  9. Philips DN028B Series User guide

Philips DN028B Series User guide

DN028B
Mounting Instruction
Philips Lighting Luminaires (Shanghai) Co., Ltd.
Address: 2F, Building 6, No. 1805, Huyi Highway, Malu Town, Jiading
District, Shanghai, P.R. China
Postal code: 201801
Product Type Power (W)
15
18
23
10
10
CCT (K)
3000
4000
3000
4000
3000
4000
3000
4000
3000
4000
V1.0
FrequencyVoltage
220-240V 50/60Hz
Lumen Output (lm) Ø A (mm)
Ø175
Ø200
Ø225
Ø115
Ø150
IP20
Essential SmartBright LED Downlight
~
Ø B Cut out (mm)
150~155
175~180
200~205
90~95
125~130
LEDs
58
81
112
40
46
1200
1500
2000
800
800
AS/NZS
60598
A
33
Indoor
use only
0.37
0.44
0.54
0.2
0.31
DN028B LED12/WW PSU II D150 CAU
DN028B LED12/NW PSU II D150 CAU
DN028B LED15/WW PSU II D175 CAU
DN028B LED15/NW PSU II D175 CAU
DN028B LED20/WW PSU II D200 CAU
DN028B LED20/NW PSU II D200 CAU
DN028B LED8/WW PSU II D90 TB
DN028B LED8/NW PSU II D90 TB
DN028B LED8/WW PSU II D125 TB
DN028B LED8/NW PSU II D125 TB
DN028B LED12/WW PSU II D150 CAU
DN028B LED12/NW PSU II D150 CAU
DN028B LED15/WW PSU II D175 CAU
DN028B LED15/NW PSU II D175 CAU
DN028B LED20/WW PSU II D200 CAU
DN028B LED20/NW PSU II D200 CAU
Unit: mm
a
DN028B LED8/WW PSU II D90 TB
DN028B LED8/NW PSU II D90 TB
DN028B LED8/WW PSU II D125 TB
DN028B LED8/NW PSU II D125 TB
Unit: mm
Terminal block
A
33
c
b
Terminal
block
This marking indicates that this product should not be disposed with other household wastes throughout the
EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of material resources. To return your used device, please use the
return and collection systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
Please read this manual carefully before using the product.
1. Do not switch on before complete installation.
2. The luminaire shall be installed by a qualified electrician and wired in accordance with the latest IEE electrical
regulations or the national requirements.
3. The external flexible cable or cord of this luminaire cannot be replaced; if the cord is damaged, the luminaire shall be
destroyed.
4. Building insulation abutting or within 100mm horizontally of the luminaire must meet the following requirements:
a) Be of a type that can maintain its dimensions and structural integrity when exposed to the maximum surface
temperatures of the class of luminaire, being 90°C.
b) Be of a type able to withstand a 30 second needle flame test carried out in accordance with AS/NZS 60695.11.5
with the flame applied to all surfaces of the test sample
5. The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole luminaire
shall be replaced.
6. The luminaire is complied with AS/NZS 60598.2.2.
7. Luminaire must not be used or stored in corrosive environment where hazardous materials such as Sulphur,
Chlorine, phthalates, etc, are present.
8. Risk of overheating or fire if the clearance distances are compromised.
9. This product complies with the IC-F rating as per AS/NZS 60598.2.2. Care should be taken at installation to
allow adequate air flow for optimum lifetime performance.
Mounting Instruction V1.0
DN028B
Essential SmartBright LED Downlight
Model Run Current (A)
(@230V)
Start Current Duration (μs) /
T(@50% of Ipeak) (μs)
Maximum Number of
Luminaire on MCB 16A
Type B (pcs)
Start (Inrush) Current(A)
/ Ipeak (A)
* Touch current or
protective conductor
current (mA)
The leakage current *(touch current or protective conductor current) of electrical circuit may be greatly dependent upon
electrical supply cables used such as its rating and length, proper connection of electrical supply cables to luminaires and
wiring connection topology of luminaires to the supply electrical circuit amongst other site conditions.
* In some cases referred to as Earth Leakage Current.
Maximum Number of
Luminaire on MCB 16A
Type C (pcs)
DN028B LED12/WW PSU II D150 CAU
DN028B LED12/NW PSU II D150 CAU
DN028B LED15/WW PSU II D175 CAU
DN028B LED15/NW PSU II D175 CAU
DN028B LED20/WW PSU II D200 CAU
DN028B LED20/NW PSU II D200 CAU
DN028B LED8/WW PSU II D90 TB
DN028B LED8/NW PSU II D90 TB
DN028B LED8/WW PSU II D125 TB
DN028B LED8/NW PSU II D125 TB
Recessed Mounting
1 2
RISK OF FIRE – Required clearance from structural
members and building elements
SCB=50mm HCB=50mm
HCB – Height clearance to building element
SCB – Side clearance to building element
0.08
0.08
0.1
0.1
0.13
0.13
0.06
0.06
0.06
0.06
15
15
16
16
16
16
15
15
15
15
158
158
219
219
219
219
158
158
158
158
<0.7
<0.7
<0.7
<0.7
<0.7
<0.7
<0.7
<0.7
<0.7
<0.7
45
45
33
33
33
33
45
45
45
45
74
74
55
55
55
55
74
74
74
74
