Photon Focus MV3-D640I-M01-144-G2-12 User manual

Photonfocus
MV3-D640I-M01-144-G2 Camera
Series
CMOS camera with Gigabit Ethernet interface
MAN076 09/2017 V1.0

All information provided in this manual is believed to be accurate and reliable. No
responsibility is assumed by Photonfocus AG for its use. Photonfocus AG reserves the right to
make changes to this information without notice.
Reproduction of this manual in whole or in part, by any means, is prohibited without prior
permission having been obtained from Photonfocus AG.
2 of 121 MAN076 09/2017 V1.0

Contents
1 Preface 7
1.1 IMPORTANTNOTICE! ..................................... 7
1.2 AboutPhotonfocus...................................... 8
1.3 Contact............................................. 8
1.4 SalesOffices .......................................... 8
1.5 Furtherinformation...................................... 8
1.6 Legend ............................................. 9
2 Introduction 11
2.1 Introduction .......................................... 11
2.2 CameraNamingConvention................................. 11
2.3 Cameralist........................................... 11
3 Product Specification 13
3.1 Introduction .......................................... 13
3.2 FeatureOverview ....................................... 15
3.3 TechnicalSpecification .................................... 16
3.3.1 Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3.2 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.3.3 SpectralResponse................................... 18
4 Image Acquisition 19
4.1 Overview............................................ 19
4.1.1 Vocabulary....................................... 19
4.1.2 Structure ........................................ 19
4.1.3 Image Acquisition, Frame and Exposure Control Parameters . . . . . . . . . . 20
4.1.4 Image Acquisition, Frame and Exposure Trigger . . . . . . . . . . . . . . . . . 21
4.1.5 Image Acquisition, Frame and Exposure Status . . . . . . . . . . . . . . . . . . 21
4.2 AcquisitionControl ...................................... 21
4.2.1 Acquisition Start and Stop Commands, Acquisition Mode and Acquisition
FrameCount...................................... 21
4.2.2 Acquisition Frame Rate and Acquisition Frame Rate Enable . . . . . . . . . . 22
4.2.3 Acquisition Start Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2.4 Acquisition End Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2.5 Acquisition Control Output Signals . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3 FrameControl ......................................... 24
4.3.1 FrameStartTrigger.................................. 24
4.3.2 Frame Burst Start Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.3.3 FrameBurstEndTrigger ............................... 26
4.3.4 Frame Control Output Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.4 ExposureControl ....................................... 27
4.4.1 ExposureMode .................................... 27
MAN076 09/2017 V1.0 3 of 121

CONTENTS
4.4.2 ExposureStartTrigger ................................ 27
4.4.3 ExposureEndTrigger................................. 28
4.4.4 Exposure Control Output Signals . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.5 Overlapped Image Acquisition Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.6 Acquisition-, Frame- and Exposure-Trigger Configuration . . . . . . . . . . . . . . . . 30
4.6.1 Trigger Source Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.6.2 TriggerSoftware ................................... 31
4.6.3 TriggerMode ..................................... 32
4.6.4 TriggerActivation................................... 32
4.6.5 TriggerDivider..................................... 32
4.6.6 TriggerDelay...................................... 32
4.7 Software Signal Pulse and User Output . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5 Counter & Timer 35
5.1 Counter............................................. 35
5.1.1 CounterUsage..................................... 35
5.1.2 CounterStatus..................................... 36
5.1.3 Counter Active, -Start and -End Signal . . . . . . . . . . . . . . . . . . . . . . . 36
5.1.4 CounterReset ..................................... 36
5.1.5 CounterEventSource................................. 37
5.1.6 CounterTriggerSource................................ 38
5.1.7 CounterResetSource................................. 39
5.2 Timer .............................................. 40
5.2.1 TimerUsage ...................................... 40
5.2.2 TimerStatus ...................................... 41
5.2.3 Timer Active, -Start and -End Signal . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2.4 TimerReset....................................... 41
5.2.5 TimerTriggerSource ................................. 41
6 I/O Control 43
6.1 InputSignalPath ....................................... 43
6.2 OutputSignalPath ...................................... 44
7 Image Format Control 47
7.1 RegionofInterest(ROI) ................................... 47
7.2 Multiple Regions of Interest (MROI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
8 Frame Rate 51
8.1 Introduction .......................................... 51
8.2 Read-outMode ........................................ 51
8.3 Commonparameters ..................................... 52
8.4 Sequential Read-out Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.5 Interleave Read-out Timing 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
8.6 Interleave Read-out Timing 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8.7 MROI .............................................. 53
8.8 MaximumFrameRateTable................................. 54
9 Pixel Data Processing 55
9.1 Overview............................................ 55
9.2 ImageCorrection ....................................... 56
9.2.1 Overview........................................ 56
9.2.2 Offset Correction (FPN, Hot Pixels) . . . . . . . . . . . . . . . . . . . . . . . . . 56
9.2.3 GainCorrection .................................... 58
4 of 121 MAN076 09/2017 V1.0

CONTENTS
9.2.4 Hot and cold pixel correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
9.2.5 CorrectedImage.................................... 60
9.2.6 CorrectionRanges................................... 61
9.3 GainandOffset ........................................ 62
9.4 Grey Level Transformation (LUT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
9.4.1 Gain........................................... 62
9.4.2 Gamma......................................... 64
9.4.3 User-defined Look-up Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.4.4 Region LUT and LUT Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
9.5 Binning............................................. 68
9.5.1 Description....................................... 68
9.5.2 Camerasettings.................................... 68
9.6 Crosshairs............................................ 68
9.6.1 Functionality...................................... 68
9.7 Status Line and Image Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
9.7.1 ImageAverageValue................................. 71
9.7.2 StatusLineFormat .................................. 71
9.7.3 CameraTypeCodes.................................. 73
9.8 TestImages........................................... 73
9.8.1 Ramp .......................................... 73
9.8.2 LFSR........................................... 73
9.8.3 Troubleshooting using the LFSR . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
10 Thermoelectric Cooler (TEC) 77
10.1TECDescription ........................................ 77
11 Precautions 79
11.1IMPORTANTNOTICE! ..................................... 79
12 Hardware Interface 83
12.1AbsoluteMaximumRatings ................................. 83
12.2 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
12.3GigECameraConnector ................................... 83
12.4PowerSupply ......................................... 83
12.5 Status Indicator (GigE cameras) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
12.6I/OConnector ......................................... 85
12.6.1Overview........................................ 85
12.6.2 Single-ended Line Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
12.6.3 Single-ended Line Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
12.6.4 Master / Slave Camera Connection . . . . . . . . . . . . . . . . . . . . . . . . . 89
12.6.5I/OWiring ....................................... 90
13 Miscellaneous 95
13.1MechanicalInterface ..................................... 95
13.1.1 MV3 cameras with GigE Interface . . . . . . . . . . . . . . . . . . . . . . . . . . 95
13.2OpticalInterface........................................ 96
13.2.1CleaningtheSensor.................................. 96
13.3TemperatureMonitor..................................... 98
14 Troubleshooting 99
14.1Noimagescanbeacquired ................................. 99
14.1.1 No acquisition due to no triggers . . . . . . . . . . . . . . . . . . . . . . . . . . 99
MAN076 09/2017 V1.0 5 of 121

CONTENTS
15 Standards Compliance 101
15.1 Directives and General Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
15.2 Country-specific Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
15.2.1 For customers in the USA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
15.2.2 For customers in Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
15.2.3 Pour utilisateurs au Canada . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
15.3Lifesupportapplications...................................102
16 Warranty 103
16.1WarrantyTerms ........................................103
16.2WarrantyClaim ........................................103
16.3BreachofWarranty......................................103
17 Support and Repair 105
17.1TechnicalSupport .......................................105
17.2 Repair and obtaining an RMA Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
17.3 Temporal Abandoning and Scrapping . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
18 References 107
A Pinouts 109
A.1 PowerSupplyConnector...................................109
A.2 GigEConnector ........................................111
B Camera Timing 113
B.1 Timed Exposure Mode Camera Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
C Use Cases 115
C.1 Acquisition...........................................115
C.1.1 Camera runs in "free-running" mode . . . . . . . . . . . . . . . . . . . . . . . 115
C.1.2 Camera runs in "constant frame rate" mode . . . . . . . . . . . . . . . . . . . 115
C.1.3 Camera runs in triggered mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
C.1.4 Camera runs in burst triggered mode . . . . . . . . . . . . . . . . . . . . . . . 116
C.1.5 Triggered controlled exposure mode . . . . . . . . . . . . . . . . . . . . . . . . 116
C.2 Timer ..............................................117
C.2.1 StrobeSignalOutput.................................117
C.3 Counter.............................................117
C.3.1 CounterReset .....................................118
C.3.2 ImageCounter.....................................118
C.3.3 RealTimeCounter ..................................118
C.3.4 Missed Trigger Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
D Document Revision History 121
6 of 121 MAN076 09/2017 V1.0

1
Preface
1.1 IMPORTANT NOTICE!
READ THE INSTRUCTIONS FOR USE BEFORE
OPERATING THE CAMERA
STORE THE INSTRUCTIONS FOR USE FOR
FURTHER READING
Photonfocus AG
Bahnhofplatz 10
CH-8853 Lachen SZ
Switzerland
www.photonfocus.com
[email protected]
+41 – 55 451 00 00
MAN076 09/2017 V1.0 7 of 121

1 Preface
1.2 About Photonfocus
The Swiss company Photonfocus is one of the leading specialists in the development of CMOS
image sensors and corresponding industrial cameras for machine vision.
Photonfocus is dedicated to making the latest generation of CMOS technology commercially
available. Active Pixel Sensor (APS) and global shutter technologies enable high speed and
high dynamic range (120 dB) applications, while avoiding disadvantages like image lag,
blooming and smear.
Photonfocus’ product range is complemented by custom design solutions in the area of camera
electronics and CMOS image sensors.
Photonfocus is ISO 9001 certified. All products are produced with the latest techniques in order
to ensure the highest degree of quality.
1.3 Contact
Photonfocus AG, Bahnhofplatz 10, CH-8853 Lachen SZ, Switzerland
Sales Phone: [phone] Email: [email protected]
Support Phone: [phone] Email: [email protected]
Table 1.1: Photonfocus Contact
1.4 Sales Offices
Photonfocus products are available through an extensive international distribution network
and through our key account managers. Contact us via email at [email protected].
1.5 Further information
Photonfocus reserves the right to make changes to its products and documenta-
tion without notice. Photonfocus products are neither intended nor certified for
use in life support systems or in other critical systems. The use of Photonfocus
products in such applications is prohibited.
Photonfocus and LinLog®are registered trademarks of Photonfocus AG.
CameraLink®and GigE Vision®are a registered mark of the Automated Imag-
ing Association. Product and company names mentioned herein are trademarks
or trade names of their respective companies.
Reproduction of this manual in whole or in part, by any means, is prohibited
without prior permission having been obtained from Photonfocus AG.
Photonfocus can not be held responsible for any technical or typographical er-
rors.
8 of 121 MAN076 09/2017 V1.0

1.6 Legend
1.6 Legend
In this documentation the reader’s attention is drawn to the following icons:
Important note, additional information
Important instructions
General warning, possible component damage hazard
Warning, electric shock hazard
Warning, fire hazard
MAN076 09/2017 V1.0 9 of 121

1 Preface
10 of 121 MAN076 09/2017 V1.0

2
Introduction
2.1 Introduction
This manual describes standard Photonfocus MV3-D640I-M01-144-G2-12 camera that has a
Gigabit Ethernet (GigE) interface. The abbreviated name MV3-D640I-M01 is used in most parts
of this manual. The camera contains the SNAKE SW InGaAs sensor from Sofradir.
2.2 Camera Naming Convention
The naming convention of the MV3-D640I-M01 camera is summarized in Fig. 2.1.
MV 3 - D 6 4 0 I - M 0 1 - 1 4 4 - G 2 - 1 2
Pr e f i x 1
P r e f i x 2
S e n s o r w i d t h
C a m e r a
s p e e d
I n t e r f a c e t y p e
I n t e r f a c e
r e s o l u t i o n
S e n s o r M a n u f a c t u r e r
S e n s o r
F a m i l y
S e n s o r
T y p e
Figure 2.1: Camera naming convention
Prefix1 Camera platform and usage prefix. The following prefix applies to this camera: MV3
Prefix2 Camera family specifier. The following specifiers are used in this manual: "D":
standard digital area scan cameras
Sensor width Width of image sensor of the camera.
Sensor Type "I": NIR / SWIR type sensor.
Sensor Manufacturer Sensor manufacturer. "M": Sofradir
Sensor Family Sensor family of the prior indicated manufacturer. "01": Snake series
Camera speed The camera speed is usually the product of the camera interface clock in MHz
and the number of parallel interface channels (taps).
Interface type Interface type specification: "G2": Gigabit Ethernet (GigE Vision)®.
Interface resolution Maximal resolution (bit width) of the camera interface.
2.3 Camera list
A list of all cameras covered in this manual is shown in Table 2.1.
MAN076 09/2017 V1.0 11 of 121

2 Introduction
Name Resolution Frame Rate Notes
MV3-D640I-M01-144-G2-12 640 x 512 300 fps 1) Gigabit Ethernet SWIR standard
camera.
Table 2.1: Camera models covered by this manual (Footnotes: 1)frame rate at full resolution)
12 of 121 MAN076 09/2017 V1.0

3
Product Specification
3.1 Introduction
The Photonfocus MV3-D640I-M01 camera series is built around the CMOS InGaAs image sensor
Snake SW from Sofradir, that provides a resolution of 640 x 512 pixels. The cameras are aimed
at applications in industrial image processing where high sensitivity within the SWIR band from
0.9 to 1.7 µm are required.
The principal advantages are:
• Resolution of 640x512 pixels
• Optimized for high sensitivity, low noise and low dark current
• Spectral range: SWIR from 900 - 1700 nm
• Global shutter
• Gigabit Ethernet interface, GigE Vision and GenICam compliant
• Frame rates of 300 fps at maximal resolution
• I/O capabilities: 2 isolated inputs and 2 isolated outputs
• Up to 512 regions of interest (MROI)
• 2 look-up tables (12-to-8 bit) on user-defined image region (Region-LUT)
• Crosshairs overlay on the image
• Image information and camera settings inside the image (status line)
• Image Binning
• Thermoelectric cooling of the image sensor to stabilize the sensor temperature and avoid
temperature drifts.
• Software provided for setting and storage of camera parameters
• The rugged housing at a compact size with integrated TEC modul of 60 x 60 x 59.3 mm3
makes the Photonfocus MV3-D640I-M01-G2 camera the perfect solution for applications
in which space is at a premium.
The general specification and features of the camera are listed in the following sections.
MAN076 09/2017 V1.0 13 of 121

3 Product Specification
Figure 3.1: Photonfocus MV3-D640I-M01-144-G2 GigE interface camera
14 of 121 MAN076 09/2017 V1.0

3.2 Feature Overview
3.2 Feature Overview
The general specification and features of the camera are listed in the following sections. The
detailed description of the camera features is given in the following chapters.
Characteristics Photonfocus MV3-D640I-M01 GigE Series
Interface Gigabit Ethernet (PoE), GigE Vision and GenICam compliant
Camera Control GigE Vision Suite
Trigger Modes Software Trigger / External isolated trigger inputs
Features
• Greyscale resolution 12bit / 10 bit / 8 bit
• Region of Interest (ROI)
• Up to 512 regions of interest (MROI)
• 2 look-up tables (12-to-8 bit) on user-defined image region
(Region-LUT)
• Binning
• Test pattern (LFSR and grey level ramp)
• Image information and camera settings inside the image (status line)
• Crosshairs overlay on the image
• Opto isolated trigger inputs and opto isolated strobe outputs
• Sensor Non-Uniformitiy Correction
• Termoelectric cooling (TEC)
Table 3.1: Feature overview
MAN076 09/2017 V1.0 15 of 121

3 Product Specification
3.3 Technical Specification
Photonfocus MV3-D640I-M01 GigE Series
Sensor Manufacturer / Type Sofradir / Snake SW
Technology CMOS active pixel, InGaAs
Optical format / diagonal 1 / 1.7” (12.3 mm diagonal)
Resolution 640 x 512 pixels
Pixel size 15 µm x 15 µm
Active optical area 9.6 mm x 7.68 mm
Dark current 30 fA @ 0.2V detector bias
Read out noise < 30 e−
Full well capacity / SNR 1.44 Me−/ 1200:1
Spectral range 900 nm to 1700 nm
Responsivity TBD x 103DN (J/m2) @ TBD nm / 8bit
Quantum Efficiency > 70% from 1 µm to 1.6 µm
Optical fill factor 95 %
Dynamic range TBD dB
Micro lenses no
Shutter mode Global shutter
Characteristic curve Linear
ADC Bit Depth 12 bit
Maximal frame rate 1) 300 fps
Camera pixel formats 12 / 10 / 8 bit
Analog gain no
Digital gain 0.1 to 15.99 (Fine Gain)
Exposure time range 11 µs ... 0.46 s
Table 3.2: General specification of the Photonfocus MV3-D640I-M01-G2 camera series (Footnotes: 1)at full
resolution)
16 of 121 MAN076 09/2017 V1.0

3.3 Technical Specification
Photonfocus MV3-D640I-M01 GigE Series
Interface Gigabit Ethernet interface, GigE Vision and GenICam compliant
Operating temperature / moisture 0°C ... 50°C / 20 ... 80 %
Storage temperature / moisture -25°C ... 60°C / 20 ... 95 %
Trigger signal input range +5 .. +15 V DC
Camera power supply +12 V DC (±10 %)
Maximal power consumption < 6 W (without TEC)
Lens mount C-Mount, CS-Mount (optional)
I/O Inputs2 2x isolated
I/O Outputs 2x isolated
Dimensions 60 x 60 x 59.3 mm3
Mass 420 g
Connector I/O Fischer Connectors DBPLU1031Z012|130G
Connector Interface X-coded M12
Conformity RoHS / WEEE
IP Code IP40
Table 3.3: Physical characteristics and operating ranges of the MV3-D640I-M01-G2 camera series
3.3.1 Absolute Maximum Ratings
Parameter Value
Camera Control Input Signal Voltage Single Ended -0 V ... +24 V
Camera Control Output Signal Voltage Single Ended 0 V ... +24 V
Camera Control Output Signal Output Current Single Ended 0.5 A
Camera Control Output Signal Output Power Single Ended 0.35 W
ESD Contact Discharge Camera Control Signals 4 kV
ESD Air Discharge Camera Control Signals 8 kV
Fast Transients/Bursts Data and Camera Control Signals 1 kV
Surge immunity Data and Camera Control Signals 1 kV
Table 3.4: Absolute Maximum Ratings
MAN076 09/2017 V1.0 17 of 121

3 Product Specification
3.3.2 Electrical Characteristics
Parameter Value
Camera Control Input Single Ended +5 V ... +20 V
Table 3.5: Electrical Characteristics
3.3.3 Spectral Response
Fig. 3.2 shows the quantum efficiency curve of the Snake SW sensors from Sofradir measured in
the wavelength range from 900 nm to 1800 nm.
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800
Wavelength [nm]
Sofradir Snake
Figure 3.2: Quantum efficiency (QE) [%] of the Snake SW image sensors
18 of 121 MAN076 09/2017 V1.0

4
Image Acquisition
This chapter gives detailed information about the controlling of the image acquisition. It
shows how the camera can be triggered or run in free-running mode, and how the frame rate
can be configured.
The structure offers a lot of flexibility in the configuration. It follows the GenI-
Cam naming convention. Typical camera configurations are included in the chap-
ter "Use Cases" in the Appendix C.
4.1 Overview
The overview shows the major camera elements which are involved in the image acquisition.
The section starts with a description of the vocabulary and terms, which are used to explain the
acquisition related features.
4.1.1 Vocabulary
An acquisition is composed of one or many frames. A frame is a single acquired image which
consists of an exposure time and an image read out. A burst of frame is defined as a capture of
a group of one or many frames within an acquisition. So an acquisition can be grouped in N
single frames or N burst of frames.
4.1.2 Structure
The camera contains a block that controls the image acquisition which contains the sub-blocks
for acquisition control, frame control and exposure control. Furthermore there are a controller
blocks of I/O signals, counters, timers and software interface. All of these elements can be
connected through an interconnection, which allows to control the image acquisition by digital
input signals, by counters, by timers and/or software access.
Co u n t e r / T i m e r
S i g n a l R o u t i n g
I / O C o n t r o l
A c q u i s i t i o n
C o n t r o l
F r a m e
C o n t r o l
E x p o s u r e
C o n t r o l
S o f t w a r e S i g n a l
P u l s e
&
U s e r O u t p u t
L i n e I n
L E D
L i n e O u t
Figure 4.1: Structure
MAN076 09/2017 V1.0 19 of 121

4 Image Acquisition
Acquisition Control The acquisition control block takes care of the acquisition function. The
camera can only capture frames, when the acquisition has been started and is active (see
Section 4.2 for more information).
Frame Control The frame control block takes care of the capturing of one or many frames and
burst of frames (see Section 4.3 for more information).
Exposure Control The exposure control block takes care of the exposure time of a frame (see
Section 4.4 for more information).
Counter The camera has four independent counters. They count events from a selectable
source (see Section 5.1 for more information about counter configuration and usage).
Timer The camera has four independent timers. A timer delay and duration are configurable
and the timers are triggered by a selectable source (see Section 5.2 for more information
about timer configuration and usage).
I/O Control The I/O control unit manages physical camera inputs and outputs and LED. A
switch matrix within this block allows connecting internal status signals to the output
lines or LED. Status signals can come from the acquisition, frame or exposure control
block, also from timer or counter, or even input lines can be routed to an output. The
input lines can be used to control the acquisition, frame and/or exposure, also to start a
timer or count events with a counter (see Chapter 6 for more information).
Software Signal Pulse and User Output The camera has user outputs, which can be set to 1 or
0 by software access, and a software signal pulse generator block (see Section 4.7). These
user outputs and signal pulses can be used to control camera functions by software
access, such like acquisition and frame capture or counter and timer.
Signal Routing All these elements are connected to each other by the signal routing block. The
following sections show which signals are available and how they can be used in the
others blocks.
4.1.3 Image Acquisition, Frame and Exposure Control Parameters
Mainly the following commands/settings are involved in order to control and configure the
camera acquisition and frame capturing:
• Acquisition Start and Stop Command
• Acquisition Mode (Single Frame, Multi Frame, Continuous Frame)
• Acquisition Frame Count
• Acquisition Frame Burst Count
• Acquisition Frame Rate
• Exposure Mode (Timed, Trigger Controlled)
• Exposure Time
This list shows only an overview of available parameters. The function and usage of them are
explained in the following chapters.
