Page 1.1
R.F. CHANGEOVER RELAY MODULE 20-711
pickering SECTION 1 - TECHNICAL SPECIFICATION
pickeringtest.com
GPIB 2/3GHz RF Switch Module 20-710A/711
ISSUE 4.4 JUL 2019
• 8 or 16 x SPDT Changeover Switches with
Bandwidths to over 3GHz
• Choice of Front Panel Mounted BNC, SMA,
SMB, BT Type 43 or 1.0/2.3 Connectors
• Insulated Coaxial Version Available
• Suitable for Building Large Switching
Networks
• Tree Networks Constructed by Interconnecting
Switches
• 75Ω Version Suitable for Telecoms and High
Quality Video Switching
• Also Suitable For Low Frequency Shielded
Applications
Switching Diagram for the 20-710A 8 x SPDT
R.F. Relay Module
Relay 1
Relay 2
Relay 3
Relay 4
C
C
C
C
Relay 5
Relay 6
Relay 7
Relay 8
C
C
C
C
NO
NC
NO
NC
NO
NC
NO
NC
NO
NC
NO
NC
NO
NC
NO
NC
Models 20-710A and 20-711 have a bank of 8 or 16 individual high
performance R.F. changeover relays (50Ωor 75Ω) with very low
insertion loss, suitable for handling signals up to 3000MHz.
Available with a choice of connectors: Industry standard BNCs are
suitable to beyond 1000MHz, for higher performance applications
SMA, SMB, BT Type 43 or 1.0/2.3 connector versions are available,
all featuring very low insertion loss & good VSWR with bandwidths
to beyond 3GHz.
The 75Ωversions are suitable for high frequency video and
telecommunication signals up to 3GHz (e.g. 622MBit data).
Programming
The RF module is simple to program either by single relay or by
pattern (8 or 16 relays simultaneously):
ARESET a Open all switches on module a
CLOSE a,b Close switch number bon module a
DELAY t Force a minimum delay of tmilliseconds
between two instructions
OPEN a,b Open switch number bon module a
RESET Open all switches on all modules
VIEW? a[,b] View status of module a, can be viewed at
any time either as a byte or by switch as a
logical value (1 or 0)
WRITE a,w Send byte wto module a
*Please contact Pickering for alternative
PXI/LXI/USB solutions
*
SECTION 1 - TECHNICAL SPECIFICATION

Page 1.2 R.F. CHANGEOVER RELAY MODULE 20-711
pickering
SECTION 1 - TECHNICAL SPECIFICATION
2/3GHz RF Switch Module – 20-710A/711
pickeringtest.com
Specifications
General Specification (All Versions)
Max Switching Power:
Max Switching Voltage:
Max Switching Current:
Nominal Switching Capacity:
10W
30VDC
0.5A
0.01A, 24VDC,
[email protected]
On Path Resistance:
Off Path Resistance:
Differential Thermal Offset:
<200mΩ
>108Ω
<20µV
Switching Time: 10ms
Expected Life, Mechanical:
Expected Life, Electrical:
>1x106ops
>3x105 ops
(10mA@24VDC)
>3x105 ops
([email protected])
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
Altitude:
0°C to +55°C
Up to 95% non-condensing
5000m
Storage and Transport Conditions
Storage Temperature:
Humidity:
Altitude:
-20°C to +75°C
Up to 95% non-condensing
15000m
Mechanical Characteristics
All modules conform to the 6U height (262mm) Eurocard standard
and are 160mm deep. Panel width is:
• 1.8 Inch for 20-710A
• 2.4 Inch for 20-711 all versions, except BNC
• 3.6 Inch for 20-711 BNC versions
Note: The 20-710A is an update to the older 20-710, the only
changes have been in improved RF performance, module width
reduced from 2.4 to 1.8 Inches and wider connector choice.
0 dB
-0.8 dB
-1.2 dB
-1.6 dB
-2.0 dB
-2.4 dB
-2.8 dB
-0.4 dB
750MHz 1500MHz 2250MHz
20-710 INSERTION LOSS
-3.2 dB
3000MHz
BNC (50Ohm)
SMA (50Ohm)
BNC (75Ohm)
750MHz 1500MHz 2250MHz
20-710 VSWR
(RETURN LOSS)
1.6
1.4
1.2
1.0
1.8
3000MHz
13dB
16dB
21dB
11dB
VSWR
Return Loss
26dB
SMA (50Ohm)
BNC (50Ohm)
BNC (75Ohm)
-80 dB
-90 dB
-70 dB
-100 dB
500MHz 1000MHz 1500MHz
20-710 ISOLATION
2000MHz
-40 dB
-50 dB
-60 dB
-30 dB
-50 dB
-60 dB
-70 dB
-80 dB
-90 dB
-40 dB
500MHz 1000MHz 1500MHz
20-710 CROSSTALK
2000MHz
Typical RF Performance Plots for 20-710
90%
50%
10%
100pS 200pS 300pS
20-710A-511 TYPICAL
STEP RESPONSE
180pS
Step Response
Plot for 20-710
Isolation and Crosstalk Specification
Isolation (0 to 2000MHz):
Crosstalk (0 to 2000MHz):
>40dB
>45dB
20-710A 50Ω Specification (SMA & SMB)
Maximum Frequency:
Rise Time:
Insertion Loss:
V.S.W.R. (0 to 2000MHz):
3000MHz
<0.2ns
<3dB
1:1.7
20-710A-501 50Ω Specification (BNC)
Maximum Frequency:
Rise Time:
Insertion Loss:
V.S.W.R. (0 to 2000MHz):
1000MHz
<0.2ns
<3dB
1:1.7
20-710A-701 75Ω Specification (BNC)
Maximum Frequency:
Rise Time:
Insertion Loss:
V.S.W.R. (0 to 2000MHz):
1000MHz
<0.3ns
<3dB
1:1.7

Page 1.3
R.F. CHANGEOVER RELAY MODULE 20-711
pickering SECTION 1 - TECHNICAL SPECIFICATION
2/3GHz RF Switch Module – 20-710A/711
pickeringtest.com
Ordering Information
© Copyright (2019) Pickering Interfaces. All Rights Reserved Pickering Interfaces maintains a commitment to continuous product development, consequently we reserve the right to vary from the description given in this data sheet.
Product Customization
Pickering System 20 modules are designed and manufactured
on our own exible manufacturing lines, giving complete product
control and enabling simple customization to meet very specic
requirements.
Customization can include:
• Alternative relay types
• Mixture of relay types
• Alternative number of relays
• Different performance specications
All customized products are given a unique part number, fully
documented and may be ordered at any time in the future. Please
contact your local sales ofce to discuss.
Product Order Codes
8 x Changeover RF Relay (SPDT):
1300MHz, BNC, 50Ω
3000MHz, SMA, 50Ω
3000MHz, SMB, 50Ω
20-710A-501
20-710A-511
20-710A-521
1300MHz, BNC, 75Ω
2000MHz, Type 43/SMZ, 75Ω
2000MHz, 1.0/2.3, 75Ω
20-710A-701
20-710A-711
20-710A-741
16 x Changeover RF Relay (SPDT):
1300MHz, BNC, 50Ω
3000MHz, SMA, 50Ω
3000MHz, SMB, 50Ω
20-711-501
20-711-511
20-711-521
1300MHz, BNC, 75Ω
2000MHz, Type 43/SMZ, 75Ω
2000MHz, 1.0/2.3, 75Ω
20-711-701
20-711-711
20-711-741
Options:
Insulated Shield, where all the shields are floating -I
Alternative connectors are available on
many modules e.g. 75Ω mini SMB etc -C
Safety & CE Compliance
All modules are fully CE compliant and meet applicable EU
directives: Low-voltage safety EN61010-1:2010, EMC Immunity
EN61326-1:2013, Emissions EN55011:2009+A1:2010.
Mating Connectors & Cabling
50Ω SMB to SMB Lead, 1m Length
50Ω SMA to SMA Lead, 1m Length
50Ω BNC to BNC Lead, 1m Length
75Ω BNC to BNC Lead, 1m Length
75Ω 1.0/2.3 to 1.0/2.3 Lead, 1m Length
75Ω SMZ to SMZ Lead, 0.5m Length
10-987-510
10-981-510
10-980-510
10-980-710
40-977-731
10-988-705
For other connection accessories for this series of modules please
refer to the 90-011D RF Cable Assemblies data sheet where a
complete list and documentation can be found for accessories, or
refer to the Connection Solutions catalog.

Page 1.4 R.F. CHANGEOVER RELAY MODULE 20-711
pickering
SECTION 1 - TECHNICAL SPECIFICATION
Mechanical Specications
Voltage Supplies
Logic Supply 5Vdc ±5%
Relay Supply 12Vdc ±10%
† Approx. dimensions. Standard 160mm Eurocard.
Model 20-711
All versions, except BNC
Model 20-711
BNC Versions
Approx. Weight 1kg 1kg
Dimensions (mm) 6U Eurocard as specied in DIN41494
Front Panel Width 61.0 91.4
Height 268 268
Overall Length † 189 189

Page 2.1
R.F. CHANGEOVER RELAY MODULE 20-711
pickering SECTION 2 - TECHNICAL DESCRIPTION
SECTION 2 - TECHNICAL DESCRIPTION
FUNCTIONAL DESCRIPTION
Figure 2.1 - R.F Changeover Relay Module: Functional Block Diagram
RELAY STATUS LEDs
SIMM RELAY CARDS
SIMM
CONTROLLER
PCB ASSY
FRONT PANEL CONNECTORS
RELAY
COILS
RELAY
CONTACTS
TO FRONT
PANEL
DRIVER
ICs
STATUS LEDs
TO FRONT
PANEL
SIMM
MOTHERBOARD
CONNECTOR J1
A functional block diagram is provided in Figures 2.1. The module is powered via the chassis connector J1 with +12V
relay and +5V logic supplies. The interface to the user test equipment is via the front panel mounted connectors. The
module comprises a Versatile SIMM Motherboard, a SIMM Controller PCB Assy and SIMM Relay Cards populated
with electro-mechanical relays.
The module is available as a 16 channel R.F switch utilising SPDT changeover relays with a choice of front panel
connectors. The relay drivers on the SIMM Relay Cards are fed with serial data from the SIMM Controller. Relay
switching is determined by operator programming. General status LEDs are provided on the front panel depending
on the module.

Page 2.2 R.F. CHANGEOVER RELAY MODULE 20-711
pickering
SECTION 2 - TECHNICAL DESCRIPTION
THIS PAGE INTENTIONALLY BLANK

Page 3.1
R.F. CHANGEOVER RELAY MODULE 20-711
pickering SECTION 3 - INSTALLATION
Page 3.1
GENERAL PURPOSE REED RELAY MODULE 20-110/115/120/125
pickering SECTION 3 - INSTALLATION
SECTION 3 - INSTALLATION
Power Supply
with
Interface Module
above
6U System 20 Modules
(Not position dependent)
3U System 10 Modules
(Not position dependent)
kg
PRE-OPERATION CHECKS (UNPACKING)
1. Check the module for transport damage and report any damage immediately to Pickering Interfaces.
Do not attempt to install the product if any damage is evident.
2. Position the chassis relative to any other equipment the module(s) will connect with. Ensure the chassis is not
connected to the electrical supply.
3. Ensure that the designated area for the chassis containing the module is of at and solid construction to
withstand and support the combined weight of the module(s) and chassis.
!
Refer to the Warnings and Cautions at the front of this manual
Modular products require installation in a suitable System 10/20 chassis.
The module is designed for indoor use only.
!
HARDWARE INSTALLATION
ELECTRICAL CONNECTION (CHASSIS)
1. The chassis must be electrically installed in accordance with local regional electrical codes by a qualied
engineer.
2. Ensure the power supply lead provides the necessary integrity of chassis ground.
Electrostatic discharge can damage the components on the module. To avoid such damage in handling the
board refer to page VII.
Ensure that there is adequate ventilation.
Figure 3.1 - System 10/20 Front Access Case Split 24/60 with Various Modules Fitted.

Page 3.2 R.F. CHANGEOVER RELAY MODULE 20-711
pickering
SECTION 3 - INSTALLATION
Page 3.2 GENERAL PURPOSE REED RELAY MODULE 20-110/115/120/125
pickering
SECTION 3 - INSTALLATION
Figure 3.2 - Module Guide Rail Position
Figure 3.3 - A Partially Built System 20 Front Access Chassis
!
MODULE INSTALLATION
The module should be installed in accordance with the following procedure:
1. Ensure that the system is turned OFF but still connected to mains so that it remains grounded.
2. If the module has address switches ensure they are set to the appropriate position. (See Section 4).
Note individual modules are not sent out with a system drawing detailing their address.
3. Choose an appropriate slot in the rack and remove the blanking plate (if tted).
(See the Pickering 10-910M IEEE-488 GPIB System 10/20 Ancillaries manual for further details).
(When tted, additional modules will be automatically recognised by the interface card. See Figure 3.1).
4. If necessary t the module guide rails as supplied with the module to both the top and bottom of the chassis
in that slot position. One guide rail slot should be to the left of the connector as shown in Figure 3.2.
5. Align the module with the backplane and screw holes at the front of the chassis.
Hold the handle whilst slowly sliding the module into the card guides until the module seats rmly into the
backplane. See Figure 3.4. The front panel of the module should be ush with the front or rear panel of the
chassis.
6. Screw the front panel of the module to the chassis front panel mounting rails.
7. Ensure all necessary modules including the power supply are tted to the rack and other slots blanked off
before powering up.
To achieve the correct initialisation of the sytem, ensure any slave chassis are powered up before the master
chassis.

Page 3.3
R.F. CHANGEOVER RELAY MODULE 20-711
pickering SECTION 3 - INSTALLATION
Page 3.3
GENERAL PURPOSE REED RELAY MODULE 20-110/115/120/125
pickering SECTION 3 - INSTALLATION
Figure 3.4 - Module Insertion in a Pickering 20-935A-001 Front Access Chassis
SOFTWARE INSTALLATION
Refer to the Pickering manual 10-921M.
For the latest version of the driver please refer to our web site pickeringtest.com where links to our Software
Download page will provide the driver software for the various programming environments encountered.
Self-Test is invoked at power on and may also be operated under software control (*TST?). Self-Test pass is indi-
cated on a front panel LED with a full pass/fail description available using the DIAGNOSTIC? command.
The Self-Test is a 1 Level Test, see Figure 3.5:
1. Logic Test: Checks all logic including on-board microprocessor, relay drivers etc.
Note: In the unlikely event of a relay needing replacement additional relays are available from Pickering Interfaces.
Self-Test Operation
Self-Test is always run at power on. If self-test is run under software control it will rstly clear the whole matrix
(Manual Test will only function when the module is in a clear state). When the self-test has nished the matrix will
be returned to an all clear state (i.e. the previous state will not be remembered!).
Please note that because of the long self-test time, your computer may time out waiting for the test result (many
PC's have default timeouts set to low values).
Detailed Self-Test Reporting using the DIAGNOSTIC? Query
The DIAGNOSTIC? query will give an ASCII string detailing any self test failures. These will include:
Logic: Microprocessor, RAM, EPROM, Relay Drivers, Invalid Link Settings etc.
This string is not intended to be processed by the user’s software, it is suitable for copying directly onto the screen
of your control computer. This information will then indicate maintenance required (please contact Pickering for
further help).
SELF-TEST FUNCTION

Page 3.4 R.F. CHANGEOVER RELAY MODULE 20-711
pickering
SECTION 3 - INSTALLATION
Figure 3.5 - Self-Test: Basic Flow Diagram
SELF TEST INITIATED BY:
• POWER ON
• *
TST? QUERY
CLEAR MODULE
LOGIC TEST:
• MICROPROCESSOR BOARD
• RELAY BOARD
LOGIC TEST
FAIL ?
SELF TEST PASS
SELF TEST FAIL:
• ERROR LED ON
• USE DIAGNOSTIC?
COMMAND TO GET
ERROR MESSAGE
Yes
No

Page 4.1
R.F. CHANGEOVER RELAY MODULE 20-711
pickering SECTION 4 - PROGRAMMING GUIDE
SECTION 4 - PROGRAMMING GUIDE
Selecting the Module Address
The module internal address is factory pre-set however this can be recongured through software as required.
Please contact the factory as necessary.
PROGRAMMING THE MODULE
Figure 4.1 - A USB/GPIB Interface Lead
Programming Using the Intelligent GPIB/RS-232 Interface
The programming computer will need a GPIB card, a USB to GPIB Interface (Figure 4.1) or an Ethernet connection
to talk to the interface and communicate with the system depending on the type of interface tted.
• A 10-921-001 Interface requires either a GPIB or RS-232 connection.
• A 10-922-001 Interface requires an Ethernet connection.
General Programming Commands
ARESET a Open all switches on device a
CLOSE a,b Close switch number b on module a
DELAY t Force a minimum delay of t milliseconds between two instructions
OPEN a,b Open switch number b on module a
RESET Open all switches on all modules
VIEW? a View status of device a
WRITE a,w Send byte w to module a
Programming Examples
The following are simple examples of how to program the module:
To close relay number 3 on module 21. CLOSE 21,3
Now look at status of relay 3 on module 21. VIEW? 21,3 will return “1".
To close all relays on module at address 21. WRITE 21,255
Now to look at module 21 status. VIEW? 21 will return “255".
For further information on programming see the Pickering Interfaces manual for the interface used.

Page 4.2 R.F. CHANGEOVER RELAY MODULE 20-711
pickering
SECTION 4 - PROGRAMMING GUIDE
THIS PAGE INTENTIONALLY BLANK
