Pico macom Mpc-hss User manual

Installation and

Operation Manual

MPC-HSS

Replacement Single Power Supply Module

Operation

Manual

Rev. 06/03

Ph:800-421-6511 www.picomacom.com

MPC-HSS

Rev. 06/03 Ph:800-421-6511 www.picomacom.com

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of un-insulated “dangerous voltage”within the

product’s enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

Product Inspection

Inspect the equipment for shipping damage. Should any damage be discovered, immediately file a claim with the carrier.

Important Safety Instructions

To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions

or comments about the MPC-HSS power supply, please contact your dealer or have him contact the PICO MACOM Service Center at these

phone numbers: 800-421-6511, 818-493-4300.

1.Read Instructions: All safety and operating instructions should

be read before the appliance is operated.

2. Retain Instructions: The safety and operating instructions

should be retained for future reference.

3. Heed Warnings: All warnings on the appliance should be

adhered to.

4. Follow Instructions: All operating and user instructions should

be followed.

5. Cleaning: Unplug this appliance from the wall outlet before clean-

ing. Use a damp cloth for cleaning. Do not use liquid cleaners or

aerosol cleansers.

6. Do Not Use Attachments: Use of attachments not recommended

by the manufacturer may cause hazards.

7. Water and Moisture: Do not use this product near water—for

example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet

basement, or near a swimming pool—and the like.

8.Accessories: Do not place this product on an unstable cart,

stand, tripod, bracket, or table.The product may fall, causing serious

injury to a child or adult, and serious damage to the appliance.

9. Ventilation: This video product should never be placed near or

over a radiator or heat register. This video product should not be

placed in a built-in installation such as a bookcase or rack unless

proper ventilation is provided or the manufacturer’s instructions have

been adhered to. Any slots or opening in the cabinet are provided for

ventilation. To ensure reliable operation of the video product and to

protect it from overheating, these openings must not be blocked or

covered.Openings should never be blocked by placing the product on

a bed, sofa, rug, or other similar surface.

10. Grounding or Polarization: This video product is equipped with

either a three prong plug for 110 VAC use or a two prong flat blade

220 VAC type plug. Each type is to be inserted into only the type of

receptacle for which they specifically designed. Do not cut off the

round grounding pin in order to be able to fit into a two prong recep-

tacle as this could cause injury and will void the warranty.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE. DO NOT OPEN THE CABINET.

REFER SERVICING TO QUALIFIED PERSONNEL ONLY.

CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION

CORD RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED

TO PREVENT BLADE EXPOSURE.

ATTENCION: POUR PREVENIR LES CHOCS ELECTRIQUES, NE PAS UTILISER CETTE FICHE POLARISEE AVEC

UN PROLONGATEUR, UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT, SAUF SI

LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT.

Safeguards

MPC-HSS

Rev. 06/03

Ph:800-421-6511 www.picomacom.com

Safeguards

11. Power Sources: This product should be operated only from the

type of power source indicated on the marking label. If you are not

sure of the type of power supplied to your home, consult your appli-

ance dealer or local power company.

12. Power-cord Protection: Power-supply cords should be routed

so they are not likely to be walked on or pinched by items placed upon

or against them. Pay particular attention to cords and plugs, conven-

ience receptacles, and the point where they exit from the appliance.

13. Lightning: For added protection for this product during a lightning

storm, or when it is left unattended or unused for long periods of time,

the unit should be disconnected from power source.

14. Power Lines: An outside antenna system should not be located

in the vicinity of overhead power lines, other electric light or power cir-

cuits, where it can fall into such power lines or circuits.When installing

an outside antenna system, extreme care should be taken to keep

from touching such power lines or circuits as contact with them may

be fatal.

15. Overloading: Do not overload wall outlets and extension cords as

this can result in risk of fire or electric shock.

16. Object and Liquid Entry: Never push objects of any kind into this

product through openings as they may touch dangerous voltage

points or short-out parts that could result in a fire or electric shock.

Never spill liquid of any kind on the product.

17. Servicing: Do not attempt to service this product yourself as

opening or removing covers may expose you to dangerous voltage or

other hazards. Refer all servicing to qualified service personnel.

18. Damage Requiring Service: Unplug this product from the wall

outlet and refer servicing to qualified service personnel under the

following conditions:

a. When the power-supply cord or plug is damaged.

b. If liquid has been spilled, or objects have fallen into the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following the oper-

ating instruction. Adjust only those controls that are covered by

the operating instructions. An improper adjustment may result in

damage and will often require extensive work by a qualified tech-

nician to restore the product to its normal operation.

e. If the product has been dropped or the cabinet has been

damaged.

f. When the product exhibits a distinct change in performance—

this indicates a need for service.

19. Replacement Parts: When replacement parts are required, be

sure the service technician has used replacement parts specified by

the manufacturer or have the same characteristics as the original

parts. Unauthorized substitutes may result in fire, electric shock or

other hazards.

20. Safety Check: Upon completion of any service or repairs to this

product, ask the service technician to perform safety checks to deter-

mine that the product is in proper operating conditions.

21. Outdoor Antenna Grounding: Before attempting to install this

product, be sure the antenna or cable system is grounded so as to

provide some protection against voltage surges and built-up static

charges.

a. Use No.10 AWG (5.3mm) copper, No.8 AWG (8.4mm) alu-

minum, No.7 AWG (10mm) copper-clad steel or bronze wire or

larger, as ground wire.

b. Secure antenna lead-in and ground wires to house with stand-

off insulators spaced from 4 feet (1.22m) to 6 feet (1.83m) apart.

c. Mount antenna discharge unit as close as possible to where

lead-in enters house.

d. A driven rod may be used as the grounding electrode where

other types of electrode systems do not exist. Refer to the

National Electrical Code, ANSI/NFPA 70-1984 for information.

e. Use jumper wire not smaller than No.6 AWG (13.3mm) copper

or equivalent, when a separate antenna grounding electrode is

used.

NOTE TO THE CATV SYSTEM INSTALLER

THIS REMINDER IS PROVIDED TO CALL THE CATV SYSTEM

INSTALLER’S ATTENTION TO ARTICLE 820-22 OF THE NEC

THAT PROVIDES GUIDELINES FOR PROPER GROUNDING

AND, IN PARTICULAR, SPECIFIES THAT THE CABLE

GROUND SHALL BE CONNECTED TO THE GROUNDING

SYSTEM OF THE BUILDING, AS CLOSE TO THE POINT OF

CABLE ENTRY AS PRACTICAL.

MPC-HSS

Descriptions

The MPC-HSS is a replacement unit for the MPC12R, a hot-swapable redundant power

supply is a highly compact series of 78 watt multiple output modules specifically

designed for mini-modulator application that require ultra-reliable DC input supply. This

series combines an advanced forward converter topology use of extensive surface mount

technology to achieve excellent power density. Sophisticated packaging and filtering

techniques are utilized thus minimizing the need for overall system filtering. The

MPC12R employs current sharing and redundant power supply design to equally share

loads between the supplies and minimize the potential for power bus glitches after a

power supply has failed, thereby improving the longevity of the power supply.Automated

manufacturing process and value engineering ensure an outstanding level of quality,

timely delivery and competitive cost.This type of power supply design eliminates down

time forever. Pico Macom, Inc. backs the product with a five-year limited warranty.

Replacement Single Power Supply Module

MPC-HSS

N+1 redundancy ensures the

power supply is configured for

dual supply operation, which

allows for hot insertion or

removal of the power supply

modules without powering down

the system

High efficiency >75% redundant

power supplies guarantees zero

down time

Home run DC cables allow removal

of individual modules without

disabling the entire system

High isolation ORing diodes (block-

ing diodes) provide short circuit

protection to the power supply by

preventing a failed supply from

causing a general system shut

down in a fault condition and also

preventing the output capacitors

of a hot inserted power supply

from draining power from the

power bus causing disturbance

Current sharing and redundant

design ensures increases in the

total amount of available load

current by providing de-ration for

the individual supplies thereby

improving their long-term reliability

Internal fusing circuitry provides

current overload protection and

precise volt-age regulation pre-

venting component damage

Status monitoring and control via

front panel LED display

Replacement Single Power Supply Module

Rev. 06/03 Ph:800-421-6511 www.picomacom.com

MPC-HSS

Specifications

Input Voltage Range: 90-264 VAC

Input Frequency: 47-63Hz

Output Specifications: V1 5VDC/4A

V2 12VDC/3.5A

V3 30VDC/.27A

Efficiency: >75% typical

Operating Frequency: 100 Khz

Input Inrush Current: <30A @ 115VAC @ 25°C

Line Protection: PCB AC line fuse

DC Output Ripple: Within 1% (Vpp) at maximum

load @ 25°C @ PS output

terminal

Line/Load Regulation: ±1%

Minimum Load: 10% of full rated load

Operating Temperature: 0 to 60°C

Storage Temperature: -40 to 85°C

Overcurrent Protection: No damage to outputs when

shorted to ground

Power Supply

Ordering Information

Replacement Single Power Supply Module

Input: IEC 320 Power Inlet

(on back plane)

Output Connector: (6X) JST B12B-XH-A, or Eq.

(on back plane/

each connector)

12 PIN V4 PIN V

1,5,9 5 1 5

2,6,10 12 2 12

3,7,11 RET 3 RET

4,8,12 30 4 30

Connectors

Front View Rear View

MPC-HSS

Replacement Single Power Supply Module

Rev. 06/03

www.picomacom.com

Ph:800-421-6511

MPC-HSS

Rev. 06/03 Ph:800-421-6511 www.picomacom.com

Installation Procedure

1. Power: This LED will illuminate when module is powered on.

2. Top Edge: This edge aligns with top guide channel of chassis.

3. Bottom Edge: This edge aligns with bottom guide channel of chassis.

POWER

Front and Side Views

1. Align the top and bottom edge of module with the guide channel in chassis.

2. Slide module into chassis until firmly seated and front LED has illuminated.

MODULE REPLACEMENT

1. Remove by sliding module out of the front of chassis

2. Insert replacement by Aligning the top and bottom edge of module with the guide channel in chassis.

3. Slide module into chassis until firmly seated and front LED has illuminated.

OPERATION & CARE

Dos & Don’ts

•Always operate in a cool well ventilated environment.

•Always provide a stable conditioned power source.

•Heed all safety warnings and obey all environmental and electrical operating requirements.

•To clean, use a damp cloth only and clean only with mild soap.

•Do not use solvents or harsh detergents.

•Do not use this product for purposes other than intended.

Installation

MPC-HSS

Warranty

Limited Warranty

Pico Macom warrants to the original purchaser that all of its new products are of sound design, quality materials and workmanship at the time of manufacture

and will be free from related defects for one year from the original purchase date. Pico Macom will repair or, at its discretion, replace without cost to the original

purchaser, the product which, upon inspection by Pico Macom, appears to be defective or not conforming to factory specifications. Pico Macom will cover the cost

of parts, labor, and return freight from factory.

Five-Year Limited Warranty

Most products designated as “Headend Electronics”are further covered by an extended 4-year period beyond the expiration of the original 1-year warranty, for a full

5-year period. Qualified equipment requiring factory repair during the extended 4-year period is covered under our re-certification program. Re-certification fees

under this program shall not to exceed 20% of the product’s List Price and whenever possible, Pico Macom will attempt to upgrade performance to the latest

improved specification.

Warranty Limitations

This warranty excludes coverage of damage or inoperability resulting from (1) use or installation other than in strict accordance with Pico Macom’s written instruc-

tions, (2) disassembly or repair by someone other than Pico Macom or a Pico Macom authorized repair center, (3) misuse, misapplication or abuse, (4) alteration,

(5) lack of reasonable care or (6) wind, ice, snow, rain, lightning, power surges, or any other weather conditions or acts of God. Pico Macom’s warranty with respect

to third-party proprietary sub-assembly modules and/or private-label products are limited to the duration and terms of third-party vendors’ warranty. Pico Macom

shall in no event and under no circumstances be liable or responsible for any consequential, indirect, incidental, punitive, direct or special damages based upon

breach of warranty, breach of contract, negligence, strict tort liability or otherwise or any other legal theory, arising directly or indirectly from the sale, use, installa-

tion or failure of any product acquired by buyer from Pico Macom.This limited warranty extends to the original purchaser. Pico Macom reserves the right to modify

or discontinue this warranty at Pico Macom’s sole discretion without notification. No other warrantees are expressed or implied.

Uptime Loaner Program

Our Uptime loaner program is designed to provide domestic users of our headend products and commercial systems the best possible support and service.This

program is established to minimize downtime resulting from equipment failure in critical service situations. We offer this program free-of-charge (excluding freight)

to qualified purchasers within the warranty period.The program provides a free equipment loan of like qualified equipment enabling seamless operation for the time

required to repair and return the unit.

The process is simple. Call our Customer Service desk requesting a return-merchandise-authorization (RMA) number for the failed equipment and ask for a loaner

unit. We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box

and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner

unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.

To qualify for the program, you must have current open-terms with us and in good standing. We must receive your failed unit within one week after the loaner unit

is shipped to you, and must likewise receive the loaner unit within one week after the repaired unit is shipped back to you. Daily rental fees not to exceed 10% of

the equipment’s List Price will apply beyond one week after the loaner or repaired unit are shipped to you. Other limitations may apply, so please call us for addi-

tional information on qualifying equipment and procedures. Pico Macom reserves the right to modify or discontinue the Uptime Loaner Program at any time, and at

its sole discretion.

Damage or Shortage Claims

Our shipping staff carefully packs and ships your orders in compliance with common carriers’ requirements. Please make note of any obvious damage or shortage

on the freight bill or carrier’s receipt next to your signature. The carrier’s agent must too sign acknowledging the loss. Failure to do so may result in the carrier’s

refusal to honor the claim. Please open your order immediately upon receipt to check for concealed damage and compare the packing list to the items shipped. If

damaged, keep the original shipping cartons for possible inspection by the carrier.You must report claims for loss or damage within 3 days of delivery, while claims

for erroneous charges or price corrections must be presented within 30 days of invoice date.

Returning Shipped Items

To return any shipped items, including those shipped for warranty repairs or credit, call our Customer Service desk to request a Return Merchandise Authorization

(RMA) number. Please reference the original invoice number and purchase date, and product serial number (if any). Be certain to mark the RMA number on the

package boldly and legibly. Unless we specify a different carrier, please ship your returned items to us via UPS freight prepaid and fully insured. If returned for

credit, we will promptly process your request upon receipt of your return order.

Our Return Policy: Your Satisfaction Guaranteed

Our goal is your complete satisfaction. If for any reason, our products were not quite what you anticipated, simply call your customer service rep and

we will be happy to assist you in replacing or returning the order.You may return current, non-discontinued items for full credit for up to 30 days from
