Pioneer AVIC-Z610BT User manual

English Français Italiano Español Deutsch Nederlands
AVIC-Z910DAB
AVIC-Z810DAB
AVIC-Z710DAB
AVIC-Z610BT
AVIC-Z7110DAB
AVIC-Z6110BT
NAVIGATION AV SYSTEM
SYSTEME DE NAVIGATION AV
SISTEMA DI NAVIGAZIONE AV
SISTEMA DE NAVEGACIÓN AV
NAVIGATIONS-/AV-SYSTEM
AV NAVIGATIESYSTEEM Installation Manual
Manuel d'installation
Manuale d'installazione
Manual de instalación
Installationsanleitung
Installatiehandleiding

2En
•The navigation features of this product
(and the rear view camera option if
purchased) are intended solely to aid you
in the operation of your vehicle. It is not a
substitute for your attentiveness,
judgement and care when driving.
•Never use this product to route to
hospitals, police stations, or similar
facilities in an emergency. Please call the
appropriate emergency number.
•Do not operate this product, any
applications, or the rear view camera
option (if purchased) if doing so will
divert your attention in any way from the
safe operation of your vehicle. Always
observe safe driving rules and follow all
existing traffic regulations. If you
experience difficulty in operating this
product, pull over, park your vehicle in a
safe location and apply the handbrake
before making the necessary
adjustments.
•This manual explains how to install this
product in your vehicle. Operation of this
product is explained in the separate
manuals.
•Do not install this product where it may
(i) obstruct the driver’s vision,
(ii) impair the performance of any of the
vehicle’s operating systems of safety
features, including airbags, hazard lamp
buttons, or
(iii) impair the driver’s ability to safely
operate the vehicle.
In some cases, it may not be possible to
install this product because of the vehicle
type or the shape of the vehicle interior.
•Model icons shown in this manual
indicate that the description is intended
for the models indicated by the icons. If
the following icon is shown, the
description is applied only to the model
shown.
e.g.)
WARNING
Pioneer does not recommend that you
install this product yourself. This product is
designed for professional installation only.
We recommend that only authorised
Pioneer service personnel, who have
special training and experience in mobile
electronics, set up and install this product.
NEVER SERVICE THIS PRODUCT YOURSELF.
Installing or servicing this product and its
connecting cables may expose you to the
risk of electric shock or other hazards, and
can cause damage to this product that is
not covered by warranty.
•Read this manual fully and carefully
before installing this product.
•Keep this manual handy for future
reference.
•Pay close attention to all warnings in this
manual and follow the instructions
carefully.
•This product may in certain
circumstances display inaccurate position
of your vehicle, the distance of objects
shown on the screen, and compass
directions. In addition, the system has
Connection
Precautions
Your new product and this
manual
Important safeguards
Z000DAB
certain limitations, including the inability
to identify one-way streets, temporary
traffic restrictions and potentially unsafe
driving areas. Please exercise your own
judgement in the light of actual driving
conditions.
•As with any accessory in your vehicle’s
interior, this product should not divert
your attention from the safe operation of
your vehicle as it may result in serious
injury or death. If you experience
difficulty in operating the system or
reading the display, please make
adjustments while safely parked.
•Please remember to wear your seat belt
at all times while operating your vehicle.
If you are in an accident, your injuries can
be considerably more severe if your seat
belt is not properly fastened.
•Certain country and government laws
may prohibit or restrict the placement
and use of this product in your vehicle.
Please comply with all applicable laws
and regulations regarding the use,
installation and operation of this product.
WARNING
Do not take any steps to tamper with or
disable the handbrake interlock system
which is in place for your protection.
Tampering with or disabling the
handbrake interlock system could result in
serious injury or death.
CAUTION
•If you decide to perform the installation
yourself, and have special training and
experience in the mobile electronics
installations, please carefully follow all of
the steps in the installation manual.
•Secure all wiring with cable clamps or
electrical tape. Do not allow any bare
wiring to remain exposed.
•Do not directly connect the yellow lead of
this product to the vehicle battery. If the
lead is directly connected to the battery,
engine vibration may eventually cause
the insulation to fail at the point where
the wire passes from the passenger
compartment into the engine
compartment. If the yellow lead’s
insulation tears as a result of contact with
metal parts, short-circuiting can occur,
resulting in considerable danger.
•It is extremely dangerous to allow cables
to become wound around the steering
column or gearstick. Be sure to install this
product, its cables, and wiring away in
such so that they will not obstruct or
hinder driving.
•Make sure that the cables and wires will
not interfere with or become caught in
any of the vehicle’s moving parts,
especially the steering wheel, gearstick,
handbrake, sliding seat tracks, doors, or
any of the vehicle’s controls.
•Do not route wires where they will be
exposed to high temperatures. If the
insulation heats up, wires may become
damaged, resulting in a short circuit or
malfunction and permanent damage to
the product.
•Do not cut the GPS aerial cable to shorten
it or use an extension to make it longer.
Altering the aerial cable could result in a
short circuit or malfunction.
•Do not shorten any leads. If you do, the
protection circuit (fuse holder, fuse
resistor or filter, etc.) may fail to work
properly.
•Never feed power to other electronic
products by cutting the insulation of the
power supply lead of this product and
tapping into the lead. The current
capacity of the lead will be exceeded,
causing overheating.
Precautions before
connecting the system

3En
English
•Use this unit with a 12-volt battery and
negative earthing only. Failure to do so
may result in a fire or malfunction.
•To avoid shorts in the electrical system,
be sure to disconnect the (–) battery
cable before installation.
WARNING
•Use speakers over 50 W (maximum input
power) and between 4 Ω to 8 Ω
(impedance value). Do not use 1 Ω to 3 Ω
speakers for this product.
•The black lead is earth. Please earth this
lead separately from the earth of high
current products such as power amps. Do
not earth more than one product
together with the earth from another
product. For example, you must
separately earth any amp unit away from
the earth of this product. Connecting
earths together can cause a fire and/or
damage the products if their earths
became detached.
•When replacing the fuse, be sure to only
use a fuse of the rating prescribed on this
product.
•When disconnecting a connector, pull the
connector itself. Do not pull the lead, as
you may pull it out of the connector.
•This product cannot be installed in a
vehicle without ACC (accessory) position
on the ignition switch.
•To avoid short-circuiting, cover the
disconnected lead with insulating tape. It
is especially important to insulate all
unused speaker leads, which if left
uncovered may cause a short circuit.
•Attach the connectors of the same colour
to the corresponding coloured port, i.e.,
blue connector to the blue port, black to
black, etc.
•For connecting a power amp or other
devices to this product, refer to the
manual for the product to be connected.
•Since a unique BPTL circuit is employed,
do not directly earth the side of the
speaker lead or connect the side of
another side of the speaker lead together.
Be sure to connect the side of the
speaker lead to the side of the speaker
lead on this product.
•The graphical symbol placed on
the product means direct current.
•When the ignition switch is turned on
(ACC ON), a control signal is output
through the blue/white lead. Connect to
an external power amp’s system remote
control terminal, the auto-aerial relay
control terminal, or the aerial booster
power control terminal (max. 300 mA 12
V DC). The control signal is output
Before installing this
product
To prevent damage
Notice for the blue/
white lead
ACC position No ACC position
through the blue/white lead, even if the
audio source is switched off.
•Be sure not to use this lead as the power
supply lead for the external power amps.
Such connection could cause excessive
current drain and malfunction.
•Be sure not to use this lead as the power
supply lead for the auto-aerial or aerial
booster. Such connection could cause
excessive current drain and malfunction.
Important
When this product is in [Power OFF] mode,
the control signal is also turned off. If
[Power OFF] mode is cancelled, the control
signal is output again and the aerial is
extended with the auto aerial function (if
the aerial is being used). Be careful so that
the extended aerial does not come into
contact with any obstacles.
WARNING
•To avoid the risk of accident and the
potential violation of applicable laws, this
product should never be used while the
vehicle is being driven except for
navigation purposes. And, also rear
displays should not be in a location
where it is a visible distraction to the
driver.
•In some countries, the viewing of images
on a display inside a vehicle even by
persons other than the driver may be
illegal. Where such regulations apply they
must be obeyed and this product’s video
source should not be used.
GPS aerial 3.55 m
Microphone 3 m
Vehicle Bus conversion cable 13 cm
Refer to the instruction manual for the
Vehicle Bus adapter (sold separately).
Digital Radio aerial input (AVIC-
Z910DAB/AVIC-Z810DAB/AVIC-
Z710DAB/AVIC-Z7110DAB)
This product
Aerial jack
AV cable IN/OUT
Power supply
Fuse (10 A)
Wired remote input
Hard-wired remote control adapter can
be connected (sold separately).
CAUTION
For improved Digital Radio reception,
make sure a Digital Radio aerial with
phantom power input (active type) is used.
Pioneer recommends using AN-DAB1 or
CA-AN-DAB.001 (sold separately). Current
consumption of the Digital Radio aerial
should be 100 mA or less.
WARNING
IMPROPER CONNECTION MAY RESULT IN
SERIOUS DAMAGE OR INJURY
Rear panel (main
terminals)
Power cord

4En
INCLUDING ELECTRICAL SHOCK, AND
INTERFERENCE WITH THE OPERATION
OF THE VEHICLE'S ANTILOCK BRAKING
SYSTEM, AUTOMATIC TRANSMISSION
AND SPEEDOMETER INDICATION.
CAUTION
It is strongly suggested that the speed
pulse wire be connected for accuracy of
navigation and better performance.
To power supply
Depending on the kind of vehicle, the
function of 2* and 4* may be different.
In this case, be sure to connect 1* to 4*
and 3* to 2*.
Yellow (2*)
Back-up (or accessory)
Yellow (1*)
To terminal supplied with power
regardless of ignition switch position.
Red (4*)
Accessory (or back-up)
Red (3*)
Connect to terminal controlled by
ignition switch (12 V DC).
Connect leads of the same colour to
each other.
Orange/white
To lighting switch terminal.
Black (earth)
To vehicle (metal) body.
Blue/white (5*)
The pin position of the ISO connector
will differ depending on the type of
vehicle. Connect 5* and 6* when Pin 5 is
an aerial control type. In another type of
vehicle, never connect 5* and 6*.
Blue/white (6*)
Connect to auto-aerial relay control
terminal (max. 300 mA 12 V DC).
Blue/white
Connect to system control terminal of
the power amp (max. 300 mA 12 V DC).
Violet/white
This is connected so that this product
can detect whether the vehicle is
moving forwards or backwards.
Connect the violet/white lead to the
lead whose voltage changes when the
gearstick is put in reverse. Unless
connected, the sensor may not detect
your vehicle travelling forwards/
backwards properly, and thus the
position of your vehicle detected by the
sensor may be misaligned from the
actual position.
When you use a rear view camera,
please make sure to connect this lead.
Otherwise you cannot switch to the rear
view camera picture.
Pink (CAR SPEED SIGNAL INPUT)
This product is connected here to
detect the distance the vehicle travels.
Always connect the vehicle’s speed
detection circuit. Failure to make this
connection will increase errors in the
vehicle’s location display.
Light green
Used to detect the ON/OFF status of the
handbrake. This lead must be
connected to the power supply side of
the handbrake switch.
If this connection is made incorrectly
or omitted, certain functions of this
product will be unusable.
Connection method
Clamp the lead (1) then clamp firmly
with needle-nosed pliers (2).
Power supply side
Handbrake switch
Earth side
Speaker leads
White: Front left + or high range left +
White/black: Front left – or high range
left –
Grey: Front right + or high range right +
Grey/black: Front right – or high range
right –
Green: Rear left + or middle range left +
Green/black: Rear left – or middle range
left –
Violet: Rear right + or middle range
right +
Violet/black: Rear right – or middle
range right –
ISO connector
In some vehicles, the ISO connector
may be divided into two. In this case, be
sure to connect to both connectors.
NOTES
•The position of the speed detection
circuit and the position of the handbrake
switch vary depending on the vehicle
model. For details, consult your
authorised Pioneer dealer or an
installation professional.
•When a subwoofer is connected to this
product instead of a rear speaker, change
the rear output setting in the initial
setting. The subwoofer output of this
product is monaural.
•When using a subwoofer of 2 Ω, be sure
to connect the subwoofer to the violet
and violet/black leads of this unit. Do not
connect anything to the green and
green/black leads.

5En
English
Important
The speaker leads are not used when this connection is in use.
Subwoofer output (SUBWOOFER OUTPUT) 23 cm (STD)
Low range output (NW)
RCA cable (sold separately)
Power amp
Front output (FRONT OUTPUT) 15 cm (STD)
High range output (NW)
Rear output (REAR OUTPUT) 15 cm (STD)
Power amp (sold separately) Middle range output (NW)
Yellow/black (MUTE)
If you use an equipment with Mute function, wire this lead to the Audio Mute lead on
that equipment. If not, keep the Audio Mute lead free of any connections.
This product
System remote control
Connect to Blue/white cable (max. 300 mA 12 V DC).
Rear speaker (STD)
Middle range speaker (NW)
Front speaker (STD)
High range speaker (NW)
Subwoofer (STD)
Low range speaker (NW)
NOTES
•Select the appropriate speaker mode between standard mode (STD) and network mode
(NW). For details, refer to the Operation Manual.
•Audio source will be set to mute or attenuate, while the following sounds will not be
muted or attenuated. For details, refer to Operation Manual.
–Voice guidance of the navigation
–Incoming ring tone and incoming voice of the mobile phone that is connected to this
product via Bluetooth wireless technology

6En
NOTES
•For details on how to connect an external
device using a separately sold cable, refer
to the manual for the cable.
•For details concerning the connection,
operations and compatibility of the
iPhone, refer to the Operation Manual.
•For details concerning the connection
and operations of the smartphone, refer
to the Operation Manual.
Attach identification labels to USB cables
before installing this product in a vehicle.
1Connect USB cables to the USB port 1
and 2 on the rear of this product.
2Attach the identification labels
corresponding to each port to the USB
cables as illustrated below.
Attach the “Port 1 Apple CarPlay” label
to the USB cable connected to the USB
port 1.
Attach the “Port 2” or “Port 2 Android
Auto” label to the USB cable connected
to the USB port 2.
USB port1
USB cable 1.5 m
USB interface cable for iPod/iPhone (CD-
IU52) (sold separately)
iPhone
USB port2
USB cable 1.5 m
USB - micro USB cable (Type USB A -
micro USB B) (supplied with CD-MU200)
Smartphone
iPod/iPhone and
smartphone
Attaching
identification labels to
USB cables
iPod/iPhone
Connecting via the USB port
Smartphone (Android™
device)
Connecting via the USB port
When you use the rear view camera, the
rear view image is automatically switched
from the video by moving the gearstick to
REVERSE (R). Camera View mode also
allows you to check what is behind you
while driving.
WARNING
USE INPUT ONLY FOR REVERSE OR MIRROR
IMAGE REAR VIEW CAMERA. OTHER USE
MAY RESULT IN INJURY OR DAMAGE.
CAUTION
•The screen image may appear reversed.
•With the rear view camera you can keep
an eye on trailers, or back into a tight
parking spot. Do not use for
entertainment purposes.
•Objects in rear view may appear closer or
more distant than in reality.
•The image area of full-screen images
displayed while backing or checking the
rear of the vehicle may differ slightly. This product
Power supply
Power cord
Violet/white (REVERSE-GEAR SIGNAL
INPUT)
Brown (REAR VIEW CAMERA IN) 23 cm
Yellow (VIDEO INPUT) 23 cm
Rear view camera (ND-BC8) (sold
separately)
To video output
RCA cable (supplied with ND-BC8)
RCA cable (sold separately)
View camera (sold separately)
NOTES
•Connect only the rear view camera to
brown cable. Do not connect any other
equipment.
•Some appropriate settings are required
to use rear view cameras. For details, refer
to the Operation Manual.
Camera

7En
English
This product
Red, white (AUDIO INPUT) 23 cm
Yellow (VIDEO INPUT) 23 cm
RCA cable (sold separately)
To audio input
To video input
External video component (sold
separately)
NOTE
The appropriate setting is required to use
the external video component. For details,
refer to the Operation Manual.
This product
Mini-jack AV cable (CD-RM10) (sold
separately)
AUX input (AUX IN) 15 cm
Yellow
Red, white
RCA cables (sold separately)
To video output
To audio outputs
External video component (sold
separately)
NOTE
The appropriate setting is required to use
the external video component. For details,
refer to the Operation Manual.
External video
component
Using AV input
Using an AUX input
CAUTION
Be sure to use a mini-jack AV cable (CD-
RM10) (sold separately) for wiring. If you
use other cables, the wiring position might
differ resulting in disturbed images and
sounds.
This product
HDMI port
High Speed HDMI® Cable (sold
separately)
HDMI device (sold separately)
NOTE
When you connect the High Speed HDMI®
Cable, use the lock tie to fix it securely
(page 7).
Be sure to fix the High Speed HDMI® Cable
with the lock tie, when you connect the
external device with the High Speed
HDMI® Cable.
1Insert the High Speed HDMI® Cable
into the HDMI port.
2Wrap the lock tie around the hook
above the HDMI port and the High
Speed HDMI® Cable, and then tighten
it to secure the High Speed HDMI®
Cable.
Hook
Lock tie
High Speed HDMI® Cable
CAUTION
Do not tighten up the lock tie more than
necessary.
Using an HDMI input
L : Left audio (White)
R : Right audio (Red)
V : Video (Yellow)
G : Earth
Z910DAB
Securing the High
Speed HDMI®
Z910DAB

8En
This product
Rear audio output (R. AUDIO OUT)
Yellow (REAR MONITOR OUTPUT) 30
cm
Mini pin plug cable (sold separately)
RCA cables (sold separately)
To audio input
To video input
Rear display with RCA input jacks (sold
separately)
WARNING
NEVER install the rear display in a location
that enables the driver to watch the video
source while driving.
This product’s rear video output is for
connection of a display to enable
passengers in the rear seats to watch the
video source.
Rear display
CAUTION
•Never install this product in places where,
or in a manner that:
–Could injure the driver or passengers if
the vehicle stops suddenly.
– May interfere with the driver’s operation
of the vehicle, such as on the floor in
front of the driver’s seat, or close to the
steering wheel or gearstick.
•Make sure there is nothing behind the
dashboard or panelling when drilling
holes in them. Be careful not to damage
fuel lines, brake lines, electronic
components, communication wires or
power cables.
•When using screws, do not allow them to
come into contact with any electrical
lead. Vibration may damage wires or
insulation, leading to a short circuit or
other damage to the vehicle.
•To ensure proper installation, be sure to
use the supplied parts in the manner
specified. If any parts are not supplied
with this product, use compatible parts in
the manner specified after you have the
part compatibility checked by your
dealer. If parts other than supplied or
compatible ones are used, they may
damage internal parts of this product or
they may work loose and the product
may become detached.
•It is extremely dangerous to allow cables
to become wound around the steering
column or gearstick. Be sure to install this
product, its cables, and wiring away in
such so that they will not obstruct or
hinder driving.
•Make sure that leads cannot get caught
in a door or the sliding mechanism of a
seat, resulting in a short circuit.
•Please confirm the proper function of
your vehicle’s other equipment after
installation of this product.
•Do not install this product where it may
(i) obstruct the driver’s vision,
(ii) impair the performance of any of the
vehicle’s operating systems or safety
features, including airbags, hazard lamp
buttons or
(iii) impair the driver’s ability to safely
operate the vehicle.
•Install this product between the driver’s
seat and front passenger seat so that it
will not be hit by the driver or passenger
if the vehicle stops quickly.
•Never install this product in front of or
next to the place in the dashboard, door,
or pillar from which one of your vehicle’s
airbags would deploy. Please refer to your
vehicle’s owner’s manual for reference to
the deployment area of the frontal
airbags.
•Failure to follow all of these precautions
may result in serious injury or death.
In order to prevent interference, set the
following items as far as possible from this
product, other cables or leads:
•FM, MW/LW aerial and its lead
Installation
Precautions before
installation
To avoid
electromagnetic
interference

9En
English
•DAB aerial and its lead (AVIC-Z910DAB/
AVIC-Z810DAB/AVIC-Z710DAB/AVIC-
Z7110DAB)
•GPS aerial and its lead
In addition, you should lay or route each
aerial lead as far as possible from other
aerial leads. Do not bind, lay or route them
together, or cross them. Electromagnetic
noise will increase the potential for errors
in the vehicle’s location display.
•Consult with your nearest dealer if
installation requires drilling holes or
other modifications of the vehicle.
•Before making a final installation of this
product, temporarily connect the wiring
to confirm that the connections are
correct and the system works properly.
Do not install this product in a position
where the opening of the LCD panel is
obstructed by any obstacles, such as the
gearstick. Before installing this product, be
sure to leave sufficient space so that the
LCD panel does not obstruct the gearstick
when it is fully opened. This may cause
interference with the gearstick, or a
malfunction of the mechanism of this
product.
•Do not install this product in places
subject to high temperatures or
humidity, such as:
–Places close to a heater, vent or air
conditioner.
–Places exposed to direct sunlight, such
as on top of the dashboard.
– Places that may be exposed to rain,
such as close to the door or on the
vehicle’s floor.
•Install this product in an area strong
enough to bear its weight. Choose a
position where this product can be firmly
installed, and install it securely. If this
product is not securely installed, the
current location of the vehicle cannot be
displayed correctly.
•Install this product horizontally on a
surface within 0 to 30 degrees tolerance
(within 5 degrees to the left or right).
Improper installation of the unit with the
surface tilted more than these tolerances
increases the potential for errors in the
vehicle’s location display, and might
otherwise cause reduced display
performance.
•When installing, to ensure proper heat
dispersal when using this unit, make sure
you leave ample space behind the rear
panel and wrap any loose cables so they
are not blocking the vents.
•The cords must not cover the area shown
in the figure below. This is necessary to
allow the amps and navigation
mechanism to dissipate heat.
Before installing
For AVIC-Z910DAB and AVIC-
Z810DAB users
Installation notes
Leave ample
space
5 cm
5 cm
Do not cover this area.
•The semiconductor laser will be damaged
if it overheats, so don’t install this product
anywhere hot- for instance, near a heater
outlet.
1Remove the trim ring.
Extend top and bottom of the trim ring
outwards to remove the trim ring.
Trim ring
2Insert the supplied extraction keys
into both sides of the unit until they
click into place.
3Pull the unit out of the holder.
Extraction key
1Install the holder into the dashboard.
2Secure the mounting sleeve by using a
screwdriver to bend the metal tabs
(90°) into place.
Dashboard
Holder
3Install this product into the holder.
Dashboard
4Attach the trim ring.
Trim ring
Before installing this
product
Installation with the
holder
112 mm
182 mm

10En
Groove
Attach the trim ring with the side
with a groove facing downward.
1Fastening this product to the factory
radio-mounting bracket.
Position this product so that its screw
holes are aligned with the screw holes
of the bracket, and tighten the screws at
three locations on each side.
Use either the truss head screws or flush
surface screws, depending on the shape
of the bracket’s screw holes.
Factory radio-mounting bracket
If the pawl interferes with
installation, you may bend it down
out of the way.
Dashboard or console
Truss head screw or flush surface
screw
Be sure to use the screws supplied
with this product.
CAUTION
Do not cut the GPS aerial lead to shorten it
or use an extension to make it longer.
Altering the aerial cable could result in a
short circuit or malfunction and
permanent damage to this product.
•The aerial should be installed on a level
surface where radio waves will be
blocked as little as possible. Radio waves
cannot be received by the aerial if
reception from the satellite is blocked.
Dashboard
Rear shelf
•When installing the GPS aerial inside the
vehicle, be sure to use the metal sheet
provided with your system. If this is not
used, the reception sensitivity will be
poor.
•Do not cut the accessory metal sheet.
This would reduce the sensitivity of the
GPS aerial.
•Take care not to pull the aerial lead when
removing the GPS aerial. The lead may
become detached.
Installation using the screw
holes on the side of this
product
Installing the GPS
aerial
Installation notes
•Do not paint the GPS aerial, as this may
affect its performance.
