Philips ProStyler 7 User manual

HOME HAIR CUTTING KIT
888
RECHARGEABLE
& CORDED
884
RECHARGEABLE
& CORDED
ProStyler
ProStyler
7
7
ProStyler
ProStyler
8
8
Mode d’emploi
Conseils & Coiffures
Instructions for use
Modelling & Styling
Mode d’emploi
Conseils & Coiffures
Instructions for use
Modelling & Styling

2

3
1234
5678
910 11 12
13 14 15 16
17 18

4

DIRECTIONS FOR USE
ENGLISH 6
DEUTSCH 12
NORSK 18
SVENSKA 24
SUOMI 30
DANSK 36
STYLING BOOKLET
ENGLISH 44
DEUTSCH 51
NORSK 59
SVENSKA 66
SUOMI 73
DANSK 80
HQC888, HQC884

Introduction
◗Dear customer, you have made the right choice!Your new Philips
3D Hair Clipper adapts to the contours of the head and enables
comfortable use.
◗To enjoy using this Philips 3D hair clipper for a long time, we
advise you to read the following information.
◗In the enclosed booklet 'Modelling and Styling' and on the
interactive instruction CD-ROM you can find instructions and
many useful tips on how to create the haircut you want.
Important
Appliance
◗Keep the appliance and the adapter dry.
◗Check if the voltage indicated on the mains plug corresponds to
the mains voltage in your home before you connect the
appliance.
◗This appliance is suitable for mains voltages from 220 to 240
Volts.
◗Only use the adapter supplied to charge the appliance.
◗The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this will cause a hazardous
situation
◗If the adapter is damaged, always have it replaced by one of the
original type in order to avoid a hazard.
◗Use, charge and store the appliance at a temperature between
15cand 35c.
◗Keep the appliance out of the reach of children.
◗This appliance is only intended for clipping human hair. Do not
use it for any other purpose.
Charging
Charge the appliance for 12 hours (HQC888)/ 8 hours (HQC884)
before you start using it for the first time.
A fully charged appliance has a cordless clipping time of up to 50
minutes (HQC 888)/ 35 minutes (HQC 884).
ENGLISH6

Do not charge the appliance for more than 24 hours.
1Make sure the appliance is switched off while charging.
2Insert the appliance plug into the appliance (fig. 1).
3Insert the adapter into the wall socket.
The pilot light will go on to indicate that the appliance is charging.
Optimising the lifetime of the battery
- After the appliance has been charged for the first time, do not
recharge it between clipping sessions. Continue using it and
recharge it only when the battery is (almost) empty.
- Discharge the battery completely twice a year by letting the motor
run until it stops.
- Do not keep the appliance plugged into a wall socket all the time.
- If the appliance has not been used for a long period of time, it must
be recharged for 12 hours.
Corded clipping
Do not run the appliance from the mains when the battery is fully
charged.
To use the hair clipper when it is connected to the mains:
1Switch the hair clipper off, connect it to the mains and wait a few
seconds before switching it on.
2If the battery is completely empty, wait a few minutes before
switching the appliance on.
Using the appliance
Also see the interactive instruction CD-ROM.
Clipping with comb attachment
Select the small or large comb attachment, depending on the desired
hair length.
ENGLISH 7

Hair length settings
◗The hair length settings are indicated in millimetres on the arms
of the comb attachment.The settings correspond to the
remaining hair length after cutting (fig. 2).
- The small comb cuts hair to a length of 3 mm, 6 mm, 9 mm, 12 mm,
15 mm, 18 mm or 21 mm.
- The large comb cuts the hair to a length of 23 mm, 26 mm, 29 mm,
32 mm, 35 mm, 38 mm or 41 mm.
1Slide the arms of the comb attachment into the guiding grooves
of the appliance until you hear a click (fig. 3).
Make sure that the arms of the comb attachment have been properly
slid into the grooves on both sides.
2Set the comb to the desired hair length by turning the hair length
adjustment ring (Precision Zoom Lock`) to the right or to the
left until the comb has been set to the desired hair length (fig. 4).
◗We advise you to start clipping at the highest setting (large
comb) and to reduce the hair length setting in small steps until
you reach the desired hair length.
3Switch the appliance on.
◗Choose the appropriate hair cutting method from the booklet
'Modelling and Styling' or consult the interactive instruction
CD-ROM.
Tip: If a lot of hair has accumulated in the comb, remove the comb
attachment and blow and/or shake the hair from the comb. Removing
the comb does not change the hair length setting.
Tip:Write down the hair length settings selected to create a certain
hairstyle as a reminder for future clipping sessions.
Clipping without comb attachment
You can use the clipper without comb attachment to contour the
neckline and the area around the ears.You can also find instructions and
tips on the instruction CD-ROM.
ENGLISH8

1Remove the comb attachment by pulling it off the appliance
(fig. 5).
Never pull at the flexible top of the comb attachment.Always pull at
the bottom part.
The comb attachment keeps the cutting unit at a certain distance
from your head.This means that, if you use the clipper without the
comb attachment, your hair will be cut off very close to the skin.
Cleaning
Clean the appliance every time you have used it.
Do not use abrasives, scourers or liquids such as alcohol, petrol or
acetone to clean the appliance.
The appliance and the adapter may only be cleaned with the brush
supplied.
1Make sure the appliance is switched off and disconnected from
the mains before you start cleaning it.
2Remove the comb attachment (fig. 5).
3Open the cutting unit by applying pressure to the centre of the
unit (fig. 6).
4Clean the cutting unit and the inside of the appliance with the
brush supplied (fig. 7).
5Close the cutting unit by pushing it back onto the appliance until
you hear a click (fig. 8).
The appliance does not need any lubrication.
Replacement
A worn or damaged cutting unit should only be replaced with an
original Philips cutting unit.
1Open the cutting unit by applying pressure in the centre and then
remove it by pulling it upwards (fig. 9).
ENGLISH 9

2Place the two lugs of the new cutting unit into the guiding slots
and push the unit back onto the appliance (fig. 10).
Environment
The built-in rechargeable battery contains substances which may
pollute the environment.
Remove the rechargeable battery when you discard the appliance.
Do not throw the battery away with the normal household waste but
dispose of it at an official collection point.
You can also take the appliance to a Philips service centre, which will
remove the battery for you and will dispose of it in an environmentally
safe way.
1Disconnect the appliance from the mains and let the appliance
run until the motor stops.
2Open and remove the cutting unit (See chapter 'Cleaning').
3Undo the screws and remove the metal clip by means of a
screwdriver (fig. 11).
4Remove the top part by pulling it off the appliance (fig. 12).
5Turn the zoom ring until the comb holder is in its highest
position (fig. 13).
6Then use some force to turn the zoom ring still further until the
comb holder comes loose from the appliance (fig. 14).
7Separate the two housing parts by means of a screwdriver (fig. 15).
8Pull out the printed circuit board (fig. 16).
9Insert a screwdriver into the small slot in the printed circuit
board. Push the screwdriver down until part of the printed circuit
board breaks off (fig. 17).
10 Open the plastic battery holder and take out the rechargeable
battery (fig. 18).
ENGLISH10
