Philips HQ C644 User manual

ENGLISH 4
DEUTSCH 8
NORSK 12
SVENSKA 16
SUOMI 20
DANSK 24
HQ C644
3

Important
◗Check if the voltage indicated on the mains
plug corresponds to the mains voltage in your
home before you connect the appliance.
◗Make sure the appliance does not get wet.
◗Store the appliance at a temperature between
15cand 35cC.
C◗Protect the instruction video from dust,
humidity,too high or too low temperatures
and magnetic fields (i.e.television sets or
loudspeakers).
◗Do not open the protective flap of the video
cassette and do not touch the tape.
◗If the video is stored in a cold environment,
do not use it until it has reached room
temperature.
◗Insert the video cassette with the window
facing upwards.
Preparing for clipping
◗See also the booklet 'Modelling and styling'
and the instruction video.
ENGLISH4

Clipping with comb attachment:
Select the small or large comb attachment,
depending on the desired hair length (see table).
C1Slide the comb holder carefully into the
guiding grooves of the appliance until you
hear a click.
C2Turn the Precicion Zoom Lock™ to the
desired hair length setting (see table).
3Insert the mains plug into the wall socket.
4Switch the appliance on.
If a lot of hair has accumulated in the comb,
remove the comb attachment and blow and/or
shake the hair out of the comb.
Cutting length settings
Small comb Large comb
setting hair length setting hair length
1 4 mm 8 24 mm
2 7 mm 9 27 mm
3 10 mm 10 30 mm
4 13 mm 11 33 mm
5 16 mm 12 35 mm
6 19 mm 13 38 mm
7 21 mm 14 40 mm
ENGLISH 5
1 • 3 • 5 • 7

Clipping without comb attachment
C1Remove the comb attachment by pulling it
off the appliance.
Clean the appliance every time you have used it.
Cleaning
Do not use abrasives,scourers or liquids such as
alcohol,petrol or acetone to clean the appliance.
1Make sure the appliance is switched off
and disconnected from the mains before
you start cleaning it.
2Remove the comb attachment.
C3Open the cutting unit.
C4Clean the cutting unit and the inside of the
appliance with the brush supplied.
C5Close the cutting unit.
6Push the cutting unit until you hear a click.
ENGLISH6

Replacement
A worn or damaged cutting unit should only be
replaced with an original Philips cutting unit.
1Remove the old cutting unit.
C2Place the two lugs of the new cutting unit
into the guiding slots and push the unit
back onto the appliance.
If the mains cord of this appliance is damaged,it
may only be replaced by Philips or an authorised
Philips service centre,as special tools and/or parts
are required.
For telephone numbers of the Philips Helpdesk,
see theWorldwide Guarantee leaflet.
ENGLISH 7
