Router-TC ROUTER 2002T-4G-2702530
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Industrial LTE 4G router, European version, fallback to 3G UMTS/HSPA and 2G GPRS/EDGE, 2Ethernet
interfaces, firewall, NAT, 2x SMA-F antenna socket, SMS and e-mail transmission, 2digital inputs, 1digital output
Why buy this product
Industrial 4G mobile router (LTE)
Fallback to 3G (UMTS/HSPA) and 2G (GPRS/EDGE)
Mobile high-speed Internet connection up to 150Mbps
Networking of VPN-capable end devices via the mobile network
Ethernet SMS gateway for easy alerting
Two switching inputs and one switching output
Stateful inspection firewall for dynamic filtering
NAT table and port forwarding for direct remote access to an end device
Configuration via web-based management or microSD card
Two local Ethernet connections
Switchable energy-saving mode
Integrated logbook
Connection monitoring
Extended temperature range, -40 °C ... +70 °C
Key Commercial Data
Packing unit 1
GTIN
GTIN 4055626212814
Custom tariff number 85176200

https://www.phoenixcontact.com/us/products/2702530
04/13/2017Page2/7
Router-TC ROUTER 2002T-4G-2702530
Technical data
Dimensions
Width 45 mm
Height 130 mm
Depth 126 mm
Ambient conditions
Ambient temperature (operation) -40 °C ... 70 °C (Maximum transmission power 5dBm)
-40 °C ... 60 °C (Maximum transmission power 23dBm)
Ambient temperature (storage/transport) -40 °C ... 85 °C
Permissible humidity (operation) 10 % ... 95 % (non-condensing)
Permissible humidity (storage/transport) 10 % ... 95 % (non-condensing)
Altitude 5000 m (For restrictions see manufacturer's declaration)
Degree of protection IP20
Noise immunity EN 61000-6-2
General
Electrical isolation VCC // LTE // Ethernet // PE
Electromagnetic compatibility Conformance with R&TTE directive 1999/5/EC
Net weight 347 g
Color gray
Conformance CE-compliant
Power supply
Supply voltage range 10 V DC ... 30 V DC (via pluggable COMBICON screw terminal block)
Max. current consumption 1.7 A
Typical current consumption < 200 mA (24 V DC)
65 mA (With activated energy-saving mode)
Serial interface
Interface 1 Ethernet interface, 10/100Base-T(X) in acc. with IEEE802.3u
Interface Ethernet
No. of channels 2
Connection method RJ45 socket, shielded
Transmission length 100 m (shielded twisted pair)
Protocols supported TCP/IP, UDP/IP, FTP, HTTP
Auxiliary protocols ARP, DHCP, PING (ICMP), SNMP V1, SMTP
Serial transmission speed 10/100 Mbps, auto negotiation
Radio interface
Interface description GSM / GPRS / EDGE / UMTS / HSPA / LTE (FDD)

https://www.phoenixcontact.com/us/products/2702530
04/13/2017Page3/7
Router-TC ROUTER 2002T-4G-2702530
Technical data
Radio interface
Frequency 850 MHz (2 W (EGSM))
900 MHz (2 W (EGSM))
1800 MHz (1 W (EGSM))
1900 MHz (1 W (EGSM))
850 MHz (0.25W (UMTS/HSPA))
900 MHz (0.25W (UMTS/HSPA))
1900 MHz (0.25W (UMTS/HSPA))
2100 MHz (0.25W (UMTS/HSPA))
800 MHz (LTE (FDD))
850 MHz (LTE (FDD))
900 MHz (LTE (FDD))
1800 MHz (LTE (FDD))
1900 MHz (LTE (FDD))
2100 MHz (LTE (FDD))
2600 MHz (LTE (FDD))
Data rate ≤ 150 Mbps (LTE (DL))
≤ 50 Mbps (LTE (UL))
Antenna 50 Ω impedance SMA antenna socket
SIM interface 1 1.8 volt, 3 volt
GPRS Class 12, Class B
CS1 ... CS4
EDGE Multislot Class 10
UMTS HSPA 3GPP R9
Function
Management Web-based management, SNMP
Digital outputs
Output name Digital output
Number of outputs 1
Voltage output signal 10 V DC ... 30 V DC (depending on the operating voltage)
Current output signal ≤ 50 mA (Not short-circuit proof)
Digital inputs
Description of the input Digital input
Number of inputs 2
Switching level "1" signal 10 V DC ... 30 V DC
Voltage input signal 10 V DC ... 30 V DC

https://www.phoenixcontact.com/us/products/2702530
04/13/2017Page4/7
Router-TC ROUTER 2002T-4G-2702530
Technical data
Standards and Regulations
Electromagnetic compatibility Conformance with R&TTE directive 1999/5/EC
Type of test Vibration resistance in acc. with EN60068-2-6/IEC60068-2-6
Test result 5g, 10...150 Hz, 2.5 h, in XYZ direction
Type of test Shock in acc. with EN60068-2-27/IEC60068-2-27
Test result 15g
Noise immunity EN 61000-6-2
Standards/regulations EN 61000-4-2
Contact discharge ± 6 kV (Test Level 3)
Standards/regulations EN 61000-4-3
Frequency range 80 MHz ... 3 GHz (Test Level 3)
Standards/regulations EN 61000-4-4
Comments Criterion B
Standards/regulations EN 61000-4-5
Signal ± 1 kV (Data line, asymmetrical)
Standards/regulations EN61000-4-6
Frequency range 0.15 MHz ... 80 MHz
Conformance CE-compliant
Environmental Product Compliance
China RoHS Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”, Category
“Manufacturer's declaration”
Drawings
Connection diagram
24V 0V I1 I2 O1
–
+
Switching inputs
Dimensional drawing
LAN 1
RESET
Micro
SD
US
ERR
CON
Micro SD
LAN 2
ANT 1
ANT 2
SIM
TC ROUTER
130
45 127,5

https://www.phoenixcontact.com/us/products/2702530
04/13/2017Page5/7
Router-TC ROUTER 2002T-4G-2702530
Schematic diagram
US
ERR
CON
Micro SD
Micro
RESET
SD
LAN 1 LAN 2
ANT 1
ANT 2
SIM
TC ROUTER
24V 0V I1 I2 O1
1
2
3
4
5
7
8
9
10
6
Front view
Schematic diagram
Micro
SD
LAN 1 LAN 2
RESET
US
ERR
CON
ANT 1
ANT 2
SIM
TC ROUTER
24V 0V I1 I2 O1
ANT 2
Connect the antenna
Schematic diagram
ANT 2
ANT 1
SIM
D
A
B
Remove SIM card holder
Schematic diagram
ANT 2
ANT 1
SIM
D
C
Insert the SIM card

https://www.phoenixcontact.com/us/products/2702530
04/13/2017Page6/7
Router-TC ROUTER 2002T-4G-2702530
Schematic diagram
Micro
SD
LAN 1 LAN 2
RESET
US
ERR
CON
ANT 1
ANT 2
SIM
TC ROUTER
24V 0V I1 I2 O1
24V 0V I1 I2 O1
Device connections
Schematic diagram
B
A
Assembly
Classifications
eCl@ss
eCl@ss 5.1 27230207
ETIM
ETIM 6.0 EC000310
Accessories
Accessories
Antenna
Antenna-TC ANT MOBILE WALL 5M-2702273
Multiband mobile phone antenna with mounting bracket for outdoor installation. 5 m antenna cable with SMA round plug


Power supply

https://www.phoenixcontact.com/us/products/2702530
04/13/2017Page7/7
Router-TC ROUTER 2002T-4G-2702530
Accessories
Power supply unit-TRIO-PS-2G/1AC/24DC/3/C2LPS-2903147
Primary-switched TRIO POWER power supply with push-in connection for DIN rail mounting, input: 1-phase, output:
24VDC/3A C2LPS


