Philips MC1000/12 User manual

Register your product and get support at
www.philips.com/welcome MC1000
EN User manual

EN
1 Important
Safety
Read and understand all instructions before you use this micro music
system. If damage is caused by failure to follow the instructions, the
warranty does not apply.

 Never expose the product and accessories to rain or water. Never
place liquid containers, such as vases, near the product. If liquids are
spilt on or into the product, disconnect it from the power outlet
immediately. Contact Philips Consumer Care to have the product
checked before use.
 
heat sources, including direct sunlight.
 Never insert objects into the ventilation slots or other openings on
the product.
 Make sure that you always have easy access to the power adaptor to
disconnect the product from the power outlet.
 Disconnect the product from the power outlet before lightning
storms.
 When you disconnect the power adaptor, always pull the plug, never
the cable.

 Before you connect the product to the power outlet, make sure
that the power voltage matches the value printed on the bottom of
the product. Never connect the product to the power outlet if the
voltage is different.
 Avoid force coming onto power plugs. Loose power plugs can cause



 Visible and invisible laser radiation when open.Avoid exposure to beam.
 Do not touch the disc optical lens inside the disc compartment.
 Never place the product or any objects on power cords or on other
electrical equipment.
 If the product is transported in temperatures below 5°C, unpack the
product and wait until its temperature matches room temperature
before connecting it to the power outlet.

 
of at least four inches around the product for ventilation.
 Make sure that curtains or other objects never cover the ventilation
slots on the product.

 The product may contain a coin type battery, which can be
swallowed. Keep the battery out of reach of children at all times!
Notice

approved by Philips Consumer Lifestyle may void the user’s authority to
operate the equipment.
Compliance
This product complies with the radio interference
requirements of the European Community.
This apparatus includes this label:

Care of the environment
Your product is designed and manufactured with high quality
materials and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a
product it means that the product is covered by the European
Directive 2002/96/EC.
Please inform yourself about the local separate collection
system for electrical and electronic products.
Please act according to your local rules and do not dispose of your old
products with your normal household waste. Correct disposal of your
old product helps to prevent potential negative consequences for the
environment and human health.
Your product contains batteries covered by the European
Directive 2006/66/EC, which cannot be disposed with normal
household waste.Please inform yourself about the local rules on
separate collection of batteries because correct disposal helps
to prevent negative consequences for the environmental and human
health.
Environmental information
All unnecessary packaging has been omitted.We have tried to make
the packaging easy to separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
Copyright

The making of unauthorized copies of copy-protected material, including

an infringement of copyrights and constitute a criminal offence.This
equipment should not be used for such purposes.
2012 © Koninklijke Philips Electronics N.V.

the property of Koninklijke Philips Electronics N.V or their respective
owners. Philips reserves the right to change products at any time
without being obliged to adjust earlier supplies accordingly.
Note
 The type plate is located on the bottom of the system.
2 Your micro music system
Congratulations on your purchase, and welcome to Philips! To fully

www.philips.com/welcome.
Introduction
With this system, you can:
 enjoy audio from discs and other external devices
 listen to FM radio stations
You can enrich sound output with the sound effect:
 Dynamic bass boost (DBB)
Playable media:
 CD-DA, CD-R, CD-RW

What’s in the box
Check and identify the contents of the package:
 Micro music system
 MP3 link cable
 User manual
Overview of the system
a
b
c
d
e
f
g
h
j
i
n
l
k
m
o
p
q
INTRO PROG
a Cover of disc compartment
b Disc compartment
c Integrated speaker
d DBB
 Slide to enable or disable the DBB sound effect.
e Indicator window
 Indicate the frequency of current FM radio station.

f TUNING
 Rotate to select an FM radio frequency.
g SHUFFLE
 
h REPEAT
 Press repeatedly to select a play mode: repeat the current
track, repeat all tracks, or play tracks in sequence.
i STOP
 Stop the play of an audio track.
 Press twice to erase a program play.
j PLAY/PAUSE
 Start, pause, or resume the play of audio tracks.
k / PREVIOUS/NEXT
 Skip to the previous/next audio track.
l PROG
 Program audio tracks.
m INTRO
 Scan all tracks.
n - VOLUME +
 Rotate to adjust the volume level.
o LCD screen
p MP3-LINK
 Connect to the audio output socket (usually the headphone
socket) of an external device.
q Power switch and source selector
 Slide to select a source or turn off the system.

3 Get started
Caution
 Use of controls or adjustments or performance of procedures
other than herein may result in hazardous radiation exposure or
other unsafe operation.
Always follow the instructions in this chapter in sequence.
Connect power
Connect the power adaptor to the power supply socket.

Turn on and select a source
Slide the power switch and source selector to CD or FM.
» The LED indicator beside the LCD screen lights up in red.
 To turn off the system, slide it to OFF.
 When the power switch and source selector is not in the “OFF“
position and an MP3 link cable is connected to the MP3-LINK
socket, the system automatically switches the source to audio
input through the MP3-LINK socket.
Switch modes
Automatically switch the modes:
After the system stays inactive for 5 minutes in CD mode, it
automatically switches to standby mode.
4 Play discs
1 Slide the power switch and source selector to CD.
2 Lift the cover of disc compartment.
3 Load a disc with the printed side facing upwards.
4 Close the cover of disc compartment.
» Play starts automatically after a few seconds.
 If play does not start automatically, press to start play.
Control play
During play, follow the instructions below to control play.
Buttons Functions LCD screen displays
Start or resume play. the track number and

Pause play. the track number and
(blinking)
Stop play. the total number of
tracks
/ Press to skip to the
previous or next track. the track number and
/ Press and hold to rewind
or search forward fast
within a track.
the track number and
Program tracks
Note
 You can program a maximum of 20 tracks.
 During programming, if no operation is made within 20 seconds, the
system returns to stop mode without saving programmed tracks.
1 Press to stop play.
» The total number of tracks is displayed.
2 Press PROG to activate the programming.
3 Press / to select a track.
» The track number blinks.
4 Press PROG again to program the selected track.
5 Repeat steps 3 and 4 to program more tracks.
6 Press to start play.

Erase the program
To erase the program,
 Press twice.
 Slide the power switch and source selector.
Scan all tracks
During play, press INTRO
by one.
 To stop scanning, press INTRO again.
5 Listen to radio
Note
 For optimal reception, fully extend the FM antenna and adjust its
position.
1 Slide the power switch and source selector to FM.
2 Rotate the TUNING knob to tune to an FM radio station.
6 Listen to an external device
You can use the system as a speaker to amplify the audio input from an
external device, for example, MP3 player.

PM
3
-K
N
I
L
1 Slide the power switch and source selector to CD or FM.
2 Connect the MP3 link cable to
 the MP3-LINK socket on the system, and
 the audio output socket (usually the headphone socket) on the
external device.
3 Play the external device.
Note
 To play audio input from other sources, disconnect the MP3 link
cable from the system.

7 Adjust sound
The following operations are applicable to all supported media.
Adjust the volume level
Rotate the - VOLUME + knob clockwise or anti-clockwise to increase
or decrease the volume level.
Use the DBB sound effect
Slide DBB to ON to enable the DBB sound effect.
 To disable the DBB sound effect, slide DBB to OFF.
8 Product information
Note
 Product information is subject to change without prior notice.


Rated output power 2 X 2 W RMS
Frequency response 40 Hz - 20 kHz, ±3 dB
Signal-to-noise ratio > 50 dB
MP3-Link input 600 mV RMS, 22 kOhm

Disc
Laser type Semiconductor
Disc diameter 12 cm, 8 cm
Supported discs CD-DA, CD-R, CD-RW
Audio DAC 24 Bits, 44.1 kHz
Total harmonic distortion < 1%
Frequency response 60 Hz -16 kHz
S/N Ratio > 55 dB
Tuner (FM)
Tuning range 88-108 MHz
Sensitivity
- Mono, 26 dB S/N Ratio
- Stereo, 46 dB S/N Ratio
< 22 dBf
< 43 dBf
Total harmonic distortion < 3%
Signal-to-noise ratio > 50 dB
General information
AC power input 100-240 V ~, 50-60 Hz
Output of AC-DC power adaptor 12 V , 1000 mA
Operation power consumption 10 W
Dimensions (W x H x D) 450 x 158 x 208.5 mm
Net weight 2.05 kg

Maintenance
Clean the cabinet
 Use a soft cloth slightly moistened with a mild detergent solution. Do
not use a solution containing alcohol, spirits, ammonia or abrasives.
Clean discs
 When a disc becomes dirty, clean it with a cleaning
cloth.Wipe the disc from the centre out.
 Do not use solvents such as benzene, thinner,
commercially available cleaners, or antistatic spray
intended for analogue records.
Clean the disc lens
 After prolonged use, dirt or dust may accumulate
at the disc lens.To ensure good play quality, clean
the disc lens with Philips CD lens cleaner or any commercially
available cleaner. Follow the instructions supplied with cleaner.
9 Troubleshooting
Warning
 Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair the product yourself.
If you encounter problems when using this product, check the following
points before requesting service. If the problem remains unsolved, go
to the Philips Web page (www.philips.com/support).When you contact
Philips, make sure that the product is nearby and the model number
and serial number are available.
Write down the model number and serial number for record.
 Model number:
 Serial number:

Problem Solution
No power. Make sure that the power adaptor is securely
connected to the power supply.
Make sure that the power supply is available.
No sound or
poor sound.
Adjust the volume level.
To play audio input from a source other than MP3-
LINK socket, disconnect the MP3 link cable.
No response
from the
system.
Reconnect the power adaptor, and then turn on the
system again.
As a power-saving feature, the system automatically
switches to standby mode after it stays inactive for 5
minutes in CD mode.
No disc is
detected.
Insert a disc.
Make sure that the printed side of the disc faces
outwards.
Wait until the moisture condensation at the lens is
cleared.
Replace or clean the disc.

Radio
reception is
poor.
Increase the distance between the system and your
TV or VCR.
Fully extend the FM antenna.
Adjust the position of the FM antenna.
Connect an outdoor FM antenna instead.


© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
MC1000_12_UM_V1.0
