Philips Speechmike6284 Instruction sheet

SPEECHMIKETM
SPEECHMIKETM
SCANNER
6284
6294
SCANNER
ADVANCED SCANNER
CONFIGURATION GUIDE
PHI
6284
6294

2
ATTENTION:
For con guring the 6284 keyboard language, pre x, and suf x please use the bar
code con guration application <BarcodeCon g.exe> provided on the installation CD.
Use this booklet only if the con guration of your SpeechMike Pro Scanner is not
suf cient with this application.
CLASS 1 LASER PRODUCT
This product complies with US 21CFR1040.10, and IEC825-1:1993+A1:1997,
EN60825-1:1994+A11:1996.
The laser classi cation is marked near the scanner window on the product.
Class 1 Laser devices are not considered to be hazardous when used for their intended
purpose. The following statement is required to comply with US and international
regulations:
Caution:
Do not try to open the unit. Allow only authorized Service technicians to repair the
unit.
Use of controls, adjustments or performance of procedures other than those
speci ed herein may result in hazardous laser light exposure.

3
Contents
Operational Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
3
Enable/Disable UPC-A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
Enable/Disable UPC-E . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19
Enable/Disable UPC-E1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .
20
Enable/Disable EAN-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
21
Enable/Disable EAN-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .
22
Enable/Disable Bookland EAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
23
Decode UPC/EAN Supplementals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
24
Decode UPC/EAN Supplemental Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
26
Transmit UPC-A Check Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27
Transmit UPC-E Check Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28
Transmit UPC-E1 Check Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
UPC-A Preamble. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13
UPC-E Preamble . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30
UPC-E1 Preamble . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
31
Convert UPC-E to UPC-A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
31
Convert UPC-E1 to UPC-A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
33
EAN Zero Extend. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
34
Convert EAN-8 to EAN-13 Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
35
UPC/EAN Security Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
36
UPC/EAN Coupon Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
37
Enable/Disable USS-128 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ..
39
Enable/Disable UCC/EAN-128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
40
Enable/Disable ISBT 128 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
41
Lengths for Code 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
42
Enable/Disable Code 39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ….
43
Enable/Disable Trioptic Code 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. … . . . . .
44
Convert Code 39 to Code 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... . . . . .
45
Code 32 Pre x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . …. . . . . .
46
Set Lengths for Code 39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . .
47
Code 39 Check Digit Veri cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
49
Transmit Code 39 Check Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... . . . . . .
50
Enable/Disable Code 39 Full ASCII . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .
51
Enable/Disable Code 93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . … . . . . . .
52
Set Lengths for Code 93 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ….. . . ... . . .
53
Enable/Disable Interleaved 2 of 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
55
Set Lengths for Interleaved 2 of 5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
56
I 2 of 5 Check Digit Veri cation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
58
Transmit I 2 of 5 Check Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
59
Convert I 2 of 5 to EAN-13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ... . . . . . .
60
Enable/Disable Discrete 2 of 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
61
Set Lengths for Discrete 2 of 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
62
Enable/Disable Codabar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
64
Set Lengths for Codabar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
65
CLSI Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
67

4
NOTIS Editing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . .
68
Enable/Disable MSI Plessey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . .
69
Set Lengths for MSI Plessey. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
70
MSI Plessey Check Digits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
72
Transmit MSI Plessey Check Digit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
73
MSI Plessey Check Digit Algorithm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. .
74
Laser Clipping Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . .
77
Cancel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
80
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
83

5
Parameter
Parameter
Number Default
Page
Number
Set Default Parameter All Defaults
Beeper Tone 0x91 Medium Frequency
Beep After Good Decode 0x38 Enable
Transmit “No Read” Message 0x5E Disable
Parameter Scanning 0xEC Enable
Linear Code Type Security Levels 0x4E 1
Bi-directional Redundancy 0x43 Disable
UPC/EAN
UPC-A 0x01 Enable
UPC-E 0x02 Enable
UPC-E1 0x0C Disabl e
EAN-8 0x04 Enable
EAN-13 0x03 Enable
9
10
11
12
13
14
17
18
19
20
21
22
Table 1. Default Table
Parameter Menus
This manual describes the programmable parameters, provides bar codes for programming,
and hexadecimal equivalents for host download programming.
Operational Parameters
The 6284 is shipped with the default settings shown in Table 1 . These default
values are stored in non-volatile memory and are preserved even when the scanner is powered
down.
You can change the default values by:
Scanning the appropriate bar codes included in this chapter. These new values
replace the standard default values in memory. The default parameter values can be
recalled by scanning the SET ALL DEFAULTS bar code on page 9.
Table 1 lists the defaults for all parameters. If you wish to change any option, scan the
appropriate bar code(s).

6
Bookland EAN 0x 53 Disable
Decode UPC/EAN Supplementals 0x 10 Ignore
Decode UPC/EAN Supplemental
Redundancy
0x 50 7
Transmit UPC-A Check Digit 0x28 Enable
Transmit UPC-E Check Digit 0x 29 Enable
Transmit UPC-E1 Check Digit 0x2A Enable
UPC-A Preamble 0x22 System Character
UPC-E Preamble 0x 23 System Character
UPC-E1 Preamble 0x 24 System Character
Convert UPC-E to A 0 x2 5 Disable
Convert UPC-E1 to A 0 x26 Disable
EAN-8 Zero Extend 0x27 Disable
Convert EAN-8 to EAN-13 Type 0x E0 Type is EAN-13
UPC/EAN Security Level 0x4D 0
UPC/EAN Coupon Code 0x55 Disable
Code 12 8
USS-128 0x 08 Enable
UCC/EAN-128 0x0E Enable
ISBT 128 0x54 Enable
Parameter
Parameter
Number Default
Page
Number
Table 1. Default Table (Continued)
23
24
26
27
28
29
30
31
32
33
34
35
36
37
39
40
41
42

7
Code 39
Code 39 0x00 Enable
Trioptic Code 39 0x0D Disable
Convert Code 39 to Code 32 0x56 Disable
Code 32 Prefix 0xE7 Disable
Set Length(s) for Code 39 0x12
0x13
2-55
Code 39 Check Digit Verification 0x30 Disable
Transmit Code 39 Check Digit 0x2B Disable
Code 39 Full ASCII Conversion 0x11 Disable
Code 93
Code 93 0x09 Disable
Set Length(s) for Code 93 0x1A
0x1B
4-55
Interleaved 2 of 5
Interleaved 2 of 0x0
6 Enable
Set Length(s) for I 2 of 5 0x16
0x17
14
I 2 of 5 Check Digit Verification 0x31 Disable
Transmit I 2 of 5 Check Digit 0x2C Disable
Parameter
Parameter
Number Default
Page
Number
Table 1. Default Table (Continued)
5
43
44
45
46
47
49
50
51
52
53
55
56
58
59

8
Convert I 2 of 5 to EAN 13 0x52 Disable
Discrete 2 of
5
Discrete 2 of 0x05 Disable
Se
t Length(s) for D 2 of 5 0x14
0x15
12
Codabar
Codabar 0x07 Disable
Set Lenght for Codabar Length 0x18
0x19
5-55
CLSI Editing 0x36 Disable
NOTIS Editing 0x3 D isable
MSI Plessey
MSI Plessey 0x0B Disable
Set Length(s) for MSI Plessey 0x1E
0x1F
6-55
MSI Plessey Check Digits 0x32 One
Transmit MSI Plessey Check Digit 0x2E Disable
MSI Plessey Check Digit Algorithm 0x33 Mod 10/Mod 10
Parameter
Parameter
Number Default
Page
Number
Table 1. Default Table (Continued)
Data Options
Transmit Code ID Character 0x2D None
Scan Angle
Scan Angle 0xBF Normal Width
60
61
62
64
65
67
68
69
70
72
73
74
75
77

9
Set Default Parameter
SET ALL DEFA ULTS
Scanning this bar code returns all parameters to the values listed in Table 1 on page 5.

10
LOW FREQUENCY
(0x02)
MEDIUM FREQUENCY
(0x01)
HIGH FREQUENCY
(0x00)
Beeper Tone
Parameter # 0x91
To select a decode beep frequency (tone), scan the appropriate bar code.

11
Beep After Good Decode
Parameter # 0x38
Scan this symbol if you want the unit to beep after a good decode.
BEEP AFTER GOOD DECODE
(0x01)
DO NOT BEEP AFTER GOOD DECODE
(0x00)
Scan this symbol if you want the unit not to beep after a good decode. The
b
eeper still operates during parameter menu scanning and indicates error
conditions.

12
ENABLE NO READ
(0x01)
DISABLE NO READ
(0x00)
Transmit “No Read” Message
Parameter # 0x5E
When enabled, if a symbol does not decode, “NR” is transmitted. Any prefix or suffixes
which have been enabled are appended around this message.
When disabled, if a symbol does not read, nothing is sent to the host.

13
Parameter Scanning
Parameter # 0xEC
To disable decoding of parameter bar codes, scan the bar code below. Note that the
Set Defaults parameter bar code will still be decoded. To enable decoding of
parameter bar codes, either scan ENABLE PARAMETER SCANNING, SET ALL
DEFAULTS or set this parameter to 0x01 via a serial command.
ENABLE PARAMETER SCANNING
(0x01)
DISABLE PARAMETER SCANNING
(0x00)

14
Linear Code Type Security Level
Parameter # 0x4E
Note: Does not apply to Cod e 12 8.
LINEAR SECURITY LEVEL 1
(0x01)
Code Type Length
Codabar A ll
MSI Plessey 4 or less
D 2 of 5 8 or less
I 2 of 5 8 or less
The 6284 offers four levels of decode security for linear code types (e.g. Code 39,
Interleaved 2 of 5). Higher security levels are selected for decreasing levels of bar
code quality.
As security levels increase, the scanner’s aggressiveness decreases.
Select the security level appropriate for your bar code quality.
Linear Security Level 1
The following code types must be successfully read twice before being decoded:

15
Linear Security Level 2
The following code types must be successfully read twice before being decoded:
LINEAR SECURITY LEVEL 2
(0x02)
Linear Security Leve l 3
Code types other than the following must be successfully read twice before being
decoded.
The following codes must be read three times:
LINEAR SECURITY LEVEL 3
(0x0
3
)
Code Type Length
All A ll
Code Type Length
MSI Plessey 4 or less
D 2 of 5 8 or less
I 2 of 5 8 or less

16
Linear Security Level 4
The following code types must be successfully read three times before being decoded:
LINEAR SECURITY LEVEL 4
(0x04)
Code Type Length
All All

17
ENABLE BI-DIRECTIONAL REDUNDANC Y
(0x01)
DISABLE BI-DIRECTIONAL REDUNDANCY
(0x00)
Bi-directional Redundancy
Parameter # 0x43
This parameter is only valid when a Linear Code Type Security Level has been enabled
(see page 14). When this parameter is enabled, a bar code must be successfully
scanned in both directions (forward and reverse) before being decoded.

18
UPC/EAN
Enable/Disable UPC-A
Parameter # 0x01
To enable or disable UPC-A, scan the appropriate bar code below.
ENABLE UP C-A
(0x01)
DISABLE UPC-A
(0x00)

19
Enable/Disable UPC-E
Parameter # 0x02
To enable or disable UPC-E, scan the appropriate bar code below
.
ENABLE UPC-E
(0x01)
DISABLE UPC-E
(0x00)

20
Enable/Disable UPC-E1
Parameter # 0x0C
To enable or disable UPC-E1, scan the appropriate bar code below
.
ENABLE UPC-E1
(0x01)
DISABLE UPC-E1
(0x00)
