Philips FC8631/01 User manual

Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
ServiceManual
Philips Consumer Lifestyle
Vacuum cleaner
FC8631/01
13/02
PRODUCT INFORMATION
Safety
• This product meets the requirements regarding
interference suppression on radio and TV.
• After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
• Colour : Deep Black
• Power consumption : 1800 W
• Duststorage capacity : 1,7 liter
• Cord length : 6 m
• Action radius : 9 m
• Filter system : HEPA 10 filter
Outlet : Microfilter
• Noise : 80 dB
• Power control : Electronic on appliance
• Coupling : Conical
• Dimensions of the appliance : 33,5 x 54 x 32,5 cm
• Weight : 6 kg
ACCESSORIES
• Nozzle : Multi nozzle
• Tubes : Aluminium 2-pieces telescopic tube
• Accessories : Crevice nozzle and Small nozzle
• Accessory storage : Clip on Tube
• Bend : Curved Bend with airslide
REPAIR INSTRUCTION
• No specific issues
OPTIONAL (accessories)
• FC8058 : Replacement Filter set

FC8631/01
2-9
• To open the appliance, first remove the bucket by
pushing the dislock-button and lifting the bucket straight
upwards, and remove the Exhaust grille and filter.
• To disassemble the Upper housing:
Remove the CW Button and On/off button by using a
screwdriver to push the buttons upwards, in this way the
clicknocks can be loosened. (see picture)
• Remove the 6 screws (B), two are positioned under the
buttons. (see exploded view on page 6-9)
• To remove the Uppperhousing:
Place one hand on the handle and the other hand in the
bottom of the Dustchamber, now simultaneously pull
on the handle and push at the bottom to separate the
upperhousing from the appliance. (see picture)
• Disconnect the connector from the potmeter PCBA
(18).
• To remove the Turning knob (11) & Potmeter
PCBA(18):
Turn the Upper housing upside down and remove the 2
screws (C). The Potmeter PCBA can now be removed
and replaced.
• Turning knob (11) can be pushed to the outside with a
screwdriver.
• The Cordwinder can be removed by pulling it in upwards
direction, the Cordwinder can replaced by placing it back
in the opposite direction.
• To remove the Motor housing:
Remove the 2 screws (D) and unclick the clicknocks
with a screwdriver. Start with the left clicknock. (see
picture)
• To re-assemble the Motor housing:
Lead the wires in the correct way and click the knocks in
place.
Remark: To replace the Motor housing in the Lower housing
it is advisable to use a magnetic screwdriver, otherwise the
appliance should be laid on its side.
DISASSEMBLY- AND RE-ASSEMBLY ADVISE

FC8631/01
3-9
M
K
AC
220 - 240V
50Hz
C1
0.47µF
275V
L
N
Motor
TMP
TR1
R5
27-¼W
R2
10k
1W
R1
10k
1W
C2
220µF
16V
ZD1
4.7V
½W
RW
47k
U1
4
5
6
7
11
10
9
8
C3
22nF
D1
1N4007
R4
10M-¼W
R3
10M-¼W
CIRCUIT DIAGRAM

FC8631/01
4-9
PARTS LIST
Pos Service code Description Remark
1
2
3
4
5
9965 100 62305
9965 100 62295
4322 004 93801
4322 004 93811
9965 100 62285
Lid
Bucket assy
HEPA lter
Sponge
Exhaust grille assy
Buffalo - Mistral
Buffalo - Mistral
6
7
8
9
10
4322 004 93821
9965 100 62299
9965 100 62306
9965 100 62291
9965 100 62292
Micro lter
Unlock button Bucket
Upper housing
CW button
On/Off button
Mistral
Deep Black
11
12
13
14
15
9965 100 62287
9965 100 62293
9965 100 62284
4322 005 34101
9965 100 62297
Turning knob
Spring for Buttons
Handle cover (Bucket assy)
Cordwinder 6 m / 4.8 plug
Safety valve assy
Mistral
16
17
18
19
20
9965 100 62288
9965 100 60941
4322 006 24891
9965 100 60949
9965 100 62294
Lower housing
Casterdish assy
PCBA
Switch
Wheel assy
Deep Black
Mistral
21
22
23
24
25
9965 100 62289
4322 006 99361
9965 100 62296
4322 004 25021
4322 004 25071
Motor front
KC Motor PHB0 1800 W IEC
Motor housing
Hose
Aluminum TT tube Conical 35 mm
230 V 50 / 60 Hz
Buffalo - Mistral
26
27
28
29
4322 004 25131
4322 004 25121
4322 004 25111
4322 004 25101
Tube clip
Small nozzle Conical 35 mm
Crevice nozzle Conical 35 mm
All oor nozzle # 34 Conical 35 mm
Deep Black 80231
Deep Black 80231
Deep Black 80231
Deep Black 80231

FC8631/01
5-9
A
2x
4
3
1
13
5
6
2
EXPLODED VIEW

FC8631/01
6-9
B
B
BB
B
C
C
B
9
10
11
18
12
2x
7
8
EXPLODED VIEW

FC8631/01
7-9
16
20
19
D
EE
D
14
17
15
18
EXPLODED VIEW

FC8631/01
8-9
21
22
23
EXPLODED VIEW

FC8631/01
9-9
24
25
27
2826
29
EXPLODED VIEW
