Philips SIC4014H/G7 User manual

Glide Handheld Scanner
SIC4014H/G7
User Manual
Scanner à main Glide
Manuel d'utilisation
Escáner de mano deslizante
Manual del usuario
ENGLISHFRANÇAISESPAÑOL

1
Important Safety Instruction
• Keep away from water or moisture and dusty areas.
• Do not place this product under direct sunlight or near heat sources,
such as in a closed car under sunlight or near a stove. The outer casing
of this product may become deformed and the sophisticated sensors
inside may become damaged due to excessive heat.
• The battery and inside of the scanner become hot during large volume
scanning operation. Allow few minutes to cool-down before operating the
unit again.
• Ambient temperature ranges from 0°C to +40°C.
• Only use attachments/accessories specified by the manufacture.
• Avoid using the scanner in a dusty environment. Dust particles and other
foreign objects may damage the unit. Place the scanner in the pouch if not
in use.
• Operate the scanner on a level, well-grounded work surface, free of
excessive vibration.
• Do not attempt to disassemble or modify this product. Attempting to do
so is extremely dangerous and will void the warranty.
• When replacing AAA batteries, only use the ones with same capacity.
Do not mix new batteries with used ones.
• Please recycle the batteries in accordance with local regulations.
Disposing of a battery in fire may cause an explosion.
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the
end of its life separately from your household waste. There are
separate collection systems for recycling in the EU. For more
information, please contact the local authority or your retailer
where you purchased the product.
Package Contents
• Glide Handheld Scanner • Mini USB Cable • Software CD
• Four AAA Battery • User Manual • Quick Start Guide
• Calibration Sheet • Cleaning Cloth • Pouch

2
Table of Contents
Package Contents ...................................................................................... 1
Important Safety Instruction ........................................................................ 1
Product Overview ....................................................................................... 3
Placing AAA Batteries ................................................................................. 4
Inserting a microSD Card ........................................................................... 4
Power on/off ............................................................................................... 4
Scanning ..................................................................................................... 5
Playback ..................................................................................................... 6
Viewing the images................................................................................... 6
Zoom ........................................................................................................ 6
Delete ...................................................................................................... 6
Settings ....................................................................................................... 7
Connecting to a PC .................................................................................... 8
Transferring the Scanned Images to PC .................................................. 8
Disconnect the scanner from a PC .......................................................... 8
ezScanPal V2.0 Software Installation ......................................................... 9
A glance at ezScanPal V2.0 ....................................................................... 9
Cleaning and Calibrating .......................................................................... 10
Cleaning the scanner.............................................................................. 10
Calibrating the scanner........................................................................... 10
Helpful Hints ............................................................................................. 10
Specifications ........................................................................................... 12
One (1) Year Limited Warranty ................................................................. 13

3
Product Overview
1Battery Indicator
2LCD Screen
3Left button • Moves left in the menu.
• Moves to the previous scanned image.
4Menu button • Moves up in the menu.
• Brings up the Mode menu.
5Right button • Moves right in the menu.
• Moves to the next scanned image.
6Power/Scan
button
• Press and hold to turn the power on/off.
• Press slightly to start/stop the image scan.
7Battery cover
8Playback • Select to view the scanned images.
9Setting • Select to make Scan Setting and System
Setting.
10 Delete button • Moves down in the menu.
• Brings up the Delete menu.
11 OK/Zoom button • Press to make or confirm the selection in the
menu.
• Zoom the scanned image.
12 MicroSD card slot • Compatible with a microSD card up to 32GB.
13 Mini USB port • Connects to PC for file transfer.
14 Alignment guide • Alignment reference before scanning.
14
13
12
7
2 3 4 5 6
10 11
1
8 9

4
microSD card (required, not
included) should be inserted
with metal side up.
Placing AAA Batteries
1. Gently push and slide the battery cover away from the LCD screen.
2. Place 4 alkaline batteries according to the polarity indicators inside the
compartment.
3. Slide back the battery cover.
Note:
• A new set of batteries will scan approximately 300 A4-sized color
documents at 300 dpi or 200 A4-sized color documents at 600 dpi with
new batteries installed.
• Remove batteries if the scanner is not used for long time.
Inserting a microSD Card
Insert a microSD card into the card slot with metal side up to scan and store
the images.
Note: The microSD card must be formatted by
the scanner for the first time use. It is recom-
mended to save any images on the memory
card before reformatting.
Formatting the microSD memory card
1. Insert a new microSD card into the scanner,
then turn on the scanner.
2. Select (Setting), and press OK/Zoom button.
3. Select SYSTEM (System Setting), and press OK/Zoom button.
4. Press Left / Right button repeatedly to select FORMAT and press
OK/Zoom button.
5. Select "Yes" to comfirm formatting.
Power on/off
• Press and hold Power/Scan button for a few seconds to turn ON/OFF.

5
Scanning
1. Press and hold Power/Scan button to turn on the power.
Note: CARD message appears on the screen if no card is inserted.
2. Select
(Setting) >
SCAN
(Scan Setting) > Direction to set the scan
direction to Up or Down.
3. Place the scanner flat against the document with the scanning lens facing
down. Make sure the area you want to scan is between the Alignment
guides.
4. Press Power/Scan button to activate the Scan. The
Scanning
/
Scanning
scanning
icon appears.
5. Follow the arrow indication on the LCD screen to
slowly slide the scanner up or down and keep your
hand stable to get the best quality picture.
6. To stop scanning, press Power/Scan button again.
The scanned image will show on the screen and save
to the memory card automatically.
7. To start a new scan, repeat the steps 3~6.
Note:
• The progress bar status during the scanning:
Green Good scan.
Orange Poor scan. Lower the scan speed.
Exclamation mark Unsuccessful scan. Please re-scan.
Helpful Hints:
• Scan at a slow and constant speed to optimize scan quality.
• When scanning books or magazines, begin scan from the bind and glide
outward.

6
Playback
Viewing the images
1. Select (Playback), and then press OK/Zoom button.
2. Press Left or Right button to view the previous or
next images.
Note: To return to the main menu, press Menu button.
Zoom
1. Select the image you want to zoom in the (Playback) mode.
2. Press OK/Zoom button repeatedly to zoom in the image.
3.
Press the directional buttons ( Up/ Down/ Left / Right) to
navigate around the image.
4. To exit the Zoom mode, press OK/Zoom button repeatedly.
Delete
1. Select the image you want to delete in the (Playback) mode.
2. Press Delete button, select DELETE ONE or
DELETE ALL, then press OK/Zoom button.
3. Select Yes, and then press OK/Zoom button to
delete.
4. To exit the Delete menu, press Menu button.
Main Menu
DELETE
ALL
DELETE
ONE

7
Settings
1. Select Setting, and then press OK/Zoom button.
2. Press Left / Right button to select either SCAN Scan Setting or SYSTEM
System Setting and then press OK/Zoom button.
3. Press Left / Right button to select the option you wish to change
and then press OK/Zoom button.
Note: To return to the Setting mode for more tasks, press Menu
button.
Menu Sub-menu Descriptions
Scan Setting
Color Mode Select Color or Gray mode for the scanning.
Resolution Select 300 dpi or 600 dpi for the scanning.
Direction Sets the scanning direction to Down or Up.
File Type Select JPG or PDF file format for the
scanning.
Calibration Calibrates the scanner. Refer to Calibrating
the scanner for details.
System Setting Language Select a screen display language list out the
languages.
Format Formats all the data stored in the memory
card.
Factory
Default
Restores the current settings to the factory
presets.

8
Connecting to a PC
Transferring the Scanned Images to PC
1. Turn off the power before connecting to a PC.
2. With the microSD inserted to the scanner, connect the mini USB cable to
the Scanner and then to a USB port on your computer.
Note: microSD card should be inserted with metal side up.
3. Turn on the power of the scanner.
4. Your computer will recognize the scanner as a removable disk. Click
“Open folder to view files”.
5. You may transfer the scanned images to your PC using the drag and drop
method.
Disconnect the scanner from a PC
• Double click the "Safely Remove Hardware" icon in Windows before re-
moving the USB connection.
Note:
• The above steps may vary in different Windows versions.
• If the removable device window did not launch automatically, go to “My
Computer” and find the device under removable disk.

9
Toolbar
Thumbnail Window
Help
ezScanPal V2.0 Software Installation
1. Insert the software CD into your CD/DVD drive. The installation will start
automatically.
2. Follow the on-screen instructions to complete the process.
Note:
• You must install ABBYY FineReader and Adobe Acrobat Reader to
enable the OCR Utility and PDF Utility in ezScanPal V2.0
• The software contained in this CD is compatible with Windows XP/Vista/7.
A glance at ezScanPal V2.0
ezScanPal V2.0 is an easy-to-use image processing application which
enables the direct communication between the scanner and the PC.
Note: ezScanPal V2.0 does not support PDF display. You may use Adobe
Acrobat Reader to open PDF files instead. For detailed information on how
to use each function, please refer to the Help section.

10
Cleaning and Calibrating
• To get high image quality and good recognition results, please perform the
step below from time to time.
• Make sure the cleaning cloth and calibration paper are clean and free of
dust before use.
Cleaning the scanner
• Wipe the scanner lens lightly using the supplied cleaning cloth.
• Do not use any solvent to clean the scanner.
• Do not use rough material such as nylon scouring pad to wipe the scanner.
Calibrating the scanner
1. Place the calibration paper on a flat
surface with the white side facing up.
2. Turn on the scanner.
3. Select CALIBRATION by following the
steps below: SETTING > SCAN SETTING > CALIBRATION> Yes.
4. Hold the calibration paper firmly by one hand, with the other hand slide
forward/backward the scanner slowly against the paper. The calibration
starts.
5. When the calibration is done, a message "Complete" appears and the
scanner will shut down automatically.
Helpful Hints
• Why isn't the scanner turning on?
Please push to open the battery compartment to verify that all batteries
are installed properly.
• Why won't the memory card fit?
Philips Glide only uses microSD cards. While inserting the memory card,
push the card in with metal side face up, until the "click".
To remove the card, simply press down on the card. Memory card will
push out automatically.
• Why isn't the scanned image clear?
It is recommended to clean scanning sensor before usage with supplied
cleaning cloth. Scanning at a consistently slow speed will increase
scanning quality.

11
• Why is the scanned image not proportional?
Scan at a slow and constant speed will increase scanning quality.
• What's the best way to scan from inside of a book?
When scanning a source with a binding, we recommend you start from
the binding and glide outward.
• Why are the scanned images backwards?
You must scan in the direction the arrow is pointing.
To change the scan direction:
1. Press the MENU button and Choose SETTINGS.
2. Scroll to Scan Setting.
3. Choose DIRECTION to personalize the direction you are comfortable
scanning from.
• How do I view the pictures from my computer?
1. With the scanner in the OFF position, establish USB connection with
mini USB cable (Included).
2. Plug the bigger USB connector into your computer.
3. Turn on the scanner by pressing the power button.
4. Your computer will detect this computer as a "portable drive", same as
a USB flash drive.
• How can I contact Philips for more support?
You can reach us at : 1-877-784-0999
Monday-Friday: 10am - 10pm EST
Saturday-Sunday: 12pm - 9pm EST
closed on all nationally observed holidays.
• I want to change the "File Created" date on these photos scanned, how
can I do that?
1. Install ezScanPal V2.0 software that came with your scanner.
2. Insert microSD (with SD adaptor) into your PC.
3. Open EzScanPal V2.0 software then RIGHT click on the photo desired,
then press PROPERTIES.
4. Click on File Date, then change from the menu.
5. Confirm your changes by pressing the green check mark.
If you have additional questions about this scanner, please refer to the FAQ’s
at www.philips.com/support and lookup product SIC4014H/G7.

12
Specifications
Scanner Type: A4 CIS Philips Glide Handheld Scanner
Display:1” Color STN LCD (64 x 96 pixels)
Scan Size: Up to A4 size
Scan Mode: Color 24-bit / Gray 24-bit
Scan Resolution: 300 / 600 dpi
Scan Speed: 5 seconds for a A4 color document at 300 dpi
10 seconds for a A4 color document at 600 dpi
Auto Power Off: 2 minutes
Memory Card Slot: MicroSD (Up to 32GB)
I/O Ports: USB mini-B
Power Supply: Alkaline batteries (AAA x 4)
File Format: JPG/PDF
Dimensions: 258 x 32.9 x 30.7 mm ; 10.2" x 1.3" x 1.2"
Weight: 163g/0.4lbs (without battery)
Supported OS for Mass Storage: Windows XP / Vista / 7 ; Mac OS X 10.4 ~ 10.7

13
One (1) Year Limited Warranty
WARRANTY COVERAGE:
This warranty obligation is limited to the terms set forth below.
WHO IS COVERED:
This product is warranted to the original purchaser or the person receiving the product
as a gift against defects in materials and workmanship as based on the date of
original purchase (”Warranty Period”) from an Authorized Dealer. The original sales
receipt showing the product name and the purchase date from an authorized retailer
is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material or workmanship occurs and a
valid claim is received within the Warranty Period. At its option, the company will either
(1) repair the product at no charge, using new or refurbished replacement parts, or
(2) exchange the product with a product that is new or which has been manufactured
from new, or serviceable used parts and is at least functionally equivalent or most
comparable to the original product in current inventory, or (3) refund the original
purchase price of the product. The Company warrants replacement products or parts
provided under this warranty against defects in materials and workmanship from the
date of the replacement or repair for the remaining portion of the original product’s
warranty. When a product or part is exchanged, any replacement item becomes your
property and the replaced item becomes the company’s property. When a refund is
given, your product becomes the company’s property.
Replacement product can only be sent if all warranty requirements are met.
Failure to follow all requirements can result in delay.
WHAT IS NOT COVERED – EXCLUSIONS AND LIMITATIONS:
This Limited Warranty applies only to the new products that can be identified by the
trademark, trade name, or logo affixed to it. This Limited Warranty does not apply to
any non-Philips hardware product or any software, even if packaged or sold with the
product. Non-Philips hardware manufacturers, suppliers, or publishers may provide a
separate warranty for their own products packaged with the bundled product.
The Company is not liable for any damage to or loss of any programs, data, or other
information stored on any media contained within the product, or any non-Philips
product or part not covered by this warranty. Recovery or reinstallation of programs,
data or other information is not covered under this Limited Warranty.
This warranty does not apply (a) to damage caused by accident, abuse, misuse,
neglect, misapplication, or non-Philips product, (b) to damage caused by service
performed by anyone other than an Authorized Service Location, (c) to a product or a
part that has been modified without written permission, or (d) if any serial number has
been removed or defaced, or (e) to a product, accessories or consumables sold “AS
IS” without warranty of any kind by including refurbished Philips products sold “As IS”
by some retailers.

14
THIS LIMITED WARRANTY DOES NOT COVER:
• Shipping charges to return defective product.
• Labor charges for installation or setup of the product, adjustment of customer controls
on the product, and installation or repair of any part outside of the product.
• Product repair and/or part replacement because of improper installation or
maintenance, connections to improper voltage supply, power line surge, lighting
damage, retained images or screen markings resulting from viewing fixed stationary
content for extended periods, product cosmetic appearance items due to normal wear
and tear, unauthorized repair or other cause not within the control of the company.
• Damage or claims for products not being available for use, or for lost data or lost
software.
• Damages from mishandled shipments or transit accidents when returning product.
• A product that requires modifications or adaptation to enable it to operate in any
country other than the country for which it was designed, manufactured, approved
and/or authorized, or repair of products damaged by these modifications.
• A product used for commercial or institutional purposes (including but not limited to
rental purposes).
• Product lost in shipment and no signature verification receipt can be provided.
• Failure to operate per Owner's Manual.
TO OBTAIN ASSISTANCE
For technical support go to www.Philips.com/support and select your product or call toll
free: 1-877-784-0999
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY FOR THE CONSUMER. Philips SHALL NOT BE LIABLE
FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY
OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some states do not allow the exclusions or limitations of incidental or consequential
damages, or allow limitations on how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you.
This warranty gives you specific legal rights. You may have other rights which may vary
from state/province to state/province.

1
Précautions importantes relatives à la
sécurité
• Gardez cet appareil à l'abri de l'eau, de l'humidité et de la poussière.
Ne placez pas ce produit directement au soleil ou à proximité de sources de
chaleur, comme dans une voiture fermée en plein soleil ou près d'un poêle.
L'enveloppe extérieure de ce produit peut se déformer et les capteurs sophis-
tiqués à l'intérieur peuvent être endommagés en raison d'une chaleur exces-
sive.
• La batterie et l'intérieur du scanner deviennent chauds pendant les opérations
de numérisation de grands volumes. Laissez quelques minutes pour le refroid-
issement avant d'utiliser l'appareil à nouveau.
Température ambiante 0~40°C.
Utilisez seulement les pièces ou les accessoires recommandés par le fabricant.
Évitez d’utiliser votre scanner dans un environnement poussiéreux. Les par-
ticules de poussières et autres corps étrangers risqueraient d’endommager l’
appareil. Rangez le scanner dans sa sacoche lorsque vous ne l’utilisez pas.
Faites fonctionner le scanneur sur une surface de travail de niveau et stable,
ne présentant aucune vibration excessive.
Ne tentez pas de démonter ou de modifier ce produit. Ce serait extrêmement
dangereux et annulerait la garantie.
Utilisez exclusivement des piles neuves de la taille et du type spécifiés. Ne
mélangez jamais piles usagées et piles neuves, piles de différents types ou
piles rechargeables de différentes capacités.
• Ne mettez pas les piles au rebut avec les ordures ménagères. Mettez-le au
rebut dans le respect de la règlementation locale. Ne jetez jamais vos piles au
feu. Vous risqueriez de provoquer une explosion.
Ce symbole qui apparaît sur le produit ou dans les instructions signifi
e que votre appareil électrique ou électronique, lorsqu’il ne fonctionne
plus, doit être jeté séparément de vos déchets ménagers. En Europe,
il existe différents systèmes de collecte pour le recyclage. Pour de plus
amples informations, contactez l’autorité locale ou le revendeur auprès
duquel vous avez acheté le produit.
•
•
•
•
•
•
•
Contenu de L’emballage
• Scanner à main Glide • Câble mini USB • CD d'application
• 4 piles AAA • Manuel d'utilisation • Guide Rapide
• Page de calibrage • Chiffon de nettoyage • Housse de transport

2
Table des Matières
Contenu de L’emballage ............................................................................. 1
Précautions importantes relatives à la sécurité .......................................... 1
Présentation du produit .............................................................................. 3
Mise en place des piles AAA ...................................................................... 4
Insertion d'une carte microSD .................................................................... 4
Mise en marche/arrêt .................................................................................. 4
Scannage ................................................................................................... 5
Lecture ........................................................................................................ 6
Affichage des images ............................................................................... 6
Zoom ........................................................................................................ 6
Effacer ...................................................................................................... 6
Réglage ...................................................................................................... 7
Connexion à un PC .................................................................................... 8
Transférer les images scannées vers un ordinateur ................................ 8
Débranchez le scanner du PC ................................................................. 8
Installation de ezScanPal V2.0 ................................................................... 9
Bref aperçu de ezScanPal V2.0 ................................................................. 9
Nettoyage et calibrage .............................................................................. 10
Nettoyage du scanner............................................................................. 10
Calibrage du scanner.............................................................................. 10
Astuces ..................................................................................................... 10
SPÉCIFICATIONS .................................................................................... 12
GARANTIE LIMITÉE D’UN (1) AN ........................................................... 13

3
Présentation du produit
1Indicateur de charge des piles
2Écran LCD
3Bouton Gauche Déplacement vers la gauche dans les menus.
Pour retourner à l’image numérisée précédente.
•
•
4Bouton Menu Déplacement vers le haut dans les menus.
Pour afficher le menu du Mode.
•
•
5Bouton Droit Déplacement vers la droite dans les menus.
Pour passer à l’image numérisée suivante.
•
•
6Marche/Numérisation Appuyez longuement sur ce bouton pour allumer ou
éteindre l’appareil.
Appuyez brièvement pour lancer/arrêter la
numérisation de l’image.
•
•
7Cache du compartiment à piles
8Lecture • Sélectionnez pour afficher les images numérisées.
9Réglages • Sélectionnez pour effectuer le paramétrage de la
numérisation et du système.
10 Bouton de
suppression
Déplacement vers le bas dans les menus.
Pour afficher le menu Suppression.
•
•
11 Bouton OK/Zoom Appuyez pour sélectionner ou confirmer une option
d’un menu.
Pour agrandir l’image numérisée.
•
•
12 Fente pour carte
microSD
• Pour accueillir une carte microSD jusqu’à 32Go.
13 Port mini USB Permet le branchement à un PC pour le transfert
des fichiers.
•
14 Guides d’alignement • Alignment reference before scanning.
13
12
7
2 3 4 5 6
10 11
1
8 9
14

4
La carte microSD (req-
uise, non fournie) doit être
insérée avec le côté métal-
lique vers le haut.
Mise en place des piles AAA
Faites glisser le cache du compartiment à piles vers l’avant et légèrement
à l’écart de l’appareil.
Insérez 4 piles alcalines en veillant à
respecter les polarités indiquées dans
le compartiment.
Remettez le cache du compartiment à
piles en place.
Remarque :
Avec des piles neuves installées, votre scanner peut numériser approxi-
mativement 300 documents couleur au format A4 à 300 dpi, ou 200 docu-
ments couleur au format A4 à 600 dpi.
Retirez les piles du scanner si vous pensez ne pas avoir à l’utiliser pen-
dant une période prolongée.
Insertion d'une carte microSD
Insérez une carte microSD dans la fente pour
carte, connecteurs dorés tournés vers le haut,
pour numériser et stocker vos images.
Remarque : La carte microSD doit être forma-
tée par le scanner avant sa première utilisation.
Il est recommandé d'enregistrer les images sur
la carte mémoire avant le reformatage.
Formatage de la carte mémoire microSD
Insérez une carte microSD neuve dans le
scanner, puis allumez ce dernier.
Sélectionnez (Réglage), et appuyez sur le bouton OK/Zoom.
Sélectionnez Système (Système), et appuyez sur le bouton OK/Zoom.
Appuyez sur le bouton Gauche / Droite à plusieurs reprises pour
sélectionner FORMAT et appuyez sur le bouton OK/Zoom.
Le système vous demande alors si vous souhaitez formater la carte,
sélectionnez « Oui » pour continuer. Le formatage commence.
Mise en marche/arrêt
• Appuyez longuement sur le bouton Marche/Numérisation pour allu-
mer/éteindre MARCHE / ARRÊT.
1.
2.
3.
•
•
1.
2.
3.
4.
5.
