Philips DCM2060/12/93/96/79 User manual

Version 1.2 3141 785 36652
Micro music system
Published by LZ1133 Service Audio Subject to modification
©Copyright 2011 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
CONTENTS
6-1..1-1............................................................noitacificepslacinhceT
Version Variation.............................................................................2-1
Block diagram................................................................................3-1
Wiring diagram..............................................................................3-2
LCD + KEY + REMOTE INCEPT + DC + USB board
Layout diagram..................................................................4-4 4-5
MAIN board
Circuit diagram ..................................................................5-1..5-7
Layout diagram..................................................................5-8..5-9
Exploded view diagram .................................................................6-1
Circuit diagram..................................................................4-1 4-3
DCM2060/12/93/96/79
REMOTE HANDSET board
Circuit diagram .........................................................................4-6
Layout diagram.........................................................................4-7
IPOD board
Circuit diagram .........................................................................4-8
Layout diagram.........................................................................4-9

TECHNICAL SPECIFICATION
1-1
6
GENERAL DESCRIPTION
Micro Hi-Fi System with PLL Tuner , CD-MP3, USB 10W * 2
MP3 LINK , Remote Control
X
7
LIFETIME : 7 Years
Class Tuner Supply + Amplifier Loudspeaker Boxes Clock MP3 LINKCDUSB
XX
IX
X
III
II X X
8 10
SAFETY requirements
Version Safety EMC
Page 9 4,5 4
/12/05/
79 EN55013IEC60065
RADIATION / IMMUNITY requirments ( EMC )
ALL climates : + 5 Dregree till + 35 Degree
MODERATE climates : + N.A till N.A Degree
CLIMATIC requirements
PERFORMANCE CLASSES
POWER SUPPLY
MAINS ( A.C. ) 100/240 Vac(AC/DC Adaptor)
Version /12/05/79
Voltage Selection NO
Frequency 60/50Hz
POWER CONSUMER
MCM2050/12/05/79
( DEMO mode " OFF " ) , NOM. A, INPUT
Stadby :
@ 1/8 Prated , NOM. A, INPUT
Maximum : /
Q and R according to Product Division Rules
Quality : 0.4 % ( Major ) 1.5 % ( Mirror )
Reliability : 2.0 % ( C 42 )
ECO Power mode : /
Tested according to General Test Instruction refer to PHILIPS standary ( UAN -D1591 )
Measured according to PHILIPS standary ( UAN - L1059 ) unless other wise stated
All not mentioned date, please refer to PHILIPS standary ( XUW - 0010 - jun 2001)

1-2
TECHNICAL SPECIFICATION
:
:
:
:
:
TECHNIAL DESCRIPTION
Total power 20W, matching LOUDSPEAKER of 2 x6 R. TWO INPUT SOURCE, ( Digital Sound Control )
GENERAL PART
Standby Mode Indicator : LCD display Clock active, LED backlight turn ON
OUTPUT stage Protection : Yes Temperature : YES Shorcircuit : Yes
LoudSpeaker D.C. Protection : Yes.
INDICATORS
Hum ( Volume Minimun - ) < 0.5
ECO Mode Indiicator : NC
ELECTRICAL DATA
dB
N/A Residual Noise ( Volume Minium ) 0.06
µW
DSC : ON/OFF Channel Differencer at -46dB 3
DBB ON/OFF
N/A Signal / Noise ( weighted ) ı55
µW
VAC : N/A Channel Separation ( at 1 kHz ) ı35 dB
SIS :
Tuner FM MODE 75KZH /(CD -6dB) Line Out ( Left / Right ) N.A
dB
INTERCONNECTS
Input Sensitity(±2 dB)rated ouput power at 1 kHz and 10kHz. Line Output Voltage ( *1 )
WOOX :
TAPE NC Headphone 700mV+/-1dB, RL = 32˟
CD / USB 0 dB track ( Audio Disc 1, Trk 35 ) Subwoofer Out N.A
AUX IN NC Booster Out N.A
MP3 Link Nor: 500mV Lim: 350mV ~ 800mV CD 0dB Digital Coaxial Out N.A
OUTPUT POWER ( * 1 ) At THD = 10% (Measured with 20Hz-22KHz filter),
Power output ( RMS ) channel 10W*2 +/-1dB (1*)
LOUDSPEAKER ( BOXES ) Please to package document of Speaker Box Assy
Rated Impedance
: 6 Ohms at Bass driver,
( *1 ) Electrical parameters are to be measuremend at specker terminals across 6 Ohm load ( pure resistor )
with rated input signal in AUX mode; DSC OFF mode with DBB OFF
IS off unless specified otherwise
Remarks :Radio Power output ( RMS ) Limit:-3dB

1-3
TECHNICAL SPECIFICATION
Signal to Noise Ratio ( 0dB,1kHz ) >= 60dBA ( A - weighted )
( 100 - 16,000 Hz ) >= 55dBA ( A - weighted )
Frequency Response ( 5dB+/- 3dB ), reference 1kHz 100Hz - 16kHz
THD + Noise ( 0dB, 1Khz ) <= 0.3 5
Channel Crosstalk ( 100Hz - 16,000 Hz ) >= 35 dB
( 0 dB, 1 KHz ) >= 40 dB
Output Resistance < = 1.5 kOhm
Output Voltage RL = 33 k ohm ( )dB, 1 Khz ) 830mVrms +/- 1.5dB
Channel Unbalance < = +/- 3 dB
GENERAL PART
Measurement are directly done at the connector on CDC board
Description Specification
TECHNIAL DESCRIPTION
USB
See also SH 190 USB Audio Module (300605)
Measurment are directly done at the coonector on the board
Signal to Noise Ratio ( 0dB,1kHz ) >= 60dBA ( A - weighted )
( 100 - 16,000 Hz ) >= 55dBA ( A - weighted )
Frequency Response ( 5dB+/- 3dB ), reference 1kHz 100Hz - 16kHz
THD + Noise ( 0dB, 1Khz ) <= 0.3 5
Channel Crosstalk ( 100Hz - 16,000 Hz ) >= 35 dB
( 0 dB, 1 KHz ) >= 40 dB
Output Resistance < = 1.5 kOhm
Output Voltage RL = 33 k ohm ( )dB, 1 Khz ) 830mVrms +/- 1.5dB
Channel Unbalance < = +/- 3 dB
GENERAL PART
Measurement are directly done at the connector on CDC board
Description Specification
TECHNIAL DESCRIPTION
USB
See also SH 190 USB Audio Module (300605)
Measurment are directly done at the coonector on the board

1-4
TECHNICAL SPECIFICATION
TECHNIAL DESCRIPTION
CD + MP3 - Part Specifications
CD mechnism refer to Philips standard specification
Measurement are directly done at the connector on CDC board
GENERAL PART
Description Extern Nom Lim Unit
Ohms
Output Voltage - Unloaded ( 0dB , 1 kHz ) No 0.5 ± 1 Vrms
Output Resistance No < 100
dB
Frequency Response ( 125 Hz - 16 kHz ) No 5 ± 3 dB
Channel Unbalance No < ± 2
dB
Signal to Noise Ratio ( A - weighted ) Yes 65 55 dBA
Signal to Noise Ratio ( Unweighted ) Yes 60 50
dB
Crosstalk ( 125Hz to 16kHz ) No 36 30 dB
Crosstalk ( 1kHz ) Yes 65 55
nW
Emphasis - / / /
Hum & Noise ( *1 ) No 400 500
Timer Setting : Clock and Timer
Timer Wakeup Mode : LAST SETTING (MODE)
TECHNIAL DESCRIPTION
SOFTWARE IMPLEMENTED CLOCK / TIMER FUNCTION WITH 75.000kHz QUARTZ OSCILLATOR.
GENERAL PART
1RRI7LPHU6HWWLQJV : 1
&ORFN$FFXUDF\ : Normal: 0.5 sec/day Limit : 1 sec/day
Remarks Time Setting : for 24hrs
Volume at Wakeup : Last Setting
,1',&$7256
'LVSOD\7\SH /&'

TECHNICAL SPECIFICATION
1-5
TECHNIAL DESCRIPTION
TUNER using SI4705
GENERAL PART
WAVE RANGE TOLERANCE TUNING GRID
FM 87.5 - 108.00 MHz (12/05/79) Quartz Precision 50KHZ
NC
INDICATORS LCD DISPLAY
AERIAL
FM : 75 OHM ANT
MW : NC
ELECTRICAL DATA
A.M Nom Limit Unit F.M. Nom Limit Unit
- 3 dB Limiting Point : 17 23.5 dBf
Amplification Reverse : 0 -4 dB Amplification Reverse / / dB
Distortion ( RF 1mV, Frq Dev.75 kHz ) : 2 3 % AGC Figure of Merit / / dB
Stereo - 46 dB Quieting : 46 49 dBf Distortion ( RF 50mV, M 80% ) / /%
Crosstalk (RF1mV, Freq Dev.40kHz ) : 25 18 dB IF / / kHz
IF / / MHz
/ //
Wave Range Noise Limited Sensitivity 26 dB Search tuning
sensitivity dBf
IF Rejection
dB
///
Large Signal
Selectivity
S3 / S9 / 300kHz
dB
MW 600 kHz Nom. 1500uV/M
MW 1400 kHz Nom. 1500uV/M
/
Lim. 4000uV/M /
///
/ ///
Lim. 4000uV/M /
FM 98 MHz Nom. 18dBf
/108 dBf 25
22 dBf /116 dBf 30
Lim. 22dBf 35 dBf

1-6
TECHNICAL SPECIFICATION
THD (1KHz, 0dB) 2% 3% 500mV 1KHz input
Crosstalk (different source, 1KHz) 60dB 50dB 500mV input
/
Frequency response (5+/-3dB)
SNR wtd. dBA / /
150mV input
50dB 500mV 1KHz input
SNR wtd. dBA 62dBA 57dBA 500mV 1KHz input
SNR unwtd. 60dB
//
100 to 10KHz (overall)
AUX IN Part
/
Crosstalk (different source, 10KHz) / / /
Crosstalk (different source, 1KHz)
TECHNIAL DESCRIPTION
MP3 Link
MP3 Link Part
Crosstalk (different source, 10KHz) 45dB 35dB 500mV input
//
Nom. Limit Condition
Frequency response (-3dB) /
THD (1KHz, 0dB) / / /
//
L, R Channel Separation / / /
L, R Channel Separation 36dB 30dB 500mV input
SNR unwtd. /

VERSION VARIATION
2 - 1
Type /Versions:
Features
Board in used:
DCM2060
Service policy
LCD BOARD
Main BOARD
* TIPS : C -- Component Lever Repair.
M -- Module Lever Repair
-- Used
/12
Feature diffrence
RDS
VOLTAGE SELECTOR
ECO STANDBY - DARK
Type /Versions:
DCM2060
/12
KEY BOARD
USB BOARD
C
DC BOARD
/93
REMOTE BOARD M+C
M+C
M+C
M+C
M+C
M+C
C
C
C
C
C
/93
/96
M+C
M+C
M+C
M+C
M+C
M+C
/96
/79
M+C
M+C
M+C
M+C
M+C
M+C
/79

2.0 SAFTETY INSTRUCTIONS
GB
WARNING
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.
F
ATTENTION
Tous les IC et beaucoup d’autres
semi-conducteurs sont sensibles aux
décharges statiques (ESD).
Leur longévité pourrait être considérablement
écourtée par le fait qu’aucune précaution n’est
prise à leur manipulation.
Lors de réparations, s’assurer de bien être relié
au même potentiel que la masse de l’appareil et
enfiler le bracelet serti d’une résistance de
sécurité.
Veiller à ce que les composants ainsi que les
outils que l’on utilise soient également à ce
potentiel.
ESD
D
WARNUNG
Alle ICs und viele andere Halbleiter sind
empfindlich gegenüber elektrostatischen
Entladungen (ESD).
Unsorgfältige Behandlung im Reparaturfall kan
die Lebensdauer drastisch reduzieren.
Veranlassen Sie, dass Sie im Reparaturfall über
ein Pulsarmband mit Widerstand verbunden
sind mit dem gleichen Potential wie die Masse
des Gerätes.
Bauteile und Hilfsmittel auch auf dieses gleiche
Potential halten.
NL
WAARSCHUWING
Alle IC’s en vele andere halfgeleiders zijn
gevoelig voor electrostatische ontladingen
(ESD).
Onzorgvuldig behandelen tijdens reparatie kan
de levensduur drastisch doen verminderen.
Zorg ervoor dat u tijdens reparatie via een
polsband met weerstand verbonden bent met
hetzelfde potentiaal als de massa van het
apparaat.
Houd componenten en hulpmiddelen ook op
ditzelfde potentiaal.
I
AVVERTIMENTO
Tutti IC e parecchi semi-conduttori sono
sensibili alle scariche statiche (ESD).
La loro longevità potrebbe essere fortemente
ridatta in caso di non osservazione della più
grande cauzione alla loro manipolazione.
Durante le riparazioni occorre quindi essere
collegato allo stesso potenziale che quello della
massa dell’apparecchio tramite un braccialetto
a resistenza.
Assicurarsi che i componenti e anche gli utensili
con quali si lavora siano anche a questo
potenziale.
“Pour votre sécurité, ces documents
doivent être utilisés par des spécia-
listesagréés,seulshabilitésàréparer
votre appareil en panne”.
GB
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used.
NL
Veiligheidsbepalingen vereisen, dat het apparaat bij reparatie in
zijn oorspronkelijke toestand wordt teruggebracht en dat onderdelen,
identiek aan de gespecificeerde, worden toegepast.
F
Les normes de sécurité exigent que l’appareil soit remis à l’état
d’origine et que soient utiliséés les piéces de rechange identiques
à celles spécifiées.
D
Bei jeder Reparatur sind die geltenden Sicherheitsvorschriften zu
beachten. Der Original zustand des Geräts darf nicht verändert werden;
für Reparaturen sind Original-Ersatzteile zu verwenden.
I
Le norme di sicurezza esigono che l’apparecchio venga rimesso
nelle condizioni originali e che siano utilizzati i pezzi di ricambio
identici a quelli specificati.
"After servicing and before returning set to customer perform a
leakage current measurement test from all exposed metal parts to
earth ground to assure no shock hazard exist. The leakage current
must not exceed 0.5mA."
CLASS 1
LASER PRODUCT
3122 110 03420
GB
Warning !
Invisible laser radiation when open.
Avoid direct exposure to beam.
SVarning !
Osynlig laserstrålning när apparaten är öppnad och spärren
är urkopplad. Betrakta ej strålen.
SF Varoitus !
Avatussa laitteessa ja suojalukituksen ohitettaessa olet alttiina
näkymättömälle laserisäteilylle. Älä katso säteeseen!
DK Advarse !
Usynlig laserstråling ved åbning når sikkerhedsafbrydere er
ude af funktion. Undgå udsaettelse for stråling.
Caution: These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
2-2

SET BLOCK DIAGRAM
3 - 1 3 - 1

WIRE CONNECT DIAGRAM
3-2 3-2

DIGITAL TUNER SECTION
LCD SECTION
SEG31 SEG30
SEG29 SEG28 SEG27
SEG26 SEG25 SEG24 SEG23 SEG22
SEG21
SEG20 SEG19
SEG18 SEG17 SEG16
SEG15 SEG14
SEG13
SEG12
SEG11
SEG10 SEG09
SEG08 SEG07
SEG06
SEG05 SEG04 SEG03 SEG02 SEG01
SEG32
COM4 COM3 COM2 COM1
LCD BOARD PART
LCD SECTION
TUNER PART
D202
1N4148
D201
1N4148
B201
BPF C207
100P
R212
10K
L202 FB1K
R208 1K
1 2 3
CN203
1
2
C206
100U
C208
104
R608 0R
R607 0R
R606 0R
R610
2K2
R609
56K
D602
BACKLIGHT LED
R612 47R
Q601
C8050
C602
104
1
S7
2
S6
3
S5
4
S4
5
S3
6
S2
7
S1
8
S0
9
CS
10
RD
11
WR
12
DATA
13
VSS
14
OSCO
15
OSCI
16
VLCD
17
VDD
18
IRQ
19
BZ
20
BZ
21
C0
22
C1
23
C2
24
C3
25 S31 26 S30 27 S29 28 S28 29 S27 30 S26 31 S25 32 S24 33 S23 34 S22 35 S21 36 S20 37 S19 38 S18 39 S17 40 S16 41 S15 42 S14 43 S13 44 S12 45 S11 46 S10 47 S9 48 S8
IC601
ET8861S
1 2 3
4
5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36
LCD601
LCD
C603
47U
S602
S601
Q602
C8050
R611 330R
R614 330R
R613 330R
R601 1K
R603 1K
R602 1K
L603 FB1K
L605 FB1K
C601
104
T3 T6 T7 T8
T14 T15 T16 T17 T18
L602 FB1K
L604 FB1K
9
8
7
6
5
4
3
2
1
CN601
CON9_S
L601 FB 1K
12
S502
SOUNCE
R502
2K4
12
S501
SKIP-
R503 3K6
12
S503
SKIP+
R504 5K6
12
S504
PLAY
R505
10K
12
S505
STOP
R506 12K
12
S506
VOLUME-
R507 43K
12
S507
VOLUME+
12
S508
STANDBY
R509 1K8
12
S509
OPEN/CLOSE
6
5
4
3
2
1
CN501
R501
N/A
D501
N/A
Q501
NA
D502 1N4148
1
2
3
4
CN902
USB_PORT
6
5
4
3
2
1
CN901
L906 FB
L911 FB
L907 FB1K
L908 FB1K
L909 FB1K
L910 FB1K
T1
T2
T4
T5
T20 T21 T23 T24 T25
T26
T27 T29 T30 T31
T34 T35
1
3
2
DC201
DC 12V JACK
12
CN202
TO MAIN BOARD
R403
10R
R402
10R
R401
NA
1OUT 2GND 3VDD
IR401
R94EV1A
1
2
3
CN401
C401
104
R511
1K5
C216
20P
C213
20P
C214
20P
C215
20P
C201
20P
C210 105
C211
105
C203103
C204103
R202 1K
R201 1K
C205
20P
C202
20P
L209 0R
T13 T19
3
4
5
6
7
8
9
10
11
12
22
21
20
19
18
17
16
15
14
13
23
24
2
1
IC201
4705/4704
X201
32.768KHz
C294
20P
C295
20P
C296
223
C299
223
R219
0R
R218
10k
R213
10k
R214
10k
R216
470R
R215470R
C298 560p
12
11
10
9
8
7
6
5
4
3
2
1
CN201
T28
T36
T37
T38
C606
220U
C209
20P
C212
20P
T33
L211
0R
T32
T52
T53
HW_SCL
HW_SDA
TUNER/CP_RESET
HW_SDA
HW_SCL
TUNER/CP_RESET
TUNER/DAB_3V3
SPI_MOSI
SPI_CLK
SPI_CS0
COM2 COM1 COM4 COM3
COM4
COM3
COM2
COM1
+3V3
BACKLIGHT_CTL1
BACKLIGHT_CTL2
SPI_CS0
SPI_MOSI
SPI_CLK
+3V3
BACKLIGHT_CTL1
BACKLIGHT_CTL2
S10
S10 S11
S12
S13
S14
S15
S11 S12
S13 S14
S15
KEY0
STANDBY_KEY
KEY1
KEY0 STANDBY_KEY
KEY1
$$$1
TUNER/DAB_3V3
CLOSE_DET
OPEN_DET
CLOSE_DET
OPEN_DET
TUNER/DAB_3V3
TUNER/DAB_3V3
4 - 14 - 1
CIRCUIT DIAGRAM - LCD + KEY + REOMOTE INCEPT BOARD

CIRCUIT DIAGRAM - DC BOARD
H H 3
L H 2
H L 1
L L 0
S0 S1 channels
IWL Word Leng
0 =16bit
1=20bit
Z=24bit
FORMAT
Z=I2S
because analog channel is reverse, so need to swap them
Tuner/DAB_ON
Tuner/DAB_ON
RDS_INT
M/S H For Master
master mode supports 384/192 FS
Only for DCM2070 (DAB)
LCD_D0
ANALOG_CH_SEL H For Tuner/DAB_ON
HW setting H for boot
Alternative FB10 only for DCM2070(DAB)
BACKLIGHT_CTL2 for dim
FB41 only for MCD2060
Only for DCM2060
DIGITAL TUNER SECTION
781(53$57
& 
5 5
& X)
& X)
& X)
& X)
&
8
&
8
0&/.
'287
/5&/.
'*1'
'9''
%&/.
,:/
)6$03(1
)250$7
 90,'

06 
$,1/ 
$,123/ 
&20 
$,15 
$,1235 
$*1' 
$9'' 
95()3 
95()*1'
8 :0
& 
& 8
&

5 .
&

&

5 .
5 .
5 .
5 .
& 8
& 8
5 5
5 5
5 5
&  & 
5 .
5 .
<
<

=
<
<

(
9((

*1'

9&&
 <
 <

=
 <
 <

6 
6
8 /93:
&

5 .
&



4

5 .
5 .
&X)
)%
)%.


4
66
5 .
)%
)%.
)%
)%.
)%
)%.
)%
)%.
5
5
5
5
& X)
& X)
5
.
5
.
5 5
)%
)%.
)%
)%.
&X) &X)
&X)
5 .
)% 1$
)% 1$
5 .
5 .
5 .
& 
5 .
5 .
)% )%.
5 .
5 .
5 5
5 5









-
&21B6
5 5
)%
$
5 5
5 5
5 5
5 5
5 .
7
7 7
7 7
7
7
7 7
7 7 7
7
7
7 7
7
7
& 
& 
        
  
&1
'
1
'
1
%
%3) &
3
5
.
5 .
  
&1


&
8
&
 &
3
&
3
&
3
&
3
&
3
& 
&

&
&
5 .
5 .
&
3
&
3
/ 8+
























,&

;
.+]
&
3
&
3
&

&

5
N
5
N
5
5
55
&

/ 7
5
1$
0$;B/
/&'B'
0$;B5
$8;B/B,1
,3B/&+
$8;B5B,1
,3B5&+
27+(5B9
$03B&/.
$'&B'$7$
$'&B/5&.
27+(5B9
$'&B%&/.
90,'
0$;B/
0$;B5
$B9
781(5'$%B9&&
27+(5B9
$1$/2*B&+B6(/
781(5'$%B9&&
781(5'$%B5,1
781(5'$%B/,1
*3,2B6'$
*3,2B6&/
781(5'$%B/,1
781(5'$%B5,1
$1$/2*B&+B6(/
781(5&3B5(6(7
27+(5B9
'$%B5;
'$%B7;
63,B&6
63,B026,
63,B&/.
9
%$&./,*+7B&7/
67$1'%<B&7/
23(1B'(7
&/26(B'(7
9
90,'
8$57B5;
8$57B7;
,32'B5;
'$%B7;
'$%B5;
,32'B7;
+:B6&/
+:B6'$
781(5&3B 5(6(7
+:B6'$
+:B6&/
781(5&3B 5(6(7
781(5

'$%
B
9
781(5'$%B9
781(5'$%B9
781(5'$%B9
4-2 4-2

CIRCUIT DIAGRAM - USB BOARD
5 .
5 .
&
3
5 .
5 .
&
3
5 .
5 .
287$


966

9''

287%




,&
(7.
5 .
5 .
&
3
5 .
5 .
&
3
5 .
5 .
& S)
5 .
& X)
& S)
5 .
& X)
5 .
5 .
& S)
5 .
5 . & S)
& 
& X)
5 5
5 .
&
X)
/
)%.
&

& 

9,1
9287
*1'
,&
/1










&1
&21B6
/
5
*
-
03B,1
5.
5.
&
3
&
3
5
.
5.









-
+3-$&.
/
)%.
/
)%.
/
)%.
/
)%.
/
)%.
7
7
7
7
7
5 . 5 .
& S) & S)
5 5
5 5
/ 8+
/ 8+
& S) & S)
& Q) & Q)
5 5
5 5
&
S
&
S
7 7
7
7
7
7
7
7
7
7
7
'
1$
/ )%.
7
7
287%
287$
287%
287$
($53+21(B5
($53+21(B/
$B9
287%
287$
$B9
287$
287%
($53+21(B5
($53+21(B/
4-3 4-3

4 - 4 4 - 4
LAYOUT DIAGARM - LCD + DC + USB + KEY + RE-LCD + DC + USB + KEY + RE-
MOTE INCEPT BOARD TOP VIEW

LAYOUT DIAGARM - LCD + DC + USB + KEY + RE-LCD + DC + USB + KEY + RE-
MOTE INCEPT BOARD BOTTOM VIEW
4-5 4-5

CIRCUIT DIAGARM - REMOTE HANDSET BOARD
4 - 6 4 - 6




















IC901
IC-SC73P1601
6:
67%<
6:
RSHQ
6:
FG
6:
WXQHU
6:
DOSU
6:
IE
6:
3$/<
6:
II
6:
DOSU
6:
XVEPS
6:
LSG
6:
&/.',6
6:
PXWH
6:
VWRSPHQX
6:
YRO
6:
YRO
6:

6:

6:

6:
6:

6:

6:

6:

6:

6:
SUVHW
6:

6:
UHS
6:
WLPHUVHHOS
6:
GVF
6: GEE
5 5
5 5
(
%
&
4

 
/('
(&
8 &
3
 
;
0


&
S


&
S

LAYOUT DIAGARM - REMOTE HANDSET
BOARD
4-7 4-7

CIRCUIT DIAGARM -IPOD BOARD
4-8 4-8
%DQGUDWHRU
L32'SLQ'RFNLQJVRFNHW
L3RGGRFNLQJVXEERDUGFRQQHFWRU
Ipod docking subboard
for IR section
pitch1.0mm
'*1'
'*1'0$,1B/,1.B/$1(B5(7851
'3B0/B/$1(B3
86%B'
'3B0/B/$1(B1
86%B'
'3B0/B/$1(B3
86%B9%86
'3B0/B/$1(B1
 $&&(B,'(17,)<
 '3B+27B3/8*B'(7(&7
 ):B3:5)/2$7,1*
 $&&(6625<B3:5,32'B287387
 5(6(59('
 '*1'$8;,/,$5<B&+$11(/B5(7851
 '*1'0$,1B/$1(B/,1.B5(7851
 5(6(59('
 5;
 7;
 $&&(B'(7(&7
 6B9,'(2B<&20321(17B35
 6B9,'(2B&&20321(17B<
 &20326,7(B9,'(23%
 5(027(B6(16(
 /,1(B,1B/'3B$8;B&+B3
 /,1(B,1B5'3B$8;B&+B1
 /,1(B287B/
 /,1(B287B5
 $8',29,'(2B5(7851
 '*1'
 &+$66,6
 &+$66,6
IP801
,32'B3,1
5
5
&

5
.
&

5
.
5
5


&1
&21B6
5
5
5
5
5
5
5
5



4
$76
5
.
5 .



4
$76
















&1
&21B6
5
.



&1
5 .
,32'B'(7
,32'B'
,32'B'
,32'B9
$&&B32:(5
*1'
*1'
,32'B'
,32'B'
,32'B5B&+
,32'B'(7
8$57B7;
8$57B5;
,32'B/B&+
,32'B5B&+
$*1'
8$57B7;
8$57B5;
,32'B9
$&&B32:(5
,32'B+:B&+$5*(B&7/
,32'B/B&+
$*1'
,32'B+:B&+$5*(B&7/

LAYOUT DIAGARM -IPOD BOARD
TOP VIEW
4-9 4-9
LAYOUT DIAGARM -IPOD BOARD
BOTTOM VIEW
