Philips Streamium MCI500H User manual

DVD Micro System MCi500H
TABLE OF CONTENTS
3141 785 32960
DB 0824
2008
Location of PCBS ............................................................ 1-1
Specifications ................................................................. 1-2
Measurement Setup ....................................................... 1-3
Service Aids, Safety Instruction, etc. .............................. 1-4
Instructions On CD Playability .............................. 1-5 to 1-6
Software & Firmware Upgrade .............................. 2-1...2-2
Malfuction Check Chart ( TBC) ......................................... 2-3
Service Test Program............................................. 3-1...3-2
Disassembly Diagram .................................................. 4-1
Block Diagram ................................................................. 5-1
Wiring Diagram................................................................. 6-1
PB - AF/AMP.................................................................... 7
Circuit diagram .................................................. 7-1...7-4
Layout diagram.................................................. 7-5...7-6
PB - KEYS...................................................................... 10
Circuit diagram .......................................................... 10-1
Layout diagram........................................................ 10-2
PB - Aux IN....................................................................... 8-1
PB - Headphone ......................................................... 9-1
PB - LCD Interface....................................................... 12-1
PB - HasLi - 08 ................................................................ 13
Circuit diagram ............................................. 13-1...13-9
Layout diagram........................................ 13-10...13-11
Explode View ............................................................ 14-1
Service Partlist ............................................................ 14-2
PB - KEYS & RC............................................................. 11
Circuit diagram .......................................................... 11-1
Layout diagram........................................................ 11-2

Location of PCBS
1-1
VERSION VARIATIONS:
Type /Versions:
Features
Board in used:
MCI500H
Service policy
SMPS BOARD
TUNER MODULE
AF&AMP BOARD
HEADPHONE BOARD
AUX IN BOARD
* TIPS : C -- Component Lever Repair.
M -- Module Lever Repair
√
-- Used
/37
/37
/12
/12
/05
/05
Feature diffrence
RDS
VOLTAGE SELECTOR
ECO STANDBY - DARK
M
M
M
M
M
M
M
M
Type /Versions:
MCI500H
AF & AMP Board
WESLI-08 Board
KEY Board
SMPS Board TUNER MODULE
KEYS&RC BOARD
KEYS BOARD
WESLI-08 BOARD
M
M
M
M
M
M
M
M
M
LCD INTERFACE BOARD M

1-2
Specification
General
AC Power
Dimensions (w x h x d)
Weight (Net)
Power consumption
Active (ON) .............................................................................. 45W
(Active) Standby .....................................................................< 15W
ECO (Passive) Standby ...................................................... < 0.9W
Amplifier
Frequency response ...................................... 30 - 22,000Hz (-3dB)
Signal-to-noise ratio .................................................. 75 dBA (IEC)
Speakers
Power .....................................................50W (RMS) / 75 W (MPO)
Frequency response .......................................60Hz -- 30kHz (-6dB)
Sensitivity ..................................................................84 dB / m / W
Impedance ..................................................................................9Ω
Speaker drivers ...................................... 2 way bass reflex system
Dimensions (w x h x d) ....................................173 x 300 x 265 mm
Headphones
Impedance .......................................................... 16 - 150Ω(Ohms)
Input sensitivity
AUX IN .............................................. 500mV / 1V (user selectable)
Wireless
Wireless standard ........802.11g, backwards compatible to 802.11b
Wireless security ...WEP(64or128 bit),WPA/WPA2(8-63characters)
Frequency range .............................. 2412 - 2462MHz (CH1-CH11)
Wired (LAN / Ethernet)
Wired standard ..........................................................802.3 / 802.3u
Speed ........................................................................ 10 / 100MBit/s
Mode ....................................................................... half / full duplex
Crossover detection (Auto MDIX) ...............................................Yes
Tuner
FM wave range ............................................. 87.5 -- 108.0 MHz
Number of presets ................................................................. 60
230V ±10%, 50Hz (for /12, /05 /79)
............................................ 120V ±10%, 60Hz (for /37)
.. 120V ±15%, 60Hz or 230V ±15%, 50Hz (for /55, /97)
Main unit: 260 x 180 x 275 mm
.......................................Main unit: 4.58 kg; Main unit +
.......................................................... Speakers: 8.40 kg
Output power .......................................................... 2 x 50W (RMS)
................................ 5¼’’ Woofer, 25mm dome Tweeter
FM antenna/cable ......................................................................
HD player
Frequency range .................................... 30 -- 20,000Hz (-3dB)
Signal-to-noise ratio ..............................................75dBA (IEC)
M4A (AAC) bit rate ............................. 16 - 320kbps, CBR/VBR
MP3 bit rate ........................................ 32 - 320kbps, CBR/VBR
WMA bit rate ..................................... up to 192kbps, CBR/VBR
Sampling frequencies .......................................32, 44.1, 48kHz
HD storage capacity ..................................................... 160GB*
Recording quality ........ 128, or 160, or 192, or 256, or 320kbps
Recording speed ............................................................. 1x, 4x
CDDB (CD recognition database) .............................................
internal Gracenote® / online access enabled
Album artwork ................................................. Yes, supported
*Actual formatted capacity will be less
CD player
Frequency range .................................... 30 -- 20,000Hz (-3dB)
Signal-to-noise ratio ..............................................75dBA (IEC)
M4A (AAC) bit rate ............................. 16 - 320kbps, CBR/VBR
MP3 bit rate ........................................ 32 - 320kbps, CBR/VBR
WMA bit rate ..................................... up to 192kbps, CBR/VBR
Sampling frequencies .......................................32, 44.1, 48kHz
USB player
USB .............. 12Mbps,V1.1(support MP3,WMA and M4A files)
USB class ................................................................ MSC, MTP
Number of tracks/titles ...................................... maximum 9999
File format .....................................................FAT, FAT-32 only
Specifications and external appearance are subject to change without notice.
COAX / Dipole-antenna (75ΩIEC-connector)

1-3
LF Generator
e.g. PM5110
Recorder
Use Universal Test Cassette CrO2 SBC419 4822 397 30069
LEVEL METER
e.g. Sennheiser UPM550
with FF-filter
S/N and distortion met
e
e.g. Sound Technology ST170
L
R
DUT
or Universal Test Cassette Fe SBC420 4822 397 30071
LEVEL METER
e.g. Sennheiser UPM550
with FF
-
filter
S/N and distortion meter
e.g. Sound Technology ST1700B
L
R
DUT
CD
Use Audio Signal Disc
(replaces test disc 3)
SBC429 4822 397 30184
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
S/N and distortion meter
e.g. Sound Technology ST1700B
Frame aerial
e.g. 7122 707 89001
Tuner AM (MW,LW)
To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday´s cage.
Use a bandpass filter (or at least a high pass filter with 250Hz) to eliminate hum (50Hz, 100Hz).
RF Generator
e.g. PM5326
Ri=50:
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
RF Generator
e.g. PM5326
S/N and distortion meter
e.g. Sound Technology ST1700B
Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz).
Ri=50:
Tuner FM
MEASUREMENT SETUP

1-4
SERVICE AIDS
GB WARNING
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.
ESD
CLASS 1
LASER PRODUCT
GB
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used
Safety components are marked by the symbol !.
Lead free

Set remains closed!
N
Y
Play a CD
for at least 10 minutes
Y
playability
ok ?
N
playability
ok ?
add Info for customer
"SET OK"
check playability
N
Y
playability
ok ?
check playability
check playability
return set
Customer complaint
"CD related problem"
"fast" lens cleaning
1
2
3For flap loaders (= access to CD drive possible)
cleaning method 4is recommended
INSTRUCTIONS ON CD PLAYABILITY
1-
Exchange CDM
1-4For description - see following pages

1
PLAYABILITY CHECK
For sets which are compatible with CD-RW discs
use CD-RW Printed Audio Disc ....................7104 099 96611
TR 3 (Fingerprint)
TR 8 (600μ Black dot) maximum at 01:00
• playback of these two tracks without audible disturbance
playing time for: Fingerprint t10seconds
Black dot from 00:50 to 01:10
• jump forward/backward (search) within a reasonable time
For all other sets
use CD-DA SBC 444A..................................4822 397 30245
TR 14 (600μ Black dot) maximum at 01:15
TR 19 (Fingerprint)
TR 10 (1000μ wedge)
• playback of all these tracks without audible disturbance
playing time for: 1000μ wedge t10seconds
Fingerprint t10seconds
Black dot from 01:05 to 01:25
• jump forward/backward (search) within a reasonable time
2
CUSTOMER INFORMATION
It is proposed to add an addendum sheet to the set which
informs the customer that the set has been checked
carefully - but no fault was found.
The problem was obviously caused by a scratched, dirty or
copy-protected CD. In case problems remain, the customer
is requested to contact the workshop directly.
The lens cleaning (method 3) should be mentioned in the
addendum sheet.
The final wording in national language as well as the printing
is under responsibility of the Regional Service Organizations.
4
LIQUID LENS CLEANING
Because the material of the lens is synthetic and coated
with a special anti-reflectivity layer, cleaning must be done
with a non-aggressive cleaning fluid. It is advised to use
“Cleaning Solvent
The actuator is a very precise mechanical component and
may not be damaged in order to guarantee its full function.
Clean the lens gently (don’t press too hard) with a soft and
clean cotton bud moistened with the special lens cleaner.
The direction of cleaning must be in the way as indicated in
the picture below.
Before touching the lens it is advised to clean the
surface of the lens by blowing clean air over it.
This to avoid that little particles make scratches on
the lens.
INSTRUCTIONS ON CD PLAYABILITY
1-

2 - 12 - 1
SOFTWARE UPGRADING PROCEDURE
Software Version Verification Procedure
It is important to write down the system version infor-
mation of your Center before you start the upgrade
procedure. This information is also useful in case you
need to call Philips Customer Care Center.
1. Press MENU.
2. Press ▲/▼ to select “Information”. Press OK.
3. Press ▲/▼ to select “System”. Press OK.
4. The software version number is shown on the
display.
5. If the software version is not the latest one, you
need to upgrade MCI500H.
There are 3 ways to update the software.
A) Using CD-Rom
B) Using WADM
A. Using CD-Rom
1. Software Upgrade Disc Preparation
Tools Required : You will need the following items :
- PC (Pentium III 300MHz processor or higher)
- CD-R/RW writer and writing application software
- Blank CD-R or CDRW disc
- Broadband / High speed internet connection
2. How to download the software to your computer
1.
2. Unzip the .zip file and extract files into your PC.
Note:
- Please do not rename the filename.
- If you do not have the software to open the .zip
file, please visit below website to download the
software.
http://www.winzip.com/
3. Steps to upgrade the MCI500H
1. Make sure the Audio Station has connected to
the Audio Center.
2. Burn the file to blank CD-R or CDRW. Finalize
the disc. (The application may do this automati-
cally.)
3. Turn on the Audio Center and turn on the
Audio Station, insert the CD to the slot loader,
CD graphic printed side facing you.
4. The Audio Center will upgrade automatically.
- The message “Updating firmware, please
wait…..” and the “process bar” show on the
display of the Audio Center.
- The upgrade process of the Center will reboot
twice
Note: Do NOT power off the Audio Center or
eject the disc at this stage.
5. It takes around 5 mins to complete the firmware
upgrade for the Audio Center.
6. When done, the Audio Center will go to the HD
mode automatically.
4. After the upgrade
Do confirm the software version by checking the
system version.
Please follow the procedure described in the
section “Software Version Verification Proce-
dures”.
To download free firmware and software upgrades
for your product, please login to
www.club.philips.com
Download the firmware upgrade files and store
them on your PC
B. Upgrading firmware
The supplied PC Installer CD Wireless Audio
Device Manager (WADM) helps you get the
upgrades for MCI500H Center.
1Register your Philips Wireless Music Center
with www.club.philips.com
2Download the firmware upgrade files and store
them on your PC
3Place Center on a flat and firm surface
4Connect Center to power supply
➜HD screen appears on Center
5Connect Center to your PC via the supplied
ethernet cable.
6Install and launch WADM (see Connect to
your PC section B)
7Click Device Configuration,and then click
the Firmware upgrade sub-menu
8As prompted, click Browse and indicate the
location where you kept the firmware upgrade
files on PC
9Click Apply to start upgrading firmware
On Philips Wireless Music Center:
➜The display shows “Updating firmware,
please wait...”
➜Center will reboot itself during the installa-
tion process
➜When Center returns to HD screen, the
installation is completed
IMPORTANT!
On Philips Wireless Music Center
– Never interrupt the firmware upgrading
before its completion.
– Before finishing the installation, never
operate other functions.
* Hints: Restoring previous
firmware
After the Center’s firmware is upgraded, you
can restore it to its previous version as desired.
1Select HD mode, and then select Restore
firmware
a. Press MENU to enter the MENU screen
b. Press the navigation controls 3or 4and 2
to enter Settings,Firmware and Restore
firmware one by one.
2Press 2to select Ye s
Helpful hint:
– After restoration to previous firmware, the set
will lost Wi-Fi links to associated stations or
external network.
* Reset
– Restoring to default settings does not delete any
stored music tracks
When to reset the Center:
– Resetting the Center helps to re-establish the
Wi-Fi connection between the Center and
Station.
– Change the way the Center connects to an
external Wi-Fi/wired network.
1Check that the set is switched on (see 5.Basic
functions).
2Press MENU to enter the menu screen
3Press the navigation controls 3or 4and 2to
enter Settings followed by Restore
settings.
4Press 2to select Ye s
➜The set is rebooted. Language selection
screen appears.
5Select your desired language: English,
Français,Español,Nederlands,Italiano or
Deutsch
➜The set enters Installation Mode
➜The search for Center starts.The Wi-Fi con-
nection is being re-established
Helpful hint:
– After restoration to default settings, the network
mode will go back to Ad-Hoc mode.

2 - 22 - 2
Gracenote CD Information
The Gracenote music recognition service
enables the set to look up CD track
information (including album, artist, genre, track
information) from its built-in database. It allows
the recorded CD tracks to be properly
categorized (for example, under Artists, Albums,
Genres or All tracks) and also be merged with
the existing tracks in the hard disk.
12.1 Gracenote music
recognition database
A 800 MB CD database (contains 800,000
most popular CDs) is embedded in every
WAC3500 Center for quick look-up on track
information. An update file that contains newly
released CDs is available quarterly on
www.club.philips.com for download.
12.1.1 To update Gracenote
music recognition database
1Use your PC to register your product on
www.club.philips.com and go to "Show
Upgrades & Support" page to download
Gracenote Music recognition database update.
Note that the updates are posted quarterly and
each update is independent of each other, i.e. a
later update could be installed without an earli-
er update.
2After storing the file on your PC, you can either
burn a CD with the update file using your
favorite CD burning software and drop the CD
into the WAC3500 Center for automatic
update, or you can use WADM's Gracenote
update option if you have connected your PC
to WAC3500 Center.
12.2 Gracenote Internet
Query
If the CD track information of your new CD
disc cannot be displayed on the WAC3500, the
quickest and surest solution is to look it up
from the internet by following steps below.
12.2.1 Connecting to the Internet
1Check that you have connected the Center to
an Access Point or Router with Internet access
or connect the Center to an ADSL modem
with Internet access directly
Helpful hint:
– Make sure that no dial-up, user name or
password is required for the Internet access.
2Set DNS and Gateway
●If you are using a DHCP* enabled Access
Point, Router or ADSL modem, the DNS
and Gateway can be got automatically, so you
need only to set the Center to Automatic
(DHCP) mode by following steps below:
*DHCP stands for Dynamic Host Configuration Protocol. It is a
protocol for assigning dynamic IP addresses to devices on a
network.
a. Press MENU
b. Press 3or 4and 2to select Settings
> Network > Wired
c. Press 2to continue
d. Press 3or 4and 2to select Automatic
(DHCP).
●If there is no DHCP, set the DNS and
Gateway manually by following steps below:
On your PC,carry out the following steps:
a. Click Start > Run
b.Type cmd and click OK
c.Type ipconfig/all
ETHERNET
Internet
WirelessBaseStation11g TWirelessBaseStation11g TrueTrueTurbourbo
WirelessWirelessModemPCModemPC PowerPower
Connect to Internet for Gracenote
Internet sevices
DSL modem
Router/Hub/Switch
for illustration only
d.Write down the DNS and Gateway of the
current connection
On the Center
a. Press MENU to enter the menu screen
b. Press
3
or
4
and
2
to enter
Settings
>
Network
>
Internet
c. Press 2to continue
d. Set DNS
1) Enter the DNS server you wrote down
2) Press OK/2; to confirm
3) Press OK/2; to skip Set DNS2
Helpful hint:
– If necessary, follow Steps 1) to 2) above to
set a secondary DNS server in Set DNS2
e. Set Gateway
1) Enter the Gateway you wrote down
2) Press OK/2; to confirm
f. Set proxy
If you are using a proxy server to visit websites,
enable Proxy and proceed with the proxy
setting as prompted, then press OK/2; to
confirm
Otherwise, press OK/2; to skip
3Choose to apply the settings as prompted
➜Settings will change. Connection to sta-
tion could be lost appears.
12.2.2 Looking up CD track information
When the internet connection is made, insert
the CD disc that you want to look for its
information into the CD loader on the Center.
Searching start immediately. It will search from
local Gracenote CD database firstly. If can’t find
the CD track information, online searching will
then start.The searching results will be shown
on the Center’s display,
Helpful hint:
If the internet query failed due to failure in
internet connection, the error message "Check the
internet setup for Gracenote online" will appear.
Check if your internet connection is correct (see
12.2.1 above)

SERVICE TEST PROGRAM
3 - 1 3 - 1
To enter service mode,keep
OK key depressed while
p
lugging the main AC cord
i
Display shows
Welcom to FSM
Ver: x.x
OK
Display shows
1.HW Test
Display shows
HW Result
111111
Display shows
2.LCD Test
Display shows
3.KEY Test
Display shows
4.WiFiSetting
VOL
VOL
OK
STOP
OK
STOP
OK
STOP
Display shows
3.1Keypad Test
Test all keys on pannel
(Disolay shows key
name
)
OK
Display shows
Key Test OK
(or Fail)
STOP
Press STOP key twice
Display shows
3.2 RC6 Test
Test all keys on remote
control
(
Disola
y
shows ke
y
name
)
OK Display shows
RC6 Test OK
(or Fail)
Press STOP key twice
STOP
Display shows
4.1 Channel1
Display shows
4.2 Channel2
Display shows
4.10 Channel10
Display shows
4.11 Channel11
STOP
OK
VOL
VOL
VOL
VOL
VOL
VOL
VOL
VOL

SERVICE TEST PROGRAM
STOP
VOL
VOL
Display shows
0.Information
Display shows
9.Reset Setting
Display shows
6.LCDContrast
Display shows
5.FANControl
OK Display shows
0.1ModVersion Display shows
0.2WiFiMAC Display shows
0.3EtherMAC
Display shows
ModuleVer
2194
OK OK
VOL
VOL
Display shows
WiFi MAC
01:23:45:67:89:01
STOP
Display shows
Ethernet MAC
01:23:45:67:89:01
OK
STOP
STOP
OK Display shows
Setting OK or Setting Fail
Display shows
5.1Full Speed Display shows 5.2FAN Off
VOL
VOL
OK
STOP
Display shows
Setting Deployed
OK
Display shows
6.1Setting1 Display shows 6.2Setting2
VOL
VOL
OK
STOP
OK
Display shows
6.3Setting3 Display shows Setting Deployed
VOL
VOL
OK Display shows
Reset OK or Reset Fail
STOP
+
-
+
-
+
-
3 - 2 3 - 2

4-1
4-1
Disassembly Diagram
- Pull the left or right cabinet and then lift it.
1. Remove Left & Right Cabinet
- remove screws T3x6 - 4 pcs
A
A
A
A
A
2. Remove Top Cabinet
- Remove screws T3x6 - 3 pcs
B
BBB
C
C
- Remove screws M2.6x8 - 2 pcs
C
3. Remove Wesli board
- Remove screws T3x6 - 4 pcs
D
D
DD
D
4. Remove SMPS board
- Remove screws T2.6x4 - 4 pcs
E
E
E
E
E
- Remove screws M3x8 - 2 pcs
F
F
5. Remove Amp board
- Remove screws T3x6 - 1 pcs
G
(Please refer to first picture) (Please refer to first picture)
(Please refer to second picture)
H
G
- Remove screws T3x6 - 1 pcs
H
(Please refer to first picture)
- Remove screws M2.6x8 - 1 pcs
I
(Please refer to first picture)
I
6. Remove rear cabinet.
- Remove screws T3x6 - 9 pcs
J
(Please refer to second picture)
J
7. Remove HDD & CD loader cover.
K
- Remove screws M2.6x8 - 2 pcs
N
K
K
L
- Remove screws T3x6 - 9 pcs
L
- Remove screws T3x6 - 2x2 pcs
- Remove screws T3x4 - 2x2 pcs
M
N
M
8. Tips - loader set as slave and HDD set as master.

5-1
5-1
Block Diagram
LCD-driver
HX8347
(Himax)
TFT LCD
320 x 240
(Color, dotmatrix,
normally black)
9ROWDJH
ERRVWHU
White Backlight
(6 LEDS’s)
+9.1V
+9.1V
+12V
Source
Selector
Incredible
Surround
filter
+
+
Incredible
Surround
filter
Volume 1
stage
Bass
&
Treble
filter
Bass
&
Treble
stage
Bass
&
Treble
filter
Volume 2
stage
+9.1V
ALC
ALC
Ripple
Filter
Control
Logic
IC – TDA7468D
HP
IC – NJM4560
Mute
Stage Headphone
socket
I2C_SDA / SCL (1)
+12V
+6.8V
+12V
ON / OFF
FAN
FAN CONTROL circuit
32Ohm
HAS-out R
HAS-out L
AUX in
Mute
Stage
R
L
L
Mute
Stage
L
R
FAN_on/off
$)$033&%
Key row 1
Key row 2
RC6 (1way)
RC5/RC6
On/Off
Switching
logic
ECO_LED
+5V2
KEY PCB
ANT +
OSC
IF
IC - AN18202A
FM-decoder
&
synthesizer
OSC out
VTUNING
PANASONIC TM-10 V2TUNER-MODULE
+9.1V
L
R
FM_TUNED / FM_STEREO
I2C_SDA / SCL (1)
4M332
RDS decoder
SAA-6588T
+5V2
I2C_SDA / SCL (1)
FM_DET
FM_DET
Ā0HORG\ā
ARM-9/EPICS-7b
(pnx-0106 / pnx-8706)
Nexperia®
Mask: /N206 … JTAG enabled
SDRAM
64MB
+3V3
(A0:A14)
CLK_54MHz
(D0:D15)
(DQM0,1:RAS:CAS:CKE::DYC S:WE)
FLASH
2MB NOR
+3V3
RESET
(A0:A19)
(D0:D15)
(CS0:OE::WE)
030&
Multiple Purpose
Memory Controller
Programming /
debugging
Interface(s)
8$57
(UART:0)
-7$*
interface
8$57
interface
$'&
inputs
KEYS 0:1
&/.
Generator
02'(/,QGLFDWRU
MCi-300
MCi-500H
&28175<,QGLFDWRU
EU/USA/Korea/China
(A6:A10)
(D0:D15)
CS1:WE : OE
ETHERNET
(AX-88796B)
ETH (RXD)
Voltage
Detector
2V9
+3V3
ETHERNET LED’s(opt.)
TFM
ETH_RESET:ETH_IRQ
+1V8
+3V3
WiFi 802.11g
(miniPCI card)
BCM4318KFBG
EPLD
(EPM3064ATC100)
(CS2:OE:WE)
CLK_54MHz
(D0:D7)
(A0:A10)
TCK
TMS TDI
TDO
JAM / JTAG interface
TMS
RESET
CARD_(A1:A14)
CARD_(D0:D15)
CARD_(REG:WAIT:WR:OE:CE:RD:WE)
+3V3
CARD_(IRQ:RESET)
ANT
DVDROM
(Liteon SHD-16D2P)
+5V+12V
3&&$5'
$7$
interface
$'&
Audio
+3
,
&
interface
V1
NTC
SMPS_NTC
I2C_SDA / SCL_1
V2 / V3
PWRDWN
RDS_IRQ
VREF
AOUT
DAC
+12V_AF
'$&
Audio
AUDIO_INTERFACE
63,
interface
63',)
interface
/&'
interface
ECO_CORE
KEY_LED
RC5/RC6 FIQ
86%
interface
KEYBOARD
INTERFACE
USB (D+ / D / ID)
+5V0
Overcurrent
Detector
0.55A / 1.1A
USB (PWR / FAULT / BOOST)
USB-INTERFACE
+5V_USB
(UART:0)
DISABLE_RC
DEVICE_ID
ECO_STBY
ECO_STBY
25.00M
ETHERNET-INTERFACE
ETH (TXD)
12.00M 32.768k
RESET
+3V3
RESET
DC
DC
+9V_ECO
OUTPUT
LEVEL CTRL.
ECO_STBY
LDO
1V8
+3V3
+1V8
ECO-STBY:3.05V
NON ECO-STBY:3.35V
LDO
3V3 +3V3_A+5V0
+3V3
ECO_STBY
+3V3_WiFi
OPTIONAL
LDO
11V
+12V_AF
+12V
+12V_DAC
+DV/LPRGXOH
EPLD
+3V3_A
+1V8 LDO
ON / OFF
PWR
FAULT
GND
ISOLATOR
(TDA8579T)
FM_STEREO
FM_TUNED
FAN_on / off
MUTE
AMP_on
ECO_LED
HP_DET
HAS R / L _OUT
Programming /
debugging
Interface(s)
63,
ECO_LED
ECO_LED
02'(
HP_DET
RDS_IRQ
MUTE
+30V
Speakerbox
50W
(9 Ohm)
R
Engage
Powerup
+30V
Speakerbox
50W
(9 Ohm)
L
Engage
Powerup
7'$7
7'$7
ECO_LED
R
AMP_ON
LAN (RJ45)
USB (Type A)
… 7/8 buttons each row …
/&'PRGXOH <%7*&'
+12.0V
+5V2
TFM (SMPS)
+5.2V
+12V
SMPS
Control
+9V0
TFM (SMPS)
SMPS
Control
+9.0V_ECO $&LQ
PWRDWN
ECO_STBY
SMPS MODULE
Over-voltage
Over-current
Short-circuit
detector
D1
D2
ON/OFF
Input-stage
with
manual
voltage selector
SMPS_NTC
D3
+30V
PART OF AF-PCB
HDD 3.5”
(160GB PATA-Harddisc)
+5V+12V
ATA_(D0:D15)
ATA_(DMARQ,DMACK,INTRQ,DIOW,DIOR,DIORDY,RESET)
ATA_(DA0:DA2,CS0:CS1)
GND
ISOLATOR
(TDA8579T)
AIN
DAC
+12V_DAC
REC_L / R
REC_L / R
+12V
BK_LIGHT
LDO
3V0
+3V3
PARALLEL (D0:D7,CS,RS,WR,RD,RESET)
ECO_CORE
ON?OFF
ON / DIM / OFF
+LCD_COLOR
BACKLIGHT
LCD color
INTERFACE
BK_LIGHT
PARALLEL (D0:D7,CS,RS,WR,RD,RESET)
+LCD_COLOR
ANALOG
On/Off
Switching
logic
KEY_LED

6-1
6-1
Wiring Diagram
272217100648
LCM 3.2’Color Yeboo
314107803051
PB 314107351043
KEY
DVD-ROM
CH-16D2P 2822 062 00194
314107021131
PB 314107351013
314107803021
PB 314107351003
AUX IN
2422 542 00049 / EU KEY & RC
242254901803
RC6 Receiver
SMPS
To HDD/CDROM
314107803031
WiFi Card
Main
AUX
USB
PBAS HasLi-08
To Service SPI Board To Service UART
Speaker JACK
Socket
1300
GND Wire
314107021211
100mm, 1p
To Metal Bracket 314107021601
180mm,3P,SCR
314107022051
190mm,6P,SCR
8004
430mm,10p,BD
314107022011
280mm,23p,BD
314107022001
181mm,40P/20P
8003
Mains Cord
WiFi ANT Internal
242254900717
314107021631
PB 314107350983
314107803001
314107802951
PB 314107351032
314107022061
280mm,24P,0.5mm AD
8001
Dipmale Dipmale
314107022041
Hard Disk
HP JACK
282206200169
2422 542 00048 / USA
WiFi ANT External
8005
AMP Vcc System Vcc
PH H
AF & AMP
PH V
SPK cable with special plug
PB 314107351023
8008
8007
314107803041
282206501728
PB 314107350993
LCM Interface Board
314107803011
8010
220mm,9P,1mm AD
8006
314107021591
230mm,5P,SCR
8002
313911036061
100mm,8P,1mm BD
8009
70mm,1P,GND CBLE
8011
1300
282206502109
Dipmale
282206241045
Power Supply Audio In/Out,Control Ethernet
Key,RC LCM
USB
314107021991
130mm,USB-A
Top Bottom
FAN
314107850341/05
2822 031 01522
TM-10
24FMN-BTRK-A
RED-YELLOW
1200-1
3
1
2
1608
1 2 3
4 5 6
4
1301
9 8 7
1 2 3
B4B-EH-A
1 2 3 4
B5B-EH-A
1
2
3 4
3 4 5 6 7 8 9
B4B-EH-A
B9B-EH-A
1 2
1102
1 2
1405
08FMN-BTRK-A
7400
7400
TSOP4836
2
GND
1
OUT
3
VS
1 2 3 4
5
1104
WHITE-RED
1202-2
6
4
5
1201
1 2 3 1 2 3 4 5
7
8
9
1302
17
18
19
2
20
21
22
23
3
4
5
6
1
10
11
12
13
14
15
16
1 2 3
1401
1 2 3 4 5
1103
8 9
1101
1 2 3 4 5 6 7 1 2 3 4 5
1108
1109
1507 1506
3 4 5 6 7 8 9
1406
09FMN-BTRK-A
1202
1 10 2
1627
1 2 3 4
1107
1 2 3
4
5
09FMN-BTRK-A
1114
1600
1
2
3
B5B-EH-A
1 2 3 4
6 7 8 9
08FMN-BTRK-A
1125
1520
1
10
2 3 4 5
24FMN-BTRK-A
1606
1614
24FMN-BTRK-A
1
2
3
4
5
1
2
3
4
5
6
1904
5
6
1302
1523
1
2
3
4
21
22
23
3
4
5
6
7
8
9
12
13
14
15
16
17
18
19
2
20
1706
1
10
11

7-1
7-1
PB - AF/AMP - Circuit Diagram - Sheet1
DGND
IN-L1
BASSO-R
CREF
VS
SDA
SCL
ALC
MIC
IN-R4
IN-R3
IN-R2
IN-R1
IN-L4
BASSI-R
IL-L3
IN-L2
TREBLE-R
IS-R
MUX-R
OUT-R
BASSO-L
BASSI-L
TREBLE-L
ISL-
MUX-L
OUT-L
GND
Option
A
B
C
D
E
F
H
1103 E2
H
G
2544 F8
2546 D9
2547 B8
2548 F8
2565 D9
2567 B8
2568 F8
2589 D10
2202 B6
5678910111234
3522 B3
3523 B3
3524 B3
3525 D6
3526 E6
3527 D5
3528 D6
3529 D6
13
iPod IN
G
2542 G9
2543 C8
5705 C9
5706 F9
6201 B6
6202 C6
7201 B6
7501 C8
F101 D3
F102 D3
2590 D10
2203 E9
2204 C5
2
3514 C3
3521 A3
9.1V
S30
~600mv
~535mv
Option
M40
SIMPLE I.S.
M40
3530 D6
12
V10
F
2541 B9
5703 C13
5704 E13
3549 B8
3550 G8
3591 D10
3592 D10
3593 D10
3594 E10
3707 E7
3708 E6
3709 E10
2593 D10
2594 E10
2534 E6
4.6V
1
3513 B3
G20
V10
2641 C12
2642 E12
2707 F7
2708 F7
3450 D3
3451 D3
3507 B9
3508 F9
3509 B5
3543 A9
F103 B6
E
G20
M10
5702 E11
5015 B6
3548 F8
7 8 9 10111213
A
B
5011 C12
5012 D12
2206 B7
2524 E6
2507 D7
2511 B4
2533 D6
2512 C4
U10
S30
9.8V
45
D
SIMPLE I.S.
5701 C11
3510 B5
3
3546 G9
3547 C8
6
2595 D10
2505 D5
2506 D6
10K
3524
C
3544 H9
3545 B8
2513 B3
2514 C3
2515 D5
2516 E5
2521 A4
2522 B4
2523 D6
2598 F7
3511 B3
3512 C3
G30
~900mv
2596 E10
2597 E7
AUX IN
2507 1n0
5703
600R
3529
GND_A
470R
3710
470R
GND_A
3508
470R
U8
3707
100R
BC337-25
7201
BZX384-C9V1
6202
GND_A
3591
8K2
470n
2595
600R
5704
5K6
2596
3593
470n
2511
2u2
GND_A
GND_A
2202
22u
16V
1n0
A_HP
GND_A
2641
GND_A
GND_A
GND_A
GND_A
2568
1n0
2589
220n
3528
GND_D
470R
GND_A
A_HAS
3543
15K
2642
1n0
GND_A
GND_A
3712
470R
470R
3711
319804000040
1105
1
2
3
4
2547
3n3
470R
3526
GND_A
1n0
GND_A
2506
GND_A
5K6
GND_A
5011
3594
1K0
2546
4n7
3525
470R
5K6
A_HAS
3545
10K
3523
GND_A
GND_A
3548
10K
16V
220u
22
12
17
14
15
9
20
1
2204
3
4
6
26
25
24
23 21
8
2
7
16
10
19
11
18
27
13 28
5
TDA7468D

7501
2542 470n
3509
390R
2707
3n3
100p
2597
2548
50V470n
3451 470R
470R
3450
2598 100n
3547
10K
2524
1n0
470n 2594
10n
2543
2505
1n0
GND_A
3511
1n0
18K
GND_A
2513
2206
68K
3513
22n
1n0
2514
2515 220p
GND_A
3530
470R
2522
100n
2544
10n
470n
GND_A
2541
2565 4n7
3522
8K2
GND_A
2516 220p
3546
5K6
3592
GND_A
8K2
2203
47u
16V
2523
GND_A
GND_A
1n0
2512
2u2
18K
3512
3514
68K
F103
2533 100p
GND_A
GND_A
5706
600R
600R
5705
3521
8K2
6201
BAS316
470R
A_HAS
3507
3527
470R
1
2
3
600R
5702
1103
319804000030
GND_A
2593 470n
3550
18K
GND_A
600R
5015
1K0
5012
3544
15K
GND_A
GND_A
A_TU
5701
600R
F102
U9
3510
3R3
A_HAS
3709
3549
18K
2708 100p
2567
A_HAS
F101
100p
1n0
2534
3708
100R
GND_A
GND_A
100n
2521
220n
2590
+12V_A
line_L
line_R
HP_R
Tu_Left
Tu_Right
HAS_Right
HAS_Left
Filt_L
Filt_R
VREF
+9.1V
SCL
SDA
HP_L

7-2
7-2
PB - AF/AMP - Circuit Diagram - Sheet2
E
G
H
C
E
H
1101 F7
5.9V
U10
5.9V
2
653 119
option
5.9V
2214 H6
2216 C4
2218 A4
2234 D6
5.9V
C
D
2611 E4
F
2622 D9
2624 H5
A
B
2627 D6
D
2633 B7
F
G
2923 B5
2924 A4
2212 C4
2926 F5
11.6V
2928 G6
5.9V
3207 A10
1
3212 B7
3 11
12
3254 B11
4
3330 D4
3331 D4
78
3602 H3
10
3607 F3
A
B
3610 F4
3611 E5
2213 A4
3613 F5
2215 C4
3621 D11
2217 A4
3623 D10
2223 D8
3629 H5
2235 B7
2608 G3
2609 F4
2610 F4
7207 B11
2612 G4
F208 B7
7601-2 E4
2625 H5
2626 D10
7601-1 G4
2628 B8
7603 F6
2905 H4
2922 G8
7622 C9
7623 D10
2925 E6
F205 G5
2927 F5
7205-2 A6
3204 D6
3625 D9
3626 D9
3627 G6
3218 C4
018654
3255 C11
F204 G8
7208 C11
F206 H5
F207 B8
5.9V
5.9V
3449 G7
3601 E3
F210 F3
3604 B7
5019 F6
3608 F3
3609 F4
7624 B8
F201 F7
F202 F7
F203 G7
3614 F5
3230 B5
3622 E11
2606 H3
3642 G8
3237 C10
5020 C3
2236 A10
2238 B10
2603 E2
2605 E3
2607 E3
5404 G6
5407 A3
5621 G6
3210 B10
3624 D10
3219 B4
3222 C5
3628 H5
F211 F3
3631 G8
3640 G8
3641 B8
7604 G6
7621 C10
3223 C5
7
3236 B10
9
7205-1 C6
2604 G2
F209 D10
3224 B5
U25
3225 B5
3612 G5
3231 A5
BC857B
7622
100p
2606
GND_A
150n
2217
2625
47u
16V
220n
2213
3642
10K
3237
4K7
1K0
3631
A_HP
GND_A
F202
3628
4K7
A_HP
22n
2624
2633 100n
600R
5407
7624
BC337-25
A_HP
3
21
84
TL082ID
7205-1
47p
2927 2926
47p
16V
47u
2214
A_HP
GND_A
50V 1u0
2236
600R
5621
2626
10u
25V
3210
560R
2922 10n
F201
GND_A
100K
3225
2215
150n
GND_A
F210
GND_A
560R
3207
GND_A
2612
22u 16V
F208
12K
3602
7207
BC817-25
2223
47p
600R
5404
2K2
3604
3
21
84
BC817-25
7603
7601-1
NJM4556AM
2235
47u 16V
A_HP
A_HP
A_HP
2622 100p
3611
82R
F207
470n
2603
GND_A
GND_A
3626
4K7
12K
3255
3608
+12V_HP
8K2
82R
3612
330n 2216
2212
220n
2218 330n
68K
+5V
3231
F206
GND_A
67
84
3601
12K
7601-2
NJM4556AM
5
330n
2924
BC817-25
7208
3449
220R
2609
47p
3609
22K
100K
3222
2607 470p
10R
A_HP
A_HP
3212
1n0
29252928
1n0
GND_A
3623
1K0
BC847B
A_HP
GND_A
7621
470n
2604
5019
600R
100n 2627
2605 100p
GND_A
10K
3218
+5V
F205
2238
1u050V
16V
22u
2611
F203
2923
330n
5020
600R
4K7
3236
F211
5
12K
3254
1101
319804000050
1
2
3
4
22K
3610
A_HP
3219
10K
10R
GND_A
+12V_HP
3627
3625
4K7
470p
2608
A_HP
BC847B
7623
16V47u
2234
7604
BC817-25
3223
100K
GND_A
3621
10K
GND_A
3624
5K6
3224
100K
4K7
3629
GND_A
A_HP
A_HP
3331
3330
3613
1K0
3640
5K6
F209
2K2
3204
3641
4K7
47p
2610
67
84
TL082ID
7205-2
5
2628
47u 16V
8K2
3607
10K
3622
1K0
3614
2905
22n
68K
3230
F204
Filt_R
Filt_L
HP_Mute
Filter_Mute
Panel_L
Panel_R
+12V_A
HP_Det
HP_L
HP_R
HPREF
HPREF
HPREF
HPREF
HPREF
HP_Mute

7-3
7-3
PB - AF/AMP - Circuit Diagram - Sheet3
I
OOSC
MPX
CIN
SCOUT
VSSA
VDDD
PSWN
MPTH
MRO
VREF
SDA
MAD
AFIN
TCON
VSSD
SCL
LVIN
DAVN
VDDA
2968 B3
2970 A3
2972 B4
975
B
D
2958 B1
2963 B2
1523 D4
2240 A8
2901 E5
3310 A3
2961 A1
3312 B7
2967 B2
3318 D7
2969 A3
3320 E8
2971 B2
3322 E8
2974 D8
431
3340 A8
6
3342 B7
8
3344 A8
A
5013 F4
C
5021 E8
F
1520 F4
1522 C5
3304 B4
2205 A1
3307 B3
3309 A3
F308 E5
3311 A8
F310 D1
3317 D8
F312 E8
3319 E2
F314 E5
3321 E8
F316 E5
2973 B2
3324 E2
2975 E2
2976 A2
89
3336 D8
2
3338 D8
3339 F8
F332 D9
3341 B7
F334 A9
3343 C7
RX-
4002 C8
R_IN
5014 E5
FM_DET
E
5027 F8
A
PWRDWN
TO FAN
B
C
1110 A1
1401 D9
3302 A2
3303 B3
F304 E8
3306 B4
F306 D1
F307 E8
AMP_2
F309 E4
SLEEP
F311 E5
TX+
F313 D1
STEREO
F315 E8
PWRDWN
3323 E8
F318 F8
3325 F4
3326 F4
2977 C3
2978 C4
AMP_On
GND_A0
FM_TUNED
67
3334 D4
3335 D8
F328 E1
3337 D8
F330 D9
F335 E8
+12V_A
Port_SL
N.A
GND_AMP
GND_A
FROM/TO TUNER
RDS_IRQ
GND
RDS DECODER
5026 E4
Filter_Mute
5039 E8
5040 F8
2979 F4
2981 C7
3205 B7
3242 D7
3243 D7
D
E
F
1102 A9
1108 D1
1109 C1
3300 A2
3301 A3
F302 C1
F303 E8
FROM / TO Supply Board
F305 E5
+5V
I2C_SDA
L_OUT
F96
SMPS_NTC
N.A
R_OUT
AMP_1
SMPS_NTC
I2C_SCL
+9V
F317 D1
TX-
F319 D1
F320 F8
3327 E5
3328 E4
W96
R10 A60
ECO_STBY
12345
3329 F4
3333 D4
F323 F8
F324 E1
F326 E1
F327 E1
F329 D8
F331 D9
F333 A9
+12V_A
GND
R out
Ethernet
FROM / TO HasLi-07 Board
SCL
GND
5710 F8
+9V_ECO
N.A
GND_A
Fan control
5041 A4
5709 F8
FAN
RX+
TUNED
3244 A4
3245 B8
3247 B8
3253 A7
3258 E8
3259 E8
6206 B7
7211 B8
7212 A7
7610 A3
7611 B7
F301 E8
GND_A1
GND_AMP
FM_STEREO
SDA
F321 F8
F322 F4
L_IN
S96
HP_Det
GND_AMP
GND_D
ECO_on
L out
FROM / TO HasLi-07 Board
R96
3325 100R
F313
GND_D
3338 220R
600R5021
GND_D
F322
GND_D
220R
3336
F306
4K7
3242
F328
25V
220R3328
10u
2969
3245
4K7
3243
GND_D
4K7
GND_D
F309
2971
GND_D
3317
100p
100n 2976
100K
1K0
3302
F315
2973 100p
2972
100n
8
9F326
1108
B9B-EH-A
1
2
3
4
5
6
7
F325
100R
4M332
1110
3311
F317
47p
2977
600R
7212
BC368
1
2 3
5026
600R
5709
F331
100R3259
GND_D
100R3326
3
4
5
6
3253
2R2
1523
319804000060
1
2
GND_D
220R
3337
100R
3312
22R
1
2
3309
319804002020
1102
F314
100R3258 F301
220R3324
297510n
PGND
GND_D
47K
3247
GND_D
7
8
910
1522
1-406541-1
1
2
3
4
5
6
220R3319
47K3318
F318
GND_DGND_D
3323 220R
2981
100u 10V
3310
22R
F333
F303
GND_D
470K
3304
GND_D
F305
GND_D
3K3
3341
5041
600R
A_TU
GND_D
3306
F310
100R
2240
GND_D
F316
16V10u
F311
82p
F321
2205
2974
22n
GND_D
BC847B
7211
GND_D
600R
5013
GND_D
F3303335 220R
220R3322
F324
F312
GND_D
F308
5040 600R
+9.1V
220K
3300
F304
GND_D
+12V_A
3333 75R
GND_D
2967 330p
3329 220R
2979 330p
F323
150K
3342
BC847B
7611
3307 100R
F320
3321 220R
75R
3334
F335
5710
600R
10
2
3
4
5
6
7
8
9
F334
1520
10FE-BT-VK-N
1
GND_A
5027 600R
600R5039
220R3320
F329
GND_D
2958
47p
2970 100n
100R
3340
3343
27K
GND_D
560p
2963
8K2
3303
2978
47p
4K7
3301
9
3
14 7
17
15
6
12
2
16 1
5
411
1018

13
19
8
20
3339
SAA6588T/V2
7610
470R
GND_D
3205
3K3
10n
2901
4002
F327
100R
GND_D
3344
2u2
2968
3327 220R
F319
F332
6206
GND_D
PDZ8.2-B
3
4
5
F307
319804002050
1109
1
2
600R5014
F302
47p
2961
3244
3R3
22
23
3
4
5
6
7
8
9
12
13
14
15
16
17
18
19
2
20
21
23FMN-BTRK-A
1401
1
10
11
GND_A
GND_A
+5V
line_R
+AMP_1
Filter_Mute
AMP_On
FAN
line_L
HP_Det
Sleep
AMP_FAULT
+AMP_2
+9V_ECO
SCL
SCL
SMPS_NTC
+12V_A
+12V_A
FAN
+5V
PWR_DWN
PWR_DWN
SMPS_NTC
FM_TU
SDA
Tu_Left
Tu_Right
ECO_STBY
RDS_DATA_RDY
FM_ST
FM_TU
RDS_IN
HAS_Right
HAS_Left
ECO_STBY
SDA
SCL
RDS_DATA_RDY
RDS_IN
FM_ST
+5V
SDA

7-4
7-4
PB - AF/AMP - Circuit Diagram - Sheet4
VSSD|HW
IN1N
IN2P
IN2N
INREF
OSCREF
OSCIO
HVPREF
DREF
ENGAGE
POWERUP
TEST
VDDP
VSSP
VDDA
STAB2
STAB1
BOOT2
BOOT1
HVP2
HVP1
DIAG
OUT2
OUT1
CGND VSSA
IN1P
VSSD|HW
IN1N
IN2P
IN2N
INREF
OSCREF
OSCIO
HVPREF
DREF
ENGAGE
POWERUP
TEST
VDDP
VSSP
VDDA
STAB2
STAB1
BOOT2
BOOT1
HVP2
HVP1
DIAG
OUT2
OUT1
CGND VSSA
IN1P
2401 A7
2410 B9
2411 B9
2412 B5
2451 F6
C
2424 C5
2425 C6
2426 B8
OPTION
2414 B6
910345
2408 B6
2481 E11
2
E
F
G
2409 B6
2428 C8
2429 C9
2430 C10
D
2400 A6
2413 B6
2439 E8
2440 E8
A
B2421 B5
2422 B8
2449 F5
2450 F6
3429 G9
OPTION
1
678
2407 A6
2468 G6
2471 G9
1404 E12
2207 A8
2282 A8
2427 C6
2479 E11
2480 E11
3462 C3
3463 C3
345
H
1104 C12
1403 D12
A
B
C
2436 D6
2437 E6
2438 E7
3414 D6
3415 D6
2415 B8
2417 B6
11 12
2420 B6
2447 F9
2448 F10
3425 F5
3426 G9
7401 E6
3435 E3
D
E
F
G
H
2465 G8
2466 G9
2467 G10
3432 B8
3422 F9
3424 F5
3452 F8
3453 F8
F405 B4
2474 G6
3464 C2
3465 C3
L+
6
2402 A8
2406 A9
12
11 12
2433 C6
2434 C9
2435 D5
3411 C6
3412 C6
3413 C9
5408 E9
5409 F5
2441 E8
2443 E9
2418 B8
2419 B9
2446 F6
6402 G6
7400 A7
3405 B5
3406 B9
3436 E3
3437 E3
L-
2462 F6
2463 F8
2464 G6 F401 C11
F402 C11
2472 E3
2473 H6
3421 F5
3447 B8
3448 B8
F403 C11
F404 C11
7403 E3
2475 D11
2476 D8
R-
2452 F8
78910
3408 B5
3409 B5
3410 C9
5402 B5
5405 C5
5406 D5
3471 G6
4000 G8
3433 F8
2444 E6
2445 F6
F407 D4
2477 E4
2478 E11
2482 C6
2483 G6
2488 D2
5415 F10
6401 C6
7409 C2
3442 B6
3443 G5
3418 F5
3419 F9
3446 H5
5017 B9
5410 F5
5411 F9
7402 E2
3434 E4
3438 E2
3439 F6
2454 F6
2431 C6
2432 C5
5018 B5
5400 A9
5401 B9
F408 F4
3466 E8
3467 A8
3468 A8
3469 E8
4001 G8
4004 D3
F406 C4
3470 C6
OPTION
R+
2459 F8
2461 F5
5412 B10
5413 C10
5414 F10
3417 E5
2489 D3
3208 A5
3209 B5
3400 A7
3403 B9
3444 G5
3445 H5
5016 D9
7408 C3
2455 F8
2456 F9
2457 F6
2458 F5
3440 F6
3441 B6
3416 D7
100n
2428
2436
10n
GND_IN
1n02479
F402
68K
3445
BC847B
2424100n
7402
120R
5413
2472
10n
3437
22K
3436
4K7
GND_IN
2480 1n0
BC857B
7403
GND_IN
GND_IN
120R
5415
2441
470u 35V
3439
47K
100n
2439
3418 4K7
GND_IN
F404
2431 100n
100n 2415
2407 470n
GND_IN
10n
2473
470n
2467
1n0
2481
2458 100p
GND_IN
2400
10u 50V
3400
10R
GND_IN
F408
470n
2450
2474
470n
5408
33u
5
GND_A
25V47u
2464
1
2
3
4
MSP-182V1-03
1104
100n
2447
2476
3n3
1
2
2446 470n
1403
B2P-VH
29
20
9 1
16 17 32 26 23
15
12
31
10
27
22
6
25
24
13
8
21
7
4
18
5
30
19
11
3
2
14
7400
TDA8932BT/N2
AMPLIFIER
POWER
CLASS D

28
F403
3434
10K
3425 39K
600R
5018
2432 100p
5409
600R
100p
2410
100n
1K0
2412
3432
2478 1n0
GND_IN
GND_IN
15n 2426
2411
470n
5405
600R
100n 2455
120R
5412
B2P-VH
1404
1
2
GND_IN
5410
600R
100n
47K
3440
2466
470p 2456
2482470n
3426
10R
1M03447
GND_IN
3448 1M0
4K7
4K7
3417
3209
2440 100n
3419
10R
100p 2421
330p 2408
470R
4K7
3444
3466
470n2448
5411
2475
33u
10n
GND_IN
5402
600R
GND_IN 3470 1M0
2430
470n
GND_A
4000
4K73421
470n
2417
GND_IN
2457
3446
4K7
100n 2459
3435
47K
15n
330p
2451
220n
100n
2429
GND_IN
2438
341322R
3405 4K7
47K
3442
GND_IN
GND_IN
3208 4K7
F406
2471 470p
GND_IN
2427 47u
3467
25V
470R
2414 330p
100n 2207
2445
330p
100n 2461
470R
3469
3468
470R
3441
47K
342222R
3410
10R
1%
GND_IN
5017
33u
3408
43K
3409
4K7
470n
2444
246315n
GND_IN
GND_IN
35V470u
2282
50V10u
2437
GND_IN
80R
5016
3433
1K0
F401
3443
150K
15n
4001
17 32 26
23
2422
6
25
24
13
8 29 20
9
1
16
19
11
3
2
14
15
12
31
10
27
22
28
21
7
4
18
5
30

CLASS D
POWER
AMPLIFIER
TDA8932BT/N2
7401
3471 1M0
150K
3412
5400
80R
2483
600R
5406
470n
2401
220n
BZX384-C18
6401
22R
6402
BZX384-C18
3406
3n3
2477
2402
2418
100n
100n
F407
3403
10R
35V
470n
2409
2443
470u
3411
4K7
GND_A
120R
5414
2435 100p
100n
2420
470p 2434
100n
3452 1M0
GND_A
2465
35V470u
100p 2449
GND_IN
2406
33u
5401
GND_A
GND_A
2454 470n
2413 470n
100n
2468
3416
10R
22R 3429
3438
330K
470p 2419
GND_IN
100n
2462
3415
68K
GND_A
4K7
3414
3424 4K7
1M0
3453
F405
470n 2433
2452
100n
2425 100n
GND_IN
PGND
AMP_On
Sleep
HVPREF1
HVPREF2
HVPREF1
HVPREF2
GND_IN
PGND
PGND
Sleep1
Sleep1
Panel_L
PGND
+5V +5V
DIAG
PGND
AMP_FAULT
+5V
Amp_On1
PGND
+AMP_2
PGND
PGND
DIAG
DIAG
Amp_On1
+AMP_1
PGND
PGND
PGND PGNDPGND PGND
PGND
Panel_R
PGND
PGND PGNDPGND

7-5
7-5
PB - AF/AMP - Layout Diagram - TOP

7-6
7-6
PB - AF/AMP - Layout Diagram - Bottom
