Philips HC7650 User manual

HC7650
HC5612

9
8
2
3
4
5
6
7
11
10
12
1
3-15 mm2 mm 16-28 mm
131415

English 6
Français (Canada) 15

English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Cutting unit
2 Zoom wheel
3 On/off button
4 Turbo button (HC76650 only)
5 Battery status indicator
6 Socket for small plug
7 Pouch
8 Small plug
9 Supply unit
10 Scissors (HC7650 only)
11 Styling comb (HC7650 only)
12 Cleaning brush
13 Long comb (16-28mm)
14 Short comb (3-15mm)
15 Beard and stubble comb (2mm)
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.
6English

- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
- Always unplug the appliance before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as
this may cause injury. Always replace a
damaged part with one of the original type.
- This appliance contains batteries that are non-
replaceable.
- Do not open the appliance to replace the
rechargeable battery.
Caution
- Never immerse the appliance in water. Do not
use the appliance in the bath or shower.
- Never use water hotter than 60°C to rinse the
appliance.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
7
English

- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General
- This appliance can be safely cleaned under the
tap.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Charging
Charge the appliance fully before you use it for the
first time or if you have not used it for a long time.
HC7650: Charging takes approx. 1 hour. When the
appliance is fully charged, it has a cordless
operating time of up to 90 minutes.
When the battery is almost empty, the battery
status indicator flashes orange.
HC5612: Charging takes approx. 8 hours. When the
appliance is fully charged, it has a cordless
operating time of up to 75 minutes.
Note: After fully charging the appliance for the first
time, you can also use the appliance while it is
connected to the wall socket.
Charging with the supply unit
1Make sure that the appliance is switched off.
8English

2Insert the small plug into the appliance and put
the supply unit in the wall socket.
When the appliance is charging, the battery
status indicator light flashes green.
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Optimizing the lifetime of the rechargeable battery
When you have charged the appliance for the first
time, we advise you to use it until the battery is
completely empty. Continue to use the appliance
until the motor almost stops operating during a
session. Then recharge the battery. Follow this
procedure at least twice a year.
Using the appliance
The hair length settings are indicated in
millimeters. The settings correspond to the
remaining hair length after trimming.
Note: Be careful when you trim for the first time.
Do not move the trimmer too fast. Make smooth
and gentle movements.
Tip: Start trimming at a high length setting and
reduce the length setting gradually until you have
reached the desired hair length.
Trimming with a trimming comb
This appliance comes with 3 combs: a beard and
stubble comb (2mm), a short comb (3 - 15mm)
and a long comb (16 - 28mm).
You can use the beard and stubble comb attached
to the cutting element to groom your beard and
moustache in your preferred style.
You can use the short and long combs to achieve
an even haircut.
9
English

1Attach one of the combs to the appliance.
2Turn the zoom wheel to select the desired
length setting.
3Switch on the appliance.
4Move the appliance slowly and with light
pressure against the direction of hair growth.
Note: Make sure that the flat part of the comb
always stays in contact with the skin to obtain
an even result.
5Switch off and clean the appliance and
attachments after each use.
Trimming without comb
Use the trimmer without the trimming comb to trim
hair close to the skin (0.5mm) or to contour the
neckline and sideburns.
Be careful when you trim without a comb because
the cutting unit removes every hair it touches.
1Gently pull the comb off of the appliance.
2Switch on the appliance.
3Touch the hair lightly with the cutting unit. Make
well-controlled movements.
4Switch off and clean the appliance after each
use.
Turbo mode (HC7650 only)
This appliance is equipped with a Turbo mode to
help you trim thick hair efficiently.
To activate the Turbo mode,press the Turbo
button once.
To deactivate,press the Turbo button again.
Cleaning
Warning: Never use compressed air,
scouring pads, abrasive cleaning agents or
10 English

aggressive liquids such as petrol or acetone
to clean the appliance.
1Make sure that the appliance is switched off
and disconnected from the wall socket.
2Wipe the housing of the appliance with a dry
cloth.
3Remove the comb and clean it with the
cleaning brush and/or rinse it under the tap.
4Press the release button. The cutting unit
comes off the appliance.
5Clean the cutting unit with the cleaning brush
and/or rinse it under the tap.
6Clean the inside of the appliance with the brush
and/or rinse it under the tap.
7Carefully shake off excess water and let all parts
air dry completely.
8Insert the lug of the cutting unit into the guiding
slot and push the cutting unit back onto the
appliance.
Storage
Store the appliance in the pouch supplied.
Note: Make sure the appliance is dry before you
store it in the pouch.
Replacement
Only replace a worn or damaged cutting unit with
an original Philips cutting unit, available from an
authorized Philips service center.
1Press the release button. The cutting unit
comes off the appliance.
2Dispose of the old cutting unit in accordance
with local waste regulations.
11
English

3Insert the lug of the new cutting unit into the
guiding slot and push the cutting unit onto the
appliance.
Ordering accessories
To buy accessories or spare parts, visit
www.philips.com/parts-and-accessories or go to
your Philips dealer. You can also contact the
Philips Consumer Care Center in your country (see
the international warranty leaflet for contact
details).
Recycling
- Do not throw away the product with the normal
household waste at the end of its life, but hand
it in at an official collection point for recycling.
By doing this, you help to preserve the
environment.
- This product contains a built-in rechargeable
battery which shall not be disposed of with
normal household waste. Please take your
product to an official collection point or a
Philips service center to have a professional
remove the rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the appliance. Before you
remove the battery, make sure that the
appliance is disconnected from the wall
socket and that the battery is completely
empty.
