Philips MAS65 User manual

Version 1.0
MAS65
©3141 785 30490
Mini System
all versions
Published by YT 0525 Service Audio Printed in The Netherlands Subject to modification
© Copyright 2005 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Handling chip components ........................................................... 1-1
Service tools ................................................................................. 1-1
Leadfree and safety information ................................................... 1-2
Technical specification .................................................................. 2-1
Service measurement setup ......................................................... 2-2
Connections and controls ..................................................... 3-1...3-3
Disassembly diagram ........................................................... 4-1...4-2
Block diagram ............................................................................... 5-1
Wiring diagram ............................................................................. 5-2
Radio board
circuit diagram.......................................................................... 6-1
layout diagram.......................................................................... 6-2
Cassette board
circuit diagram.......................................................................... 7-1
layout diagram.......................................................................... 7-2
CD board
circuit diagram.......................................................................... 8-1
layout diagram.......................................................................... 8-2
Control and Main board
circuit diagram (control board) ................................................. 9-1
circuit diagram (main board) .................................................... 9-2
layout diagram ......................................................................... 9-3
Power board
circuit diagram ....................................................................... 10-1
layout diagram ....................................................................... 10-2
Exploded view diagram.....................................................11-1 ...11-2
Mechanical partslist......................................................................11-2
Electrical partslist ........................................................................ 12-1
TABLE OF CONTENTS

1 - 1
HANDLING CHIP COMPONENTS

1 - 2

2 - 1
SPECIFICATIONS
GENERAL:
Mains voltage : 110-127/220-240V Switchable
Mains frequency : 50/60 Hz
Power consumption : < 50W max.
< 5W at standby
Clock accuracy : 4 seconds per day
Dimension center unit : 267 x 298 x 254 mm
TUNER:
FM
Tuning range : 87.9 – 107.9 MHz
IF Frequency : 10.7 MHz r20kHz
Aerial input : 300 :dipole wire
Sensitivity at 26sb S/N : < 18 PV
Selectivity at 600 kHz
Bandwidth : > 46 dB
IF rejection : > 50 dB
Image rejection : > 25 dB
Distortion : < 2%
Crosstalk : > 18 dB
MW
Tuning range : 520 – 1710 kHz
Grid : 10 kHz
IF Frequency : 450 kHz r1kHz
Aerial input : Loop antenna
Sensitivity at 26sb S/N : < 4.4 mV/M
Selectivity at 18 kHz
Bandwidth : > 18 dB
IF rejection : > 28 dB
Image rejection : > 32 dB
Distortion : < 5%
AMPLIFIER:
Output power : 2 x 20 W RMS
Speaker impedance : 6 ohm
Frequency response
Within r3dB : 50Hz – 15 kHz
Hyper bass sound ON : 10dB r3dB at 100Hz
Digital sound control : Flat /Rock/Jazz/Pop/
Classic
Headphone output : 32 mW r2dB at 32 :
CASSETTE RECORDER:
Number of tracks : 2 x 2 stereo
Tape speed : 4.76 cm/sec +2.5/-1.5%
Wow and flutter : < 0.35% DIN
Fast-wind/rewind time : < 160 sec. With C-60
Bias frequency : 65 r5 kHz
R/P frequency response : 50 – 10 kHz (8 dB)
Signal to noise radio : > 35 dB with type 1 tape
COMPACT DISC:
Number of programming track : 32
Frequency response
Within r1.5 dB : 20 Hz – 20 kHz
Signal/Noise ratio : 50 dB/A-weighted
Distortion at 1 kHz : < 3%
Channel separation at 1 kHz : > 25 dB
Support disc format :
Disc format ISO9660, single session CD
Max albums: 25, max. titles: 255
Bit rate : 128 bits (recommended)

2 - 2
SERVICE MEASUREMENT
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
RF Generator
e.g. PM5326
S/N and distortion meter
e.g. Sound Technology ST1700B
Tuner FW
Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz).
Ri=50
½
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
S/N and distortion meter
e.g. Sound Technology ST1700B
Frame aerial
e.g. 7122 707 89001
Tuner AM (MW,LW)
To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday«s cage.
Use a bandpass filter (or at least a high pass filter with 250kHz) to eliminate hum (50Hz, 100Hz).
RF Generator
e.g. PM5326
Ri=50
½
L
R
LEVEL METER
e.g. Sennheiser UPM550
with FF-filter
S/N and distortion meter
e.g. Sound Technology ST1700B
DUT
CD RECORDER
Use Audio Signal Disc SBC429 4822 397 30184
(replaces test disc 3)
Use Universal Test Cassette Fe SBC420 4822 397 30071
L
R
LEVEL METER
e.g. Sennheiser UPM550
with FF-filter
S/N and distortion meter
e.g. Sound Technology ST1700B
DUT
LF Generator
e.g. PM5110
Ri=50
½

3 - 1
CONNECTION AND CONTROLS

3 - 2
CONNECTION AND CONTROLS















3 - 3
CONNECTION AND CONTROLS
For more information onoperation instruction please visit Philips Audio internet site : http://www.audio.philips.com

4 - 1
DISASSEMBLY DIADRAMS
A1
A3
A2
A2
B1
A. Remove of Back cabinet
A1 : Remove screw SP3x10 - 2 pcs.
A2 : Remove screw SP3x25 - 5 pcs.
A3 : Remove screw SP3x8 - 5 pcs.
B. Remove of CD Tray
B1 : Remove screw SP3x10 (Washer) - 2 pcs.

4 - 2
DISASSEMBLY DIADRAMS
C1
C. Remove of Main PCB Assembly
C1 : Remove screw SP3x10 - 2 pcs.
D1 D2
D. Remove Tuner PBAS and CD PBAS
D1 : Remove screw SP3x8 - 3 pcs.
D2 : Remove screw SP3x8 - 4 pcs.

5 - 1
BLOCK DIADRAMS

5 - 2 5 - 2
SET WIRING DIAGRAM

6 - 16 - 1
CIRCUIT DIAGRAM - RADIO BOARD

6 - 2 6 - 2
IC101
LAYOUT DIAGRAM - RADIO BOARD
COMPONENT SIDE COPPER SIDE

7 - 17 - 1
CIRCUIT DIAGRAM - CASSETTE BOARD

7 - 2
LAYOUT DIAGRAM - CASSETTE BOARD
7 - 2
COMPONENT SIDE COPPER SIDE

8 - 1 8 - 1
CIRCUIT DIAGRAM - CD BOARD

8 - 2 8 - 2
LAYOUT DIAGRAM - CD BOARD
COMPONENT SIDE COPPER SIDE

9 - 1
9 - 1
CIRCUIT DIAGRAM - CONTROL BOARD

9 - 2 9 - 2
CIRCUIT DIAGRAM - MAIN BOARD
