Philips Comfort GC143 Series User manual

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
ServiceManual
Philips Consumer Lifestyle
Comfort Steam Iron
17/06
GC1436
GC1439
RI1430
RI1436
GC1430
GC1432
GC1433
GC1434
Version 4
01-Jun-2017
Product information
Calc management
•Calc clean solution: Self clean
Easy to use
•Water tank capacity: 220 ml
•Ultra light and comfortable
•Filling and emptying water: Large filling hole
Fast & powerful crease removal
•Continuous steam output: 15 - 25 g/min
•Power: 1400 - 2000 W
•Soleplate: Non-stick
•Spray
•Steam boost: 70 - 100 g
•Steam tip
•Drip stop
Sustainability
•User manual: 100% recycle paper
Technical information
•Voltage : 127 - 240 V
•Power : 1400 - 2000 W

GC143x / RI143x
2-9
Product matrix
Model Number GC1430/20 GC1430/26 GC1430/28 GC1432/40 GC1433/30
Power 1700 W 1700 W 1400 W 2000 W 2000 W
Voltage 240 V 240 V 220 V 240 V 240 V
Continuous steam 20 g/min 20 g/min 20 g/min 25 g/min 25 g/min
Steam boost 70 g 70 g 70 g No 90 g
Soleplate Non-stick Non-stick Non-stick Non-stick Non-stick
Spray Yes Yes Yes Yes Yes
Steam tip Yes Yes Yes Yes Yes
Drip stop No No No No No
Water tank 220 ml 220 ml 220 ml 220 ml 220 ml
Calc solution Self clean Self clean Self clean Self clean Self clean
Model Number GC1433/40 GC1433/48 GC1434/70 GC1436/20 GC1436/28
Power 2000 W 1700 W 2000 W 2000 W 1700 W
Voltage 240 V 220 V 240 V 240 V 220 V
Continuous steam 25 g/min 25 g/min 25 g/min 25 g/min 25 g/min
Steam boost 90 g 90 g 90 g 90 g 100 g
Soleplate Non-stick Non-stick Non-stick Non-stick Non-stick
Spray Yes Yes Yes Yes Yes
Steam tip Yes Yes Yes Yes Yes
Drip stop No No Yes Yes Yes
Water tank 220 ml 220 ml 220 ml 220 ml 220 ml
Calc solution Self clean Self clean Self clean Self clean Self clean

GC143x / RI143x
3-9
Product matrix
Model Number GC1439/20 RI1430/32 RI1436/22 RI1436/24
Power 2000 W 1400 W 1400 W 1700 W
Voltage 240 V 127 V 127 V 240 V
Continuous steam 25 g/min 15 g/min 15 g/min 15 g/min
Steam boost No 70 g 70 g 70 g
Soleplate Non-stick Non-stick Non-stick Non-stick
Spray Yes Yes Yes Yes
Steam tip Yes Yes Yes Yes
Drip stop Yes No No No
Water tank 220 ml 220 ml 220 ml 220 ml
Calc solution Self clean Self clean Self clean Self clean

GC143x / RI143x
4-9
Disassembly advice
THERMOSTAT DIAL 3
WATER TANK ASSY 9
SOLEPLATE COVER 8
SOLEPLATE ASSY 12
TANK SEAL 13
Disassemble THERMOSTAT DIAL PRINTED 3
Disassemble Bullet spring
Remove Screws E1, E2
Remove Screws F1, F2
Disassemble WATER TANK ASSY 9
Disassemble Steam connector SOS inlet tube
Disassemble Steam plunger with spring
Disassemble Thermostat bush
Remove Screws G1, G2, G3 with insulation washer
Disassemble SOLEPLATE COVER 8
Disassemble TANK SEAL 13
Disassemble SOLEPLATE ASSY 12
Disassemble Tank seal
Remove Screws H1, H2
Remove Steam button assy
Disassemble Pump assy
Disassemble Pump post
Disassemble Pump plunger
Disassemble Pump spring
Disassemble Iron paul
Disassemble Pump body
Disassemble Throat ring
Disassemble Stopple
Disassemble Throat ring
Disassemble Silicon Stopper
FILLING DOOR 7
SOS KNOB 5
SPRAY KNOB 4
Remove Screws A1, A2
Disassemble FILLING DOOR 7
Disassemble Screw cover
Remove Screw B1
Disassemble SOS KNOB 5
Disassemble SPRAY KNOB 4
Remove Screw C1
INLAY BACKPLATE 1
CORD CLAMP 10
WIRE CONNECTOR CAP 2
SWIVEL 11
CORDSET 6
Disassemble INLAY BACKPLATE 1
Disassemble Spray inlet tube
Disassemble Nozzle from inlay
Remove Screws D1, D2
Remove CORD CLAMP 10
Disassemble Lamp assy
Remove WIRE CONNECTOR CAP 2
Disassemble SWIVEL 11
Disassemble CORDSET 6

GC143x / RI143x
5-9
Part lists
Pos Description
GC1430/20
Service code
GC1430/26
Service code
GC1430/28
Service code
GC1432/40
889143240510
Chile
Service code
1 Backplate inlay 9965 100 73868 9965 100 73868 9965 100 73864 9965 100 75432
2 Wire crimping cap 9965 100 73814 9965 100 73814 9965 100 73814 9965 100 67004
3 Thermostat dial 9965 100 73874 9965 100 73874 9965 100 73869 9965 100 73872
4 Spray knob 9965 100 73877 9965 100 73877 9965 100 73877 9965 100 77352
5 SOS knob 9965 100 73882 9965 100 73882 9965 100 73882 N/A
6 Cordset 9965 100 73886 9965 100 73886 9965 100 73884 9965 100 77324
7 Filling door 9965 100 73891 9965 100 73891 9965 100 73891 9965 100 75438
8 Soleplate cover 9965 100 73892 9965 100 73892 9965 100 73892 9965 100 77006
9 Inlay base and Water tank assy 9965 100 73895 9965 100 73895 9965 100 73893 9965 100 77351
10 Cord clamp 9965 100 73815 9965 100 73815 9965 100 73815 9965 100 73815
11 Swivel 9965 100 73812 9965 100 73812 9965 100 73812 9965 100 73812
12 Soleplate 9965 100 73898 9965 100 73898 9965 100 73898 9965 100 76989
13 Tank seal 9965 100 73813 9965 100 73813 9965 100 73813 9965 100 73813
Pos Description
GC1433/30
Service code
GC1433/40
Service code
GC1433/48
889143348710
China
Service code
GC1434/70
889143470400
EEU
Service code
1 Backplate inlay 9965 100 73865 9965 100 73866 9965 100 76465 9965 100 77003
2 Wire crimping cap 9965 100 73814 9965 100 73814 9965 100 73814 9965 100 67004
3 Thermostat dial 9965 100 73871 9965 100 73872 9965 100 76461 9965 100 77007
4 Spray knob 9965 100 73875 9965 100 73876 9965 100 75434 9965 100 77005
5 SOS knob 9965 100 73879 9965 100 73881 9965 100 75435 9965 100 77001
6 Cordset 9965 100 73885 9965 100 73885 9965 100 76462 9965 100 69329
7 Filling door 9965 100 73887 9965 100 73888 9965 100 75438 9965 100 77002
8 Soleplate cover 9965 100 73892 9965 100 73892 9965 100 75439 9965 100 77006
9 Inlay base and Water tank assy 9965 100 73894 9965 100 73896 9965 100 76464 9965 100 77004
10 Cord clamp 9965 100 73815 9965 100 73815 9965 100 73815 9965 100 73815
11 Swivel 9965 100 73812 9965 100 73812 9965 100 73812 9965 100 73812
12 Soleplate 9965 100 73899 9965 100 73899 9965 100 76463 9965 100 77364
13 Tank seal 9965 100 73813 9965 100 73813 9965 100 73813 9965 100 73813

GC143x / RI143x
6-9
Part lists
Pos Description
GC1436/20
Service code
GC1436/20
889143620400
EEU
Service code
GC1436/20
889143620650
Indonesia
Service code
GC1436/28
889143628710
China
Service code
1 Backplate inlay 9965 100 73867 9965 100 77312 9965 100 77312 9965 100 76468
2 Wire crimping cap 9965 100 73814 9965 100 67004 9965 100 67004 9965 100 73814
3 Thermostat dial 9965 100 73873 9965 100 77361 9965 100 77361 9965 100 76466
4 Spray knob 9965 100 73878 9965 100 77375 9965 100 77375 9965 100 75669
5 SOS knob 9965 100 73883 9965 100 77367 9965 100 77367 9965 100 75673
6 Cordset 9965 100 73885 9965 100 69329 9965 100 77357 9965 100 76462
7 Filling door 9965 100 73889 9965 100 77362 9965 100 77362 9965 100 75672
8 Soleplate cover 9965 100 73892 9965 100 77313 9965 100 77313 9965 100 75439
9 Inlay base and Water tank assy 9965 100 73897 9965 100 77314 9965 100 77358 9965 100 76467
10 Cord clamp 9965 100 73815 9965 100 73815 9965 100 73815 9965 100 73815
11 Swivel 9965 100 73812 9965 100 73812 9965 100 73812 9965 100 73812
12 Soleplate 9965 100 73901 9965 100 77364 9965 100 77364 9965 100 76463
13 Tank seal 9965 100 73813 9965 100 73813 9965 100 73813 9965 100 73813
Pos Description
GC1439/20
889143920510
Chile
Service code
RI1430/32
886143032240
Brazil
Service code
RI1436/22
886143622240
Brazil
Service code
RI1436/24
886143624240
Brazil
Service code
1 Backplate inlay 9965 100 77321 9965 100 76026 9965 100 77312 9965 100 77312
2 Wire crimping cap 9965 100 67004 9965 100 73814 9965 100 77072 9965 100 77072
3 Thermostat dial 9965 100 77323 9965 100 76022 9965 100 77328 9965 100 77328
4 Spray knob 9965 100 77327 9965 100 76024 9965 100 77375 9965 100 77375
5 SOS knob N/A 9965 100 76021 9965 100 77367 9965 100 77367
6 Cordset 9965 100 77324 9965 100 76025 9965 100 77355 9965 100 77331
7 Filling door 9965 100 77326 9965 100 76027 9965 100 77362 9965 100 77362
8 Soleplate cover 9965 100 77313 9965 100 75439 9965 100 77313 9965 100 77313
9 Inlay base and Water tank assy 9965 100 77325 9965 100 76023 9965 100 77356 9965 100 77337
10 Cord clamp 9965 100 73815 9965 100 73815 9965 100 73815 9965 100 73815
11 Swivel 9965 100 73812 9965 100 73812 9965 100 73812 9965 100 73812
12 Soleplate 9965 100 77322 9965 100 76019 9965 100 77354 9965 100 77329
13 Tank seal 9965 100 73813 9965 100 73813 9965 100 73813 9965 100 73813

GC143x / RI143x
7-9
C1
B1
D1
A1
A2
D2
3
2
10
5
1
11
9
13
8
12
7
6
4
Exploded view - Iron

GC143x / RI143x
8-9
•Due to the high wattage of the iron, only the specified cordset must be used.
•Should damage be observed on the CORDSET 6, it must be replaced. Continued usage is not allowed.
•After the product has been repaired, it should function properly and has to meet the safety requirements & legal regulation
as laid down & officially established at this moment.
•The following tests are common checks that are conducted on a repaired product before it is returned to the consumer.
1. Soleplate temperature
Check the soleplate temperature is within IEC requirement.
Soleplate temperature (Deg C)
Materials, for example
Test-
point
==
Minimum Maximum
160 220 All fabric types
2. Leakage current
Check that leakage current is within IEC requirement.
Measure leakage current between LIVE/NEUTRAL & EARTH.
IEC requirement is that at 230 V supply, the EARTH leakage current must be less than 0.75 mA.
3. Water leakage / Functionality
Check that there is no water leakage from any part of product during operation.
Check that the functionality of the product (product dependent) eg. steaming, variable steam, SOS, ASO etc is working
properly.
4. Loose part
Check that there are no loose parts eg. extra screw in the product that can cause short-circuit or product malfunctions.
5. Fuse open circuit
When replacing fuse, to also service the water tubes which is probably choked with calc.
6. Screws
Screws should be the dened screws in terms of length and material used.
Repair Instruction

GC143x / RI143x
9-9
Record History
Version 1 - Created on Aug 2015
Version 2 - Created on Aug 2016
Added RI1430/32
Added Product Matrix
Version 3 - Created on Sep 2016
Added GC1433/48 & GC1436/28
Updated Product Matrix
Version 4 - Created on Jun 2017
Added GC1432/40, GC1434/70, GC1436/20, GC1439/20, RI1436/22 & RI1436/24
Updated Product Matrix
