Pioneer AVIC-N2 User manual

ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2005
AVIC-N2/XU/UC
CRT3423
DVD MULTIMEDIA AV NAVIGATION SERVER
AVIC-N2
/XU/UC
DVD AV NAVIGATION HEAD-UNIT
AVIC-X1R
/XU/EW
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks
CX-3016 CRT3056 MS3 DVD Mech. Module:Circuit Description, Mech. Description, Disassembly
NOTE:
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks
of Dolby Laboratories.
This product has the unit part number as below.
Unit Part No.
CPN1955
CPN1953
CPN1954
CPN1952
Description
Navigation Unit(AVIC-N2/XU/UC)
Hideaway Unit(AVIC-N2/XU/UC)
Navigation Unit(AVIC-X1R/XU/EW)
Hideaway Unit(AVIC-X1R/XU/EW)
*) The unit part numbers listed above are not for the service components.
For details, refer to "Important Check Points for Good Servicing".
K-ZZW. FEB. 2005 Printed in Japan

AVIC-N2/XU/UC
2
1234
1234
C
D
F
A
B
E
SAFETY INFORMATION
UC
C
A
U
TI
O
N
This service manual is intended for
q
ualified service technicians; it is not meant for the casual do-it-
y
ourself
e
r.
Qualified technicians have the necessar
y
test e
q
ui
p
ment and tools, and have been trained to
p
ro
p
erl
y
and safel
y
re
p
ai
r
Im
p
ro
p
erl
y
p
erformed re
p
airs
ca
n adversel
y
a
ff
ect
t
h
e
safet
y
a
n
d
reliabilit
y
of
t
h
e
p
roduct
a
n
d
ma
y
v
o
i
d
t
h
e
warrant
y
.
If
y
ou
a
r
e
n
ot
q
ualified
to
p
erform
t
h
e
re
p
air
of
t
hi
s
p
roduct
p
ro
p
erl
y
a
n
d
safel
y
,
y
ou
s
h
ou
l
d
n
ot
ri
s
k
t
ryin
g
to
do
so
W
ARNING
W
ARNING
W
Thi
s
p
roduct
co
n
ta
in
s
l
ead
in
so
l
de
r
a
n
d
cer
ta
in
e
l
ect
ri
ca
l
p
arts
co
n
ta
in
c
h
e
mi
ca
l
s
whi
c
h
a
r
e
kn
o
wn
to
t
h
e
state
of
California to cause cancer
, birth defects or other reproductive harm.
r
Health & Safet
y
Code Section 25249.6 - Pro
p
osition 6
5
EW
1.
Safet
y
Precautions for those who Service this Unit
.
•
Follow the adjustment steps in the service manual when servicin
g
this unit. When checkin
g
or adjustin
g
the emittin
g
power of the laser diode exercise caution in order to
g
et safe, reliable results
.
Caut
i
o
n
:
1.
Durin
g
repair or tests, minimum distance of 13cm from the focus lens must be kept
.
2.
Durin
g
repair or tests, do not view laser beam for 10 seconds or lon
g
e
r
.
2.
The trian
g
ular label is attached to the mechanis
m
u
ni
t
fr
a
m
e.
This product contains mercury. Disposal of this material may be re
g
ulated due to environmental considerations.
For disposal or recyclin
g
information, please contact your local authorities or the Electronics Industries
Alliance: www.eiae.or
g.

AVIC-N2/XU/UC 3
5678
5678
C
D
F
A
B
E
On the top of the player.
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO! :
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN. VRW1860
CLASS 1
LASER PRODUCT
WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should do servicing operation of the apparatus.
Laser diode characteristics
Wave length:
DVD:640~660nm
CD:770~810nm
Maximum output:2.48mw(Emitting period :9sec.)
DVD:705µw(Emitting period : unlimited)
Additionla Laser Caution
Transistors Q1101 and Q1102 in PCB drive the laser diodes for DVD and CD
respectively. When Q1101 or Q1102 is shorted between their terminals,
the laser diodes for DVD or CD will radiate beam. If the top cover is removed
with no disc loaded while such short-circuit is continued, the naked eyes may
be exposed to the laser beam.

AVIC-N2/XU/UC
4
1234
1234
C
D
F
A
B
E
DVD MECHANISM MODULE section precaution
1. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during
power-on mode may damage the ICs inside the unit.
2. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment
(shorting-solder) by referring to "the DISASSEMBLY".
3. After replacing the pickup unit, be sure to check the grating.
4. During disassembly, be sure to turn the power off since an internal IC might be destroyed when a connector is
plugged or unplugged.
NAVIGATION UNIT section precaution
1. Inverter for LCD back light becomes a high voltage.
2. When inspecting the touch panel, use something thin with a round tip such as the touch pen. Furthermore,
do not apply excessive force to the touch panel.
3. Since this product does not have OSD IC, OSD for adjustment is displayed by using GGF1416 and GGF1463
at the time of monitor adjustment. As you will find lands for 14 pins with 0.8mm pitch at the left top part of
the monitor board, directly solder a flexible PCB of GGD1323 for adjustment. As GGD1322 is not used, be
careful not to short the terminal.
4. The region code determination at the time of DVD hardware change is made by the destination (UC: Region 1,
EW: Region 2) of the car control unit.
5. If you reconnected the Hide-away unit, press the RESET button.
-Service Precautions
1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations),
and should keep the safety during servicing by following the safety instructions described in this manual.
is a trademark of DVD Format/Logo Licensing Corporation.

AVIC-N2/XU/UC 5
5678
5678
C
D
F
A
B
E
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
3Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs.
In addition, be sure that there are no pinched wires, etc.
7Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
0Safe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.

AVIC-N2/XU/UC
6
1234
1234
C
D
F
A
B
E
CONTENTS
SAFETY INFORMATION.....................................................................................................................................2
1. SPECIFICATIONS ............................................................................................................................................ 8
2. EXPLODED VIEWS AND PARTS LIST..........................................................................................................12
2.1 PACKING (AVIC-N2/XU/UC)....................................................................................................................12
2.2 PACKING (AVIC-X1R/XU/EW).................................................................................................................14
2.3 NAVIGATION UNIT (1).............................................................................................................................16
2.4 NAVIGATION UNIT (2).............................................................................................................................18
2.5 NAVIGATION UNIT (3).............................................................................................................................20
2.6 HIDEAWAY UNIT AND CORD ASSY ...................................................................................................... 22
2.7 DVD MECHANISM MODULE .................................................................................................................. 24
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM..........................................................................................26
3.1 BLOCK DIAGRAM...................................................................................................................................26
3.2 OVERALL CONNECTION DIAGRAM......................................................................................................40
3.3 CC UNIT (P/S)(GUIDE PAGE)................................................................................................................. 42
3.4 CC UNIT (SYSCOM, VIDEO, IF)(GUIDE PAGE).....................................................................................48
3.5 CC UNIT (AUDIO)(GUIDE PAGE)............................................................................................................54
3.6 CC UNIT (CPU, ASIC, SDRAM)(GUIDE PAGE)......................................................................................60
3.7 CC UNIT (GRAPHIC)............................................................................................................................... 66
3.8 CC UNIT (MAIN, CC CORE I/F) ..............................................................................................................68
3.9 CC UNIT (ROM, SRAM, BUS-BUFFER) .................................................................................................70
3.10 KEYBOARD PCB...................................................................................................................................72
3.11 PANEL PCB ........................................................................................................................................... 74
3.12 DVD CORE UNIT(MS3)(SODC)(GUIDE PAGE)....................................................................................76
3.13 DVD CORE UNIT(MS3)(CPU)(GUIDE PAGE)....................................................................................... 82
3.14 COMPOUND UNIT(A) AND COMPOUND UNIT(B) .............................................................................. 90
3.15 PU UNIT(REFERENCE)........................................................................................................................91
3.16 MONITOR PCB AND UPPER PCB(GUIDE PAGE)...............................................................................92
3.17 INVERTER PCB...................................................................................................................................100
3.18 RELAY PCB ......................................................................................................................................... 102
3.19 MOTHER PCB (H/A SYSTEM)(GUIDE PAGE).................................................................................... 104
3.20 MOTHER PCB (SENSOR)...................................................................................................................110
3.21 CONNECTOR PCB..............................................................................................................................112
3.22 MAIN UNIT, SW UNIT AND VOLUME UNIT........................................................................................ 114
3.23 GPS UNIT(GUIDE PAGE)....................................................................................................................116
4. PCB CONNECTION DIAGRAM ...................................................................................................................122
4.1 CC UNIT.................................................................................................................................................122
4.2 KEYBOARD PCB...................................................................................................................................126
4.3 PANEL PCB ........................................................................................................................................... 127
4.4 DVD CORE UNIT(MS3).........................................................................................................................128
4.5 COMPOUND UNIT(A) AND COMPOUND UNIT(B) .............................................................................. 132
4.6 CONNECTOR PCB................................................................................................................................133
4.7 MONITOR PCB...................................................................................................................................... 134
4.8 UPPER PCB ..........................................................................................................................................138
4.9 INVERTER PCB.....................................................................................................................................139
4.10 RELAY PCB ......................................................................................................................................... 140
4.11 MOTHER PCB.....................................................................................................................................142
4.12 GPS UNIT............................................................................................................................................146
4.13 MAIN UNIT........................................................................................................................................... 148
4.14 SW UNIT AND VOLUME UNIT............................................................................................................150
5. ELECTRICAL PARTS LIST ..........................................................................................................................151
6. ADJUSTMENT ............................................................................................................................................. 192
6.1 JIG CONNECTION DIAGRAM...............................................................................................................192
6.2 DVD ADJUSTMENT............................................................................................................................... 193
6.3 CC UNIT ADJUSTMENT .......................................................................................................................213
6.4 MOTHER PCB ADJUSTMENT..............................................................................................................215
6.5 INVERTER PCB ADJUSTMENT ...........................................................................................................217
6.6 MONITOR PCB ADJUSTMENT.............................................................................................................218
6.7 TEST MODE ..........................................................................................................................................227
6.8 USING THE TEST DISC........................................................................................................................249
7. GENERAL INFORMATION........................................................................................................................... 262
7.1 DIAGNOSIS...........................................................................................................................................262
7.1.1 DISASSEMBLY ...................................................................................................................................262
7.1.2 PCB LOCATIONS ............................................................................................................................... 270
7.1.3 CONNECTOR FUNCTION DESCRIPTION........................................................................................ 271
7.2 PARTS....................................................................................................................................................273

AVIC-N2/XU/UC 7
5678
5678
C
D
F
A
B
E
7.2.1 IC.........................................................................................................................................................273
7.2.2 DISPLAY..............................................................................................................................................292
7.3 EXPLANATION.......................................................................................................................................293
7.3.1 MECHANISM DESCRIPTIONS...........................................................................................................293
7.3.2 OPERATIONAL FLOW CHART...........................................................................................................299
7.4 CLEANING .............................................................................................................................................303
8. OPERATIONS ...............................................................................................................................................304

AVIC-N2/XU/UC
8
1234
1234
C
D
F
A
B
E
1. SPECIFICATIONS
General
Rated power source ............ 14.4 V DC
(10.8 - 15.1 V allowable)
Grounding system ............... Negative type
Max. current consumption
................................... 10.0 A
Backup current .................... 6.5 mA or less
Display unit:
Dimensions (W x H x D):
DIN
Chassis ................. 178 x 50 x 160 mm
(7 x 2 x 6-1/4 in.)
Nose...................... 188 x 58 x 34 mm
(7-3/8 x 2-1/4 x 1-3/8 in.)
D
Chassis ................. 178 x 50 x 165 mm
(7 x 2 x 6-1/2 in.)
Nose...................... 170 x 46 x 29 mm
(6-3/4 x 1-3/4 x 1-1/4 in.)
Weight .......................... 2.5 kg(5.5 lbs)
Hideaway unit:
Dimensions (W x H x D)
................................... 180 x 30 x 140 mm
(5-7/8 x 1-1/8 x 3-7/8 in.)
Weight .......................... 0.7 kg(1.5 lbs)
Navigation
GPS Receiver:
System.......................... L1, C/Acode GPS
SPS (Standard Positioning Service)
Reception system ........ 8-channel multi-channel
reception system
Reception frequency ... 1,575.42 MHz
Sensitivity ..................... –130 dbm
Position update frequency
................................... Approx. once per second
GPS antenna:
Antenna........................ Micro strip flat antenna/
right-handed helical polarization
Antenna cable.............. 5.0 m(16 ft. 5 in.)
Dimensions (W x H x D)
................................... 33 x 13 x 36 mm
(1-1/4 x 1/2 x 1-3/8 in.)
Weight .......................... 105 g(0.23 lbs)
Display
Screen size/aspect ratio ..... 6.5 inch wide/16:9
(effective display area: 144 x
76 mm)
Pixels .................................. 336,960 (1,440 x 234)
Type..................................... TFT active matrix,
transmissive type
Color system ....................... NTSC
Operating temperature range
........................................... –14 – +122 °F
Storage temperature range
........................................... –4 – +176 °F
Angle adjustment................ 50 – 110°
(initial settings: 110°)
Audio
Continuous power output is 22 W per channel minimum
into 4 ohms, both channels driven 50 to 15,000 Hz with
no more than 5% THD.
Maximum power output ...... 50 W x 4
50 W x 2 ch/4 Ω+ 70 W x 1
ch/2 Ω(for subwoofer)
Load impedance................... 4 Ω(4 – 8 Ω[2 Ωfor 1 ch]
allowable)
Preout max output level/output impedance
............................................ 2.0 V/100 ohm
Equalizer (3-Band Parametric Equalizer):
Low
Frequency ............. 40/80/100/160 Hz
Q Factor................. 0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain ....................... ±12dB
Mid
Frequency ............. 200/500/1k/2k Hz
Q Factor................. 0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain ....................... ±12dB
High
Frequency ............. 3.15k/8k/10k/12.5k Hz
Q Factor................. 0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain ....................... ±12dB
Loudness contour
Low ................................ +3.5 dB (100 Hz), +3 dB (10
kHz)
Mid................................. +10 dB (100 Hz), +6.5 dB
(10 kHz)
High....................... +11 dB (100 Hz), +11 dB
(10 kHz)
(volume: –30 dB)
Tone controls:
Bass
Frequency ............. 40/63/100/160 Hz
Gain ....................... ±12dB
Treble
Frequency ............. 2.5k/4k/6.3k/10k Hz
Gain ....................... ±12dB
HPF:
Frequency ..................... 0/80/125 Hz
Slope.............................. –12 dB/oct
Subwoofer:
Frequency ..................... 50/80/125 Hz
Slope.............................. –18 dB/oct
Gain ............................... ±12dB
Phase ............................ Normal/Reverse
-AVIC-N2/XU/UC

AVIC-N2/XU/UC 9
5678
5678
C
D
F
A
B
E
DVD Drive
System.................................. DVD-Video, Compact disc
audio, MP3 system
Usable discs ........................ DVD-Video, Compact disc,
MP3
Region number..................... 1
Signal format:
Sampling frequency.... 44.1/48/96 kHz
Number of quantization bits
................................... 16/20/24; linear
Frequency response ............ 5 –44,000 Hz (with DVD, at
sampling frequency 96 kHz)
Signal-to-noise ratio ............. 97 dB (1 kHz) (IHF-A network)
(CD: 96 dB (1 kHz) (IHF-A
network))
Dynamic range ..................... 95 dB (1 kHz)
(CD: 94 dB (1 kHz))
Distortion............................... 0.008 % (1 kHz)
Output level:
Video ............................. 1.0 Vp-p/75 Ω(±0.2 V)
Audio ............................. 1.0 V (1 kHz, 0 dB)
Number of channels.............. 2 (stereo)
MP3 decoding format ........... MPEG-1 & 2 Audio Layer 3
FM tuner
Frequency range................... 87.9 –107.9 MHz
Usable sensitivity.................. 8 dBf (0.7 µV/75 Ω, mono, S/
N: 30 dB)
50 dB quieting sensitivity...... 10 dBf (0.9 µV/75 Ω, mono)
Signal-to-noise ratio ............. 75 dB (IHF-A network)
Distortion............................... 0.3 % (at 65 dBf, 1 kHz,
stereo)
0.1 % (at 65 dBf, 1 kHz,
mono)
Frequency response ............ 30 –15,000 Hz (±3 dB)
Stereo separation ................. 45 dB (at 65 dBf, 1 kHz)
Selectivity ............................. 80 dB (±200 kHz)
Three-signal intermodulation (desired signal level)
............................................ 30 dBf (two undesired signal
level: 100 dBf)
AM tuner
Frequency range................... 530 –1,710 kHz (10 kHz)
Usable sensitivity.................. 18 µV (S/N: 20 dB)
Signal-to-noise ratio ............. 65 dB (IHF-A network)
Note:
•Specifications and the design are subject to
possible modifications without notice due to
improvements.

AVIC-N2/XU/UC
10
1234
1234
C
D
F
A
B
E
General
Rated power source ............ 14.4 V DC
(allowable voltage range:
12.0 –14.4 V DC)
Earthing system................... Negative type
Max. current consumption
................................... 10.0 A
Backup current .................... 6.5 mA or less
Display unit:
Dimensions (W x H x D):
DIN
Chassis ................. 178 x 50 x 160 mm
Nose...................... 188 x 58 x 34 mm
D
Chassis ................. 178 x 50 x 165 mm
Nose...................... 170 x 46 x 29 mm
Weight .......................... 2.5 kg
Hideaway unit:
Dimensions (W x H x D)
................................... 180 x 30 x 140 mm
Weight .......................... 0.7 kg
Navigation
GPS Receiver:
System.......................... L1, C/Acode GPS
SPS (Standard Positioning Service)
Reception system ........ 8-channel multi-channel
reception system
Reception frequency .... 1,575.42 MHz
Sensitivity ..................... –130 dbm
Position update frequency
................................... Approx. once per second
GPS aerial:
Aerial ............................ Micro strip flat aerial/righthanded
helical polarization
Aerial cable .................. 5.0 m
Dimensions (W x H x D)
................................... 33 x 13 x 36 mm
Weight .......................... 105 g
Display
Screen size/aspect ratio ..... 6.5 inch wide/16:9
(effective display area: 144 x
76 mm)
Pixels ................................... 336,960 (1,440 x 234)
Type...................................... TFT active matrix, transmissive
type
Colour system...................... NTSC/PAL compatible
Operating temperature range
........................................... –10 –+50 °C
Storage temperature range
........................................... –20 –+80 °C
Angle adjustment................. 50 –110°
(initial settings: 110°)
Audio
Maximum power output ....... 50 W x 4
50 W x 2 ch/4 Ω+ 70 W x 1
ch/2 Ω(for subwoofer)
Continuous power output.... 27 W x 4 (DIN 45324,
+B=14.4 V)
Load impedance................. 4 Ω(4 –8 Ω[2 Ωfor 1 ch]
allowable)
Preout max output level/output impedance
............................................ 2.0 V/100 ohm
Equalizer (3-Band Parametric Equalizer):
Low
Frequency ............. 40/80/100/160 Hz
Q Factor................. 0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain ....................... ±12dB
Mid
Frequency ............. 200/500/1k/2k Hz
Q Factor................. 0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain ....................... ±12dB
High
Frequency ............. 3.15k/8k/10k/12.5k Hz
Q Factor................. 0.35/0.59/0.95/1.15 (+6 dB
when boosted)
Gain ....................... ±12dB
Loudness contour
Low ................................ +3.5 dB (100 Hz), +3 dB (10
kHz)
Mid................................. +10 dB (100 Hz), +6.5 dB
(10 kHz)
High....................... +11 dB (100 Hz), +11 dB
(10 kHz)
(volume: –30 dB)
Tone controls:
Bass
Frequency ............. 40/63/100/160 Hz
Gain ....................... ±12dB
Treble
Frequency ............. 2.5k/4k/6.3k/10k Hz
Gain ....................... ±12dB
HPF:
Frequency ..................... 50/80/125 Hz
Slope.............................. –12 dB/oct
Subwoofer:
Frequency ..................... 50/80/125 Hz
Slope.............................. –18 dB/oct
Gain .............................. ±12dB
Phase ............................ Normal/Reverse
DVD Drive
System................................ DVD-Video, Compact disc
audio, MP3 system
Usable discs ...................... DVD-Video, Compact disc,
MP3
Region number................... 2
Signal format:
Sampling frequency..... 44.1/48/96 kHz
Number of quantization bits
.................................... 16/20/24; linear
Frequency response........... 5 –44,000 Hz (with DVD, at
sampling frequency 96 kHz)
Signal-to-noise ratio ........... 97 dB (1 kHz) (IEC-A network)
-AVIC-X1R/XU/EW

AVIC-N2/XU/UC 11
5678
5678
C
D
F
A
B
E
(CD: 96 dB (1 kHz) (IEC-A
network))
Dynamic range .................... 95 dB (1 kHz)
(CD: 94 dB (1 kHz))
Distortion.............................. 0.008 % (1 kHz)
Output level:
Video ............................. 1.0 Vp-p/75 Ω(±0.2 V)
Audio.............................. 1.0 V (1 kHz, 0 dB)
Number of channels............. 2 (stereo)
MP3 decoding format .......... MPEG-1 & 2 Audio Layer 3
FM tuner
Frequency range.................. 87.5 –108.0 MHz
Usable sensitivity................. 8 dBf (0.7 µV/75 Ω, mono, S/
N: 30 dB)
50 dB quieting sensitivity..... 10 dBf (0.9 µV/75 Ω, mono)
Signal-to-noise ratio ............ 75 dB (IEC-A network)
Distortion.............................. 0.3 % (at 65 dBf, 1 kHz,
stereo)
0.1 % (at 65 dBf, 1 kHz,
mono)
Frequency response ............ 30 –15,000 Hz (±3 dB)
Stereo separation ................ 45 dB (at 65 dBf, 1 kHz)
Selectivity ............................ 80 dB (±200 kHz)
MW tuner
Frequency range.................. 531 –1,602 kHz (9 kHz)
Usable sensitivity................. 18 µV (S/N: 20 dB)
Signal-to-noise ratio ............ 65 dB (IEC-A network)
LW tuner
Frequency range.................. 153 –281 kHz (9 kHz)
Usable sensitivity................. 30 µV (S/N: 20 dB)
Signal-to-noise ratio ............ 65 dB (IEC-A network)
Note:
•Specifications and the design are subject to
possible modifications without notice due to
improvements.

AVIC-N2/XU/UC
12
1234
1234
C
D
F
A
B
E
2. EXPLODEDVIEWS AND PARTS LIST
2.1 PACKING (AVIC-N2/XU/UC)
N
OTES : • Parts marked by " * " are generally unavailable because they are not in our Master Spare Parts List.
• The >mark found on some component parts indicatesthe importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
• Screw adjacent to mark on the product are used for disassembly.
• For the applying amount of lobricants or glue, follow the instructions in this manual.
(In the case of no amount instructions,apply as you think it appropriate.)
"

AVIC-N2/XU/UC 13
5678
5678
C
D
F
A
B
E
PACKING (AVIC-N2/XU/UC) SECTION PARTS LIST
Mark No. Description Part No.
1 Air Cushioned Bag CEG1007
2 Polyethylene Bag CEG1173
3 Carton CHG5463
4 Contain Box CHL5463
5 Protector CHP2879
6 Protector CHP2877
7 Protector CHP2876
8 Protector CHP2945
9 Cord CDE5044
10 Cord CDE6825
11 Cord Assy CDE7398
12 Cord Assy CDE7399
13 Cord Assy CDE7487
14 Antenna Cable CDH1325
15 Accessory Assy CEA3685
16 Screw CBA1650
17 Bush CNV1917
* 18 Polyethylene Bag E36-615
19 Screw JGZ20P070FTC
20 Screw Assy CEA3686
21 Screw BMZ50P060FTC
22 Screw(M4x6) CBA1468
23 Screw CMZ50P060FTC
* 24 Polyethylene Sheet CNM4338
25 Spacer CNM9149
26 Accessory Assy CEA3996
27 Screw Assy CEA4396
28 Screw CBA1795
* 29 Polyethylene Sheet CNM4338
30 Screw HMF40P080FTC
* 31 Polyethylene Bag CEG1163
32 Angle Assy CXC1079
33 Sub Carton CHG5440
34 •••••
35 GPS Antenna Assy CXC4864
36 Water Proof Pad CZN5442
37 Sheet CZN7008
38-1 Polyethylene Bag CEG1116
38-2 Owner's Manual CRB2025
38-3 Owner's Manual CRB2026
38-4 Owner's Manual/POC/FRE CRB2027
38-5 Owner's Manual/POC/FRE CRB2028
38-6 Installation Manual CRD3957
38-7 Caution Card CRP1310
* 38-8 Card ARY1048
38-9 Cleaning Cloth Assy CEA3952
* 38-10 Registration Card CRY1238
* 38-11 Caution Card CRP1321
38-12 Connector CKX1049
Mark No. Description Part No.
-Owner's Manual, Installation Manual
Part No.
CRB2025, CRB2026
CRB2027, CRB2028
CRD3957
Language
English
French
English, French

AVIC-N2/XU/UC
14
1234
1234
C
D
F
A
B
E
2.2 PACKING (AVIC-X1R/XU/EW)

AVIC-N2/XU/UC 15
5678
5678
C
D
F
A
B
E
PACKING (AVIC-X1R/XU/EW) SECTION PARTS LIST
Mark No. Description Part No.
1 Air Cushioned Bag CEG1007
2 Polyethylene Bag CEG-162
3 Carton CHG5462
4 Contain Box CHL5462
5 Protector CHP2879
6 Protector CHP2877
7 Protector CHP2876
8 Protector CHP2945
9 Cord CDE5044
10 Cord CDE6825
11 Cord Assy CDE7398
12 Cord Assy CDE7399
13 Cord Assy CDE7486
14 Antenna Cable CDH1325
15 Accessory Assy CEA3685
16 Screw CBA1650
17 Bush CNV1917
* 18 Polyethylene Bag E36-615
19 Screw JGZ20P070FTC
20 Screw Assy CEA3686
21 Screw BMZ50P060FTC
22 Screw(M4x6) CBA1468
23 Screw CMZ50P060FTC
* 24 Polyethylene Sheet CNM4338
25 Spacer CNM9149
26 Accessory Assy CEA3996
27 Screw Assy CEA4396
28 Screw CBA1795
* 29 Polyethylene Sheet CNM4338
30 Screw HMF40P080FTC
* 31 Polyethylene Bag CEG1163
32 Angle Assy CXC1079
33 Sub Carton CHG5440
34 •••••
35 GPS Antenna Assy CXC4864
36 Water Proof Pad CZN5442
37 Sheet CZN7008
38-1 Polyethylene Bag CEG1116
38-2 Owner's Manual/PEE/ENG CRB2029
38-3 Owner's Manual/PEE/ENG CRB2030
38-4 Owner's Manual/PEE/SPA CRB2031
38-5 Owner's Manual/PEE/SPA CRB2032
38-6 Owner's Manual/PEE/GER CRB2033
38-7 Owner's Manual/PEE/GER CRB2034
38-8 Owner's Manual/PEE/FRE CRB2035
38-9 Owner's Manual/PEE/FRE CRB2036
38-10 Owner's Manual/PEE/ITA CRB2037
38-11 Owner's Manual/PEE/ITA CRB2038
38-12 Owner's Manual/PEE/DUT CRB2039
38-13 Owner's Manual/PEE/DUT CRB2040
38-14 Installation Manual CRD3958
* 38-15 Passport CRY1013
* 38-16 Warranty Card CRY1157
38-17 Cleaning Cloth Assy CEA3952
38-18 Sheet CNM8603
* 38-19 Lock Tie CNV-754
* 38-20 Caution Card CRP1322
38-21 Connector CKX1049
Mark No. Description Part No.
-Owner's Manual, Installation Manual
Part No.
CRB2029, CRB2030
CRB2031, CRB2032
CRB2033, CRB2034
CRB2035, CRB2036
CRB2037, CRB2038
CRB2039, CRB2040
CRD3958
Language
English
Spanish
German
French
Italian
Dutch
English, Spanish, German, French, Italian, Dutch

AVIC-N2/XU/UC
16
1234
1234
C
D
F
A
B
E
2.3 NAVIGATION UNIT (1)

AVIC-N2/XU/UC 17
5678
5678
C
D
F
A
B
E
NAVIGATION UNIT (1) SECTION PARTS LIST
Mark No. Description Part No.
1 Screw BMZ20P030FZK
2 Screw(M2x3) CBA1527
3 Screw BMZ26P025FTC
4 Screw BMZ26P040FTC
5 Screw(M2x2.5) CBA1615
6 Screw(M2.6x12) CBA1620
7 Spacer CNM9200
8 Label(EW model) VRW1860
9 Cord Assy CDE7401
10 FFC CDE7740
11 FFC CDE7403
12 FFC CDE7727
13 Screw CMZ50P060FTC
14 Case CNB3155
15 Panel CNB3048
16 Holder CND2812
17 Bracket CND2815
18 Bracket CND2816
19 Bracket CND2817
20 Bracket CND1947
21 Holder CND1948
22 Insulator CNM8043
23 Insulator CNM8571
24 Insulator CNM8715
25 Cover CNM8874
26 IC(IC2405) PAL007A
27 Spacer CNM9246
28 Panel CNS7797
29 CC Unit(UC model) CWM9948
CC Unit(EW model) CWM9947
30 Screw BMZ26P160FTC
31 Terminal(CN100) CKF1064
32 Terminal(CN604) CKF1064
33 Terminal(CN605) CKF1064
34 Terminal(CN614) CKF1064
35 Terminal(CN615) CKF1064
36 Terminal(CN2601) CKF1064
37 Connector(CN802) CKM1332
38 Connector(CN2552) CKS1940
39 Connector(CN971) CKS4822
40 Connector(CN608) CKS3751
41 Connector(CN2701) CKS3810
42 Connector(CN2) CKS4052
43 •••••
44 Connector(CN609) CKS4068
45 Connector(CN607) CKS4132
46 •••••
47 Connector(CN692) CKS4473
48 Connector(CN2551) VKN1928
49 Connector(CN731) CKS4646
50 Connector(CN691) CKS4814
51 Shield CND2822
52 Shield CND2823
53 Shield CND1951
54 Shield CND1952
55 Holder CND1953
56 Holder CND1954
57 Holder CND1955
58 Sheet CNM7902
59 Insulator CNM8572
60 Insulator CNM8573
61 Insulator CNM8856
62 Heat Sink CNR1739
63 Detach Grille Assy(UC model) CXC4305
Detach Grille Assy(EW model) CXC4304
64 Screw BPZ20P080FZK
65 Button(DETACH) CAC8431
66 Button(SRC) CAC8432
67 Button(EQ) CAC8433
68 Button CAC8434
69 Button(RESET) CAC8503
70 Spring CBH2680
71 Cover CNS7759
72 Sheet CNM9576
73 Connector(CN5901) CKS3965
74 Connector(CN5501) CKS4657
75 Connector(CN5902) CKS4658
76 Sub Grille Unit(UC model) CXC4636
Sub Grille Unit(EW model) CXC4635
77 Knob Unit(VOLUME) CXC4641
78 Knob Unit(SELECT) CXC4642
79 Button CAC9276
80 Screw(M2x4) CBA1734
81 Screw(M2.6x2.5) CBA1777
82 Screw(M2x4) CBA1778
83 Spring CBH2681
84 Spring CBH2682
85 Spring CBH2790
86 FFC CDE7405
87 Holder CND1840
88 Holder CND1841
89 Insulator CNM8510
90 Arm CNV8571
91 Arm CNV8572
92 Arm CNV8573
93 Panel Unit CXC2693
94 DVD Mechanism Module(MS3) CXK6325
95 Fan Motor(M100) CXM1284
96 Fan Motor(M101) CXM1289
97 Screw ISS26P050FTC
98 Screw PMZ20P160FTC
99 Mother Tuner Unit(UC model) CWM9946
Mother Tuner Unit(EW model) CWM9945
100 Connector(CN2801) CKS4871
101 Connector(CN2802) CKS4822
102 Connector(CN2803) CKM1365
103 Connector(CN2804) CKS4752
104 Holder CND1956
105 Holder CND2824
106 Sheet CNM9536
Mark No. Description Part No.

AVIC-N2/XU/UC
18
1234
1234
C
D
F
A
B
E
2.4 NAVIGATION UNIT (2)

AVIC-N2/XU/UC 19
5678
5678
C
D
F
A
B
E
NAVIGATION UNIT (2) SECTION PARTS LIST
Mark No. Description Part No.
1 Drive Unit CXB9508
2 Screw(M2x3) CBA1082
3 Screw(M2x2.5) CBA1250
4 Screw(M2x4) CBA1277
5 Screw(M2x1.5) CBA1615
6 Washer CBF1038
7 Spring CBH2645
8 Spring CBH2646
9 Spring CBH2647
10 Spring CBL1585
11 Spring CBL1586
12 Spring CBL1587
13 Spring CBL1642
14 Cord Assy CDE7047
15 Cord Assy CDE7213
16 Shaft CLA4270
17 Shaft CLA4305
18 Shaft CLA4306
19 Shaft CLA4309
20 Bracket CND1221
21 Case CND1229
22 Holder CND1318
23 Holder CND1449
24 Sheet CNM8522
25 Sheet CNM8037
26 Insulator CNM8048
27 Insulator CNM8158
28 Sheet CNM8159
29 Tape CNM8160
30 Insulator CNM8294
31 Gear CNR1664
32 Gear CNR1665
33 Gear CNR1677
34 Gear CNR1678
35 Gear CNR1679
36 Gear CNR1680
37 Gear CNR1688
38 Gear CNR1708
39 Gear CNR1709
40 Gear CNV7383
41 Holder CNV7384
42 Holder CNV7385
43 Rack CNV7386
44 Rack CNV7387
45 Slider CNV7388
46 Slider CNV7389
47 Holder CNV7390
48 Arm CNV7391
49 Gear CNV7522
50 Gear CNV7523
51 Gear CNV7524
52 Gear CNV7529
53 Chassis Unit CXB9509
54 Frame Unit CXB9511
55 Holder Unit CXB9512
56 Shaft Unit CXB9513
57 Holder Unit CXB9514
58 Motor Unit(M3001)(Position) CXB9515
59 Motor Unit(M3002)(Angle) CXB9516
60 Screw CZB3082
61 Screw CZB3083
62 Washer CZB3084
63 Screw(M2x1.8) CZB3085
64 Screw(M2x4) CZB3088
65 Main Unit CZW3087
66 Screw BMZ26P050FTC
67 Connector(CN3801) CKS4068
68 Connector(CN3802) CKS4732
69 Connector(CN3803) CKS4732
70 Connector(CN3807) CKS4733
71 Connector(CN3809) CKS4733
72 Heat Sink CND1228
73 IC(IC3801) BA00AST
74 SW Unit CZW3088
75 Volume(VR3841) CCW1025
76 Volume Unit CZW3089
77 Screw IMS20P020FTC
78 Screw IMS20P030FZK
79 Washer YE15S
80 Washer CZB3089
81 Holder CND2813
82 Screw JFZ20P022FNI
83 Cover CNS7760
84 Holder CNV8569
85 Flexible PCB CNP7621
86 Shield CNM8969
87 Screw(M2x2) CBA1753
88 Screw(M2x3) CBA1797
89 Sheet CNM9201
Mark No. Description Part No.

AVIC-N2/XU/UC
20
1234
1234
C
D
F
A
B
E
2.5 NAVIGATION UNIT (3)
