Philips cBright I Series User manual

Amazingly compact
Amazingly bright
Another bright idea
ULTRA BRIGHT
NEW COMPACT DESIGN
HOT PLUG&PLAY
3 YEARS WARRANTY
cBright series
PHILIPS MULTIMEDIA PROJECTORS
www.pcstuff.philips.com/projectors
series
series
cBright
cBright
Image diagonal size Projection distance
Tele zoom Wide zoom
[inch][
metres][ inch][ metres][ inch][ metres]
40
60
70
80
100
150
200
250
1,0
1,5
1,8
2,0
2,5
3,8
5,1
6,4
80
120
202
303
405
506
141
161
62
156
234
316
395
109
124
93
2,0
3,1
3,6
4,1
5,1
7,7
10,3
12,9
1,6
2,4
2,8
3,2
4,0
5,9
8,0
10,0
3122 435 95020 Design and specifications are subject to change without notice
* Available in the US,Western Europe.Chec k with your dealer for similar coverage in other regions.
More information
XG1 Impact
• 1500 ANSI lumens
• XGA resolution
XG1
•1100 ANSI lumens
•XGA resolution
SV1
•1400 ANSI lumens
•SVGA resolution
cBright series
Compact (H:102mm W:328mm D:226mm)
Weight (3.6 kg; 7,9 lbs)
Complete picture control (Digital Freeze,
Digital Zoom, Auto Image, Picture formats
4:3 or 16:9)
USB (hot plug&play mouse control and
USB audio)
Digital keystone correction
Unique 1 cable concept for data, USB
mouse and USB audio connection
Easy plug&play
200W long-lasting UHP lamp for uniform
images, rich colours and brightness
over time
Hot plug&play USB mouse control and
USB audio
Advanced compatibility for both data
and video
37dB Philips Air System™for silent opera-
tion
Auto-image for trouble-free operation and
optimal image quality
Kensington lock
Ceiling mountable
Free support:
• First Choice* support
• Free toll-free technical support*
• 3 year warranty
•
•
•
•
•
•
•
•
•
XG1 Impact XG1 SV1
LC 4345 LC 4341 LC 4331
LCD 3x 0.9" high-temperature poly-silicon active matrix LCDs
Resolution XGA resolution (1024x768) SVGA resolution (800x600)
Number of pixels 2,359,296 1,440,000
Brightness 1500 Ansi Lumens 1100 Ansi Lumens 1400 Ansi Lumens
Contrast 260:1 310:1 340:1
Lamp UHP™200W (1500 hours),end user replaceable
Lens F/2.0-2.2 ; f = 36.5 –46.6 mm
1.3x Manual Zoom; Manual Focus
Projection distance 1.0 - 12 m (image diagonal 20" - 300")
Input signals
Video NTSC 3.58, 4.43 / PAL B/G, N, M / SECAM
Data PC and MAC compatible, Multi scanVGA-SXGA; Auto Image
Horizontal Scan rate: up to 100 kHz; Vertical Refresh rate: up to 120 Hz
Bandwidth 140 MHz
Input connectors
Video 1x S-Video (Y/C DIN) e.g. for DVD,1x CVBS Audio/Video (3x RCA)
Data 1x D-sub (15 pin)
Other 1x USB type B connector (upstream)
Power in 100 - 240V, 50/60 Hz;250 W
Output connectors
Audio 1x Stereo Audio (3.5 mm.stereo jack)
Other Monitor out 1x D-sub (15 pin)
Specialties Long life and constant light output over entire lamp life projection lamp
Auto-image for trouble-free operation and optimal image quality
Full PC mouse control via RC unit and USB
USB Audio for sound from an external source on the projector
37dB Philips Air System for silent operation
Digital keystone correction,digital zoom/freeze, picture format 4:3 or 16:9
Kensington lock
Dimensions 102 x 328 x 226 mm (4.0" x 12.9" x 8.9") (HxWxD)
Net weight 3.6 kg; 7,9 lbs
Operating temperature +5 .. +35 ºC (41 ..95 ºF)
Package cBright XG1 Impact cBright XG1 cBright SV1
Trackerball remote control Compact remote control
Power cord,Combi VGA/USB cable (1,8m)
Audio/Video cable (3x RCA, 2m)
Scart adapter (scart to RCA audio/video)*
Lenscap
Soft carrying bag
CD-ROM User Guide (UK, GE, FR, ES, PT, NL, IT)
Quick Set up card (UK, GE, FR, ES, PT, NL, IT)
Optional accessories UHP™200W replacement lamp (LCA3111/00)
Ergonomic trackerball remote control (LCA4117/00)
VGA extension cable, 15 meters (LCA5300/00)
Ceiling mount (LCA2210/00)
Executions LC4345/17 for USA LC4341/17 for USA LC4331/17 for USA
LC4345/40 for EU/ROW LC4341/40 for EU/ROW LC4331/40 for EU/ROW
LC4345/45 for UK LC4341/45 for UK LC4331/45 for UK
* depending on regional requirement. Information subject to change without notice.
technical specificationsfeatures

Amazingly bright
Specifically designed for your medium-sized
meeting rooms, the new cBright is the
answer to all of your presentation needs.
With its 200w UHP™bulb producing up to
1550 ANSI Lumens, it’s more than powerful
enough to project clearly in the biggest
and brightest meeting rooms, while still
maintaining extremely high resolution
and contrast.
Amazingly compact
You ’ll only notice the rest of cBright’s
outstanding features when you’re up close.
It always impresses with its uniquely stylish
curves, and sharp metallic finish.
But never distracts, thanks to its silent
cooling system. Its design is also extremely
durable, compact and lightweight, for easy
handling. All of which means that with a
cBright, you know you’re always projecting
the right image.
Wonderfully simple
There’s no complicated instruction manual to
memorise before you can use a cBright.
Its advanced user-friendly features, such as
digital zoom and freeze, auto imaging, digital
keystone correction, OSD, and USB plug &
play, are all extremely intuitive. Leaving you
free to concentrate on making that perfect
presentation.
Another bright idea
Do you want a projector that will work in the brightest of meeting rooms?
Do you want a projector that offers hassle-free any to use installation.
Do you want a projector that looks as stylish as you do?
Well then the new cBright series is for you. Consummate projection systems
that impress as much with their design, as they do with their performance.
The Philips Guarantee
The Philips range of advanced multimedia
projectors. Combining portability, reliability,
and unsurpassed performance with a host
of technological innovations. All of which
guarantees you impressive and hassle-free
projection wherever you are. Just what
you’d expect from the innovative world
leader in sound and vision technology.
3 years warranty and free support
Every cBright projector comes with a full
three-year warranty. This unique offer is
backed up by the outstanding Philips First
Choice service, including a toll-free helpline*,
offering you help and advice seven days a
week. While the Philips First Choice*
service is there for more difficult problems
–guaranteeing you a temporary
replacement, with free delivery, within 48hrs.
An unbeatable package.
UHP™lamp
All of our projectors contain the unique
Philips UHP™(Ultra High Performance)
lamp that cuts costs and hassle. It’s the first
lamp to retain rich colours and brightness
without creating hot spots over its amazingly
long life of around 1,500 hours.
Extremely compatible
Philips projectors are extremely compatible
with a whole range of data and video sources.
This is thanks to their highly advanced
scaling technology –converting information
without any loss or deterioration. A serious
advantage when you need to make an extra
special impression.
Philips projectors
The cBright series is part of the award-
winning range of Philips projectors.
Projectors with different strengths and
features, to meet the different needs of
different applications. So whatever your
demands, Philips projectors can more than
match them. Visit www.pcstuff.philips.com
for more information.
* Currently only available in the US and Western Europe.
Check with your Philips dealer for more details.
www.pcstuff.philips.com/projectors
Standard accessories
Every cBright projector package comes with
the following as standard:
•Power cord (combinedVGA/USB cable)
•Audio/video cable
•Scart adapter (Scart to RCA audio/video)
•Lens cap
•Soft carrying case
•CD-ROM User Guide
•Quick set-up card
Optional accessories
A range of additional accessories are on
offer to help you make that extra special
impression.
•Ceiling mount
•Replacement 200W UHP™lamp
•Ergonomic trackerball remote control
•VGA extension cable (15m)
The full digital Philips portfolio
A selection of additional presentation aids
are also available, including everything from
monitors, TVs, and digital cameras, to
video-conferencing links, DVD players, and
notebook computers. Visit our website
for the complete list.
Compact
H:102mm W:328mm D:226mm
3.6kg (7.9lbs) lightweight
design
38dB: super-silent Philips Air
System
•200W UHP™lamp
•USB audio for external sound source
•Kensington lock
•Digital keystone correction
•Digital zoom/freeze
•4:3 or 16:0 –Choice of picture
formats
•Full PC mouse control via RC unit
and USB
•Advanced compatibility for both
data and video input (compatible
with main notebook computers)
•Unigue one-cable concept
cBright
XG1
impact
XG1
Impact
cBright
Taking projection
to the next level
The cBright XGA Impact harnesses the
power of its 200w UMP™bulb to create
pictures that always get your message across.
1500 ANSI Lumens
XGA resolution
cBright
XG1
XG1
cBright
Maximum resolution
Minimum hassle
Producing silent power, at XGA resolution,
this projector will always rise to the occasion.
1100 ANSI Lumens
XGA resolution
cBright
SV1
SV1
cBright
The projector
with punch
All of the cBright benefits at an affordable
price. The cBright SVGA is the advanced
multi-purpose projector you can rely on
to excel.
1400 ANSI Lumens
SVGA resolution
