ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Vacuum cleaner
FC8917
10/03
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Type : FC8917 Parquet
- Colour : Star White
- Power consumption : 1250 W (IEC) 230 V
- Maximum Air displacement : 37 L/sec
- Vacuum : 260 mbar
- Noise level : 78 dB(A)
- Dust storage capacity : 2,5 L
- Cord length : 7 m
- Hose length : 1,75 m
- Motor : Electronic Power Control
- Filter system : 5 Layer Ultra Filtration
System
: Classic S-Bag long
performance
: Triple layer permanent
motor protection filter
: Ultra clean air washable
HEPA12 exhaust filter
- Net weight : 5,5 kg
- Dimensions of the cleaner : 430 x 275 x 240 mm
- Dimensions of the packaging : 590 x 395 x 335 mm
ACCESSORIES
- Nozzle : Tri-Active nozzle
- Tubes : Metal lacquered telescopic tube with
extension piece
- Accessories : Hard floor nozzle, Crevice nozzle,
Small nozzle and Brush
- Accessory storage : Accessory clip on tube
- Coupling : All button coupling
OPTIONAL (accessories)
- FC8021 : S-bag Classic
- FC8022 : S-bag Clinic
- FC8023 : S-bag Anti-Odor
- FC8044/02 : Ultra clean air washable HEPA12
exhaust filter

FC8917
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- To open the appliance, first remove the outlet grill and
exhaust filter.
- Remove the Handle Cover by pushing the retaining pins
inwards (see picture). Take out the Roller Top.
11
2
- Unscrew screws Cof the Handle Bottom (Two Torx head
screws T15).
- Remove the Buttons and Handle Bottom, mind the Roller
Bottom attached to the PCB.
- Remove the Handle inlay by unhooking the back side of the
inlay, and then simultaneously opening the Dust Cover and
pulling the Handle Inlay up- and backwards (see picture).
3
21
- Remove the Dust Cover by unhooking the hinges.
- Unscrew screws Dand remove the left and right Back
Bumper. Unscrew and unclick the Back Panel.
- Unscrew the 9 screws Efrom the Dust Chamber Motor
Pod.
- You can now access all internal components.
- When the repair is finished, check whether all functions of
the appliance work properly.
- To disassemble the cord winder, use TORX screwdriver
no. T10, which is one of a set consisting of T20; T15; T10;
T9; T8; T7 and T6 (code number 4822 395 50145).
- Reassembly in reverse order of disassembly, make sure you
route all electrical cables correctly.
REPAIR INSTRUCTION
- The spare parts have been standardized as much as possible.
- Cotton dust bags are used in countries where paper dust
bags are not available.
- Depending on the original cord, the spare cord must be
shortened to the length of the original cord.
- The cord winder spring must be tensioned to the maximum
level and then be rewound approx. 1.5 turn.
- Item 3, safety valve, opens to cool the motor if the air
displacement is too low or when the airflow is blocked.
- When the vacuum cleaner is used to clean fine dust the
pores of the dust bag may become clogged, causing the
passage of air through the dust bag to become obstructed.
As a result the dust bag-full indicator will indicate the dust
bag needs to be replaced, even though the dust bag is not
full at all.
In this case, replace the dust bag anyhow.
ELECTRICAL DIAGRAM
Blue
Brown
Black
White
M
Cord
Winder
Motor
Power
Module
2-7

FC8917
PARTS LIST
3-7
Pos Service code Description
1*
2
3
4
5
6*
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26*
27
28
29
30
31
32
33
34
35
36*
37
38
39
40
41
42
43
44*
45*
46*
47
48
49*
50
51
52
53
54
4222 459 46931
4222 459 46911
4322 005 10321
4222 459 46941
4322 000 39441
4222 459 47481
4222 459 46971
4222 459 47001
4222 459 47031
4222 459 47101
4222 459 47061
4322 000 09970
4222 459 47091
4322 001 74531
4222 459 47201
4222 459 47271
4222 459 47131
4322 000 39431
4222 459 47231
4341 003 02390
4322 001 74521
4222 459 47301
4322 006 24161
4222 459 47261
4222 459 47331
4322 000 39090
4322 000 39461
4222 459 47141
4322 001 74511
4322 009 09960
4322 000 39451
4222 459 45608
4322 001 74541
4222 459 47161
4222 459 47431
4322 009 00371
4222 459 47391
4222 459 47151
4222 459 47171
4322 000 39421
4322 000 39411
4222 459 47361
4222 459 47421
4322 006 07390
4322 006 07400
4322 006 02170
4222 459 47461
4322 004 23630
4341 003 02470
4322 003 41441
4322 004 22560
4341 004 20510
4322 004 23661
4322 004 23770
Dust Bag Holder Grey
Dust Cover assy Star White Parquet
DBFI assy
Dust Bag Detector Kit
Triple Inlet Filter
Inlet Grille*
Handle Cover Star White
Roller Top Green
Handle Bottom Star White
Roller Base
Buttons Green
Button Spring
Handle Inlay Star White
Dust Chamber Seal
Back Bumper Left Green
CW Lever
Dust Chamber Motor Pod White
Silencer 3
Back Bumper Right Green
Switch Lever
Hose PCB
Cord Outlet Bottom White
PCB assy
Outlet Grill Star White
Back Panel Star White
HEPA12 Exhaust Filter
Exhaust Seal
Motor Housing Top
Buffer Ring Front
Motor
Silencer 4
Motor Bracket
Buffer Back
Motor Housing Bottom
Cast Dish assy
Cord winder (No Cord)
Side Wall Star White
Inlet Seal
S-class Sealing
Silencer 2
Silencer 1
Lower Housing Green
Rear Wheel assy Green
Cord (EU)
Cord (Swiss)
Cord (UK)
Hose assy Green Button
Telescopic Tube Button
Accessory Clip
Crevice nozzle Button
Small nozzle Button
Brush nozzle Button
Tri-Active nozzle Button
Hard Floor nozzle Button
* Standardized part

FC8917
EXPLODED VIEW
5
3
6
1
2
4
7
8
9
10
11
12
13
14
AA
B
C
C
4-7

FC8917
EXPLODED VIEW
15
16
17
18
26
25
27
23
24
19
20
21
22
D
D
X
Y
Z
W
F
E
9x
5-7

FC8917
EXPLODED VIEW
28
30
31
32
33
34
39
40
38
37
42
41
36
33
G
3x
H
X
Y
Z
W
43
35
29
6-7

FC8917
EXPLODED VIEW
Europe Ø 4.8mm 44 46U.K. / H.K.
50
52
48
49
51
47
Swiss 45
54
53
