Philips SPD5220 User manual

External hard disk SPD5220
Ekstern harddisk SPD5230
SPD5240
SPD5250
User manual 3
Brugervejledning 9
DK
EN

2

3
4 What’s in the box?
5 How to connect this external hard disk to
your computer?
5 How to safely disconnect?
6 How to use the One-Click Back-Up button?
6 How to install for Mac
7 Warranty, Environment and Safety
8 Specifications
Contents EN
Important note
To startusing the One-Click Back-Up button, first activate the Carry it
Easy software (once only) byclicking on the CarryitEasy.exe file located on your
hard disk. For instructions and more information, see page 6.
When the computer does not recognize the hard disk (some computers
provide insufficient bus power), we advise you to use the Y-cable supplied together
with this product. For instructions and more information, see page 5.

4
What’s in the box?
EN
A: External hard disk
C: Quick Start Guide
B:Y-cable

5
EN
How to connect this external hard disk
on your system?
Plug the wrap around USB cable into an empty
USB port of your computer.
Adrive icon, Philips External Hard Disk, appears in
Windows Explorer. (The computer sometimes needs to
be restarted, before you can use the new hardware).
When the computer does not recognize the hard disk
(some computers provide insufficient bus power), we
advise you to use the Y-cable supplied together with this
product. Connect the Y-cable to the USB cable of the
hard disk and plug in the 2 connectors in the free
USB ports of your computer.The black connector is for
data transfer and power, the gray connector is for
additional power only.
How to safely disconnect?
1Double-click the Safely Remove Hardware icon
in the system trayin the lower right part of the screen.
2In the window that appears, select the name of the device that is to be removed,
then click the Stop button.
3When the Stop a hardware device screen appears, make sure the correct
information is displayed, and then click the OK button.
4When the message Safeto remove hardware appears, remove the drive from
the computer’sUSB port.
1
2

The hard disk is preconfigured for Windows 2000,Windows XP and Windows Vista,
with a NTFS format. For Mac, the hard disk needs to be formatted to FAT32.
Howto install for Mac
6
How to use the One-Click Back-Up button
For windows only, this functionality doesn’t work with Mac computers
The One-Click Back-Up button allows you to instantly synchronize or back-up your
files with the CoSoSys Carry it Easy software.To launch the software, double-click on
the CarryitEasy.exe file on the hard disk in your Windows explorer.
Follow the instructions on your screen to get started.
See the Carry it Easy manual in the folder manuals on your hard disk for more
instructions and more information.
EN

7
EN
Warranty, Environment and Safety
How to find warranty information?
Browse to the Philips warranty folder on the hard disk or look on
www.philips.com/support
You need Adobe Reader software to open these files. If you don’t have Adobe Reader,
you can download it for free on www.adobe.com.
The Philips warranty may not apply if damage is caused by accidents, shock, misuse or
neglect.
‘The making of unauthorized copies of copy-protected material including computer
programs, files, broadcasts and sound recordings, may be an infringement of copyrights
and constitute a criminal offence.This equipment should not be used for such
purposes.’
WEEE mark:“Information to the Consumer”.
Disposal of your old product
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused. Please inform yourself about the local
separate collection system for electrical and electronic products, including those
marked by the crossed-out wheel bin symbol. Please act according to your local rules
and do not dispose of your old products with your normal household waste.
WARNING
Plastic bags can be dangerous
To avoid danger of suffocation, keep this bag awayfrom babies and small children.
Although this product has been designed with utmost care for long-lasting
performance. Philips does advise you to handle electronics with good care:
Avoid contact with water, exposure to extreme forces.
Please make sure you place the device in a well-ventilated environment, to ensure
longest possible lifetime and optimal performance.

8
Specifications
Technical Specifications:
Interface Hi-Speed USB 2.0
Transfer speed 480 Mb/s
Rotational speed 5400 rpm
Cache memory 8 MB
System requirements USB1.1 (USB 2.0 for max. transfer speed)
Windows 2000,Windows XP,Windows Vista
For interactive help and support:
www.philips.com/support
For software updates and frequently asked questions:
www.philips.com/storageupdates
EN

9
9 Hvad er der i æsken?
10 Hvordan tilsluttes denne eksterne harddisk til din
computer?
10 Hvordan frakobles den på en sikker måde?
11 Hvordan bruger man One-Click Back-Up knappen?
11 Hvordan installerer man på en Mac?
12 Garanti, miljø og sikkerhed
13 Specifikationer
Indhold
Vigtigt at bemærke
Når du skal begynde at brugeOne-Click Back-Up knappen, skal du først
aktivere Carry it Easy softwaren (kun én gang) ved at klikke på Carryiteasy.exe-
filen, der ligger på din harddisk. For vejledning og mere information se side 6.
Hvis computeren ikke genkender harddisken (nogle computeres USB-port
leverer ikke spænding nok), anbefaler vi dig at bruge Y-kablet der leveres sammen
med dette produkt. For vejledning og mere information se side 5.
DK

10
Hvad er der i æsken?
A: Ekstern harddisk
C: Hurtigt i gang - guide
B:Y-kabel
DK
