Philips HD4566 User manual

HD4566
User Manual
Always there to help you
Register your product and get support from
Question?
Contact
Philips
www.philips.com/welcome

2EN
9 Specications 24
10 Troubleshooting 25
Contents
1 Your rice cooker 3
2 Important 4
Power failure backup function 5
Electromagnetic elds (EMF) 5
3 What’sinthebox 6
4 Overview 7
Product overview 7
Controls overview 8
5 Usingtheappliance 9
Before rst use 9
Three ways of using the slider bar 9
东北米 (Northeast rice), 丝苗米 (See-
mew rice), 寿司米 (Sushi rice), 香米
(Jasmine rice), 其它 (others) 10
旋风煮 (Ultra quick rice cooking), 农家
饭 (Country avored rice cooking), 粗粮
饭 (Cooking grain), 八宝饭 (Eight-treasure
rice pudding), 少量煮 (Small portion rice
cooking), 菜饭 (Cooking rice with food) 13
煮粥 (Cooking congee), 杂粮粥 (Cooking
congee with grains), 稀饭 (Cooking gruel),
煲汤 (Making soup), 慢炖 (Slow cooking) 14
煲仔饭 (Claypot rice cooking) 15
煮面 (Cooking noodles) 16
热饭 (Reheating) 17
Set the cooking time 18
Preset time for delayed cooking 18
Set up My Favorite menu 19
Set up child lock 20
6 CleaningandMaintenance 21
Disassemble the inner lid and steam valve 21
Interior 22
Exterior 22
Accessories and inner pot 22
7 Environment 23
8 Guaranteeandservice 23

3
EN
1 Your rice cooker
Congratulations on your purchase, and
welcome to Philips!
To fully benet from the support that
Philips offers, register your product at
www.Philips.com/welcome.

4EN
2 Important
Read this safety leaet carefully before you
use the appliance and save it for future
reference.
Danger
• Donotimmersetheappliancein
water,norrinseitunderthetap.
Warning
• Thisapplianceisnotintendedforuse
bypersons(includingchildren)with
reducedphysicalsensoryormental
capabilities,orlackofexperience
andknowledge,unlesstheyhave
beengivensupervisionorinstruction
concerninguseoftheappliancebya
personresponsiblefortheirsafety.
• Childrenshouldbesupervisedto
ensurethattheydonotplaywiththe
appliance.
• Thisapplianceshouldbepositionedin
astablesituationwiththehandles(if
any)positionedtoavoidspillageofthe
hotliquids.
• Thisapplianceisintendedtobeused
inhouseholdandsimilarapplications
suchas:
• staffkitchenareasinshops,ofces
andotherworkingenvironments;
• farmhouses;
• byclientsinhotels,motels
andotherresidentialtype
environments;
• bedandbreakfasttype
environments.
• Makesurethatthedamagedpower
cordisreplacedbyPhilips,aservice
centerauthorizedbyPhilipsor
similarlyqualiedpersonsinorderto
avoidahazard.
• Theapplianceisnotintendedtobe
operatedbymeansofanexternal
timeroraseparateremote-control
system.
• Checkifthevoltageindicatedonthe
appliancecorrespondstothelocal
powervoltagebeforeyouconnectit.
• Onlyconnecttheappliancetoa
groundedpoweroutlet.Alwaysmake
surethattheplugisinsertedrmly
intothepoweroutlet.
• Donotusetheapplianceiftheplug,
thepowercord,theinnerpot,the
sealingring,orthemainbodyis
damaged.
• Donotletthepowercordhangover
theedgeofthetableorworktopon
whichtheappliancestands.
• Makesuretheheatingelement,the
temperaturesensor,andtheoutside
oftheinnerpotarecleananddry
beforeyouputthepluginthepower
outlet.
• Donotplugintheapplianceorpress
anyofthebuttonsonthecontrol
panelwithwethands.
Caution
• Neveruseanyaccessoriesor
partsfromothermanufacturers
orthatPhilipsdoesnotspecically
recommend.Ifyouusesuch
accessoriesorparts,yourguarantee
becomesinvalid.
• Donotexposetheapplianceto
hightemperatures,norplaceitona
workingorstillhotstoveorcooker.
• Donotexposetheappliancetodirect
sunlight.
• Placetheapplianceonastable,
horizontal,andlevelsurface.

5
EN
• Alwaysputtheinnerpotinthe
appliancebeforeyouputtheplugin
thepoweroutletandswitchiton.
• Donotplacetheinnerpotdirectly
overanopenretocookrice.
• Donotusetheinnerpotifitis
deformed.
• Theaccessiblesurfacesmaybecome
hotwhentheapplianceisoperating.
Takeextracautionwhentouchingthe
appliance.
• Bewareofhotsteamcomingoutof
thesteamventduringcookingorout
oftheappliancewhenyouopenthe
lid.Keephandsandfaceawayfrom
theappliancetoavoidthesteam.
• Donotliftandmovetheappliance
whileitisoperating.
• Donotexceedthemaximumwater
levelindicatedintheinnerpotto
preventoverowwhichmightcause
potentialhazard.
• Donotplacethecookingutensils
insidethepotwhilecooking,keeping
warmorreheatingrice.
• Onlyusethecookingutensils
provided.Avoidusingsharputensils.
• Toavoidscratches,itisnot
recommendedtocookingredients
withcrustaceansandshellsh.Remove
thehardshellsbeforecooking.
• Donotinsertmetallicobjectsoralien
substancesintothesteamvent.
• Donotplaceamagneticsubstanceon
thelid.Donotusetheappliancenear
amagneticsubstance.
• Alwayslettheappliancecooldown
beforeyoucleanormoveit.
• Alwayscleantheapplianceafter
use.Donotcleantheapplianceina
dishwasher.
• Alwaysunplugtheapplianceifnot
usedforalongerperiod.
• Iftheapplianceisusedimproperlyor
forprofessionalorsemiprofessional
purposes,orifitisnotusedaccording
totheinstructionsinthisusermanual,
theguaranteebecomesinvalidand
Philipsrefusesliabilityforanydamage
caused.
Powerfailurebackupfunction
This appliance has a backup function that
reserves the status before a power failure.
• If the power failure occurs during a
cooking process, and the power supply is
resumed within 1 hours, the countdown
of the cooking time continues where it
is left off.
• If the power failure occurs when the
appliance is at preset mode, and the
power supply is resumed within 1 hours,
the countdown of the preset time
continues where it is left off.
• If the power supply is not resumed
within 1 hours, the appliance might not
continue with the previous working
process, but stay in standby mode.
Electromagneticelds(EMF)
This Philips appliance complies with all
applicable standards and regulations
regarding exposure to electromagnetic
elds.

6EN
3 What’sinthebox
aMain unit eUser manual
bRice Scoop fSteam rack
cPower cord gMeasuring cup
dWarranty card
http://www.philips.com/welcome
用户手册
http://www.philips.com/welcome
保修卡
a
b
c
d
f
g
e

7
EN
4 Overview
Productoverview
aControl panel fOn/Off switch
bTop lid gPower socket
cDetachable inner lid hMain unit
dInner pot iWater level indications
eLid release button jDetachable steam valve
b
a
d
c
e
fg
h
j
i

8EN
Controlsoverview
aSlider bar for time regulation eDisplay screen
bPreset/cooking time fStart cooking
cWarm/off gMenu/Child lock
dMy favorite hSlider bar for menu selection
Note
•升温吸水 (heat up and absorb water), 淀粉溶出 (dissolution of starch), 淀粉糊化
(gelatinization of starch), 吸水扩张 (absorb water and expand), 加速膨胀 (accerate the
expand speed), 浸润保水 (reserve water) are the six stages for rice cooking.
a
b
c
d
h
g
f
e

9
EN
5 Usingtheappliance
Tip
• The appliance comes with a certain
protection when opening or closing
the top lid. To avoid unexpected
operations on the control panel, it will
be turned off when the lid is open.
This is normal.
• To cancel an ongoing cooking process,
press , and the appliance
will be in standby mode.
Note
•During the cooking process, if you
want to open and close the lid
(especially when there are a lot of
water in the inner pot), make sure to
slowly close it or wait for 1-2 minutes,
so that the steam disperses and the
pressure is released. This is to avoid
liquid in the inner pot being ejected
from the steam vent.
Beforerstuse
1 Take out all the accessories from the
inner pot, and remove all packaging
materials of it.
2 Clean the parts of the appliance
thoroughly before using it for the
rst time (see chapter "Cleaning and
Maintenance").
Note
•Make sure all parts are completely dry
before you start using the appliance.
•There is an on/off switch on the lower
right side of the appliance (next to the
power socket). Make sure to turn it to
the "I" position to switch it on before
cooking.
Threewaysofusingtheslider
bar
1 Slide: slide your nger up or down
the bar to choose different menus or
setting time.
滑动 滑动
Slide Slide
2 Tap: tap on the "+" or "-" to choose
different menus or setting time.
短按 短按
Tap Ta p

10 EN
3 Tap and press: tap and press on "+" or
"-" to fast forward in choosing different
menus or setting time.
长按 长按
Tapandhold
东北米(Northeastrice),丝
苗米(See-mewrice),寿司
米(Sushirice),香米(Jasmine
rice),其它(others)
Menu Flavor Default
cooking
time
Time
regulation
东北米
丝苗米
寿司米
香米
其它
Sticky
（香糯） ~ 45 mins
N/A
Chewy
（劲道） ~ 35 mins
Fluffy
（松软） ~ 40 mins
糙米
Sticky
（香糯） ~ 80 mins
N/A
Chewy
（劲道） ~ 60 mins
Fluffy
（松软） ~ 70 mins
1 Measure some rice with the provided
measuring cup.
2 Rinse rice, and put the washed rice in
the inner pot.
3 Add water to the level indicated on
the scale inside the inner pot that
corresponds to the number of cups
of rice used. Then smooth the rice
surface.
» For instance, if you cook 4 cups of
northeast rice, add water up to the
4-cup level indicated on the scale
( 东北米 - 4).

11
EN
Note
•Do not exceed the volume indicated
or exceed the maximum water level,
as this may cause the appliance to
overow.
•Different types and quantity of rice
require different amount of water.
The amount of water you pour in
will directly affect the avor and
nutrition of the rice. Use the provided
measuring cup and follow the water
level indications to get best cooking
result.
•To cook jasmine rice and brown rice,
follow the water level indication of the
northeast rice.
4 Wipe off water outside of the inner
pot and put it into the appliance.
Note
•Make sure that the outside of the inner
pot is dry and clean, and that there is
no foreign residue on the inside of the
appliance.
5 Close the lid, and put the plug into the
power socket.
6 Turn the on/off switch to "I".
7 Tap and you can start
with the default cooking menu: 东北米
(northeast rice), 香糯 (sticky avor).
8 If you need to choose a different rice
type or avor, tap and
choose a different type of rice.
9 Slide on the bar to choose the type of
rice you need.

12 EN
10 Tap again and choose
the avor you need.
11 Slide on the bar to choose the aovr
you need.
12 Tap to start the cooking
process.
13 When the cooking is nished, the
appliance beeps, and switches to warm
keeping mode automatically.
» The warm keeping indicator lights
up.
Tip
•After the cooking is nished, stir the
rice and loosen it immediately to
release excessive moisture for uffy
rice.
Note
•Depending on the cooking conditions,
rice on the bottom may become
slightly browned.

13
EN
旋风煮(Ultraquickrice
cooking),农家饭(Country
avoredricecooking),粗粮
饭(Cookinggrain),八宝饭
(Eight-treasurericepudding),
少量煮(Smallportionrice
cooking),菜饭(Cookingrice
withfood)
Menu Default
cookingtime
Time
regulation
旋风煮 ~ 25 mins
N/A
农家饭 ~ 45 mins
粗粮饭 ~ 45 mins
八宝饭 ~ 45 mins
少量煮 ~ 30 mins
菜饭 ~ 35 mins
1 Put the ingredients in the inner pot.
2 Add water to the level indicated on
the scale inside the inner pot that
corresponds to the number of cups
of rice used. Then smooth the rice
surface.
3 Wipe off water outside of the inner
pot and put it into the appliance.
4 Close the lid, and put the plug into the
power socket.
5 Turn the on/off switch to "I".
6 Tap until the specialty
menu is selected.
7 Slide on the bar until the menu you
need is selected.
8 Tap to start the cooking
process.
9 When the cooking is nished, the
appliance beeps, and switches to warm
keeping mode automatically.
» The warm keeping indicator lights
up.

14 EN
煮粥(Cookingcongee),杂
粮粥(Cookingcongeewith
grains),稀饭(Cookinggruel),
煲汤(Makingsoup),慢炖
(Slowcooking)
Note
• It is normal to nd the congee stickier
if it is left in the warm keeping mode
for too long.
• When you cook congee, make sure
to follow the water level indications
accordingly.
Menu Default
cookingtime
Time
regulation
煮粥 ~ 90 mins 1 - 4 hrs
杂粮粥 ~ 90 mins 1 - 4 hrs
稀饭 ~ 90 mins 1 - 4 hrs
煲汤 ~ 2 hrs 1 - 4 hrs
慢炖 ~ 4 hrs 3 - 6 hrs
1 Put the ingredients in the inner pot.
2 Wipe off water outside of the inner
pot and put it into the appliance.
3 Close the lid, and put the plug into the
power socket.
4 Turn the on/off switch to "I".
5 Tap until the specialty
menu is selected.
6 Slide on the bar until the menu you
need is selected.
7 Tap to start the cooking
process.
8 When the cooking is nished, the
appliance beeps, and switches to warm
keeping mode automatically.
» The warm keeping indicator lights
up.

15
EN
煲仔饭(Claypotrice
cooking)
Menu Default
cookingtime
Time
regulation
煲仔饭 ~ 60 mins N/A
1 Follow steps 1 to 6 in "Cooking rice".
2 Tap until the specialty
menu is selected.
3 Slide on the bar until the menu you
need is selected.
4 Tap to start the cooking
process.
5 When the rice is ready, the appliance
beeps.
6 Add the ingredients for the claypot
rice by placing them on top of the
rice. Coat the inner pot with some
cooking oil. Close the lid to resume
the cooking process.
7 When the cooking is nished, the
appliance beeps, and switches to warm
keeping mode automatically.
» The warm keeping indicator lights
up.
Note
•Depending on the cooking conditions,
rice on the bottom may become
slightly browned.

16 EN
煮面(Cookingnoodles)
Menu Default
cookingtime
Time
regulation
煮面 ~ 10 mins 5 - 20 mins
1 Pour some water into the inner pot.
2 Wipe off water outside of the inner
pot and put it into the appliance.
3 Close the lid, and put the plug into the
power socket.
4 Turn the on/off switch to "I".
5 Tap until the specialty
menu is selected.
6 Slide on the bar until the menu you
need is selected.
7 Tap to start the cooking
process.
8 The timer starts counting down when
the water is brought up to boil.
9 Open the lid and put noodles into the
inner pot.
Note
• To avoid overow, or to keep the
noodles from sticking together,
constantly stir the noodles during
cooking.
• Do not exceed the maximum water
level indication when cooking noodles.
After the noodles are put in the inner
pot, keep the lid open, or the contents
may overow.
•Do not close the lid after the noodles
are put in the inner pot, or the
appliance will beep and remind you to
open the lid.

17
EN
10 When the cooking is nished, the
appliance beeps, and switches to warm
keeping mode automatically.
» The warm keeping indicator lights
up.
热饭(Reheating)
Menu Default
cookingtime
Time
regulation
热饭 ~ 25 mins 25 - 59 mins
1 Loosen the cooled rice and evenly
distribute it in the inner pot.
2 Pour some water onto the rice to
prevent it from becoming too dry. The
quantity of the water depends on the
amount of rice.
3 Close the lid, and put the plug into the
power socket.
4 Turn the on/off switch to "I".
5 Tap until the specialty
menu is selected.
6 Slide on the bar until the menu you
need is selected.
7 Tap to start the cooking
process.
8 When the cooking is nished, the
appliance beeps, and switches to warm
keeping mode automatically.
» The warm keeping indicator lights
up.

18 EN
Setthecookingtime
You can set the cooking time for some
menus, including "cooking congee", "cooking
congee with grains", "cooking gruel",
"making soup", "slow cooking", "cooking
noodle" and "reheating". Refer to the
cooking time table in each chapter for the
detailed regulating range.
1 Choose the menu you need.
2 Tap until 烹饪时长 is
displayed on the screen.
3 Slide on the bar to select the cooking
time you need.
4 Tap to conrm the
cooking time and start the cooking
process.
Note
•Tap and hold "+" or "-" to fast forward
in choosing the cooking time.
Presettimefordelayed
cooking
You can preset the delayed cooking time
for some menus. The preset timer is
available from 1 hour up to 24 hours.
Note
•The cooking process will be nished
by the time the preset time has
elapsed. For instance, if the current
time is 12:00 (noon time), and you
would like the rice ready by 18:00 in
the afternoon, you need to set the
preset time of 6 hours.
•If the preset time is shorter than the
cooking time, the cooking process will
start immediately.
•The preset timer is not available in the
following menus: "Cooking noodle" and
"Reheating".

19
EN
1 Choose the menu you need.
2 Tap until 倒计时间 is
displayed on the screen.
3 Slide on the bar to select the preset
time you need.
4 Tap to conrm the preset
time. The cooking process will be
nished by the time is preset time has
elapsed.
SetupMyFavoritemenu
You can set any three menus as "My
Favorite". Before you make any changes to
the setting, the default menus are "Jasmin
rice/Sticky", "Cooking congee" and "Making
soup".
• Tap once or more times to
select the menu you need, and then tap
to quickly start with the
cooking process.
If you need to change the menu in "My
Favorite", for instance to change "Making
soup" to "Cooking noodle", follow the
steps below.
1 Tap until "Making soup" is
selected.
2 Tap .

20 EN
3 Slide on the bar until "Cooking noodle"
is selected.
Note
•Refer to chapter "Set the cooking
time" if you need a different cooking
time. The revised cooking time will also
be saved in the "My Favorite" menu.
4 Tap and hold for 3
seconds, "Making soup" will be changed
to "Cooking noodle" in the "My
Favorite" menu.
Follow the same logic to change the other
menus in "My Favorite".
Setupchildlock
To protect your child from using the
appliance, or to avoid unexpected
operations during cooking, you can set up
the child lock function.
1 Ta p for 3 seconds to
activate child lock.
3秒
» The child lock icon appears on the
display screen.
» Apart from , all the
other selections are disabled.
To unlockthe appliance , press and hold
for 3 seconds again.
Note
•The child lock can only be activated
when the cooking process in ongoing.
