Philips HQ-C 280 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Hair clipper
HQ-C 280
PRODUCT INFORMATION
Features :
- Adjustable attachment comb for even cutting result.
- 7 hair length settings from 4 to 21 mm.
- Maintenance free cutting element; no oiling required.
- Width cutting unit 32 mm.
- Rechargeable for cordless operation.
- Mains operation possible for trimming when batteries are empty.
- AC/DC adapter.
- Charging time ( empty →full ) 12 hours.
- Operation time ( full →empty ) 30 minutes.
4322 277 00041
99/11
PCS 101 333
Product meets the requirements regarding
interference suppression on radio andTV.
!Service
Information

PCS 101 333
DISASSEMBLY ADVICE + EXPLODED VIEW + PARTS LIST HQ-C 280
TO REPLACE
BATTERY (6)
Remove styling comb (2)
Remove cutter (1)
Remove trimmer clamp (5)
Remove screw “A”
Open housing
Dimensions screw A : 2.2 x 6
Pos Description Service code
Cutter
Adjustable comb
Cleaning brush
Styling comb
Trimmer clamp, cutter (1) included
Battery (NiCd)
AC/AD adapter EURO
AC/AD adapter UK
AC/AD adapter USA
AC/AD adapter CDN
AC/AD adapter JPN
AC/AD adapter AUS
AC/AD adapter TWN
AC/AD adapter KOR
Scissors
Dir. for use: D, I, P, UK, F
Dir. for use: N, S, SF, DK, NL
Dir. for use: E, P, Arab, Gr,TR
1
2
3
4
5
6
7
8
4822 690 10212
4822 690 10203
4822 479 30183
4822 690 30433
4822 310 11351
4822 138 10336
4822 690 30441
4822 690 30442
4822 690 30443
4822 690 30444
4822 219 10148
4822 219 10149
4822 219 10151
4822 219 10152
4822 690 30434
4203 035 72050
4203 035 72060
4203 035 72070
TO REPLACE
TRIMMER CLAMP (5)
3
4
8
1
52
6
7
