PI L-505.011212 User manual

L505M0006EN ‒ 3/18/2020
User Manual
L-505.011212 LINEAR STAGE WITH STEPPER MOTOR
MOTION | POSITIONING

Contents
1 Legal Information.........................................................................................................4
2 About this Document..................................................................................................5
2.1 Objective and Target Group..............................................................................5
2.2 Other Applicable Documents............................................................................5
2.3 Explanation of Symbols....................................................................................5
2.3.1 Typographic Conventions................................................................. 5
2.3.2 Symbols Used.................................................................................... 6
2.4 Figures................................................................................................................6
2.5 Downloading Manuals...................................................................................... 6
3 Safety............................................................................................................................8
3.1 Intended Use......................................................................................................8
3.2 General Safety Instructions.............................................................................. 8
3.3 Organizational Measures.................................................................................. 8
3.3.1 User Manual....................................................................................... 8
3.3.2 General Personnel Qualification.......................................................8
4 Product Description..................................................................................................... 9
4.1 Product Labeling................................................................................................9
4.1.1 Type Plate........................................................................................... 9
4.2 Scope of Delivery.............................................................................................10
4.3 Overview.......................................................................................................... 10
4.3.1 Base Body......................................................................................... 11
4.3.2 Drive Connector................................................................................11
4.4 Suitable Electronics......................................................................................... 11
4.5 Optional Accessories.......................................................................................12
5 Unpacking.................................................................................................................. 13
6 Installation................................................................................................................. 14
6.1 Mounting the L-505.011212..............................................................................14
6.2 Connecting the L-505.011212 to the Protective Earth Conductor..................15
6.3 Setting Up a Multi-Axis System..................................................................... 16
6.4 Building a Vertical Multi-Axis System............................................................18
6.5 Mounting the Load onto the L-505.011212..................................................... 22
6.6 Connecting the L-505.011212...........................................................................24
7 Startup and Operation.............................................................................................. 25
7.1 Starting and Operating the L-505.011212....................................................... 25
8 Maintenance...............................................................................................................26
8.1 Maintenance Run.............................................................................................26
8.2 Relubricating.................................................................................................... 26
8.3 Cleaning............................................................................................................27
8.4 Moving the Motion Platform by Hand........................................................... 27
CONTENTS L505M0006EN ‒ 3/18/2020
2MOTION | POSITIONING

9 Troubleshooting......................................................................................................... 29
10 Transportation............................................................................................................30
11 Customer Service Department.................................................................................31
12 Technical Data............................................................................................................ 32
12.1 Specifications...................................................................................................32
12.2 Maximum Ratings........................................................................................... 34
12.3 Ambient Conditions and Classifications........................................................34
12.4 Dimensions...................................................................................................... 35
13 Old Equipment Disposal........................................................................................... 36
14 Appendix.................................................................................................................... 37
14.1 Pin Assignment................................................................................................37
14.1.1 Motor and Position Sensor Connector...........................................37
14.2 Drive Properties............................................................................................... 38
14.3 Reference Switch Specifications.................................................................... 38
14.4 Limit Switch Specifications.............................................................................39
15 EU Declaration of Conformity...................................................................................40
CONTENTS L505M0006EN ‒ 3/18/2020
3MOTION | POSITIONING

1 Legal Information
The following company names and brands are registered trademarks of Physik Instrumente
(PI) GmbH & Co. KG:
PI®, PIC®, NanoCube®, PICMA®, PIFOC, PILine®, NEXLINE®, PiezoWalk®, PicoCube®,
PiezoMove, PIMikroMove, NEXACT®, Picoactuator®, PInano®, NEXSHIFT®, PITOUCH®,
PIMag®, PIHera, Q-Motion®
The patents held by PI can be found in our list at http://www.physikinstrumente.com/en/
about-pi/patents.
© 2020 Physik Instrumente (PI) GmbH & Co. KG, Karlsruhe, Germany. The text, photographs,
and drawings in this manual are protected by copyright. With regard thereto, Physik
Instrumente (PI) GmbH & Co. KG reserves all rights. The use of any text, images and
drawings is permitted only in part and only when indicating the source.
Original instructions
First print: 3/18/2020
Document number: L505M0006en, ASt
Subject to change. This manual is superseded by any new release. The latest versions of the
user manuals are available for download (p. 6) at www.pi.ws.
Publisher:
PI miCos GmbH
Freiburger Strasse 30
79427 Eschbach
Germany
[email protected]
www.pi.de
Customer service department:
Physik Instrumente (PI) GmbH & Co. KG
Auf der Roemerstrasse 1
76228 Karlsruhe
Germany
[email protected]
www.pi.de
1 LEGAL INFORMATION L505M0006EN ‒ 3/18/2020
4MOTION | POSITIONING

2 About this Document
2.1 Objective and Target Group
This user manual contains the information needed for the intended use of the L-505.011212.
Basic knowledge of closed-loop systems, motion control concepts, and applicable safety
measures is assumed.
2.2 Other Applicable Documents
The devices and software tools that are mentioned in this documentation are described in
separate manuals.
Document number Document type Product
MP146EK Short instructions Positioners with electric motors
MS208E User Manual C-663 Mercury Step Controller
MS241E User Manual C-663.12 Mercury Step Stepper Motor Con-
troller
- Hardware Manual SMC Hydra Motion Controller
- Hardware Manual SMC Pollux Motion Controller
The latest versions of the user manuals can be downloaded (p. 6) at www.pi.ws.
2.3 Explanation of Symbols
This chapter explains the symbols and markings used by PI in their user manuals.
2.3.1 Typographic Conventions
Symbol / label Meaning
1.
2.
Action consisting of one or several steps with strict sequential order
► Action consisting of one or more steps without relevant sequential or-
der
■ Lists
p. 5 Cross-reference to page 5
RS-232 Label on the product indicating an operating element (example: RS-232
interface socket)
Start > Settings Menu path in the PC software (example: to open the menu, Start and
Settings must be clicked successively)
POS? Command line or a command from PI's General Command Set (GCS)
(example: command to get the axis position)
Device S/N Parameter name (example: parameter where the serial number is stor-
ed)
5Value that must be entered or selected via the PC software
2 ABOUT THIS DOCUMENT L505M0006EN ‒ 3/18/2020
5MOTION | POSITIONING

2.3.2 Symbols Used
Symbol / Label Meaning
General hazard symbol
DANGER
Dangerous situation
Failure to observe can lead to death or serious injury.
►Measures for avoiding the risk.
WARNING
Dangerous situation
Failure to observe can lead to serious injury.
►Action to take to avoid the risk.
CAUTION
Dangerous situation
Failure to observe can lead to minor injury.
►Actions to take to avoid the risk.
NOTICE
Dangerous situation
Failure to observe can lead to material damage.
►Action to take to avoid the risk.
Information
Additional information on the L-505.011212 that can affect your application.
2.4 Figures
For better understandability, the colors, proportions and degree of detail in illustrations can
deviate from the actual circumstances. Photographic illustrations may also differ and must
not be seen as guaranteed properties.
2.5 Downloading Manuals
Information
If a manual is missing or problems occur with downloading:
►Contact our customer service department (p. 31).
Downloading Manuals
1. Open the website www.pi.ws.
2. Search the website for the product number (e.g., P-882) or the product family (e.g.,
PICMA® bender).
3. Click the corresponding product to open the product detail page.
4. Click the Downloads tab.
➔The manuals are shown under
Documentation .
2 ABOUT THIS DOCUMENT L505M0006EN ‒ 3/18/2020
6MOTION | POSITIONING

5. Click the desired manual and fill out the inquiry form.
➔The download link will then be sent to the email address entered.
2 ABOUT THIS DOCUMENT L505M0006EN ‒ 3/18/2020
7MOTION | POSITIONING

3 Safety
3.1 Intended Use
The L-505.011212 is a laboratory device as defined by DIN EN 61010-1. It is intended for indoor
use and use in an environment that is free of dirt, oil, and lubricants.
In accordance with its design, the L-505.011212 is intended for positioning, adjusting and
shifting loads in one axis at various velocities. The L-505.011212 is not intended for
applications in areas, in which a failure would present severe risks to human beings or the
environment.
The intended use of the L-505.011212 is only possible when completely mounted and
connected. The L-505.011212 must be operated with suitable electronics (p. 11). The
electronics are not in the scope of delivery of the L-505.011212.
The L-505.011212 may not be used for purposes other than those stated in this user manual.
The L-505.011212 may only be used in compliance with the technical specifications and
instructions in this user manual.
3.2 General Safety Instructions
The L-505.011212 is built according to state-of-the-art technology and recognized safety
standards. Improper use of the L-505.011212 may result in personal injury and/or damage to
the L-505.011212.
►Use the L-505.011212 only for its intended purpose and if it is in perfect condition.
►Read the user manual.
►Eliminate any faults and malfunctions that are likely to affect safety immediately.
The operator is responsible for correct installation and operation of the L-505.011212.
3.3 Organizational Measures
3.3.1 User Manual
►Always keep this user manual available with the L-505.011212. The latest versions of the
user manuals can be downloaded (p. 6) at www.pi.ws.
►Add all information from the manufacturer such as supplements or technical notes to the
user manual.
►If you give the L-505.011212 to a third party, also include this user manual as well as other
relevant information provided by the manufacturer.
►Only use the device on the basis of the complete user manual. Missing information due to
an incomplete user manual can result in minor injury and damage to equipment.
►Only install and operate the L-505.011212 after you have read and understood this user
manual.
3.3.2 General Personnel Qualification
The L-505.011212 may only be installed, started up, operated, maintained, and cleaned by
authorized and appropriately qualified personnel.
3 SAFETY L505M0006EN ‒ 3/18/2020
8MOTION | POSITIONING

4 Product Description
4.1 Product Labeling
1 2 34
Figure 1: Product label on the L-505.011212
1. Type plate
2. Warning symbol: Electrostatic sensitive device
3. Protective earth connector
4. Warning symbol: Risk of crushing
4.1.1 Type Plate
The type plate is on the plug connector of the L-505.011212.
Figure 2: Type plate of the L-505.011212
1. Product number (example)
2. Serial number (example), individual for each L-505.011212
Meaning of the position (counting from the left):
1 = internal information,
2 and 3 = year of manufacture,
4 to 9 = consecutive numbers
3. Warning and conformity symbols (old equipment disposal (p. 36), CE mark (p. 40))
4 PRODUCT DESCRIPTION L505M0006EN ‒ 3/18/2020
9MOTION | POSITIONING

4.2 Scope of Delivery
Product number Description
L-505.011212 Linear stage according to the order
L505B1000 Mounting kit for mounting the L-505.011212,
consisting of
■4 socket head screws, ISO 4762 M3×6
■2 dowel pins, ISO 2338, 2h8×8
For securing extension cables:
■4 spacer bolts, 4-40 UNC-2B, 4.5 mm
across flats, 6.3 mm height
MP146EK Short instructions for positioners with elec-
tric motors
Extension cable, depending on the controller ordered:
Product number Description
720090669-0300 Drive/encoder cable, stepper motor and en-
coder to SMC Hydra controller, HD Sub-D 26
(f) to Sub-D 15 (m) (motor) and HD Sub-D 15
(encoder), 3 m
7200900860-0300 Drive/encoder cable, stepper motor and en-
coder to C-663.11 Mercury Step stepper mo-
tor controller, HD Sub-D 26 (f) to Sub-D 15
(m), 3 m
C-815.00UP0100-0300 Drive/encoder cable, stepper motor and en-
coder to C-663.12 Mercury Step stepper mo-
tor controller, HD Sub-D 26 (f) to HD-Sub-D
26 (m), 3 m
4.3 Overview
123
Figure 3: Elements of the L-505.011212
1. Drive
2. Motion platform
3. Base body
4 PRODUCT DESCRIPTION L505M0006EN ‒ 3/18/2020
10 MOTION | POSITIONING
