42-924 User Manual
PXIe 8-Slot Full Hybrid Chassis

Page (II) PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
Page (II) REED RELAY MODULE 40-110/115/120/125
pickering
© COPYRIGHT (2023) PICKERING INTERFACES. ALL RIGHTS RESERVED.
No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by
any means without the written permission of Pickering Interfaces.
Technical details contained within this publication are subject to change without notice.
ISO 9001
Reg No. FM38792

Page (III)
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
Page (III)
REED RELAY MODULE 40-110/115/120/125
pickering
TECHNICAL SUPPORT
For Technical Support please contact Pickering Interfaces either by phone, the website or via e-mail.
WARRANTY
All products manufactured by Pickering Interfaces are warranted against defective materials and workmanship for a period of
three years, excluding programmable power supplies, from the date of delivery to the original purchaser. Any product found to be
defective within this period will, at the discretion of Pickering Interfaces be repaired or replaced.
Products serviced and repaired outside of the warranty period are warranted for ninety days.
Extended warranty and service are available. Please contact Pickering Interfaces by phone, the website or via e-mail.
ENVIRONMENTAL POLICY
Pickering Interfaces operates under an environmental management system similar to ISO 14001.
Pickering Interfaces strives to full all relevant environmental laws and regulations and reduce wastes and releases to the
environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and
safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can
be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.
Worldwide Technical Support and Product Information
pickeringtest.com
Germany
Tel: [phone]
E-mail: [email protected]
Sweden
Tel: [phone]
E-mail: [email protected]
USA
Tel: (West) [phone]
Tel: (East) [phone]
E-mail: [email protected]
Czech Republic
Tel: [phone]
E-mail: [email protected]
France
Tel [phone]
E-mail [email protected]
Pickering Interfaces Headquarters
Stephenson Road Clacton-on-Sea CO15 4NL United Kingdom
Tel: [phone]
E-Mail: [email protected]
China
Tel: [phone]
E-mail: [email protected]

Page (IV) PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
Page (IV) REED RELAY MODULE 40-110/115/120/125
pickering
MEANING / DESCRIPTION SYMBOL
PROTECTIVE EARTH (GROUND)
To identify any terminal which is intended for connection to an external conductor for
protection against electric shock in case of a fault, or the terminal of a protective earth
(ground) electrode.
DANGEROUS VOLTAGE
To indicate hazards arising from dangerous voltages.
WARNING / CAUTION
An appropriate safety instruction should be followed or caution to a potential hazard
exists.
Refer to the relevant instructions detailed within the product manual.
HEAVY
If this product is heavy reference should be made to the safety instructions for
provisions of lifting and moving.
STATIC SENSITIVE
To indicate that static sensitive devices are present and handling precautions should
be followed.
!
kg
SAFETY SYMBOLS
PRODUCT SAFETY
The following safety symbols may be used on the product and throughout the product documentation.

Page (V)
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
Copyright Statement ...................................................................II
Technical Support and Warranty................................................III
Product Safety .............................................................................IV
Contents (this page)....................................................................V
Warnings and Cautions ..............................................................VII
Section 1
Technical Specication...............................................................1.1
Section 2
Technical Description .................................................................2.1
Mechanical Overview ............................................................2.1
Backplane Overview..............................................................2.2
Section 3
Installation....................................................................................3.1
Installing the Chassis............................................................3.1
Chassis Cooling ....................................................................3.4
Power Supply.........................................................................3.6
Section 4
Chassis Management System....................................................4.1
Chassis Status LEDs.............................................................4.1
Fan Speed & Trigger Bus Settings.......................................4.1
I²C Interface Description.......................................................4.2
Register Map..........................................................................4.3
Section 5
Trouble Shooting & Maintenance...............................................5.1
Installation Problems ............................................................5.1
Basic Trouble Shooting ........................................................5.1
Periodic Maintenance............................................................5.1
Cooling Fan Replacement ....................................................5.3
Appendix A
Chassis Dimensions ...................................................................A.1
Appendix B
Rack Mounting The Chassis.......................................................B.1
CONTENTS

Page (VI) PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
THIS PAGE INTENTIONALLY BLANK

Page (VII)
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
WARNINGS AND CAUTIONS
WARNING - HAZARDOUS ENVIRONMENTS SYMBOL
This product is not specically designed for use in hazardous environments, for example in explosive
atmospheres. If the product is to be used in hazardous environments we recommend that the user
ensures suitable protective measures are taken.
!
WARNING - DANGER OF ELECTRIC SHOCK SYMBOL
This chassis may be populated with modules that contain hazardous voltages. Before removing any
module from the rack remove all supplies and disconnect user I/O signals.
Unused slots in this chassis are populated with blanking plates to prevent access to user I/O signals
that may be present. Blanking panels are available to order from Pickering in a variety of slot widths.
If the product is not used in this manner for example by using an extender card then additional care
must be taken to avoid contact with exposed signals.
CAUTION - HANDLING OF ELECTROSTATIC-SENSITIVE DEVICES SYMBOL
Certain semiconductor devices used in this equipment are liable to damage due to static voltage.
Observe the following precautions when handling these devices in their unterminated state, or
sub-assemblies containing these devices:
1. Persons removing sub-assemblies from equipment using these devices must be earthed by a
wrist strap and a resistor at the point provided on the equipment.
2. Soldering irons used during the repair operations must be low voltage types with earthed tips and
isolated from the mains voltage by a double insulated transformer.
3. Outer clothing worn must be unable to generate static charges.
4. Printed Circuit Boards (PCBs) tted with these devices must be stored and transported in
anti-static bags.
CAUTION - PRODUCT DOCUMENTATION SYMBOL
Suitably qualied & trained users should ensure that the accompanying documentation is fully read
and understood before attempting to install or operate the product.
!
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O
signals (refer to the Maintenance Section).
• Appropriate manual handling procedures should be followed as dictated by the weight of the individual module or
the combined weight of the modules & chassis.
• Should a fault occur with the module or chassis, immediately isolate and disconnect the incoming power to the
chassis and the user I/O signals.
• Ensure the equipment is installed, operated and maintained by trained and authorised personnel.
• For suitably equipped products in the event of an emergency press the red “emergency stop” button situated on
the front of the unit.

Page (VIII) PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
THIS PAGE INTENTIONALLY BLANK

Page 1.1
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering SECTION 1 - TECHNICAL SPECIFICATION
SECTION 1 - SPECIFICATION
pickeringtest.com
PXIe Full Hybrid Chassis, 8-Slot 42-924
ISSUE 1.6 AUG 2023
yHigh Performance 8-Slot PXIe Backplane
y7 Hybrid Compatible Slots
yUltra-High Performance PCIe Switching
With a Default Four-Link (4x4) System
Slot
yHigh Data Bandwidth (Max. 4 GB/s
Slot-to-Slot)
yRear Panel External 10 MHz Clock Input/
Output
y600 W Industrial Grade Power Supply
yCompact Benchtop Footprint
yLow Profile 4 U Rugged Design
yRemote Chassis Monitoring System
yLow Audible Operating Noise
y3 Year Warranty
Pickering Interfaces’ 42-924 PXIe Chassis provides seven
hybrid-compatible slots for application flexibility. The
chassis utilizes a single PCI segment with a dedicated
PCIe-to-PCI bridge module for the hybrid slots. The PXI
specific high accuracy clocks and trigger signals are
generated and controlled by an independent clock module
attached to the rear of the backplane.
The chassis is fitted with a 600 W industrial grade power
supply mounted at the rear of the unit with sufficient
capacity to support PXI modules with very high current
demands.
An intelligent chassis management system monitors the
power supply voltage, internal temperature and cooling
fan speed. The current condition of the chassis can be
monitored remotely via a port on the rear panel.
Two 80mm fans insure maximum PXI module cooling and
an efficient direct convection design allows the chassis to
operate over an extended ambient temperature range of
0 °C to +50 °C.
Rear of the 42-924 PXIe Chassis Showing Cooling
Air Outlets, Reference Clock Connectors, Voltage
Monitoring Port and Power Connector
Pickering’s Range of PXI & PXIe Chassis
Chassis Type Slots Chassis Size Model No.
PXI 8 4U Full Rack 40-908
PXI 14 4U Full Rack 40-914
PXI 19 4U Full Rack 40-923A
PXI 8 4U Half Rack 40-924
PXIe Hybrid (Gen 3) 8 4U Half Rack 42-924
PXIe Hybrid (Gen 3) 18 4U Full Rack 42-925
PXIe Hybrid (Gen 2) 18 4U Full Rack 42-926
PXI with LXI Control* 7 4U Half Rack 60-102D
PXI with LXI Control* 18 4U Full Rack 60-103D
PXI with LXI/USB Control 2 1U Half Rack 60-104
PXI with LXI/USB Control 4 2U Half Rack 60-105
PXI with LXI/USB Control* 6 1U Full Rack 60-106
*Includes Scan List Sequencing and optional Triggering function.

Page 1.2 PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
SECTION 1 - TECHNICAL SPECIFICATION
PXIe 8-Slot Full Hybrid Chassis, 42-924
pickeringtest.com
Specifications & Ordering Information
Operating/Storage Conditions
Operating Conditions
(operating with specified
airflow)
Operating Temperature:
Humidity:
0 °C to +50 °C
20 % to 80 % non-condensing
Storage and Transport Conditions
Storage Temperature:
Humidity:
-20 °C to +70 °C
10 % to 90 % non-condensing
Safety, CE & RoHS Compliance
All modules are fully CE compliant and meet applicable
EU directives: Low-voltage safety EN61010-1:2001,
EMC Immunity EN61000-6-1:2001,
Emissions EN55011:1998.
The 42-924 Chassis also complies with the European
Restriction of Hazardous Substances directive (RoHS).
Specifications
Number of Slots: 1 System slot with three expansion
slots.
7 PXI Express Hybrid slots.
Bus Interface: Four-link capacity PXI Express
system slot.
High data bandwidth (4 GB/s slot-
to-slot)
PXI-1 compatible with
32 bit / 33 MHz PCI bus.
Cooling
Airflow:
Per-slot Cooling
Capacity:
Fans:
Front & bottom panel intake, rear
exhaust.
50 W at 15 K
2 off 80 mm fans - 152.3 cfm
Power Supply
Input Voltage Range:
Input Frequency:
100 - 240 VAC full range
50 to 60 Hz
Supplied with a 600 W DC output power supply with the
following total capacity:
DC Outputs
+3.3 V
+5 V
+5 V aux
+12 V
-12 V
Max Current
25 A
25 A
1 A
30 A
2.5 A
Ripple
±50 mV
±50 mV
±50 mV
±100 mV
±100 mV
Chassis Monitoring
Remote Interface: Monitor port on rear panel
Frequency Standard
Source: Either 10 MHz PXI compliant
internal standard or external
10 MHz standard applied to rear
panel BNC connector.
Mechanical Specification
Cardcage: Front loading 3 U x 160mm, 8 slots,
IEEE 1101.1, 1101.10 and 1101.11
Dimensions: Width: 245.5 mm (9.67”)
Height: 177 mm (6.97”)
Depth: 315 mm (12.40”)
Weight: 3.9 kg (8.6 lbs) without PXI modules
Product Order Codes
8-Slot, 3 U, PXIe Chassis 42-924-001
Optional 19” rack mounting hardware* 63-924-001
* Please refer to the 42-924 User Manual for information
on the optional chassis mounting hardware.

Page 1.3
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering SECTION 1 - TECHNICAL SPECIFICATION
PXIe 8-Slot Full Hybrid Chassis, 42-924
pickeringtest.com
Supporting Products & Software
We also offer customized cabling and have a free online Cable Design Tool
that can be used to create custom cable solutions for many applications.
Visit: pickeringtest.com/cdt to start your design.
Mass Interconnect
We recommend the use of a mass interconnect solution when an
Interchangeable Test Adapter (ITA) is required for a PXI or LXI based
test system. Our modules are fully supported by both Virginia Panel and
MacPanel.
Pickering Reed Relays
We are the only switch provider with in-house reed relay manufacturing
capability via our Relay Division. These instrument grade reed relays
feature SoftCenter™ technology, ensuring long service life and repeatable
contact performance.
To learn more, please go to: pickeringrelay.com
Connectivity Solutions
We provide a full range of supporting cable and connector solutions for all our switching products—20 connector families
with 1200+ products. We offer everything from simple mating connectors to complex cables assemblies and terminal
blocks. All assemblies are manufactured by Pickering and are guaranteed to mechanically and electrically mate to our
modules.
Connectors & Backshells Multiway Cable Assemblies RF Cable Assemblies Connector Blocks
Programming
Pickering provide kernel, IVI and VISA (NI & Keysight) drivers which are compatible with all Microsoft supported versions of
Windows and popular older versions. For a list of all supporting operating systems, please see: pickeringtest.com/os
The VISA driver support is provided for LabVIEW Real Time Operating Systems (Pharlap and Linux-RT). For other RTOS
support contact Pickering. These drivers may be used with a variety of programming environments and applications
including:
• Pickering Interfaces Switch Path Manager
• National Instruments products (LabVIEW, LabWindows/CVI, Switch Executive, MAX, TestStand, VeriStand, etc.)
• Microsoft Visual Studio products (Visual Basic, Visual C++)
• Programming Languages C, C++, C#, Python
• Keysight VEE and OpenTAP
• Mathworks Matlab
• Marvin ATEasy
• MTQ Testsolutions Tecap Test & Measurement Suite
Drivers for popular Linux distributions are available, other environments are also supported, please contact Pickering
with specific enquiries. We provide Soft Front Panels (SFPs) for our products for familiarity and manual control, as well as
comprehensive documentation and example programs to help you develop test routines with ease.
To learn more about software drivers and development environments, please go to: pickeringtest.com/software

Page 1.4 PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
SECTION 1 - TECHNICAL SPECIFICATION
PXIe 8-Slot Full Hybrid Chassis, 42-924
pickeringtest.com
Supporting Products & Software
© Copyright (2023) Pickering Interfaces. All Rights Reserved Pickering Interfaces maintains a commitment to continuous product development, consequently we reserve the right to vary from the description given in this data sheet.
Signal Routing Software
Our signal routing software, Switch Path Manager, automatically selects and energizes
switch paths through Pickering switching systems. Signal routing is performed by simply
defining test system endpoints to be connected together, greatly accelerating Test System
software development.
To learn more, please go to: pickeringtest.com/spm
Diagnostic Relay Test Tools
eBIRST Switching System Test Tools are designed specifically for our PXI, PCI
or LXI products, these tools simplify switching system fault-finding by quickly
testing the system and graphically identifying the faulty relay.
To learn more, please go to: pickeringtest.com/ebirst
Three Year Warranty & Guaranteed Long-Term Support
All standard products manufactured by Pickering Interfaces are warranted against defective materials and workmanship
for a period of three years from the date of delivery to the original purchaser. Extended warranty and service agreements
are available for all our modules and systems with various levels to suit your requirements. Although we offer a 3-year
warranty as standard, we also include guaranteed long-term support—with a history of supporting our products for typically
15-20 years. To learn more, please go to: pickeringtest.com/support
Available Product Resources
We have a large library of product resources including success stories, product and support videos, articles and white
papers as well as application specific product brochures to assist when looking for the switching, simulation and connection
solutions you need. We have also published handy reference books on Switching Technology and for the PXI and LXI
standards.
To view, download or request any of our product resources, please visit: pickeringtest.com/resources

Page 2.1
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering SECTION 2 - TECHNICAL DESCRIPTION
SECTION 2 - TECHNICAL DESCRIPTION
MECHANICAL OVERVIEW
The 42-924 PXI Chassis comprises the following:
• Shielded 4U case with front handles and tip-up feet for desktop use
• 8-slot front card cage for 3U boards
• 8 slot 3U backplane with:
- 1 PXIe system slot 4 - 12HP
- 7 PXI Express Hybrid slots 4HP accepting PXIe modules according to the PXI Express (PXI-5)
standard as well as PXI, CompactPCI, CompactPCI Express modules
• BNC connectors for 10MHz clock input/output on the rear panel
• Integrated power supply (600W) with wide range input
• Power input module with IEC 60320-C14 connector, mains/line switch, mains/line lter and fuses
• 2x 80mm Fans for the active cooling of the boards and the power supply, controlled and monitored by
the Chassis Monitoring Module (CMM)
• Power switch with chassis status LEDs built in

Page 2.2 PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
SECTION 2 - TECHNICAL DESCRIPTION
BACKPLANE OVERVIEW
The PXIe backplane provides:
• 1 PXIe system slot
• 7 PXIe Hybrid slots
- accepting CompactPCI, PXI, CompactPCI Express, and PXIe modules.
• PCIe-to-PCI high performance bridge
- utilize a single PCI segment for the hybrid slots.
- designed to the PCI Express-to-PCI Bridge Specication 1.0 that enables applications to
migrate legacy parallel PCI bus interfaces to the advanced serial PCI Express.
- the bridge is equipped with a single lane PCI Express port and a parallel bus segment
supporting the conventional PCI operation for up to eight PCI peripheral devices concurrently.
- Primary Bus: x1 PCI Express Base Specication R1.1 compliant.
- Secondary Bus: 33MHz/32-bit PCI Local Bus Specication R3.0 compliant.
• All PXIe hybrid slots with 32-bit 33MHz PCI interface.
• 1 PXIe clock module
- generates and controls PXI specic high accuracy clocks and trigger signals.
• 4 ultra-high performance PCIe switches that operates with up to Gen 3 speeds
• All PXIe hybrid and the timing slots have an x4 PCIe link providing a maximum data bandwidth of 4GB/s each.
The architecture of the 42-924 backplane is shown in Figure 2.1

Page 2.3
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering SECTION 2 - TECHNICAL DESCRIPTION
Figure 2.1 - 42-924 PXIe Backplane Architecture

Page 2.4 PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
SECTION 2 - TECHNICAL DESCRIPTION
PCIe-to-PCI Bridge
The PCIe-to-PCI Bridge is a high performance bridge designed to the PCI Express-to-PCI Bridge Specication 1.0
that enables applications to migrate legacy parallel PCI bus interfaces to the advanced serial PCI Express.
The bridge module is equipped with a single lane PCI Express port and a parallel bus segment supporting the
conventional PCI operation for up to eight PCI peripheral devices concurrently.
Primary Bus: x1 PCI Express Base Specication R1.1 compliant.
Secondary Bus: 33MHz/32-bit PCI Local Bus Specication R3.0 compliant.
PCIe Switch
The PCIe Switch is a 24-lane, 6-port, PCIe Gen 3 switch device that enables users to connect a PCIe host to
respective endpoints via a fully transparent, high-bandwidth, non-blocking peer-to-peer interface. The default
conguration with a x4 upstream port to the host supports up to ve independent x4 down-stream clients.
Port Conguration: 1 x4 upstream port, 5 x4 downstream ports
Compatibility: PCI Express Base Specication R3.0, PCI Express Base Specication R2.0, PCI Express Base
Specication R1.0a/1.1
Figure 2.2 - 42-924 Chassis PCIe to PCI Bridge
Figure 2.3 - 42-924 Chassis PCIe Switch Architecture

Page 2.5
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering SECTION 2 - TECHNICAL DESCRIPTION
System Synchronisation Clocks
Acc. to the PXI specications, the PXIe system routes the PXI_CLK10 to slot 1-18 and PXIe_CLK100 and PXIe_
SYNC100 to the peripheral slots 2-18.
PXI_CLK10 is also routed to the external BNC connector 10MHz REF OUT at the chassis rear side.
All clocks/timing signals are generated by the PXI-5 compliant PXIe Clock Module.
When a 10MHz reference clock signal is present at the System Timing Slot or the rear panel connector 10MHz
REF IN, PXI_CLK10, PXIe_CLK100 and PXIe_SYNC100 are phase-locked to this reference clock signal
according to the following table:
PXIe Backplane Clock Modes
Mode System Timing Slot Ext. 10MHz REF In Backplane Clock Module
110MHz clock present 10MHz clock present
10 MHz REF IN, PXI_CLK10, PXIe_CLK100 and
PXIe_SYNC100 are phase-locked to reference
clock signal from System Timing Slot
110MHz clock present ─
10 MHz REF IN, PXI_CLK10, PXIe_CLK100 and
PXIe_SYNC100 are phase-locked to reference
clock signal from System Timing Slot
2─10MHz clock present
10 MHz REF IN, PXI_CLK10, PXIe_CLK100 and
PXIe_SYNC100 are aphase-locked to reference
clock signal from Ext. 10 MHz REF In
3─ ─ 10 MHz REF IN, PXI_CLK10, PXIe_CLK100 and
PXIe_SYNC100 are generated by the Clock Module
The source for the reference signal is selected automatically, if a 10MHz reference clock is present at the System
Timing Slot and the external clock input, the signal from the System Timing Slot is selected.
Figure 2.3 - 42-924 Chassis PXIe Clock Module

Page 2.6 PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
SECTION 2 - TECHNICAL DESCRIPTION
PXIe Chassis Management Module (CMM)
The PXIe Chassis Management Module (CMM) allows access from the operating system to all important chassis
functions. The CMM provides an I²C interface which is connected to backplane SMB (system slot pins XP3-a3,
-b3).
The CMM:
• Monitors all chassis voltage levels
• Monitors and control the power supply
• Monitors and control the fans
• Monitors the chassis temperatures (inlet and outlet)
• Controls SYNC100 frequency from clock module
• Controls the PXI trigger bridges
• Controls the chassis status LEDs.
Note: To use the CMM‘s full capabilities, you have to access the CMM‘s I²C register with an Embedded Controller
or another appropriately congured and programmed third party system controller. For further information see the
Chassis Management Module section of this manual.
Figure 2.3 - 42-924 Chassis Management Module

Page 3.1
PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering SECTION 3 - INSTALLATION
SECTION 3 - INSTALLATION
Refer to the Warnings and Cautions at the front of this manual
The chassis is designed for indoor use only.
!
Connecting Safety Ground
WARNING
THE 42-924 CHASSIS IS DESIGNED WITH A THREE-POSITION IEC CONNECTOR THAT CONNECTS
THE GROUND LINE TO THE CHASSIS GROUND. TO MINIMIZE SHOCK HAZARD, MAKE SURE YOUR
ELECTRICAL POWER OUTLET HAS AN APPROPRIATE EARTH SAFETY GROUND THAT IS CONNECTED
WHENEVER YOU POWER UP THE CHASSIS.
IF YOUR POWER OUTLET DOES NOT HAVE AN APPROPRIATE GROUND CONNECTION, YOU MUST
CONNECT THE FACTORY WIRE SAFETY GROUND TO THE CHASSIS. TO CONNECT THE SAFETY
GROUND, COMPLETE THE FOLLOWING STEPS:
•Connect a 16AWG (1.3mm) wire to a chassis grounding screw using a toothed grounding lug. The wire must
have green insulation with a yellow stripe or must be non-insulated (bare).
•Attach the opposite end of the wire to permanent earth ground using toothed washers or a toothed lug.
!
Unpacking
WARNING
WHEN OPENING THE SHIPPING CARTON, USE CAUTION TO AVOID DAMAGING THE CHASSIS.
Consider the following when unpacking and storing the system:
•Leave the system packed until it is needed for immediate installation.
•After unpacking the system, save and store the packaging material in case the system must be returned.
If the packaging is damaged and possible system damage is present, report to the shipper and analyze the damage.
!
INSTALLING THE CHASSIS

Page 3.2 PXIe 8-SLOT FULL HYBRID CHASSIS 42-924
pickering
SECTION 3 - INSTALLATION
INITIAL OPERATION
WARNING
THIS EQUIPMENT IS INTENDED TO BE ACCESSED, TO BE INSTALLED AND MAINTAINED BY QUALIFIED
AND TRAINED SERVICE PERSONNEL ONLY.
•Ensure that the system has not been damaged during transport, storage or assembly
•Check the Protective Earth (PE) resistance, should be < 0,1Ω
•Plug-in the boards
•Ensure that all open Slots are covered with ller panels
•Ensure that the switch INHIBIT MODE on the rear panel is set to DEF
•Ensure that the switch FAN SPEED on the rear panel is set to AUTO
•Connect the power cable and switch on the Mains Supply Switch on the rear panel.
•Push the power button on the front panel to switch on the system
!
Figure 3.1 - 42-924 Chassis Front Panel Features
PXIe Hybrid
Peripheral Slots
System
Controller
Slot
PS-ON
Switch With
Status LEDs
Air Intake
Filler Panels for
4/8HP System
Controller Slot
Extension
