Philips Magnavox FW 520C User manual

Sound Enhancement
2 x 50 Watts RMS Stereo
50 watts continuous RMS power output per channel,at 6
Ohms, from 80Hz-16kHz, with no more than 10% Total
Harmonic Distortion (THD).
4-Speaker Surround Sound System
Provide the essence of surround sound with one left
front, right front, left rear, and right rear speaker for
exceptional listening pleasure.
Digital Sound Control
(Optimal, Jazz, Rock, Techno, Classic)
Digital sound control (or DSC) offers different sound
settings tailored for specific musical styles.
3-Step Dynamic Bass Boost (Beat, Punch, Blast)
Bass reproduction is essential for deep and rich music. 3
Step DBB offers the optimal level for any kind of music.
3-Way Speaker with Bass Reflex
Equipped with one 51/2" woofer, one 21/2" ferro-fluid
cooled tweeter and one 1" polydome tweeter, 3-way
enclosures feature a wider range of frequency response
for greater listening pleasure.
AM/FM Stereo Digital Tuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Bitcheck Digital-to-Analog Conversion
Employs dynamic element matching to eliminate
deviations in bit current to eliminate crossover distortion
and supply extremely high linearity in audio reproduction.
Convenience
3-CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
23-Button Remote Control
This infrared remote control operates volume +/–, all
CD functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE,REPEAT,SHUFFLE,PROGRAM,DISC 1,2,3, ,
), CD, AUX, TAPE 1/2, TUNER and sound
enhancement features including Incredible Surround™,
Dynamic Bass Boost,and Digital Sound Control.
Easy Set
Press Standby ‘ON’ for 2 secs to automatically program
40 tuner presets.(FM only)
40-Random Channel Presets
Random memory presets allow pre-programming of up
to 40 AM and FM station frequencies into the tuner
memory.
Auto Store
Automatically stores up to 40 preset FM orAM stations .
40-Track CD Programmability
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
Video/AUX Input
For connection of audio accessory pieces such as a LD
or DVD player,television,or external cassette deck.
Auto Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press “STOP” for 3 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
Change While Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start
of a recording on an analog audio cassette deck with the
start of a CD or a CD program.
Repeat
Repeat your favorite track.
Pause
Interrupts playback of a CD without returning to the
beginning of the disc, so when play resumes, the music
begins exactly where it stopped.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the
sequential order in which they were originally recorded.
UPC Code: 037849863602
Product Dimensions:
10.5"W x .12.2"H x 12.2"D (electronics)
9.4"W x 12.2"H x12.6"D (speakers)
8.8"W x 3.86"H x8.8"D (surround speakers)
Package Dimensions:
29"W x 28.5"H x 16"D
Product weight: 42 lbs.
Carton contains: CD Mini System, Multi-Function Remote Control,
Batteries, Operating instructions,Warranty information
Printed in Singapore
©1997 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Next/Previous Skip
This two button feature offers you the opportunity to skip
back to the previous track or skip up to the next track
instantly.
Dual Mechanical Tape Deck
Feature full function control via a simple, easy-to-use
mechanical push button assembly.
High-Speed Dubbing/Continuous Play
High-speed dubbing makes it possible to create good
quality recordings (dubs) from one tape to another at
twice the normal speed in RECORD mode. Continuous
play offers automatic switching from cassette deck A to
cassette deck B providing an uninterrupted, continuous
flow of music in the PLAY mode.
Clock/Timer
Set the alarm portion of a built-in digital clock to wake you
to music from your favorite CD or an AM/FM radio station
at any desired time of the day.
Stereo Headphone Jack
Design
Design Concept
The linear theme, and contrasting surface definitions,
reflecting future "edge design" trends, combine to create a
modern and attractive design. Attention to details,
interactive lighting, and the use of rich materials and
metallic finishings further compliment the visual appeal.The
element of power is visualised through the dramatic three
dimensional speaker box surfacing.
Oversized, MultiColor, Digital FTD Display
This large display is easy to read at any distance with no
distortion or distraction and the multi-color format makes
it easy to recognize different functions at a glance.
PINGS (Philips Magnavox Intelligent Navigation
Guidance System)
Onboard intelligence monitors the systems and provides
information on status and available functions by means of
backlightling.
Ergonomic Control Layout
Convenient grouping of related functions along with
positive tactile feedback from front-mounted controls
optimize this model for comfort and conveniece.
Removable Cloth Speaker Grilles
Removable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
2

AUX
CD TAPE 1/2 TUNER
CD DIRECT
DBB DSC MUTE
REPEAT SHUFFLE PROGRAM
É
Ç
ë
í
Å á
á
VOLUME
PLAY
STOP
PREV. NEXT

123
DIGITAL REMOTE CONTROL
FW520C
CD Mini System
FW520C
CD Mini System
3 CD Changer with 100WattsTotal Power
and 4-Speaker Surround Sound System
• 2 x 50Watts RMS Stereo
• 4-Speaker Surround Sound System
• Digital Sound Control (Optimal,Jazz,Rock,Techno,Classic)
• 3-Step Dynamic Bass Boost
• Subwoofer Ready
• 40-Track CD Programmability
• AM/FM Stereo DigitalTuner with 40 Presets
• Oversized,MultiColor, Digital FTD Display
• 23-Button Remote Control
• 3-Way Speaker System with Bass Reflex and Removable Grilles
• OneTouch CD Synchro Recording
• Bedroom Clock withWake-up Alarm
• 4-Color Packaging
3 CD CHANGER 100watts
Total PowerTotal Power
SETEASY
RADIO

Sound Enhancement
2 x 50 Watts RMS Stereo
50 watts continuous RMS power output per channel,at 6
Ohms, from 80Hz-16kHz, with no more than 10% Total
Harmonic Distortion (THD).
4-Speaker Surround Sound System
Provide the essence of surround sound with one left
front, right front, left rear, and right rear speaker for
exceptional listening pleasure.
Digital Sound Control
(Optimal, Jazz, Rock, Techno, Classic)
Digital sound control (or DSC) offers different sound
settings tailored for specific musical styles.
3-Step Dynamic Bass Boost (Beat, Punch, Blast)
Bass reproduction is essential for deep and rich music. 3
Step DBB offers the optimal level for any kind of music.
3-Way Speaker with Bass Reflex
Equipped with one 51/2" woofer, one 21/2" ferro-fluid
cooled tweeter and one 1" polydome tweeter, 3-way
enclosures feature a wider range of frequency response
for greater listening pleasure.
AM/FM Stereo Digital Tuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Bitcheck Digital-to-Analog Conversion
Employs dynamic element matching to eliminate
deviations in bit current to eliminate crossover distortion
and supply extremely high linearity in audio reproduction.
Convenience
3-CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
23-Button Remote Control
This infrared remote control operates volume +/–, all
CD functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE,REPEAT,SHUFFLE,PROGRAM,DISC 1,2,3, ,
), CD, AUX, TAPE 1/2, TUNER and sound
enhancement features including Incredible Surround™,
Dynamic Bass Boost,and Digital Sound Control.
Easy Set
Press Standby ‘ON’ for 2 secs to automatically program
40 tuner presets.(FM only)
40-Random Channel Presets
Random memory presets allow pre-programming of up
to 40 AM and FM station frequencies into the tuner
memory.
Auto Store
Automatically stores up to 40 preset FM orAM stations .
40-Track CD Programmability
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
Video/AUX Input
For connection of audio accessory pieces such as a LD
or DVD player,television,or external cassette deck.
Auto Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press “STOP” for 3 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
Change While Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start
of a recording on an analog audio cassette deck with the
start of a CD or a CD program.
Repeat
Repeat your favorite track.
Pause
Interrupts playback of a CD without returning to the
beginning of the disc, so when play resumes, the music
begins exactly where it stopped.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the
sequential order in which they were originally recorded.
UPC Code: 037849863602
Product Dimensions:
10.5"W x .12.2"H x 12.2"D (electronics)
9.4"W x 12.2"H x12.6"D (speakers)
8.8"W x 3.86"H x8.8"D (surround speakers)
Package Dimensions:
29"W x 28.5"H x 16"D
Product weight: 42 lbs.
Carton contains: CD Mini System, Multi-Function Remote Control,
Batteries, Operating instructions,Warranty information
Printed in Singapore
©1997 Philips Consumer Electronics Co.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Next/Previous Skip
This two button feature offers you the opportunity to skip
back to the previous track or skip up to the next track
instantly.
Dual Mechanical Tape Deck
Feature full function control via a simple, easy-to-use
mechanical push button assembly.
High-Speed Dubbing/Continuous Play
High-speed dubbing makes it possible to create good
quality recordings (dubs) from one tape to another at
twice the normal speed in RECORD mode. Continuous
play offers automatic switching from cassette deck A to
cassette deck B providing an uninterrupted, continuous
flow of music in the PLAY mode.
Clock/Timer
Set the alarm portion of a built-in digital clock to wake you
to music from your favorite CD or an AM/FM radio station
at any desired time of the day.
Stereo Headphone Jack
Design
Design Concept
The linear theme, and contrasting surface definitions,
reflecting future "edge design" trends, combine to create a
modern and attractive design. Attention to details,
interactive lighting, and the use of rich materials and
metallic finishings further compliment the visual appeal.The
element of power is visualised through the dramatic three
dimensional speaker box surfacing.
Oversized, MultiColor, Digital FTD Display
This large display is easy to read at any distance with no
distortion or distraction and the multi-color format makes
it easy to recognize different functions at a glance.
PINGS (Philips Magnavox Intelligent Navigation
Guidance System)
Onboard intelligence monitors the systems and provides
information on status and available functions by means of
backlightling.
Ergonomic Control Layout
Convenient grouping of related functions along with
positive tactile feedback from front-mounted controls
optimize this model for comfort and conveniece.
Removable Cloth Speaker Grilles
Removable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
2

AUX
CD TAPE 1/2 TUNER
CD DIRECT
DBB DSC MUTE
REPEAT SHUFFLE PROGRAM
É
Ç
ë
í
Å á
á
VOLUME
PLAY
STOP
PREV. NEXT

123
DIGITAL REMOTE CONTROL
FW520C
CD Mini System
FW520C
CD Mini System
3 CD Changer with 100WattsTotal Power
and 4-Speaker Surround Sound System
• 2 x 50Watts RMS Stereo
• 4-Speaker Surround Sound System
• Digital Sound Control (Optimal,Jazz,Rock,Techno,Classic)
• 3-Step Dynamic Bass Boost
• Subwoofer Ready
• 40-Track CD Programmability
• AM/FM Stereo DigitalTuner with 40 Presets
• Oversized,MultiColor, Digital FTD Display
• 23-Button Remote Control
• 3-Way Speaker System with Bass Reflex and Removable Grilles
• OneTouch CD Synchro Recording
• Bedroom Clock withWake-up Alarm
• 4-Color Packaging
3 CD CHANGER 100watts
Total PowerTotal Power
SETEASY
RADIO
