User Manual for CoolSNAPcf ™and CoolSNAPES™Systems
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

© Copyright 2003 Roper Scientific, Inc.
3440 East Britannia Drive
Tucson, Arizona 85706
Tel: [phone].889.9933
Fax: [phone]
All rights reserved. No part of this publication may be reproduced by any means without the written
permission of Roper Scientific, Inc.
Printed in the United States of America.
Acrobat is a registered trademark and Reader is a trademark of Adobe Systems Incorporated, which may
be registered in certain jurisdictions.
CoolSNAPcf, CoolSNAPES, Roper Scientific, and RS Image are trademarks and PVCAM is a registered
trademark of Roper Scientific, Inc.
Pentium is a registered trademark of Intel Corporation.
Windows and Windows NT are registered trademarks of Microsoft Corporation.
Other brand and product names are the trademarks or registered trademarks of their respective owners and
manufacturers.
The information in this publication is believed to be accurate as of the publication release date. However,
Roper Scientific does not assume any responsibility for any consequences including any damages
resulting from the use thereof. The information contained herein is subject to change without notice.
Revision of this publication may be issued to incorporate such change.
57-061-001 Rev F0
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

LIMITED WARRANTY — Roper Scientific Analytical Instrumentation
Roper Scientific, Inc. (“Roper Scientific,” us,” “we,” “our”) makes the following limited warranties. These
limited warranties extend to the original purchaser (“You”, “you”) only and no other purchaser or transferee.
We have complete control over all warranties and may alter or terminate any or all warranties at any time we
deem necessary.
Basic Limited One (1) Year Warranty
Roper Scientific warrants this product against substantial defects in materials and / or workmanship for a period
of up to one (1) year after shipment. During this period, Roper Scientific will repair the product or, at its sole
option, repair or replace any defective part without charge to you. You must deliver the entire product to the
Roper Scientific factory or, at our option, to a factory-authorized service center. You are responsible for the
shipping costs to return the product. International customers should contact their local Roper Scientific
authorized representative/distributor for repair information and assistance, or visit our technical support page at
www.roperscientific.com.
Limited One (1) Year Warranty on Refurbished or Discontinued Products
Roper Scientific warrants, with the exception of the CCD imaging device (which carries NO WARRANTIES
EXPRESS OR IMPLIED), this product against defects in materials or workmanship for a period of up to one (1)
year after shipment. During this period, Roper Scientific will repair or replace, at its sole option, any defective
parts, without charge to you. You must deliver the entire product to the Roper Scientific factory or, at our option,
a factory-authorized service center. You are responsible for the shipping costs to return the product to Roper
Scientific. International customers should contact their local Roper Scientific representative/distributor for
repair information and assistance or visit our technical support page at www.roperscientific.com.
Shutter Limited One Year Warranty
Roper Scientific warrants for a period of up to one (1) year after shipment the standard, factory-installed camera
shutter of all our products that incorporate an integrated shutter. This limited warranty applies to the standard
shutter installed in the camera system at the time of manufacture. Non-standard shutters, special product request
(SPR) shutters, and third-party shutter drive equipment carry NO WARRANTIES EXPRESSED OR IMPLIED.
Roper Scientific will supply, at no cost to the customer, up to one (1) replacement shutter during the warranty
period. Roper Scientific will, at Roper Scientific's option, either ship a ready-to-install shutter to the customer
site for installation by the customer according to the instructions in the product User Manual or arrange with the
customer to return the camera system (or portion of the camera system) to the factory (or factory-authorized
service center) for shutter replacement by us or a Roper Scientific-authorized agent. Responsibility for shipping
charges is as described above under our Limited One (1) Year Warranty.
VersArray (XP) Vacuum Chamber Limited Lifetime Warranty
Roper Scientific warrants that the cooling performance of the system will meet our specifications over the
lifetime of the VersArray (XP) detector or Roper Scientific will, at its sole option, repair or replace any vacuum
chamber components necessary to restore the cooling performance back to the original specifications at no cost
to the original purchaser. Any failure to “cool to spec” beyond our Basic (1) year limited warranty from date of
shipment, due to a non-vacuum-related component failure (e.g., any components that are electrical/electronic) is
NOT covered and carries NO WARRANTIES EXPRESSED OR IMPLIED. Responsibility for shipping charges is
as described above under our Basic Limited One (1) Year Warranty.
Sealed Chamber Integrity Limited 24 Month Warranty
Roper Scientific warrants the sealed chamber integrity of all our products for a period of twenty-four (24)
months after shipment. If, at anytime within twenty-four (24) months from the date of delivery, the detector
should experience a sealed chamber failure, all parts and labor needed to restore the chamber seal will be
covered by us. Open chamber products carry NO WARRANTY TO THE CCD IMAGING DEVICE, EXPRESSED OR
IMPLIED. Responsibility for shipping charges is as described above under our Basic Limited One (1) Year
Warranty.
Vacuum Integrity Limited 24 Month Warranty
Roper Scientific warrants the vacuum integrity of all our products for a period of up to twenty-four (24) months
from the date of shipment. We warrant that the detector head will maintain the factory-set operating temperature
without the requirement for customer pumping. Should the detector experience a Vacuum Integrity failure at
anytime within twenty-four (24) months from the date of delivery all parts and labor needed to restore the
i
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

vacuum integrity will be covered by us. Responsibility for shipping charges is as described above under our
Basic Limited One (1) Year Warranty.
Image Intensifier Detector Limited One Year Warranty
All image intensifier products are inherently susceptible to Phosphor and/or Photocathode burn (physical
damage) when exposed to high intensity light. Roper Scientific warrants, with the exception of image intensifier
products that are found to have Phosphor and/or Photocathode burn damage (which carry NO WARRANTIES
EXPRESSED OR IMPLIED), all image intensifier products for a period of one (1) year after shipment. See
additional Limited One (1) year Warranty terms and conditions above, which apply to this warranty.
Responsibility for shipping charges is as described above under our Basic Limited One (1) Year Warranty.
X-Ray Detector Limited One Year Warranty
Roper Scientific warrants, with the exception of CCD imaging device and fiber optic assembly damage due to X-
rays (which carry NO WARRANTIES EXPRESSED OR IMPLIED), all X-ray products for one (1) year after
shipment. See additional Basic Limited One (1) year Warranty terms and conditions above, which apply to this
warranty. Responsibility for shipping charges is as described above under our Basic Limited One (1) Year
Warranty.
Software Limited Warranty
Roper Scientific warrants all of our manufactured software discs to be free from substantial defects in materials
and / or workmanship under normal use for a period of one (1) year from shipment. Roper Scientific does not
warrant that the function of the software will meet your requirements or that operation will be uninterrupted or
error free. You assume responsibility for selecting the software to achieve your intended results and for the use
and results obtained from the software. In addition, during the one (1) year limited warranty. The original
purchaser is entitled to receive free version upgrades. Version upgrades supplied free of charge will be in the
form of a download from the Internet. Those customers who do not have access to the Internet may obtain the
version upgrades on a CD-ROM from our factory for an incidental shipping and handling charge. See Item 12 in
the following section of this warranty ("Your Responsibility") for more information.
Owner's Manual and Troubleshooting
You should read the owner’s manual thoroughly before operating this product. In the unlikely event that you
should encounter difficulty operating this product, the owner’s manual should be consulted before contacting
the Roper Scientific technical support staff or authorized service representative for assistance. If you have
consulted the owner's manual and the problem still persists, please contact the Roper Scientific technical
support staff or our authorized service representative. See Item 12 in the following section of this warranty ("Your
Responsibility") for more information.
Your Responsibility
The above Limited Warranties are subject to the following terms and conditions:
1. You must retain your bill of sale (invoice) and present it upon request for service and repairs or provide
other proof of purchase satisfactory to Roper Scientific.
2. You must notify the Roper Scientific factory service center within (30) days after you have taken
delivery of a product or part that you believe to be defective. With the exception of customers who claim
a “technical issue” with the operation of the product or part, all invoices must be paid in full in
accordance with the terms of sale. Failure to pay invoices when due may result in the interruption
and/or cancellation of your one (1) year limited warranty and/or any other warranty, expressed or
implied.
3. All warranty service must be made by the Roper Scientific factory or, at our option, an authorized service
center.
4. Before products or parts can be returned for service you must contact the Roper Scientific factory and
receive a return authorization number (RMA). Products or parts returned for service without a return
authorization evidenced by an RMA will be sent back freight collect.
5. These warranties are effective only if purchased from the Roper Scientific factory or one of our
authorized manufacturer's representatives or distributors.
6. Unless specified in the original purchase agreement, Roper Scientific is not responsible for installation,
setup, or disassembly at the customer’s location.
ii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7. Warranties extend only to defects in materials or workmanship as limited above and do not extend to
any product or part which has:
• been lost or discarded by you;
• been damaged as a result of misuse, improper installation, faulty or inadequate maintenance or
failure to follow instructions furnished by us;
• had serial numbers removed, altered, defaced, or rendered illegible;
• been subjected to improper or unauthorized repair; or
• been damaged due to fire, flood, radiation, or other “acts of God” or other contingencies beyond the
control of Roper Scientific.
8. After the warranty period has expired, you may contact the Roper Scientific factory or a Roper
Scientific-authorized representative for repair information and/or extended warranty plans.
9. Physically damaged units or units that have been modified are not acceptable for repair in or out of
warranty and will be returned as received.
10. All warranties implied by state law or non-U.S. laws, including the implied warranties of
merchantability and fitness for a particular purpose, are expressly limited to the duration of the limited
warranties set forth above. With the exception of any warranties implied by state law or non-U.S. laws,
as hereby limited, the forgoing warranty is exclusive and in lieu of all other warranties, guarantees,
agreements, and similar obligations of manufacturer or seller with respect to the repair or replacement
of any parts. In no event shall Roper Scientific’s liability exceed the cost of the repair or replacement of
the defective product or part.
11. This limited warranty gives you specific legal rights and you may also have other rights that may vary
from state to state and from country to country. Some states and countries do not allow limitations on
how long an implied warranty lasts, when an action may be brought, or the exclusion or limitation of
incidental or consequential damages, so the above provisions may not apply to you.
12. When contacting us for technical support or service assistance, please refer to the Roper Scientific
factory of purchase, contact your authorized Roper Scientific representative or reseller, or visit our
technical support page at www.roperscientific.com.
iii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Optional CoolSNAP Camera System Service Contract
The optional CoolSNAP Camera System Service Contract provides extended coverage for the CoolSNAP
camera system. All terms and conditions listed in the CoolSNAP Camera System Warranty, including those
pertaining to shipping costs and appropriate system use, apply to the CoolSNAP Camera System Service
Contract.
The Service Contract also guarantees that Roper Scientific shall ship a complete replacement CoolSNAP
camera system within forty-eight (48) hours of receiving notification of a CoolSNAP camera system defect.
All components of the defective CoolSNAP camera system must be returned to Roper Scientific. Shipment
of these components should not be made without prior authorization by Roper Scientific.
When purchased within two (2) months of the date listed on the packing slip shipped with the original
equipment, the Service Contract is valid for a period of twenty-seven (27) months from the packing slip
date.
This period comprises the initial CoolSNAP Camera System Warranty period of twelve (12) months, the
CoolSNAP Camera System Service Contract period of twelve (12) months, and an additional three (3)
months of free coverage.
When purchased prior to the lapse of the CoolSNAP Camera System Warranty or an active CoolSNAP
Camera System Service Contract, the CoolSNAP Camera System Service Contract is valid for twelve (12)
months beyond the lapse date of the Camera System Warranty or current Service Contract.
The CoolSNAP Camera System Service Contract can be renewed repeatedly. If the renewal occurs outside
of a period covered by Warranty or Service Contract, Roper Scientific may, at its sole discretion, require an
inspection of the camera system as a condition of consent to place it under Service Contract.
U. S. Government Restricted Rights
The software and documentation are provided with Restricted Rights. Use, duplication, or disclosure by
the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical
Data and Computer Software clause at DFARS 252.227-7013 or subparagraphs (c)(1) and (2) of the
Commercial Computer Software-Restricted Rights at 48 CFR 52.227-19, as applicable.
Contractor/manufacturer is Roper Scientific, 3440 East Britannia Drive, Tucson, AZ 85706.
This license is effective until terminated. It will terminate upon the conditions set forth above or if you fail
to comply with any term hereof. Upon termination, you agree that the software and accompanying
materials, and all copies thereof, will be destroyed. This agreement is governed by the laws of the State of
Arizona. You acknowledge that you have read this agreement, you understand it, you agree to be bound by
its terms, and that this is the complete and exclusive statement of the agreement between you and Roper
Scientific regarding the software.
iv
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Declaration of Conformity
Roper Scientific, Inc. declares that the equipment described in this document is a CLASS A
DEVICE in conformance with the requirements of the European Council Directives, listed below:
89/336/EEC EMC Directive & Amendments
93/68/EEC EMC Directive & Amendments
73/23/EEC Product Safety with Amendments
on the application of the laws of Member States relating to Electromagnetic Compatibility
and Product Safety.
This declaration is based upon compliance of the product to the following standards:
EN 55022 RF Emissions Control
EN 61000-3 Series Harmonics & Flicker
EN 55024 Immunity from Electromagnetic Disturbances
EN 60950 Product Safety
Product Description: Video Camera
Model: CoolSNAPcf / CoolSNAPES
Test Reports: EMC Rpt 2K01-0122-003B- EN55022
EMC Rpt 2K00-0122-003C- EN55024
EMC Rpt 2K01-0122-003D-EN61000-3 Series
SAFETY Rpt 2K01-0122-003E-EN60950
Roper Scientific, Inc.
3440 East Britannica Drive
Tucson, AZ, 85706
USA
Manufacturer: ROPER SCIENTIFIC
v
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

This page intentionally left blank.
vi
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Table of Contents
Chapter 1. Introduction
Description................................................................................................................................1
System Components................................................................................................................1
About This Manual..................................................................................................................2
Precautions ................................................................................................................................2
Environmental Requirements................................................................................................2
Storage Requirements.............................................................................................................3
Microscopes, Lenses, and Tripods ........................................................................................3
Repairs .......................................................................................................................................3
Cleaning.....................................................................................................................................3
Roper Scientific Customer Service .......................................................................................4
Chapter 2. System Installation
Introduction ..............................................................................................................................5
Software Compatibility Requirements................................................................................5
Host Computer Requirements...............................................................................................5
Multiple Cameras ....................................................................................................................6
Software Installation...............................................................................................................6
Installing the PCI Card ...........................................................................................................6
Connecting Your CoolSNAP Camera...................................................................................7
Chapter 3. Operating Features
Common Features ....................................................................................................................9
Readout Speed...................................................................................................................9
Binning ...............................................................................................................................9
RS170/PAL Operation ......................................................................................................9
CoolSNAPES Features ..............................................................................................................9
Dual Mode Operation......................................................................................................9
Antiblooming ..................................................................................................................10
Application Examples ....................................................................................................11
Chapter 4. Troubleshooting
System Does Not Boot Normally ........................................................................................13
New Hardware Found Dialog Box Does Not Appear (Windows 95/98/2000/ME/XP).....13
Green LED Does Not Illuminate (Camera Has No Power) ............................................13
Images Not Displayed Properly ..........................................................................................14
Bright Spots in Image / Increased Background Noise ........................................................14
Camera Running Too Warm ................................................................................................14
PVCAM Error Message Appears.........................................................................................14
Lengthy Pauses During Imaging ........................................................................................14
Chapter 5. Basic Specifications
Dimensions .............................................................................................................................15
CCD Specifications and Orientations................................................................................16
Additional Measurements....................................................................................................16
Detector....................................................................................................................................17
Index ....................................................................................................... 19
vii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

This page intentionally left blank.
viii
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 1. Introduction
Description CoolSNAPcf and CoolSNAPES, from Roper Scientific, are ideal cameras for
digital microscopy and many other biological applications. The simple, compact
CoolSNAPcf incorporate a high-quality CCD (charge-coupled device), a 12-bit
scientific digitizer, and low-noise electronics to produce high-quality 12-bit
monochrome or 36-bit digital color images at greater than 1k x 1k resolution. The
CoolSNAPES offers higher sensitivity (especially in the red region) and lower
read noise to produce high quality 12-bit monochrome images.
Note: Unless otherwise noted, the CoolSNAPcf and the CoolSNAPES cameras are referred
to by the name "CoolSNAP".
System
Components
Components for the CoolSNAP camera system are listed as follows:
• Camera
• Interface hardware (PCI card installation covered in the Installation
Guide insert packaged with the CD-ROM)
• Data cable (connects camera and PCI card)
• Software (PVCAMand RS Image™) and
• Manual (PDF on the CD-ROM).
CoolSNAP Camera with Test Lens
CoolSNAP Cable
CoolSNAP PCI Card
1
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

About This
Manual
The CoolSNAP User Manual is divided into four chapters. It is suggested that
you read the entire manual before operating the camera in order to ensure
proper use. The chapters that follow this introduction are:
• System Installation — Instructions for installing the camera system’s
hardware and software.
• Troubleshooting — Answers to camera system problems.
• Basic Specifications — Specifications for CoolSNAP components.
Precautions The CCD and other system electronics are extremely sensitive to electrostatic
discharge (ESD). To avoid permanently damaging the system, please observe
the following precautions:
• This is a Class A product. In a domestic environment, this product
may cause radio interference, in which case, the user may be required
to take adequate measures.
• If you are using high-voltage equipment (such as an arc lamp) with
your camera system, be sure to turn the camera power on last and
power the camera off first.
• Never connect or disconnect any cable while the camera system is
powered on.
• Although you should switch off the camera’s power before
disconnecting the CoolSNAP cable from the DATA connector or the
PCI card, you do not need to power off your computer to detach the
cable.
• Use caution when triggering high-current switching devices (such as
an arc lamp) near your system. The CCD can be permanently damaged
by transient voltage spikes. If electrically noisy devices are present, an
isolated, conditioned power line or dedicated isolation transformer is
highly recommended.
• Always leave 1/2 inch of space around the camera’s external cooling
fins for air flow.
• Never open the camera. There are no user-serviceable parts inside the
CoolSNAP camera. Opening the camera voids the warranty.
• Use only a CoolSNAP cable and a CoolSNAP PCI card with your
CoolSNAP camera. Using a different cable or PCI card may result in
permanent damage to your system.
• Do not use a screw longer than 1/4 inch (.63 cm) in the camera’s tripod
mounting hole.
• Do not use a C-mount lens having optics that extend farther than .47
inches (11.9 mm) behind the flange of the lens.
Environmental
Requirements
The CoolSNAP camera system should be operated in a clean, non-condensing
environment.
The camera system’s ambient operating temperature is 15°C to 30°C.
2 CoolSNAPcf /CoolSNAPES
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Storage
Requirements
Store the CoolSNAP camera system in its original containers. To protect the
system from excessive heat, cold, and moisture, store at an ambient
temperature between 0°C and 70°C with a relative humidity of 0%-80%
noncondensing.
Microscopes,
Lenses, and
Tripods
The camera has a standard threaded video mount and can be mounted to any
microscope that accepts a standard C-mount adapter. The camera also allows
you to install any lens that is compatible with a standard threaded video
mount as long as its optics do not extend farther than .47 inches (11.9 mm)
behind the flange of the lens. The CoolSNAP camera can be mounted to a
tripod using the tripod-mounting hole located on the bottom of the camera.
See Additional Measurements on page 16 for more information.
Note: In microscopy applications, a 0.5x C-mount camera coupler is recommended for an
expanded field of view.
Repairs The CoolSNAP camera system contains no user-serviceable parts. Repairs
must be done by Roper Scientific. Should your camera system need repair,
contact Roper Scientific Customer Service. Please save the original packing
materials so you can safely ship the camera system to another location or
return it for repairs if necessary.
Note: Do not open the camera. Opening the CoolSNAP camera voids the warranty.
Cleaning Clean exterior surfaces of the camera with a dry, lint-free cloth. To remove
stains, contact Roper Scientific Customer Service.
To clean the camera’s imaging window, use only a filtered compressed-air
source. Do not touch the window.
Chapter 1. Introduction 3
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Roper Scientific
Customer Service
If you have any questions about your camera system, contact Roper Scientific
Customer Service. When you call, please have your Roper Scientific job
number or equipment serial numbers available.
• Tel: [phone] and 520.889.9933 between 8:00 am and 5:00 pm MST
• Fax: [phone]
• E-mail: [e-mail]
• Mail: Roper Scientific
3440 East Britannia Drive
Tucson, Arizona 85706
In Europe, you can reach Customer Service at:
BENELUX
• Phone: [phone]
• Fax: [phone]
• E-mail: [email protected]
• Mail: Roper Scientific, BV
Ir. D.S. Tuijnmanweg 10
4131 PN VIANEN, Netherlands
FRANCE
• Phone: [phone]
• Fax: [phone]
• E-mail: [email protected]
• Mail: Roper Scientific, SARL
Z.I. Petite Montagne Sud
4, rue de l'Oisans - C.E. 1702
91017 Evry Cedex, France
GERMANY
• Phone: [phone]
• Fax: [phone]
• E-mail: [email protected]
• Mail: Roper Scientific, GmbH
Rosenheimer Landstr. 87
D-85521 Ottobrunn, Germany
In Japan, you can reach Customer Service at:
• Phone: [phone]
• Fax: [phone]
• E-mail: [email protected]
• Mail: Nipon Roper, K.K.
D-10E 1-3 Nakase,
Mihama-ku, Chiba-shi
Japan 261-8501
General product information and answers to some customer service questions can
be found on our website:
http://www.roperscientific.com
4 CoolSNAPcf /CoolSNAPES
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Chapter 2. System Installation
Carefully review the Precautions section on page 2 before performing any of the
procedures outlined here. Again, use only a CoolSNAP cable and a CoolSNAP PCI card
with your CoolSNAP camera. Using a different cable or PCI card may result in
permanent damage to your system.
Introduction Your CoolSNAPcf or CoolSNAPES camera system has the following hardware
components:
• PCI card
• Camera and Data cable
CoolSNAP system components are linked by the data cable and controlled by
your host computer system. All of these hardware components should be
included with your shipment. Refer to the information and figures in System
Components on page 1.
The CCD you selected is installed in your camera.
Keep all the original packing materials so you can safely ship the CoolSNAP
system to another location or return it for service if necessary.
If you have any difficulty with any step of the instructions, call Roper
Scientific Customer Service.
Software
Compatibility
Requirements
The CoolSNAP package includes the RS Image capture software program
designed for use with your CoolSNAP camera.
All other imaging software must also be PVCAM-compatible. For full access
to imaging software functions, PVCAM must be version 2.6.5 or higher.
Host Computer
Requirements
The host computer for your CoolSNAP camera must have the following:
• Windows®98SE, Windows®ME, Windows®2000, or Windows®XP
operating system
• 500 MHz Pentium®III (or greater)
• 256 MB RAM (or greater)
• CD-ROM drive
• At least one unused PCI card slot
• 16-bit color display (or greater)
5
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6 CoolSNAPcf /CoolSNAPES
If you are a Mac®user, the host computer for your CoolSNAP camera must
have the following:
Macintosh®OS 8.X or OS 9.X
• 64 MB RAM (or greater)
• CD-ROM drive
• At least one unused PCI card slot
• Video adapter that supports 24-bit color (millions of colors)
Multiple Cameras
PVCAM supports multiple open cameras. In order to use this function, it must
also be supported by your imaging software. The RS Image capture software
program included with your system supports multiple cameras, as do many other
imaging packages.
If your imaging software supports multiple cameras, there must be a separate
PCI card for each camera.
Software
Installation
An Installation Guide appropriate to your system is included as an insert in
the CD-ROM case. This guide provides step-by-step instructions for installing
the camera interface software and the application software for Windows-
based and Macintosh-based PCs. Additional instructions are included for
installing a PCI card in your computer and capturing images.
The CD-ROM contains the following files.
• Readme text files — these files contain the latest information on the
software installations and should be read before you run the
PVCAMSetup program.
• PVCAMSetup software program — this software installs the camera
interface software.
• RSImageSetup software program — this software installs the
RS Image application program.
• MacOS8_OS9 directory — this directory contains the files required for
installing to a Macintosh computer.
• Acrobat directory — this directory contains subdirectories containing
installation programs for Acrobat Reader.
• Manuals directory — this directory contains user manuals in PDF
format.
Installing the
PCI Card
You will be using a CoolSNAP PCI card to allow the camera to communicate
with your computer.
Refer to the Readme text files on the CD-ROM and to the Software
Installation insert supplied with the CD-ROM before installing the PCI card.
Depending on your system, you will have received one of two different PCI
cards available for CoolSNAP cameras: Video or Non-Video. Please follow
the instructions appropriate to the card you have received with your system.
Note: The Video-capable PCI card accepts a standard BNC connector for video output.
After installing the PCI card, proceed to Connecting your CoolSNAP Camera
on page 7.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Connecting Your
CoolSNAP
Camera
The CoolSNAP cable connects your CoolSNAP camera to the PCI card. This
cable is designed to serve as a conduit both for data and power.
To connect your CoolSNAP camera:
1. Connect either end of the CoolSNAP cable to the CoolSNAP PCI card that
you have installed in the host computer.
2. Connect the other end of the CoolSNAP cable to the DATA connector
located on the back of the camera (shown below).
The following connectors and display lights, as well as the power switch, are
located on the back of the CoolSNAP camera.
• DATA connector: 20-pin, high-density connector for data transfer and
power.
• EXPOSE OUT connector: standard BNC connector (not video); the signal
at the BNC connector will go to a TTL high level when the exposure
begins; useful for synchronizing an external shutter in the illumination
pathway; will not power the shutter.
• XFER display light: amber LED illuminates during data transfer.
• ON display light: green LED illuminates when camera is powered on.
• POWER switch: momentary on/off rocker switch (CoolSNAPcf ) or toggle
switch (CoolSNAPES).
Note: CoolSNAP cameras draw power from the PCI bus via the PCI card. Therefore, the
computer must be powered on for the CoolSNAP camera to operate.
Chapter 2. System Installation 7
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8 CoolSNAPcf /CoolSNAPES
This page intentionally left blank.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
