and rechargeable batteries. Follow local
rules and never dispose of the product and rechargeable batteries
with normal household waste. Correct disposal of old products and
rechargeable batteries helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery if it is completely empty.
1
operate until the motor stops.
2 Press the release button (1) and remove the cutting unit (2).
3 Insert the screwdriver between the motor unit and the back panel of
the appliance. Press down the screwdriver as far as it will go.
4 Tilt the handle of the screwdriver downwards (1) and separate the
back panel from the appliance (2).
1
2
2
1
ENGLISH12
5 Remove the side panels. Pull the bottom part of the printed circuit
board with the rechargeable battery attached from the appliance.
6 Cut the wires to separate the rechargeable battery from the
appliance.
Guarantee and support
www.philips.com/
support
ENGLISH 13
14
Introduktion
Tillykke med dit køb og velkommen til Philips!
produkt på www.philips.com/welcome.
1 Skærhoved
2 Hukommelsesknap
3 Berøringsfølsomt område
4 On/off-knap
5 Længdeindstillingslås
6 Opladeindikator med lys
7 Hukommelsesindstillinger
8 Display
9 Trimmerkam (1-7 mm)
10 Trimmerkam (7-24 mm)
11 Trimmerkam (24-42 mm)
12 Adapter
13 Lille stik
14 Rensebørste
Vigtigt
Fare
- Både apparat og adapter skal holdes tørre.
Advarsel
- Adapteren indeholder en transformer. Adapteren må ikke klippes af og
- Dette apparat kan bruges af børn fra 8 år og op og personer med
ikke lege med apparatet. Rengøring og brugervedligeholdelse må ikke
foretages af børn uden opsyn.
Forsigtig
- Dette apparat er ikke vaskbart. Apparatet må aldrig kommes ned
i vand eller skyldes under vandhanen.
-
-
- Udskift altid en beskadiget adapter eller del med en tilsvarende original
type.
- Brug kun apparatet til det tilsigtede formål som vist i
brugervejledningen.
-
DANSK
Elektromagnetiske felter (EMF)
Dette Philips-apparat overholder alle branchens gældende standarder og
regler angående eksponering for elektromagnetiske felter.
Generelt
- Apparatet er udstyret med automatisk spændingstilpasning til
netspændinger mellem 100 og 240 volt.
- Adapteren omformer 100 - 240 Volt til en sikker lavspænding under
24Volt.
Opladning
den ikke har været brugt i en længere periode.
120 minutter.
Opladeindikator
Indikator for lavt batteriniveau
-
blinke orange.
Opladning
-
Batteri fuldt opladet
-
Opladning
1 Kontroller, at apparatet er slukket.
2 Sæt det lille stik i apparatet.
3 Slut adapteren til stikkontakten.
4 Efter opladning skal du tage adapteren ud af stikkontakten og tage
det lille stik ud af apparatet.
DANSK 15
Optimering af det opladelige batteris levetid
næsten holder op med at køre under en behandling. Genoplad derefter
batteriet. Følg denne procedure mindst to gange om året.
Sådan bruges apparatet
Hårlængdeindstillingerne er angivet i millimeter. Indstillingerne svarer til
hårets længde efter trimningen.
Vær forsigtig, første gang du trimmer.Trimmeren skal ikke bevæges for
hurtigt – kun i langsomme og rolige bevægelser.
Anvendelse af displayet
måder:
igennem længdeindstillingerne.
langsomt igennem længdeindstillingerne.
3 Tryk på nederste eller øverste del af touchområdet for at gå
igennem længdeindstillingerne én ad gangen. Hold den nederste og
øverste del af touchområdet nede for at rulle automatisk igennem
DANSK16
Trimning med kam
Der er 3 forskellige trimmerkamme:
- 1-7 mm
- 7-24 mm
- 24-42 mm
1 Sæt én af trimmerkammene i apparatet.
2 Stryg op eller ned for at vælge den ønskede længdeindstilling.
3 Tænd for apparatet.
4
i kontakt med huden.
DANSK 17
Trimning uden kam
Brug trimmeren uden trimmerkammen til ekstra kort trimning tæt mod
Vær meget forsigtig ved trimning uden kam, da skærhovedet fjerner
1 Skub kammen af apparatet.
2 Tænd for apparatet.
3
kontrollerede bevægelser.
Funktioner
Memory
ofte anvendte længdeindstillinger for hver trimmerkam. Hver kam har
forskellige længdeafstande.
Lagring af en indstilling
1 Stryg op eller ned for at vælge den ønskede længdeindstilling.
2
,Nummer 1 begynder at blinke.
2 sec.
DANSK18
3
,
Hukommelsesindstillingsnummer 1, 2 eller 3 lyser konstant.
Valg af en hukommelsesindstilling
1
,Nummer 1 begynder at blinke.
Længdeindstillingslås
Denne funktion forhindrer utilsigtet ændring af længdeindstillingen
slukker for apparatet.
1 Stryg op eller ned for at vælge den ønskede længdeindstilling.
2 Tænd for apparatet.
,
længdeindstillingen.
2 sec.
DANSK 19
Rengøring
benzin eller acetone til rengøring af apparatet.
1 Kontrollér, at apparatet er slukket, og at stikket er taget ud af
stikkontakten.
2 Tør apparatets ydersider af med en tør klud.
3
4
5 Rengør skærenheden med børsten.
6 Rengør apparatets inderside med rensebørsten.
1
2
DANSK20
This manual suits for next models
3
Table of contents
Languages:
Other Philips Hair Clipper manuals
Philips
Philips QC5090 User manual
Philips
Philips QC5580/13 User manual
Philips
Philips Headgroom QC5572/15 User manual
Philips
Philips HC7462/15 User manual
Philips
Philips Norelco QC5130 User manual
Philips
Philips HC5100 User manual
Philips
Philips Norelco QC5510 User manual
Philips
Philips QC5340/40 User manual
Philips
Philips HQ-C 280 User manual
Philips
Philips ProStyler 7 User manual
Philips
Philips QC5570 User manual
Philips
Philips HC3420 User manual
Philips
Philips QT4005 User manual
Philips
Philips HC5410/15 User manual
Philips
Philips QC5045 User manual
Philips
Philips HC9450/20 User manual
Philips
Philips Norelco QC5055 User manual
Philips
Philips HC3412/15 User manual
Philips
Philips QT4045 User manual
Philips
Philips QC5340 User manual
