Philips US2-PH61159 User manual

Your Video RF Modulator is designed to convert the separate audio and
video signals (from a video camera, computer, portable VCR, satellite
receiver, DVD player, etc.) into normal VHF TV signals that you can see on
any regular TV set.
INTRODUCTION
This symbol is intended to inform you that important
operating and maintenance instructions are included
in the literature accompanying this RF Modulator.
This symbol is intended to alert you to the presence of
uninsulated dangerous voltage within the RF
Modulator’s enclosure that might be of sufficient
magnitude to constitute a risk of electric shock. Do not
open the RF Modulator’s case.
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION:
REFER SERVICING TO QUALIFIED PERSONNEL.
Warning: For indoor use only; to reduce risk of fire or shock hazard, do not
expose this product to rain or moisture.
Video RF Modulator
Owner’s Manual

This device complies with Part 15 of the
FCC Rules
. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesirable operation.
Even under optimum conditions, your Video RF Modulator may cause
undesirable interference. We suggest the following methods for trouble
shooting:
1. Use an AC outlet that is not the same circuit as the receiver.
2. Place the RF Modulator in a location further away from your receiver.
In the event that interference still occurs after the above steps have been
taken, you are required by FCC regulations to discontinue use of this
product.
Important Safety Information:
1. Before beginning installation of your Video RF Modulator read all
instructions and follow exactly throughout the installation.
2. After installation is complete, keep all instructions in a safe place so
they may be referred to in the future if necessary.
3. Please note the ideal environment for this device is on a hard flat
surface away from all heat sources and moisture.
THE FCC WANTS YOU TO KNOW

You need the following items, not supplied with your Video RF Modulator,
to connect it between a video input source (video game, video camera,
satellite receiver, DVD player, etc.) and your TV.
• Two 75-ohm coaxial cables with F-type connectors
• If your TV does not have a VHF 75-ohm F-connector, you will also
need a 75-ohm-to-300-ohm matching transformer
•One video shielded cable with RCA Plugs and one audio (stereo)
cable with RCA Plugs OR Dubbing Cable for VCR/DVD with RCA
Plugs OR 3 shielded cables with RCA Plugs
•One S-Video Cable
PARTS REQUIRED
Follow these steps to connect your RF Modulator:
1. Connect an S-Video or video cable between the S-Video or video output
jack on your video source and the RF Modulator’s S-VIDEO or VIDEO IN
jack.
CONNECTIONS
ANT IN
TO TV
LR
60Hz/4.5W
V
IN S-VIDEO
Jack Jack
S-Video OutputVideo Output OR
Video Source
Note: If both the S-Video and standard video are hooked up,
the S-Video will be given priority

2. Connect an audio cable between the audio output jacks on your video
source and the RF Modulator’s AUDIO IN jacks.
AUDIO IN Jacks
Audio Output
Audio Source
ANT IN
TO TV
LR
60Hz/4.5W
IN S-VIDEO
3. Connect the 75-ohm coaxial cables to the RF Modulator using one of
these two (2) options:
Option 1: If your TV is already connected to another VHF input source
(such as cable TV, VCR, etc.):
TO TV
CATV/ANT
VHF
RF ModulatorVCR
ANT INT mhO57VTO 75 Ohm
Disconnect
from here
a. Disconnect the current CATV/antenna connection from the 75-ohm
input terminal of your VHF source, and reconnect it to the RF
Modulator’s ANT IN terminal.
b. Then add a 75-ohm coaxial cable connected between the TO TV
terminal of the RF Modulator and the 75-ohm input terminal of your
VHF source.

75 Ohm
CATV
300 Ohms
VHF
RF ModulatorTV
ANT INTO TV
Option 2: If your TV is not already connected to another VHF source:
a. Disconnect the current CATV/antenna cable from the 75-ohm input
terminal of your TV, and reconnect it to the RF Modulator’s ANT IN
terminal.
b. Then add a 75-ohm coaxial cable connected between the TO TV
terminal of the RF Modulator and the 75-ohm VHF input terminal on
your TV.
Note: If your TV has only 300-ohm VHF screw terminals, use a 75-ohm-
to-300-ohm matching transformer to complete the connection.
4. Plug the RF Modulator’s power cord into a standard AC outlet.
CONNECTIONS continued
75 Ohm75 Ohm OUTIN
CATV
VHF
Add this cable
Reconnect
here
RF Modulator VCR
ANT INTO TV
TO TV

3. Turn on the connected video source, the modulator will deliver the
video/audio signal to the TV set and the red light of MOD. ON will be ON.
4. Turn off the connected video source, the modulator will be switched
automatically to deliver the ANT/Cable signal to the TV set and the red
led of MOD. ON will be off.
1. Turn on the TV and set it to either Channel 3 or 4, whichever of the
two is not used for regular broadcasts in your area.
2. Set the RF Modulator’s CHANNEL 3 or 4 switch to the same channel
you set on the TV (3 or 4)
OPERATION
4
3
MOD. ON
CHANNEL

SPECIFICATIONS
Video Carrier Output Level 63 dB uV
RF Output Channels 3 or 4
RF Output Impedance 75 ohms
Video Input Impedance 75 ohms/1 k ohms
Audio Input Impedance 13 ±3 k ohms
Specifications are typical, individual units might vary. Specifications
are subject to change and improvement without notice.
Limited Lifetime Warranty The Manufacturer warrants that this product shall be
free from defects in material, workmanship and assembly, under normal use, in
accordance with the specifications and warnings, for the life of the product. This
warranty extends only to the original purchaser and is non-transferable. Defective
products must be returned with the dated proof of purchase to the place of
purchase for replacement. THERE ARE NO OTHER EXPRESS OR IMPLIED
WARRANTIES. Incidental or consequential damages are disclaimed where permitted
by law.

Este Modulador de RF para Vídeo está diseñado para convertir señales
separadas de audio y de vídeo (provenientes de una videocámara, computa-
dora, videocasetera portátil, receptor satelital, reproductor de DVDs, etc.) en
señales de televisión VHF corrientes, para que Ud. las pueda ver en cualquier
televisor común.
INTRODUCCIÓN
Este símbolo tiene por objeto informarle que la literatura
que acompaña a este Modulador de RF contiene impor-
tantes instrucciones de operación y mantenimiento.
Este símbolo tiene por objeto alertarle acerca de la
presencia de voltaje peligroso sin aislación en el interior
del Modulador de RF, de suficiente intensidad para repre-
sentar peligro de electrochoque. No abra la caja del
Modulador de RF.
PRECAUCIÓN
PELIGRO DE ELECTROCHOQUE
NO ABRIR
PRECAUCIÓN:
SERVICIO A PERSONAL HABILITADO.
Advertencia: para uso en interiores solamente; para reducir el riesgo de
incendio o electrochoque,no exponga este producto a la lluvia o a la humedad.
Modulador de RF para
Vídeo-Manual del Usuario

Este aparato está en conformidad con la Parte 15 de las normas de la
Comisión Federal de Comunicaciones (FCC Rules). Su funcionamiento está
sujeto a las siguientes condiciones: (1) este aparato no debe causar interfer-
encia perjudicial, y (2) este aparato debe aceptar toda interferencia recibida,
incluso interferencia capaz de causar un funcionamiento no satisfactorio.
Aun en las mejores condiciones, el Modulador de RF para Vídeo podría causar
interferencia indeseable. Sugerimos las siguientes medidas para resolver el
problema:
1. Use un tomacorriente de corriente alterna conectado a un circuito distinto
al del receptor.
2. Coloque el Modulador de RF lo más lejos posible del receptor.
Si después que se hayan tomado estas medidas la interferencia persiste, las
reglamentaciones de la FCC exigen suspender el uso de este producto.
Información importante relativa a seguridad:
1. Antes de comenzar la instalación de su Modulador de RF de Vídeo,
lea todas las instrucciones y sígalas estrictamente durante la
instalación.
2. Después de completar la instalación, guarde todas las instrucciones en
un sitio seguro para poder consultarlas en el futuro en caso necesario.
3. Sírvase notar que el sitio ideal para este aparato es colocado sobre
una superficie dura, lejos de toda fuente de calor y de humedad.
LA FCC QUIERE QUE UD. SEPA LO SIGUIENTE:

Para conectar el Modulador de RF de Vídeo entre una fuente de señales de
vídeo (juego de vídeo, videocámara, receptor satelital, reproductor de DVDs,
etc.) y su televisor, se necesitan los siguientes elementos, que no se suminis-
tran con el Modulador.
• Dos cables coaxiales de 75 ohms con conectores de tipo F
• Si su televisor no tiene un conector F de 75 ohms para VHF, también
necesitará un transformador de adaptación de 75 a 300 ohms
• Un cable blindado para vídeo con clavijas de conexión RCA y un cable
para audio (estereofónico) con clavijas de conexión RCA O Cable de
transposición para VCR/DVD con clavijas de conexión RCA O 3 cables
blindados con clavijas de conexión RCA
•Un Cable de S-Video
PIEZAS NECESARIAS
Para conectar su Modulador de RF siga los pasos siguientes:
1. Conecte un cable e s-vídeo o vídeo entre el receptáculo de salida de vídeo
de la fuente de señales de s-vídeo o vídeo empleada y el receptáculo rotulado
S-VIDEO IN o VIDEO IN del Modulador de RF.
CONEXIONES
ANT IN
TO TV
LR
60Hz/4.5W
IN S-VIDEO
VIDEO IN S-VIDEO IN
Salida de vídeo OSalida de s-vídeo
Fuente de vídeo
#72102 China
Nota: Si el S-Video y video uniforme se enganchan arriba,
el S-Video se dará la prioridad
