Philips FW-C85 User manual

FW-C85
Mini Hi-Fi System
3 CD Changer with 220WattsTotal Power,
Logic Deck and wOOxTechnology Speaker System
• 2 x 110Watts RMS Stereo
• wOOxTechnology Speaker System
• Sound Navigation and 6 digital Sound Control modes and 6
Virtual Environment Control modes and 6 Personal Settings
• 3-Step wOOx level control
• 7-Band Spectrum Analyzer with 3 Dim Display Modes
• Bass &Treble Control
• 3-Way Bass Reflex Speaker System with wOOx Speaker
Technology
• 6 1/2"Top firing wOOx woofer
• CD-Rewritable Compatible
• 40-Track CD Random Program
• AM/FM Stereo DigitalTuning with 40 Presets
• Dual LogicTape Deck with Auto Reverse
• Digital Recording Ready (digital and line out)
• Bedroom Clock withWake-upAlarm and Sleep-timer
• Subwoofer Ready
• Easy set for radio
• Energy Saving Standby mode (<2 watts)
• 45-Button Remote Control
• 4-Color Packaging
d
i
g
i
t
a
l
r
e
c
o
r
d
i
n
g
r
e
a
d
y
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N
w
a
k
e
u
p
/
s
l
e
e
p
t
i
m
e
r
auto rauto reverse
auto reverse
KEY
45
KEY
45

Sound Enhancement
2 x 110Watts RMS Stereo
110 watts continuous RMS power output per channel, at
6 Ohms,from 80Hz-16kHz,with no more than 10%Total
Harmonic Distortion (THD).
wOOxTechnology
Philips patented wOOx Technology ensures superior bass
results. The dual suspension bass radiator, together with
dedicated amplifier circuitry, is especially designed to produce
and handle high dynamic sound signals at very low
frequencies. Because of the dual suspension, the excursion
of the membrane can be extreme (see illustration). This is in
combination with the symmetrical sandwich construction,
provides for very low and precise bass without noticeable
distortion. The net effect of using wOOx Technology is a
tight bass sound that is significantly "lower and louder" than
conventional mini shelf systems.
Sound Navigation
(Jog + DSC +VEC + PS)
The Sound Navigation System is a complete set of sound
manipulation tools consisting
6 Digital Sound Control settings : (CLASSIC, ROCK,
VOCAL,TECHNO,OPTIMAL,JAZZ),
6 ModesVirtual Environment Control :(Hall, DISCO,
CONCERT,CINEMA,CLUB,ARCADE)
6 Personal Settings : To preserve your favourite sound
settings and save them into 6 different memory settings,
Bass &Treble Control
Bass and treble allows sound adjustment of high and low
frequencies to personal preferences.
3-Step wOOx Level Control
As the human ear does not perceive low frequencies at
the same level as higher frequencies (though at the same
"volume"), the bass sound needs to be enhanced to
achieve maximum impact. The wOOx is progressively
driven at different optimization levels in setting wOOx 1,
2 and 3.
3-Way Bass Reflex Speaker System
Equipped with one 6 1/2" woofer for smooth low and mid
range reproduction, one 2 1/2" ferro-fluid cooled tweeter
and one 1" Polydome tweeter for crisp high tones.
AM/FM Stereo DigitalTuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Design
Design Concept
The attractive and shelf appealing emphasis on the sound
control panel dominates and determines this range’s
character.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
Convenience
3-CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
CD-Rewritable Compatible
The player offers 100% playback guarantee of CD
Rewritable CD's over the entire lifetime of the player. Even
CD-RW audio recordings on computers can be used.
Dual LogicTape Deck
Offer the ability to switch from one function, such as fast
forward,to another function,such as play,by remote control.
Auto Reverse
The feature employs an auto reverse mechanism to
sense the end of the tape and automatically reverse the
direction of tape travel in the PLAY mode providing an
uninterrupted, continuous flow of music without
manually flipping the cassette tape.
45-Button Remote Control
This infrared remote control operates volume +/–, all
CD functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE, SHUFFLE, REPEAT, PROGRAM, CD123, CD
DIRECT 1, 2, 3, F and G), AUX/CDR select,TUNER
select, TAPE 1/2 select, TV select, numeric 1 to 9 & 0,
CLOCK, AUTO REV., TIMER ON/OFF, SLEEP, DIM,
Personal Setting select and sound enhancement features
including, Digital Sound Control, Virtual Environment
Control, BASS/TREBLE, wOOx select, wOOx Level
select,Bass +/- andTreble +/-.
Easy Set
Press Standby `ON' for 5 secs to automatically program
40 tuner presets.(FM only)
40-Random Channel Presets
Random memory presets allow pre-programming of up to
40AM and FM station frequencies into the tuner memory.
Auto Store
Automatically stores up to 40 preset FM orAM stations .
40-track CD Random Program
Store up to 40 of your favorite CD track selections,from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
AUX/Video Input
For connection of audio accessory pieces such as a LD
or DVD player, television, or external cassette deck.
Direct Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press 'STOP' for 5 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the
sequential order in which they were originally recorded.
Repeat track/disc/all
Repeat your favorite track,disc or all.
UPC Code:0 37849 89374 6
Product Dimensions:
10.4"W x .12.2" H x 15.4" D (electronics)
10.2"W x 13.8"H x 12.4" D (speakers)
Package Dimensions:
23.4" W x 28.6" H x 16.1" D
Product weight: 48.5 lbs.
Carton contains: 3CD Changer Mini System,
Multi-Function Remote Control, Batteries,
Operating instructions,Warranty information
Printed in Singapore
Date printed : Oct 1999
©1999 Royal Philips Electronics N.V.
All right reserved.
A Division of Philips Electronics North
America Corp.
Specifications subject to change without
notice.
As an ENERGY STAR® Partner, Philips has
determined that this product meets the ENERGY
STAR® guidelines for energy efficiency.
ChangeWhile Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start of
a recording on an analog audio cassette deck with the start
of a CD or a CD program.
Pause
Interrupts playback of a CD without returning to the
beginning of the disc, so when play resumes, the music
begins exactly where it stopped.
Next/Previous Skip
This two button feature offers you the opportunity to skip
back to the previous track or skip up to the next track instantly.
High-Speed Dubbing
High-speed dubbing makes it possible to create good
quality recordings (dubs) from one tape to another at
twice the normal speed in RECORD mode.
Clock/Timer and Sleeptimer
Set the alarm portion of a built-in digital clock to wake you
to music from your favorite CD or an AM/FM radio station
at any desired time of the day. Sleeptimer settings of 60,
45,30 or 15 minutes.
3 Dim Display modes (including nite mode)
2 different display options showing different amounts of display
activity can be selected and 1 nite mode display which shows
minimal display activity and turns most of the lights off.
Energy Saving Standby Mode (<2 watts)
Most systems consume 10-15 watts just on standby.Philips
systems consumes less than 2 watts of energy on standby for
big savings to the listener.
FW-C85
Mini Hi-Fi System
13
VOLUME
2
AUX/CDR
MUTE
CD 123 TUNER TAPE 1/2
AUTO REV.
REPEATPROGRAM SHUFFLEDIM
CD
DIRECT
á
à
ë
í
Ç
TREBLE
TIMER ON/OFF
BASS
DSC
PERSONAL
SLEEP WOOX WOOX LEVEL
BASS/TREBLE
VEC
++ --
13
2
46
5
79
8
0
2
CLOCK
É
Å
suspension 1suspension 2
excursion 1
excursion 2
excursion 2
excursion 1
wOOxTechnology
double suspension = double excursion
