Philips GC 6005 User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Provapor elance
GC 6005
SAP coding GC 6005
PRODUCT INFORMATION
Feataures : optinox sole plate
boiler capacity 1 litre
length steam hose 1,9 metre
length cord set 1,9 metre
maximum steam output 80 gr/min
steam ready indicator
Voltage : 220-240Volt
Frequency : 50-60 Hz
Power consumptium : Boiler : 1200 Watt
Pressure : 3,5 bar
Iron : 800 Watt
4322 277 00601
01/04
Product meets the requirements regarding interference
suppression on radio and television.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as laid
down officially established at this moment.
!Service
Information

EXPLODED VIEW IRON
B
B
B
C
C
A
DAP1560
3
2
6
14
8
13
9
7
12
5
4
14
11
2
10
1

PARTS LIST IRON
Pos Service Nummer Description
Iron inlay
Intermediate cable + microswitch
Electro valve trigger
Thermostat dial
Thermostat joint
6
7
8
9
10
9965 000 08140
9965 000 08141
9965 000 08184
9965 000 08185
9965 000 01682
Ball swivel
Iron back part
Iron thermostat
Spring clamp
11
12
13
14
1
2
3
4
5
Iron handle
Rattle
Iron skirt
Soleplate unit
Iron lamp
9965 000 08186
4822 492 71445
9965 000 08187
9965 000 08188
9965 000 01686
9965 000 01687
9965 000 08189
9965 000 01690
4822 492 71001
Cut
out
Steam
ready
Boiler
thermostat
Main
switch
STAND IRON
Steam-
switch
Thermostat
Electro-
valve
Boiler
heating
element
p

DISASSEMBLY ADVISE IRON
BACK PLATE 12
remove SCREW A
INLAY 1
remove LAMP 10
remove MICRO SWITCH 2
ADJUSTMENT AND CONTROLS
Thermostat 13
Thermostat ( 13 ) supplied as a spare part or fitted to
the sole plate ( 9 ) has already been a djusted by the
supplier and secured by glue.
To avoid disfunction of the iron , NEVER readjust the
thermostat.
HANDLE 6
remove THERM. DIAL 4
remove SCREW B (4x)
unlock HANDLE carefully
SKIRT 8
remove ELECTRICAL
WIRES
remove EXTENSION
PIECE 5
remove SPRING CLAMP
FROM STEAM HOSE
remove SCREW C (3x)
Bend back the contact points
THERMOSTAT 13
ONLY
cut CONDUCTOR A
at location P
remove SCREW D
P
Q
BA
D
ASSEMBLY
REQUIREMENTS
THERMOSTAT 2
Instead of metal conductor A,
the new thermostat has a wire
with AMP clamp.
After fixing screw D, connect
the AMP clamp to tag Q.
After assembling SKIRT 8
ALWAYS turn conductor B
through 180 degrees.
NOTE :
For opening you need aTorx screwdriver 362TR
T20 x 100.

EXPLODED VIEW STAND
DAP1571
24
26
27
25
28
30
27
29
31
33
32
36
35
34
22
23
37
E

PARTS LIST + DISASSEMBLY ADVICE STAND
Pos Service Nummer
Tray rubber foot for fixation
Complete tray
Safety cap for boiler
Filling hole gasket for alu boiler
Superior stand printed
22
23
24
25
26
9965 000 08193
9965 000 08194
9965 000 08195
9965 000 01782
9965 000 08252
27
28
29
30
31
32
33
34
35
36
OPENTHE STAND
pressure fixation rubber through
the tray
E
EE
remove SCREW E (3 x)
remove LOCKED INSERT 29
NOTE:
OPEN NOWTHE STAND.
DON’T WORRY IFTHE SNAPS AT THE SIDE WILL BE
BROKEN.
THEY ARE ONLY FORTHE ASSEMBLY.
THE STAND REMAINS CLOSEWITHOUTTHESE SNAPS.
ADJUSTMENT AND CONTROLS
–To avoid leakage of the sealings and damage to
the components in and on the boiler, NEVER clean
the boiler with vinegar, a descaling agent or other
chemicals.
–The boiler doesn’t contain serviceable parts.
Never disassemble the boiler body and /or
components on and in the boiler.
–ALWAYS REPLACE THE BOILER ( 28 ) WHEN:
*the mechanical safety valve ( 24 ) has been
activated.
*the boiler thermostat or hand - resettable safety
thermostat are open, because the boiler has
been subjected to too high temperatures.
*the electrovalve ( 33 ) fails or the sieve is soiled
with scale.
–After the product has been repaired, it should
function properly and has to meet the safety
requirements as laid down and officially established
at this moment.
Description
4822 462 71999
9965 000 08240
9965 000 08201
9965 000 08202
9965 000 01790
Boiler rubber feet
Complete boiler
Locket insert
Inferior stand
Filter
9965 000 08203
4822 218 11561
9965 000 08241
9965 000 01900
9965 000 01902
Main switch
Electrovalve
Steam dial
Sream regulator
Steam ready light
37 9965 000 08246 Funnel
